Piaa S-RF Series User manual

-1-
PKI-0072-4
S-RF Series
Installation Instructions
Please read the cautionary points before installation to ensure safe utilization of the product.
●The lamp and the switch harness are intended for motorized vehicle use only. Do not use for any other purpose.
●This lamp is intended for use in rain (day or night), during foggy or snowy conditions where visibility is hampered.
Do not use during normal driving conditions.
●Do not operate the switch while driving, unless local laws allow you to do so.
●If the lamp is kept on when the engine is not running, it will drain the battery.
●Make sure the lamp is installed securely before driving the vehicle. If a problem is found, x it immediately.
●Check for any loose screws that hold the lamp in place before driving. If you nd any loose screws or bolts (if a bracket is
used), tighten them securely. If you notice a loose part while driving, inspect the section immediately and make the
necessary adjustments.
●Avoid repeatedly turning the lamp o and on as it may reduce the overall life of the LED.
●Some vehicles produce a high voltage electric charge when the engine is started. Avoid loading extra voltage to lamps by
turning the switch o when you start engine.
●Avoid needless disassembly of the lamp or the switch harness as it may cause it to fail.
●If the lamp and/or the switch harness is removed and set aside for safekeeping, wipe away all dust or grime and store in a
place free of moisture.
●If the lens is cracked or damaged in any way, verify whether there is any damage to the harness. If there is any damage to
the cord covering, replace it immediately.
●Avoid injury when replacing the harness and the switch Please dispose of it as a non-combustible item.
The ●marks indicated in this manual are cautionary points related to the installation of the product.
To ensure safe and secure installation of the product, please follow these points closely.
To user … Please keep this manual and a receipt with the name of the shop where
you bought it. When giving this product to a third party, always include
this manual together with the product.
To shop owners installing the product … After installation of the product, make sure the customer is provided
with this owner's manual.
●The lamp becomes hot when turned on. When parking your car near ammable items such as dried leaves, turn o the
lamp as it may cause a re.
●Do not look directly into the light for long periods. Doing so may cause eye irritation or visual impairment.
Thank you very much for purchasing PIAA product. Please read this instruction manual
thoroughly for proper use of the product. After completing your installation, keep this
manual for future reference.

PKI-0072-4
-2-
Please read the installation procedures thoroughly beforehand.
●In order for the lamp to perform at its full potential, use the relay harnesses that comes with your PIAA light kit.
●All work procedures should be carried out in a location with adequate space. Place the vehicle in the parked position.
Turn o the engine and set the parking brake.
●Make sure the engine compartment is adequately cool before starting work. Do not begin work if engine parts such as
radiator, oil-cooler or turbo parts are still hot.
●Do not add additional holes to the main body of the lamp. Also, do not apply adhesives or stickers to the lamp parts.
●Do not modify the lamp harness or the switch harness in any way. Such modications may cause it to overheat or short.
In some cases, it may cause the vehicle to catch re. PIAA will not be liable for damage caused by such modications.
●When removing the battery terminals, do not touch the (-) and (+) terminals simultaneously.
An electrical shock may occur. Wear rubber gloves when carrying out such work procedures.
●Make sure the (-) and (+) terminals do not make contact with metal. It can be extremely dangerous if a short occurs.
●Make sure all bolts are tightly secure. If there are any loose bolts tighten them accordingly.
●After installing the lamp, adjust the lamp so the beam shines at least 40m in front of the vehicle. Also, adjust the lamp a
little toward the right so that it does not shine directly into the eyes of the opposing driver of a vehicle.
(as trac laws stipulate -refer to p.6 for adjustment procedures)
●When the battery terminal is removed, memory related to the clock, radio, audio system etc, will be aected.
After all work procedures are completed, reset to the original settings.
(For adjustment procedures refer to your car's instruction manual)
●When installing the wiring harness, strictly follow the cautionary points mentioned below. Incorrect or faulty wiring may
cause the lamp to operate incorrectly. In some cases, it may cause the vehicle to catch re.
●Before you begin always remove the (-) and (+) terminals.
Always remove the (-) terminal rst and make sure a short does not occur.
●When removing the battery terminals, always turn the key to OFF and remove it. Turn all other electrical units o such as
the light switch.
●When removing the battery terminals, if a cord (for an electrical unit) is connected, wind a length of vinyl tape around the
(-) and (+) terminals to clearly identify them.
●Verify the (+) terminal (white) and earth (black) before connecting.
●Do not obtain (+) voltage from the alternator.
●Install the switch harness in a position where it will not make contact with high temperature surfaces such as the engine,
radiator or engine compartment.
●Arrange the switch harness so that it does not make contact with moving parts.
●If the switch harness makes contact with a part of the engine, apply a length heat-resistant cushioned tape around the harness.
●When connecting the connector, insert until you hear an audible “click”
●When removing the connector, hold the main body of the connector press the locking tab down and pull outwards.
If excess force is used to pull the cord, it may damage the connection, which could cause it to overheat.
●Make sure the harness does not sag. Use a harness band of vinyl tape to secure it in place to wiring inside the engine
compartment.
Caution Regarding Wiring / Please read thoroughly

