Page 1.1
PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755
pickering SECTION 1 - TECHNICAL SPECIFICATION
SECTION 1 - TECHNICAL SPECIFICATION
pickeringtest.com
PXI SP4T RF Multiplexer 40-755
ISSUE 5.1 MAY 2022
Supported by eBIRST
SMB builds of this product are supported by eBIRST test
tools which simplify fault-finding by quickly testing the
system and graphically identifying the faulty relay.
For more information go to: pickeringtest.com/ebirst
yUp To 10off SP4T in a Single Module
y1.8 GHz Switching (50 Ω SMB Version)
y1.3 GHz Switching (75 Ω SMB Version)
y1.3 GHz Switching (50 Ω Multiway Version)
y1.3 GHz Switching (75 Ω Multiway Version)
ySMB and Multiway Connector Versions
yLow Cost, High Performance
yVISA, IVI & Kernel Drivers Supplied for
Windows
ySupported by PXI or LXI Chassis
ySupported by
eBIRST ™
y3 Year Warranty
1
2
3
4
C1
BANK 1
1
2
3
4
C2
BANK 2
1
2
3
4
C3
BANK 3
1
2
3
4
C4
BANK 4
1
2
3
4
C5
BANK 5
1
2
3
4
C6
BANK 6
1
2
3
4
C7
BANK 7
1
2
3
4
C8
BANK 8
1
2
3
4
C9
BANK 9
1
2
3
4
C10
BANK 10
40-755-x10 10 off SP4T RF MUX
Switching Diagram (Default Switch Paths Shown)
The 40-755 is a high density RF multiplexer available in
50 Ω and 75 Ω variants with up to 10xSP4T switches in
a single PXI module. It is available with two connector
options; SMB that provides a frequency range of 1.8 GHz
(50 Ω) / 1.3 GHz (75 Ω), or multiway which limits the
bandwidth to 1.3 GHz but offers a high density solution
occupying one PXI slot. The connectors used are fully
supported by the range of Pickering Interfaces connection
solutions.
40-755 RF Multiplexer Range:
10 off SP4T, 50 Ω, 1.8 GHz, SMB, Dual PXI Slot
10 off SP4T, 50 Ω, 1.3 GHz, Multiway, Single PXI Slot
5 off SP4T, 50 Ω, 1.3 GHz, Multiway, Single PXI Slot
4 off SP4T, 50 Ω, 1.8 GHz, SMB, Single PXI Slot
10 off SP4T, 75 Ω, 1.3 GHz, SMB, Dual PXI Slot
10 off SP4T, 75 Ω, 1.3 GHz, Multiway, Single PXI Slot
5 off SP4T, 75 Ω, 1.3 GHz, Multiway, Single PXI Slot
4 off SP4T, 75 Ω, 1.3 GHz, SMB, Single PXI Slot
The module offers low insertion loss and low VSWR through
its usable frequency range and each multiplexer has been
designed to have path independent loss.
The array of SP4T switches can be connected into alternative
configurations through the use of external cabling.
The 40-755 is supplied with drivers that allow the user
to support the module in all popular PXI software
environments. In addition, the module can be supported in
all Pickering’s LXI Modular Chassis, allowing the use of a
PXI or LAN controlled switching solution with the same high
levels of performance.

Page 1.2 PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755
pickering
SECTION 1 - TECHNICAL SPECIFICATION
SP4T RF Multiplexer, 40-755
pickeringtest.com
Specifications
RF Specification
Impedance: 50 Ω
RF Frequency Range: DC to 1.3 GHz
Insertion Loss: <1 dB to 500 MHz (typically 0.7 dB)
2.5 dB to 1.3 GHz (typically 2.0 dB)
VSWR: <1.8:1 to 500 MHz
(typically 1.5:1 max)
3.2:1 to 1.3 GHz (typically 2.8:1)
Isolation: >50 dB to 1.3 GHz
(typically >55 dB)
Crosstalk: <-50 dB to 1.3 GHz
(typically <-55 dB)
Maximum RF Power: 10 W at 1.3 GHz
Other Switching Specification
Maximum Hot Switch Voltage: 200 VDC or AC peak
Maximum Hot Switch Current: 1 A
Maximum Cold Switch Current: 1 A
Maximum Hot Switch Power: 10 W
Operating Time: 3 ms typical
Life Expectancy: 10 million operations
at <100 mW
40-755 Specification - 50 Ω Versions with Multiway Connectors
Typical insertion loss plot - 50 Ω multiway
Typical VSWR plot - 50 Ω multiway
Typical bank to bank crosstalk plot - 50 Ω multiway
Typical channel to common isolation plot - 50 Ω multiway
40-755-010 10off SP4T RF MUX with
MS-M RF
multiway connectors

