Page 1.1
LXI SIMULATION TOOL 60-901
pickering SECTION 1 - TECHNICAL SPECIFICATION
SECTION 1 - TECHNICAL SPECIFICATION
pickeringtest.com
LXI Simulation Tool 60-901
ISSUE 1.2 APR 2018
• Simulates All Pickering PXI & LXI Switching
Products
• More Than 1000 Switching Product
Configurations Available
• Supports Over 18 Simulated PXI Slots
• Allows Code Development Independently
From The Application Hardware
• Ethernet 100base T Interface
• Powered From Standard 5V Inline Power Supply
• Highly Portable
• 3 Year Warranty
The 60-901 simulates of all Pickering’s PXI and LXI switching
products, and most of the simulation and instrumentation range
in one highly portable package. Each product is supported as
a virtual LXI device allowing code development with minimal
hardware, it also has the ability to show real-time switching and
debug information and comes complete with a driverless soft front
panel that provides complete control of the module’s functions. The
60-901 provides the user with a simple and highly portable platform
for application development.
Supported Products
The 60-901 allows the user to simulate any of Pickering Interface’s
PXI switching modules tted into a virtual Modular LXI Chassis,
over 18 virtual PXI card slots can be supported. There is also
partial support for Pickering’s simulation and instrumentation
modules including programmable resistors. All Pickering’s LXI
switching products are also supported.
Software
The tool provides a link to a downloadable generic IVI driver
to control the PXI and LXI products in accordance with the LXI
specication, but can also be controlled through a kernel driver.
A library of PXI and LXI products and rmware is installed on
the Simulation Tool on a removable memory card, allowing easy
upgrades.
Code Development
Our standard LXI driver and debug panel are provided to assist
application development. An 8x8 LED matrix on the tool along with
a web panel displays the switch status of the simulated module
for debug purposes. With the 60-901 you can code and test your
LXI control application before purchasing or connecting to your
Pickering LXI test system.
Ethernet Control
The Ethernet interface enables control through standard LAN
interfaces found on all system PC/host controllers. The 60-901 can
be easily congured using any standard web browser. The interface
can be used to load a Java based soft front panel for any of the
products simulated by the tool, permitting users to access products
without the need for drivers on the PC/host.
Pickering Card Library
Virtual PXI Modules
LAN Interface
and Embedded
Controller
External 5V
Power Supply
60-901-001
LXI Simulation
Tool
1 2 3 4 5 N
Ethernet
PC
Simulation of Pickering Interfaces PXI modules using the 60-901 LXI Simulation Tool provides an application
development platform. A simple Ethernet lead is the only physical control connection required.

Page 1.2 LXI SIMULATION TOOL 60-901
pickering
SECTION 1 - TECHNICAL SPECIFICATION
LXI Simulation Tool – 60-901
pickeringtest.com
Overview
Configuration page for a modular chassis which allows a choice of virtual PXI modules
The 60-901 selected chassis provides soft front panels to enable manual operation through the web
interface, in this example for a 40-726 matrix module.

Page 1.3
LXI SIMULATION TOOL 60-901
pickering SECTION 1 - TECHNICAL SPECIFICATION
LXI Simulation Tool – 60-901
pickeringtest.com
Specifications & Ordering Information
Specification
Capacity: Over 18 simulated user
slots available.
Power Supply: Supplied with a 5V 1A DC
in line power supply.
Monitoring
Top Panel Display: Dual function LED matrix
shows IP address and
switch status.
LAN Interface
Connector: RJ45 Connector.
Connection Speed: 100baseT interface.
Supporting Documentation:
Manuals, drivers and product catalogs can be downloaded from
the Pickering Interfaces website.
Mechanical Characteristics
Dimensions: Width: 94mm (3.70”)
Height: 76mm (3.00”)
Depth: 32mm (1.26”)
Weight: 100g
Operating/Storage Conditions
Operating Conditions
Operating Temperature:
Humidity:
0°C to +55°C
10% to 95% non-condensing
Storage and Transport Conditions
Storage Temperature:
Humidity:
-20°C to +70°C
10% to 90% non-condensing
Safety & CE Compliance
All products are fully CE compliant and meet applicable EU
directives: Low-voltage safety EN61010-1:2010, EMC Immunity
EN61326-1:2013, Emissions EN55011:2009+A1:2010.
The 60-901 LXI Simulator also complies with the European
Restriction of Hazardous Substances directive (RoHS).
Product Compatibility
The LXI Simulator is supplied with links to drivers for the majority
of Pickering’s PXI and LXI products.
Switching Support All of Pickering Interface’s
PXI and LXI switching
products.
Instrumentation support: Partial support:
PXI programmable resistor/
potentiometer modules and
RF attenuators.
Soft Front Panel: All supported products can
be controlled through a
standard W3C compliant
web browser.
For a selection guide on the range of PXI modules capable of
being simulated by the 60-901 tool, please see the PXI Module
Selection Guide in the LXI Product Guide. This is available as
a download from the On-Line Catalogs section of our website:
pickeringtest.com
Product Order Codes
LXI Simulation Tool 60-901-001
Product Customization
Pickering PXI modules are designed and manufactured on our own
exible manufacturing lines, giving complete product control and
enabling simple customization to meet very specic requirements.
All customized products are given a unique part number, fully
documented and may be ordered at any time in the future. Please
contact your local sales ofce to discuss.

