Photoflex UM-RUT30 User manual

For detailed specifications, product tutorial videos and more, please visit www.photoflex.com Rev 09/2016
White Converble Umbrella Instrucons • Item #s: 871087 (UM-RUT30) / 871090 (UM-RUT45) /
871093 (UM-RUT60)
Figure 1
Figure 3
Figure 8
Figure 10
Figure 2
Figure 4
Figure 9
These instrucons include
• Opening the umbrella.
• Adding and removing the black cover.
(RUT Umbrellas).
• Folding the Umbrella.
Opening the Umbrella
The Umbrella opens like a common
rain umbrella. Figures 1– 4
1. Pull open the Velcro® strap that holds the umbrella closed.
2. Reach under the material to nd the metal slider on the post.
3. Push the slider up the post and the umbrella will open.
4. The umbrella will lock in place when the metal slider is pushed over
the metal locking tab on the post.
Securing the Umbrella to your Light
NOTE: Set up your light stand and light head in the manner suggested by
your equipments’ manufacturers.
Most light heads, head mounng clamps, and LiteStand mounts will
have a receptacle and locking mechanism for securing the umbrella in
front of the light. Figures 5 – 7
5. Here we show a ShoeMount MulClamp (available separately) as
our umbrella and ash support. Slide the post of the umbrella into
the receptacle hole.
6. Hand-ghten the locking knob.
7. Image shows the umbrella with a ash unit aached.
Adding and Removing the Black Cover Figures 8 – 14
8. The black cover is fastened to the umbrella with end caps that t
over the end of each rib.
9. Hold a rib with one hand while pulling the cap away from the rib
with the other hand.
10. Pulling o the black cover reveals the white shoot-through umbrella
beneath it.
White Converble Umbrella
The RUT White Converble umbrella features a removable light blocking
black cover which easily converts from a highly ecient bounce umbrella
to a “shoot through” umbrella.
Get the best of both shoong styles in one umbrella. Industry exclusive
durable and exible oversized ribs and struts with new and improved
beefy rib and strut pivot points. Premium quality white san 190 thread
count fabric interior for buery so reecons or shoot through diusion.
Figure 5
Figure 7
Figure 6

For detailed specifications, product tutorial videos and more, please visit www.photoflex.com Rev 09/2016
Figure 12
Figure 16
Figure 13
Figure 17
Figure 14
Figure 18
Figure 15
Figure 11
11. Here is the umbrella with half the black cover removed.
12. When all eight caps are removed, unscrew the cap at the top of
the umbrella.
13. With the cap loose, remove the black cover and replace the cap on
the umbrella.
14. You’re now ready to use the umbrella as a shoot-through.
Folding the Umbrella Figures 8 – 14
Put the black cover on the umbrella, if removed.
15. Remove the umbrella from the MulClamp or light. Hold the lower
end of the post with one hand.
16. With the other hand, push the metal locking tab into the post unl
the metal slider is free.
17. Pull the metal slider down the post unl the umbrella is closed.
18. Wrap the Velcro strap around the material and secure it.
Customer Support [phone]
E-mail: [email protected]
Photoflex is a division of PromarkBRANDS, Bartlett, IL USA.
©2016 ALL RIGHTS RESERVED. Photoflex® and the Photoflex logo are trademarks or
registered trademarks of Photoflex and/or its affiliates in the U.S. and other countries.
PHOTOFLEX® WARRANTY
• Warranties only cover manufacturer’s defects and workmanship.
• We reserve the right to inspect all merchandise returned (end
users and dealers) for warranty fulfillment.
• All returns must be pre-approved with Return Manufacturers
Authorization obtained from Photoflex/PromarkBRANDS.
• A receipt showing date of purchase will be required for all returns.
• Freight must be paid by the customer or dealer.
• Warranties are valid only from date of Original Purchase.