-3-
PKI-0072-4
●Verify all the parts are included. If a part is missing, please contact the place of purchase or PIAA directly.
●Depending on mounting methods, some parts may not be used.
Product Details
Mounting Hardware
Two 8mm allen
head bolts
Two 8mm
Lock Washer
Four 8mm
Lock Nuts
●Before connecting PIAA Lamp relay harness to the battery, verify the wiring arrangement.
●When connecting the battery terminal and or other electrical units, do not mistake the (-) and (+) terminals. Always start
with the (+) terminal.
●After all wiring is complete, conrm that it works properly. If it fails to activate, refer to“8 Troubleshooting”section of this manual.
One side
mounting bracket(R)
One Relay harness
As for S-RF50
(DKSR509),
due to the high
operation wattage,
an additional fuse
unit is added to the
lamp wire harness.
One S-RF Lamp
S-RF6
S-RF9
S-RF20
S-RF30
S-RF40
S-RF50
Four 8mm Socket
head bolts
Two 6mm Socket
head bolts
Two 6mm
Lock Nuts
Two bottom
mounting brackets
Two Rubber Parts
Two Protection
spacers
● Thisproductpackagecontainsoneofthefollowinglampunits
 "S-RF6","S-RF9","S-RF20","S-RF30","S-RF40"or"S-RF50".
● S-RF50relayharnessisnotcompatiblewithS-RF6,S-RF9,S-RF20,
 S-RF30,andS-RF40lampkitrelayharness.
 S-RF50lampandrelayharnesshasadifferentconnector.
 InstallationprocedureorS-RF50relayharnessisthesame.
One side
mounting bracket(L)

PKI-0072-4
-4-
For lamp installation, a hole with a diameter of 8mm is required. Make necessary preparation such as installation
of lamp bracket.
Lamp installation
●When using a commercially supplied lamp bracket, before removing the bolt that is already installed on the car
body, make sure that it is safe to do so.
●The lamp should be mounted in an area sucient to support its size and weight.
●Failure to do so may result in excess vibration leading to shorter life and or physical damage to the lamp or your vehicle.
●Do not attempt to install the lamp directly to any plastic part of the car body.
●If the lamp needs to be installed on the plastic reinforcement materials should be placed on both sides of the plastic part.
●When installing, make sure the lamp body, lens and rim are not touching the bumper and other plastic parts.
Such plastic parts might deform.
●The lamps are designed to be mounted upright. But the mounting brackets can be rotated for hanging pendant mounting.
●
Torquespecificationsonthebasemountingnutis9.5ft・lbs(13N・m)
8mm Socket head bolts
8mm Lock Nuts
8mm allen head bolts
8mm Lock Washer
①
②
Impactwrench
9.5ft・lbs(13N・m)
③
When using the side bracket
Side mounting bracket(L)
Side mounting
bracket(R)
Lamp harness

-5-
PKI-0072-4
For lamp installation, a hole with a diameter of 8mm is required. Make necessary preparation such as installation
of lamp bracket.
●When using a commercially supplied lamp bracket, before removing the bolt that is already installed on the car
body, make sure that it is safe to do so.
●The lamp should be mounted in an area sucient to support its size and weight.
●Failure to do so may result in excess vibration leading to shorter life and or physical damage to the lamp or your vehicle.
●Do not attempt to install the lamp directly to any plastic part of the car body.
●If the lamp needs to be installed on the plastic reinforcement materials should be placed on both sides of the plastic part.
●When installing, make sure the lamp body, lens and rim are not touching the bumper and other plastic parts.
Such plastic parts might deform.
●The lamps are designed to be mounted upright. But the mounting brackets can be rotated for hanging pendant mounting.
●
Torquespecificationsonthebasemountingnutis9.5ft・lbs(13N・m)
8mm Lock Nuts
①
Impactwrench
9.5ft・lbs(13N・m)
③
When using the bottom bracket
②
6mm Socket head bolts
8mm Socket head bolts
④
⑤
⑥
⑦
Bottom mounting brackets
6mmLock Nuts
Rubber Parts
Protection spacers
6mm Socket head bolts
Lamp harness