Page 1.4 LXI SIMULATION TOOL 60-901
pickering
SECTION 1 - TECHNICAL SPECIFICATION
LXI Simulation Tool – 60-901
pickeringtest.com
Supporting Products & Software
We also offer customized cabling and have a free online Cable Design Tool that can
be used to create custom cable solutions for many applications.
Visit: pickeringtest.com/cdt to start your design.
Mass Interconnect
We recommend the use of a mass interconnect solution when an Interchangeable
Test Adapter (ITA) is required for a PXI or LXI based test system. Our modules are
fully supported by both Virginia Panel and MacPanel.
Pickering Reed Relays
We are the only switch provider with in-house reed relay manufacturing capability
via our sister company, Pickering Electronics. These instrument grade reed relays
feature SoftCenter® technology, ensuring long service life and repeatable contact
performance.
To learn more, please go to: pickeringrelay.com
Connectivity Solutions
We provide a full range of supporting cable and connector solutions for all our switching products—20 connector families with 1200+
products. We offer everything from simple mating connectors to complex cables assemblies and terminal blocks. All assemblies are
manufactured by Pickering and are guaranteed to mechanically and electrically mate to our modules.
Connectors & Backshells Multiway Cable Assemblies RF Cable Assemblies Connector Blocks
Programming
All LXI devices are supplied with built-in software drivers, web pages for conguration and soft front panels as required by the LXI
specication. A variety of drivers are provided (C, .NET, IVI, SOAP) which are compatible with all Microsoft supported versions of Windows
and popular older versions. For a list of all supporting operating systems, please see: pickeringtest.com/os
The drivers may be used in many commonly used programming environments and applications including:
• Pickering Interfaces Switch Path Manager
• National Instruments products (LabVIEW, LabWindows/CVI, Switch Executive, MAX, TestStand, VeriStand, etc.)
• Microsoft Visual Studio products (Visual Basic, Visual C++, Visual C#)
• Keysight VEE and OpenTAP
• Mathworks Matlab
• Marvin ATEasy
• MTQ Testsolutions Tecap Test & Measurement Suite
As well as various open source environments such as:
• Sharp Develop
• Dev-C++
To learn more about software drivers and development environments, please go to: pickeringtest.com/software

Page 1.5
LXI SIMULATION TOOL 60-901
pickering SECTION 1 - TECHNICAL SPECIFICATION
LXI Simulation Tool – 60-901
pickeringtest.com
Supporting Products & Software
© Copyright (2020) Pickering Interfaces. All Rights Reserved Pickering Interfaces maintains a commitment to continuous product development, consequently we reserve the right to vary from the description given in this data sheet.
Signal Routing Software
Our signal routing software, Switch Path Manager, automatically selects and energizes switch
paths through Pickering switching systems. Signal routing is performed by simply dening
test system endpoints to be connected together, greatly accelerating Test System software
development.
To learn more, please go to: pickeringtest.com/spm
Diagnostic Relay Test Tools
eBIRST Switching System Test Tools are designed specically for our PXI, PCI or LXI
products, these tools simplify switching system fault-nding by quickly testing the system
and graphically identifying the faulty relay.
To learn more, please go to: pickeringtest.com/ebirst
Three Year Warranty
All standard products manufactured by Pickering Interfaces are warranted against
defective materials and workmanship for a period of three years from the date of delivery to the original purchaser. Extended warranty and
service agreements are available for all our modules and systems with various levels to suit your requirements. Although we offer a 3-year
warranty as standard, we also include guaranteed long-term support—with a history of supporting our products for typically 15-20 years. To
learn more, please go to: pickeringtest.com/support
Available Product Resources
We have a large library of product resources including success stories, product and support videos, articles, as well as complete product
catalogs and product reference maps to assist when looking for the switching, simulation and cable and connector solutions you need.
We have also published handy reference books on Switching Technology and for the PXI and LXI standards.
To view, download or request any of our product resources, please visit: pickeringtest.com/resources