Page 1.3
PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755
pickering SECTION 1 - TECHNICAL SPECIFICATION
SP4T RF Multiplexer, 40-755
pickeringtest.com
Specifications
RF Specification
Impedance: 50 Ω
RF Frequency Range: DC to 1.8 GHz
Insertion Loss: <1.3 dB to 1.8 GHz
(typically 0.8 dB)
VSWR: <1.6:1 to 1.8 GHz
Isolation: >40 dB to 1.8 GHz
Crosstalk: <-40 dB to 1.8 GHz
Maximum RF Power: 10 W at 1.8 GHz
Other Switching Specification
Maximum Hot Switch Voltage: 200 VDC or AC peak
Maximum Hot Switch Current: 1 A
Maximum Cold Switch Current: 1 A
Maximum Hot Switch Power: 10 W
Operating Time: 3 ms typical
Life Expectancy: 10 million operations
at <100 mW
40-755 Specification - 50 Ω Versions with SMB Connectors
40-755-110 10off SP4T RF MUX with SMB
coaxial connectors
Typical insertion loss plot - 50 Ω SMB
Typical VSWR plot - 50 Ω SMB
Typical bank to bank crosstalk plot - 50 Ω SMB
Typical channel to common isolation plot - 50 Ω SMB

Page 1.4 PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755
pickering
SECTION 1 - TECHNICAL SPECIFICATION
SP4T RF Multiplexer, 40-755
pickeringtest.com
Specifications
RF Specification
Impedance: 75 Ω
RF Frequency Range: DC to 1.3 GHz
Insertion Loss: 2.5 dB to 1.3 GHz
(typically 2.0 dB)
VSWR: 2.8:1 to 1 GHz (typically 2.6:1)
4:1 to 1.3 GHz (typically 3.6:1)
Isolation: >50 dB to 1.3 GHz
(typically >55 dB)
Crosstalk: <-48 dB to 1.3 GHz
(typically <-55 dB)
Maximum RF Power: 10 W at 1.3 GHz
Other Switching Specification
Maximum Hot Switch Voltage: 200 VDC or AC peak
Maximum Hot Switch Current: 1 A
Maximum Cold Switch Current: 1 A
Maximum Hot Switch Power: 10 W
Operating Time: 3 ms typical
Life Expectancy: 10 million operations
at <100 mW
40-755 Specification - 75 Ω Versions with Multiway Connectors
Typical insertion loss plot - 75 Ω multiway
Typical VSWR plot - 75 Ω multiway
Typical bank to bank crosstalk plot - 75 Ω multiway
Typical channel to channel isolation plot - 75 Ω multiway Typical channel to channel crosstalk plot - 75 Ω multiway
RF Specification – 75 Ohm multiway
------------------------------------------------
Impedance: 75 Ohm
Frequency Range: DC to 1.3GHz
Insertion loss: <2.5dB to 1.3GHz (typically 2dB)
VSWR: <2.8:1 to 1GHz (typically 2.6:1 max)
4:1 to 1.3GHz (typically 3.6:1 max)
Isolation: >50dB to 1.3GHz (typically >55dB)
Crosstalk: <-48dB to 1.3GHz (typically <-55dB)

Page 1.5
PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755
pickering SECTION 1 - TECHNICAL SPECIFICATION
SP4T RF Multiplexer, 40-755
pickeringtest.com
Specifications
Power Requirements
+3.3 V +5 V +12 V -12 V
1 A 0.65 A 0 0
Operating/Storage Conditions
Operating Conditions
Operating Temperature:
Humidity:
Altitude:
0 °C to +55 °C
Up to 90 % non-condensing
5000 m
Storage and Transport Conditions
Storage Temperature:
Humidity:
Altitude:
-20 °C to +75 °C
Up to 90 % non-condensing
15000 m
PXI & CompactPCI Compliance
The module is compliant with the PXI Specification
2.2. Local Bus, Trigger Bus and Star Trigger are not
implemented.
Uses a 33MHz 32-bit backplane interface.
Safety & CE Compliance
All modules are fully CE compliant and meet applicable
EU directives: Low-voltage safety EN61010-1:2010,
EMC Immunity EN61326-1:2013,
Emissions EN55011:2009+A1:2010.
Mechanical Characteristics
• 40-755-005/010/104 Single slot 3U PXI
(CompactPCI card)
• 40-755-110 Dual slot 3U PXI
(CompactPCI card)
• 40-755-205/210/304 Single slot 3U PXI
(CompactPCI card)
• 40-755-310 Dual slot 3U PXI
(CompactPCI card)
3D models for all versions in a variety of popular file
formats are available on request.
Connectors
PXI bus via 32-bit P1/J1 backplane connector.
Signals via front panel RF connectors:
• 40-755-005 1off high density male 26-pin MS-M RF
multi-way connector
• 40-755-010 2off high density male 26-pin MS-M RF
multi-way connector
• 40-755-104 20off SMB coaxial connectors
• 40-755-110 50off SMB coaxial connectors
• 40-755-205 1off high density male 26-pin MS-M RF
multi-way connector
• 40-755-210 2off high density male 26-pin MS-M RF
multi-way connector
• 40-755-304 20off SMB coaxial connectors
• 40-755-310 50off SMB coaxial connectors
For pin outs please refer to the operating manual.
40-755-104 4off SP4T RF MUX with SMB
coaxial connectors