For detailed specifications, product tutorial videos and more, please visit www.photoflex.com Rev 09/2016
Family of Umbrellas
Applicaons
Can be used with strobes
or hot lights
Specicaons
Sha diameter: 8mm
Available Sizes
SKU# UM-ADH30 (35 inch arc)
SKU# UM-ADH45 (49 inch arc)
New Large (not adjustable)
Sixteen Rib Parabolic Umbrella
SKU# UM-ADH72 (86 inch arc)
Applicaons
Can be used with strobes
or hot lights
Specicaons
Sha diameter: 8mm
Available Sizes
SKU# UM-ADW30 (35 inch arc)
SKU# UM-ADW45 (49 inch arc)
Applicaons
Can be used with strobes
or hot lights
Specicaons
Sha diameter: 8mm
Available Sizes
SKU# UM-RUT30 (35 inch arc)
SKU# UM-RUT45 (49 inch arc)
SKU# UM-RUT60 (69 inch arc)
Applicaons
Can be used with strobes
or hot lights
Specicaons
Sha diameter: 8mm
Available Sizes
SKU# UM-RUD30 (35 inch arc)
SKU# UM-RUD45 (49 inch arc)
New Large Sixteen Rib Umbrella
SKU# UM-RUD72 (86 inch arc)
Customer Support [phone]
E-mail: [email protected]
Photoflex is a division of PromarkBRANDS, Bartlett, IL USA.
©2016 ALL RIGHTS RESERVED. Photoflex® and the Photoflex logo are trademarks or
registered trademarks of Photoflex and/or its affiliates in the U.S. and other countries.
PHOTOFLEX® WARRANTY
• Warranties only cover manufacturer’s defects and workmanship.
• We reserve the right to inspect all merchandise returned (end
users and dealers) for warranty fulfillment.
• All returns must be pre-approved with Return Manufacturers
Authorization obtained from Photoflex/PromarkBRANDS.
• A receipt showing date of purchase will be required for all returns.
• Freight must be paid by the customer or dealer.
• Warranties are valid only from date of Original Purchase.
The Photoex umbrella line is new and improved! Now our umbrella ribs and strut pivots are constructed of
a berglass composite, which is not only stronger, but also oers beer resiliency and durability than steel
or aluminum. This new feature allows for carefree handling, all but eliminang damage caused from over
bending delicate steel tube ribs. All umbrella center poles are extruded and closed o at the base (vs. folded,
hollow tubes, like many other umbrellas, that are easily bent and dented) adding to the durability of the
Photoex® umbrella model.
Adjustable Silver Umbrella
The ADH Adjustable Silver Umbrella is
the most versale, highest quality silver
umbrella on the market. It features a
premium quality mul-laminated silver
interior for maximum light reecon.
Industry exclusive exible oversized
berglass ribs and struts with new and
improved beefy rib and strut pivot points
provide a durable frame for the longevity
of the umbrella. Four moveable ribs make
this umbrella adjustable. This allows
you to alter the shape of the umbrella
and quickly change from standard (round)
to square or oval with ease.
Adjustable White Umbrella
The ADW Adjustable White Umbrella has
a black exterior with a white polyure-
thane-coated interior. This is the most
light-ecient white interior umbrella
available on the market,which gives
maximum light reecon with lower
contrast than silver umbrellas. Industry
exclusive exible berglass ribs and struts
with new and improved beefy rib and
strut pivot points increase the longevity
of the umbrella. Four moveable ribs
make this umbrella adjustable. This allows
you to alter the shape of the umbrella
and quickly change from standard
(round) to square or oval with ease.
White Converble Umbrella
The RUT White Converble Umbrella
features a removable light-blocking black
cover and easily converts from a highly
ecient bounce umbrella to a "shoot
through" umbrella, which produces a
diused so light.
Get the best of both shoong styles in
one umbrella. Industry exclusive durable
and exible oversized ribs and struts
with new and improved beefy rib and
strut pivot points.
Premium quality white san 190 thread
count fabric interior for
buery so reecons or shoot through
diusion.
Shoot Through Umbrella
The white san Shoot Through Umbrella
features a premium quality white san
190 thread count fabric for a buery
so shoot through diusion. This
umbrella uses Photoex® industry
exclusive durable and exible oversized
ribs and struts with new and improved
beefy rib and strut pivot points.