Page 1.6 LXI SIMULATION TOOL 60-901
pickering
SECTION 1 - TECHNICAL SPECIFICATION
THIS PAGE INTENTIONALLY BLANK

Page 2.1
LXI SIMULATION TOOL 60-901
pickering SECTION 2 - TECHNICAL DESCRIPTION
SECTION 2 - TECHNICAL DESCRIPTION
FUNCTIONAL DESCRIPTION
The 60-901 LXI Simulation Tool is a self-contained unit capable of emulating all of Pickering’s PXI and LXI switching
products, the only connections required are power and an Ethernet lead. The tool consists of an embedded controller
powered from an external 5V mains power unit. Control and programming information for Pickering’s switching
products is stored in the controller’s memory enabling it to emulate any LXI device or any PXI switching module
installed in an LXI Modular Switching Chassis. Over 18 PXI slots can be supported on a virtual PXI backplane.
Control information for the tool is sent via the LAN interface from a remote computer using the tool’s unique Ethernet
address. An 8x8 LED matrix on the top panel of the tool can be used to display information such as the tool’s
Ethernet address or the switch status of the module being simulated.
EXTERNAL
5V POWER
SUPPLY
LAN
INTERFACE
RJ45
SOCKET PROCESSOR
PXI Card Library
VIRTUAL PXI MODULE SLOTS
1 2 3 4 5 N
EMBEDDED
CONTROLLER CARD
60-901-001
LXI Simulation
Tool
8x8 LED MATRIX
Figure 2.1 - Block Diagram for the 60-901 LXI Simulation Tool

Page 2.2 LXI SIMULATION TOOL 60-901
pickering
SECTION 2 - TECHNICAL DESCRIPTION
THIS PAGE INTENTIONALLY BLANK

Page 3.1
LXI SIMULATION TOOL 60-901
pickering SECTION 3 - INSTALLATION
SECTION 3 - INSTALLATION
INSTALLING THE SIMULATION TOOL
Site Considerations
The 60-901 is designed to be highly portable and operate on a desk top or any location near a power socket and
LAN cable socket.
Figure 3.1 - Top view of the 60-901-001 LXI Simulation Tool
Refer to the Warnings and Cautions at the front of this manual
The chassis is designed for indoor use only.
!
This unit is designed for indoor use only

Page 3.2 LXI SIMULATION TOOL 60-901
pickering
SECTION 3 - INSTALLATION
THIS PAGE INTENTIONALLY BLANK

Page 4.1
LXI SIMULATION TOOL 60-901
pickering SECTION 4 - CONFIGURATION & SET-UP
SECTION 4 - CONFIGURATION & SET-UP
HARDWARE SET-UP
Before you begin, take a moment to check your box contents to ensure you have the necessary components
present. Contact your local sales ofce if you nd that any part or component is missing.
Your box will contain:
1. A 60-901-001 LXI Simulation Tool
2. The document entitled ‘Getting started with your LXI device’.
3. Two 2 metre ethernet patch leads:
One labelled “Crossover” (grey) and the other “Straight-Through” (blue)
4. A power supply with pin adapters suitable for international usage
5. A micro SD card (may already be inserted into the Simulation Tool)
Remove your 60-901-001 Simulation Tool from its protective packaging.
Next, if it has not already been tted, insert the supplied micro SD card into the slot on the left hand side of the
Simulation Tool as shown below:
Page 1
LXI COMPLIANT CHASSIS 60-100/101
pickering
GETTING STARTED GUIDE
Issue A, February 2006
www.pickeringtest.com
pickering
ISO9002
RegNo. FM38792

Page 4.2 LXI SIMULATION TOOL 60-901
pickering
SECTION 4 - CONFIGURATION & SET-UP
If you are using an ethernet hub or switch, use the Ethernet cable marked “Straight-Through”. Connect one end to
the RJ45 socket on the right hand side of your 60-901-001 Simulation Tool, and the other to a free socket on your
hub or switch. If you are connecting directly from your computer to the LXI device, use the Ethernet lead marked
“Crossover”.
Note: When connecting directly to a computer with a Gigabit compliant Ethernet port the crossover cable may not
be required, communication can be carried out using the straight-through cable.
The Simulation Tool is supplied with an international power adapter which includes four types of mains connector.
First clip the correct pin format of connector for your country into the power adapter, then connect the ying lead
from the adapter into the power socket on the right hand side of the Simulation Tool.
Insert the power adapter into a mains electricity socket. As the Simulation Tool has no power switch, it will start up
as soon as power is applied.
Your Simulation Tool will now start going through its boot up procedure which can take up to 40 seconds to complete.
When the controller has successfully booted it will indicate its IP address by scrolling characters on its LED matrix
display. If an IP address is not displayed, check your Ethernet connection.