Page 1.6 PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755
pickering
SECTION 1 - TECHNICAL SPECIFICATION
SP4T RF Multiplexer, 40-755
pickeringtest.com
Ordering Information
Support Products
eBIRST Switching System Test Tool
SMB builds of this product is supported by the eBIRST
test tools which simplify the identification of failed
relays, the required eBIRST tools are below. For more
information go to: pickeringtest.com/ebirst
Product Test Tool Adaptor
40-755-110/104
40-755-010/005
40-755-310/304
40-755-210/205
93-005-001
Unsupported
93-005-001
Unsupported
93-005-202A
93-005-202A
Mating Connectors & Cabling
For connection accessories for the SMB version of the
40-755 please refer to the 90-011D RF Cable Assemblies
data sheet, or for the multiway MS-M connector version
please refer to the 90-017D Cable Assemblies where
a complete list and documentation can be found for
accessories, or refer to the Connection Solutions catalog.
Product Order Codes
50 Ω SP4T RF Multiplexer:
10off SP4T, 1.3 GHz Multiway Connectors
5off SP4T, 1.3 GHz Multiway Connector
10off SP4T, 1.8 GHz SMB Connectors
4off SP4T, 1.8 GHz SMB Connectors
40-755-010
40-755-005
40-755-110
40-755-104
75 Ω SP4T RF Multiplexer:
10off SP4T, 1.3 GHz Multiway Connectors
5off SP4T, 1.3 GHz Multiway Connector
10off SP4T, 1.3 GHz SMB Connectors
4off SP4T, 1.3 GHz SMB Connectors
40-755-210
40-755-205
40-755-310
40-755-304
Product Customization
Pickering modules are designed and manufactured on our
own flexible manufacturing lines, giving complete product
control and enabling simple customization to meet very
specific requirements.
All customized products are given a unique part number,
fully documented and may be ordered at any time in the
future. Please contact your local sales office to discuss.
Pickering can supply cable assemblies for all its modules.
The cable shown (MS-M RF to unterminated coax) is
suitable for multiway connector versions of the 40-755.

Page 1.7
PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755
pickering SECTION 1 - TECHNICAL SPECIFICATION
SP4T RF Multiplexer, 40-755
pickeringtest.com
Supporting Products & Software
We also offer customized cabling and have a free online Cable Design Tool
that can be used to create custom cable solutions for many applications.
Visit: pickeringtest.com/cdt to start your design.
Mass Interconnect
We recommend the use of a mass interconnect solution when an
Interchangeable Test Adapter (ITA) is required for a PXI or LXI based
test system. Our modules are fully supported by both Virginia Panel and
MacPanel.
Pickering Reed Relays
We are the only switch provider with in-house reed relay manufacturing
capability via our Relay Division. These instrument grade reed relays feature
SoftCenter™ technology, ensuring long service life and repeatable contact
performance. To learn more, please go to: pickeringrelay.com
Chassis Compatibility
This PXI module must be used in a suitable chassis. It is compatible with the following chassis types:
• All chassis conforming to the 3U PXI and 3U Compact PCI (cPCI) specification
• Legacy and Hybrid Peripheral slots in a 3U PXI Express (PXIe) chassis
• Pickering Interfaces LXI or LXI/USB Modular Chassis
Chassis Selection Guide
Standard PXI or hybrid PXIe Chassis from any Vendor:
• Mix our 1000+ PXI switching & simulation modules with
any vendor’s PXI instrumentation
• Embedded or remote Windows PC control
• Real-time Operating System Support
• High data bandwidths, especially with PXI Express
• Integrated module timing and synchronization
Pickering LXI or LXI/USB Modular Chassis—only accept
our 1000+ PXI Switching & Simulation Modules:
• Ethernet or USB control enables remote operation
• Low-cost control from practically any controller
• LXI provides manual control via Web browsers
• Driverless software support
• Power sequencing immunity
• Ethernet provides chassis/controller voltage isolation
• Independence from Windows operating system
Connectivity Solutions
We provide a full range of supporting cable and connector solutions for all our switching products—20 connector families
with 1200+ products. We offer everything from simple mating connectors to complex cables assemblies and terminal blocks.
All assemblies are manufactured by Pickering and are guaranteed to mechanically and electrically mate to our modules.
Connectors & Backshells Multiway Cable Assemblies RF Cable Assemblies Connector Blocks