PKI-0072-4
-6-
The numbers shown in the gure below indicate the sequence the parts should be installed.
Remove the (-) terminal
from the battery.
Remove the (+) terminal
from the battery
Connect the lamp harness
to the connector.
First ground the terminal
then take the (-) cord
(black) and connect it
to the (-) terminal.
Take the (+) terminal
cord (white) and attach
it to the (+) terminal and
connect to the battery
After lamp has been installed, verify the relay
harness does not make contact with the
engine's moving parts or sections that emit
extreme heat. Use wire ties to secure the harnesses
inside engine compartment.
Relay Harness Installation Sequence
Harness
Relay
Switch
Battery
(+) cord (red) (-) cord (Black)
Run the switch through
the engine rewall and
into the cab of the
vehicle.
The switch can be mounted anywhere in
the vehicle that will be free of moisture
or other electrical hazards. When you
select a mounting location, check behind
the panel to make sure there is no wires
that will be damaged when drilling.
Using a drill bit, drill a hole so the switch
will t tightly in the mounting hole.
Remove the wires from the back of the
switch, noting the pin locations and sh
the wires from the back side of the dash
through the switch hole. Re-install the
wires and push the switch into place of
the previously drilled hole.
Wire tie
Facing down
Make sure to properly
secure the relay
unit using a
bolt or a zip tie.
The harness
must be facing
downward.
As for S-RF50(DKSR509), due to thehigh
operation wattage, an additional fuse unit is
added to the lamp wire harness.

-7-
PKI-0072-4
1 After installation, if the lamp does not activate
●Check the wiring and make sure there are no faulty or irregular connections .
●If the switch illumination does not light up.
●Verify the (+) wire from the switch is properly connected. If it is not correctly connected it will not activate.
●Verify the fuse located on the vehicle's wiring system. (The switch's (+) wire should be connected to the
fuse box). If it is burned out, connect it to another circuit.
●If the switch itself is faulty, the same symptoms may exist. We recommend that the entire switch unit
be replaced.
●Check the fuse for the switch harness. If it is burned out, follow instructions indicated in
[ 3 Fuse replacement Procedures].
●The switch illumination lights up but when operating does not work.
●Check the connectors on the battery terminals
●There may be cases where each terminal related to specic sections may be incorrectly connected.
Check for any lose or cut wires and also for dirt or grime.
●Check the switch operation If an abnormality is found, replace it accordingly.
2 If the LED suddenly fails to light up …
●Check the fuse located on the vehicle's wiring system. If it is burned out, replace accordingly.
●Check the fuse for the switch harness. If it is burned out, follow instructions indicated in
[ 3 Fuse replacement Procedures].
●There may be cases where each terminal related to specic sections may be incorrectly connected.
Check for any lose wires and also for dirt or grime.
●Check the switch operation if an abnormality is found, replace it accordingly.
3 Fuse replacement procedures
●A short circuit may have occurred. Check the wiring system. If any type of damage is
found replace accordingly. (Non-replacement may pose a potential danger) (Short circuits are mainly
caused when wires are caught in the assembly or when there is a gap in the sleeve connected to the
lamp harness).
Troubleshooting……Verify each section according to the following.
●Do not use driving lights into
oncoming trac.
Driving lights should never be
the only forward light source.
Driving lights should only be
used with the headlamp high
beams.
1.5
DRIVING Light Aiming
Typically, driving lights are mounted above the front bumper about 30 inches(76cm) from the ground to provide extra high
beam illumination. Driving lights can be mounted below the bumper, although they will not be as eective because the
light will hit the ground sooner and reduce the range of the light.
Visual aim is made with the center of the beam hot spot 1.5 inches(4cm) below the lamp center at 25feet(7.6m) with the
lamp facing straight forward. (See below.)

PKI-0072-4
-8-
PIAA LIMITED WARRANTY
www.piaa.com
If a PIAA product is suspected of being defective, it must be submitted freight prepaid, to either an
authorized dealer or distributor for warranty inspection within the 2 year warranty period. The receipt
or other proof of purchase and a description of the problem must be included. The returned product will be
inspected. If the product is found to be defective and covered by this Limited Warranty, the sole remedy is
repair or replacement, at PIAA's option. A repaired or replacement product will be shipped back at no charge.
Removal, installation, or reinstallation costs are not covered by this 2 year Limited Warranty.
This Limited Warranty specically excludes defects resulting from misuse, abuse, neglect, alteration,
modication, improper installation, unauthorized repairs, submersion, theft, vehicle crash, or by any
other type of impact. Except for the Limited Warranty stated above, there are no warranties of PIAA
products or any part thereof, whether express or implied. Any implied warranty of merchantability
or any warranty of tness for a particular purpose is expressly disclaimed. Some states do not
permit the disclaimer of implied warranties.
Crash or impact damage is not covered. This can be determined by a chip or scrape on the lens or the
housing. Stress cracks sometimes occur when the lens is subjected to sudden and extreme temperature
changes. A stress crack has no chip or other sign of impact. Stress cracks are covered under warranty.
In no event shall PIAA be liable for any damages whatsoever (including, without limitation, consequential
damages, incidental damages, or damages for loss of use, loss of business prots, business interruption,
loss of business information, loss of time, inconvenience, or other losses) arising out of the use, misuse,
or inability to use a PIAA product. PIAA reserves the right to change the design of its products without any
obligation to modify any previous product. This warranty gives you specic legal rights. You may also
have other rights that vary from state to state.
REPAIR AND REPLACEMENT
EXCLUSIONS
LENS CRACKS
EXCLUSION OF DAMAGES