Page 1.8 PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755
pickering
SECTION 1 - TECHNICAL SPECIFICATION
SP4T RF Multiplexer, 40-755
pickeringtest.com
Supporting Products & Software
© Copyright (2022) Pickering Interfaces. All Rights Reserved Pickering Interfaces maintains a commitment to continuous product development, consequently we reserve the right to vary from the description given in this data sheet.
Programming
Pickering provide kernel, IVI and VISA (NI & Keysight) drivers which are compatible with all Microsoft supported versions of
Windows and popular older versions. For a list of all supporting operating systems, please see: pickeringtest.com/os
The VISA driver is also compatible with Real-Time Operating Systems such as LabVIEW RT. For other RTOS support contact
Pickering. These drivers may be used with a variety of programming environments and applications including:
• Pickering Interfaces Switch Path Manager
• National Instruments products (LabVIEW, LabWindows/CVI, Switch Executive, MAX, TestStand, VeriStand, etc.)
• Microsoft Visual Studio products (Visual Basic, Visual C+)
• Keysight VEE and OpenTAP
• Mathworks Matlab
• Marvin ATEasy
• MTQ Testsolutions Tecap Test & Measurement Suite
Drivers for popular Linux distributions are available, other environments are also supported, please contact Pickering
with specific enquiries. We provide Soft Front Panels (SFPs) for our products for familiarity and manual control, as well as
comprehensive documentation and example programs to help you develop test routines with ease.
To learn more about software drivers and development environments, please go to: pickeringtest.com/software
Signal Routing Software
Our signal routing software, Switch Path Manager, automatically selects and energizes
switch paths through Pickering switching systems. Signal routing is performed by simply
defining test system endpoints to be connected together, greatly accelerating Test System
software development. To learn more, please go to: pickeringtest.com/spm
Diagnostic Relay Test Tools
eBIRST Switching System Test Tools are designed specifically for our PXI,
PCI or LXI products, these tools simplify switching system fault-finding by
quickly testing the system and graphically identifying the faulty relay.
To learn more, please go to: pickeringtest.com/ebirst
Three Year Warranty & Guaranteed Long-Term Support
All standard products manufactured by Pickering Interfaces are warranted against defective materials and workmanship
for a period of three years from the date of delivery to the original purchaser. Extended warranty and service agreements
are available for all our modules and systems with various levels to suit your requirements. Although we offer a 3-year
warranty as standard, we also include guaranteed long-term support—with a history of supporting our products for typically
15-20 years. To learn more, please go to: pickeringtest.com/support
Available Product Resources
We have a large library of product resources including success stories, product and support videos, articles and white
papers as well as application specific product brochures to assist when looking for the switching, simulation and
connection solutions you need. We have also published handy reference books on Switching Technology and for the PXI
and LXI standards.
To view, download or request any of our product resources, please visit: pickeringtest.com/resources

Page 2.1
PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755
pickering SECTION 2 - TECHNICAL DESCRIPTION
SECTION 2 - TECHNICAL DESCRIPTION
FUNCTIONAL DESCRIPTION
A functional block diagram is provided in Figure 2.1. The RF Multiplexer Module is powered by 3.3V and 5V inputs
via Compact PCI connector J1. The interface to the user test equipment is via the front panel mounted coaxial
connectors which can be - depending upon the model number - 26-pin multiway or individual SMB coaxial connectors.
The module comprises a PCB populated with high quality electro-mechanical relays arranged as a four, ve or ten
banks of 4-channel tree multiplexers. The relays are energised via control signals from relay drivers U50 and U51.
The relay drivers are fed with serial data from PCI bridge U1 via isolators U59 and U60. Module conguration is
determined by data stored in EEPROM U3, the PCI Bridge U1 is congured by EEPROM U2.
FRONT PANEL
COAXIAL CONNECTORS
MODULE
CONFIGURATION
U3
PCI
BRIDGE
U1
PCI BRIDGE
CONFIGURATION
U2
TERMINATING
RESISTORS
R1 TO R12
COMPACT PCI
BUS
CONNECTOR
J1
+3.3V
0V
RELAY
DRIVERS
U50, U51
RELAY COILSRELAY CONTACTS
RL11 TO RL103
DIGITAL
ISOLATORS
U59, U60
+5V
10 X RF 4:1 MULTIPLEXER
BANK 1
BANK 2
BANK 3
BANK 4
BANK 5
BANK 6
BANK 7
BANK 8
BANK 9
BANK 10
Figure 2.1 - RF Multiplexer Module 40-755:
Functional Block Diagram
(10-bank version)

Page 2.2 PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755
pickering
SECTION 2 - TECHNICAL DESCRIPTION
THIS PAGE INTENTIONALLY BLANK

Page 3.1
PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755
pickering SECTION 3 - INSTALLATION
Page 3.1
REED RELAY MODULE 40-110/115/120/125
pickering SECTION 3 - INSTALLATION
kg
PREOPERATION CHECKS (UNPACKING)
1. Check the module for transport damage and report any damage immediately to Pickering Interfaces.
Do not attempt to install the product if any damage is evident.
2. Position the chassis relative to any other equipment the module(s) will connect with. Ensure the chassis is not
connected to the electrical supply.
3. Ensure that the designated area for the chassis containing the module is of at and solid construction to
withstand and support the combined weight of the module(s) and chassis.
SECTION 3 - INSTALLATION
!
Refer to the Warnings and Cautions at the front of this manual
Modular products require installation in a suitable PXI/LXI chassis. The module is designed for indoor use only.
Figure 3.1 - Installing the Module into a PXI/cPCI/LXI Chassis
PXI / LXI Chassis

Page 3.2 PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755
pickering
SECTION 3 - INSTALLATION
Page 3.2 REED RELAY MODULE 40-110/115/120/125
pickering
SECTION 3 - INSTALLATION
SOFTWARE INSTALLATION
First install the appropriate Pickering PXI switch card drivers by running the installer program Setup.exe (provided
in a compressed zip le), either from the CD-ROM supplied, or by downloading the latest version from our website
pickeringtest.com - the recommended method. Setup is accompanied by a ReadMe le containing
additional installation information. A single installation covers all cards in the System 40, System 45 and System
50 ranges.
When installation completes, the installed drivers’ ReadMe le is offered for display. It can also be displayed
later using a shortcut on the Programs>>Pickering menu.
If you are not a LabVIEW user you should choose the “full” version, and once that has been installed run
the LabVIEW Runtime Engine installer via the shortcut on the Programs>>Pickering menu. In the absence of
LabVIEW the Runtime Engine is required to support the Pickering Test Panels application.
!
HARDWARE INSTALLATION
ELECTRICAL CONNECTION (CHASSIS)
1. The chassis must be electrically installed in accordance with local regional electrical codes by a qualied
engineer.
2. The chassis must be grounded.
Electrostatic discharge can damage the components on the module. To avoid such damage in handling the
board refer to page VII.
Ensure that there is adequate ventilation.
The module should be installed in accordance with the following procedure:
1. Ensure that the system is turned OFF but still connected to mains so that it remains grounded.
2. Choose an appropriate slot in the rack.
3. Remove the blanking plate for the chosen slot.
4. Ensure that the injector/ejector handle is in its downward position. Align the module with the card guides on
the top and bottom of the slot.
Do not raise the injector/ejector handle whilst inserting the module as the module will not insert properly.
5. Hold the handle whilst slowly sliding the module into the card guides until the handle catches on the injector/
ejector rail (refer to Figure 3.1).
6. Raise the injector/ejector handle until the module rmly seats into the backplane. The front panel of the
module should be ush with the front panel of the chassis.
7. Secure the front panel of the module using both screws to the chassis front panel mounting rails.
8. In a system employing a remote control interface to connect an external controller to a PXI chassis or to link
multiple chassis, power-up the system as follows:
a. For a system comprising an external controller and one chassis, power up the chassis before powering up
the external controller.
b. For a system comprising more than one chassis, turn ON the last chassis in the system followed by the
penultimate, etc, and nally turn ON the external controller or chassis containing the system controller.
9. For Pickering Interfaces modular LXI installation there is no requirement to use any particular power up
sequence.
