RF SWITCHING MODULE 40-710
pickering
Issue 6.2 May 2017
User Manual
RF Relay Module
(Model No. 40-710)
pickeringtest.com pickering
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (II)
RF SWITCHING MODULE 40-710
pickering
Page (II) REED RELAY MODULE 40-110/115/120/125
pickering
© COPYRIGHT (2017) PICKERING INTERFACES. ALL RIGHTS RESERVED.
No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by
any means without the written permission of Pickering Interfaces.
Technical details contained within this publication are subject to change without notice.
ISO 9001
Reg No. FM38792
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (III)
RF SWITCHING MODULE 40-710
pickering
Page (III)
REED RELAY MODULE 40-110/115/120/125
pickering
TECHNICAL SUPPORT
For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.
WARRANTY
All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of
three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be
defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.
Products serviced and repaired outside of the warranty period are warranted for ninety days.
Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.
ENVIRONMENTAL POLICY
Pickering Interfaces operates under an environmental management system similar to ISO 14001.
Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the
environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and
safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can
be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.
Worldwide Technical Support and Product Information
pickeringtest.com
Germany
Tel: [phone]
E-mail: [email protected]
Sweden
Tel: [phone]
E-mail: [email protected]
USA
Tel: (West) [phone]
Tel: (East) [phone]
E-mail: [email protected]
Czech Republic
Tel: [phone]
E-mail: [email protected]
France
Tel [phone]
E-mail [email protected]
Pickering Interfaces Headquarters
Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom
Tel: [phone]
E-Mail: [email protected]
China
Tel: [phone]
E-mail: [email protected]
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (IV)
RF SWITCHING MODULE 40-710
pickering
Page (IV) REED RELAY MODULE 40-110/115/120/125
pickering
MEANING / DESCRIPTION SYMBOL
PROTECTIVE EARTH (GROUND)
To identify any terminal which is intended for connection to an external conductor for
protection against electric shock in case of a fault, or the terminal of a protective earth
(ground) electrode.
DANGEROUS VOLTAGE
To indicate hazards arising from dangerous voltages.
WARNING / CAUTION
An appropriate safety instruction should be followed or caution to a potential hazard
exists.
Refer to the relevant instructions detailed within the product manual.
HEAVY
If this product is heavy reference should be made to the safety instructions for
provisions of lifting and moving.
STATIC SENSITIVE
To indicate that static sensitive devices are present and handling precautions should
be followed.
!
kg
SAFETY SYMBOLS
PRODUCT SAFETY
The following safety symbols may be used on the product and throughout the product documentation.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (V)
RF SWITCHING MODULE 40-710
pickering
Copyright Statement ...................................................................II
Technical Support and Warranty................................................III
Product Safety .............................................................................IV
Contents (this page)....................................................................V
Warnings and Cautions ..............................................................VII
Section 1
Technical Specication...............................................................1.1
Section 2
Technical Description .................................................................2.1
Functional Description..........................................................2.1
Section 3
Installation....................................................................................3.1
Pre Operation Checks...........................................................3.1
Hardware Installation ............................................................3.2
Software Installation .............................................................3.2
Testing Operation ..................................................................3.3
Section 4
Programming Guide....................................................................4.1
Programming Options For Pickering PXI Cards.................4.1
Module Architecture 40-710 ........ .......................................4.3
Programming The Module 40-710.......................................4.4
Section 5
Connector Information................................................................5.1
Section 6
Trouble Shooting .........................................................................6.1
Section 7
Maintenance Information............................................................7.1
Relay Lookup Tables.............................................................7.1
Component Layout................................................................7.2
CONTENTS
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (VI)
RF SWITCHING MODULE 40-710
pickering
THIS PAGE INTENTIONALLY BLANK
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (VII)
RF SWITCHING MODULE 40-710
pickering
Page (VII)
REED RELAY MODULE 40-110/115/120/125
pickering
WARNINGS AND CAUTIONS
WARNING - HAZARDOUS ENVIRONMENTS SYMBOL
This product is not specically designed for use in hazardous environments, for example in explosive
atmospheres. If the product is to be used in hazardous environments we recommend that the user
ensures suitable protective measures are taken.
!
WARNING - DANGER OF ELECTRIC SHOCK SYMBOL
This module may contain hazardous voltages. Before removing the module from the rack remove all
supplies and disconnect user I/O signals.
Unused slots in the PXI/LXI chassis are populated with blanking plates to prevent access to user
I/O signals that may be present. Blanking panels are available to order from Pickering in a variety
of slot widths. If the product is not used in this manner for example by using an extender card then
additional care must be taken to avoid contact with exposed signals.
CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL
Certain semiconductor devices used in this equipment are liable to damage due to static voltage.
Observe the following precautions when handling these devices in their unterminated state, or
sub-assemblies containing these devices:
1. Persons removing sub-assemblies from equipment using these devices must be earthed by a
wrist strap and a resistor at the point provided on the equipment.
2. Soldering irons used during the repair operations must be low voltage types with earthed tips and
isolated from the mains voltage by a double insulated transformer.
3. Outer clothing worn must be unable to generate static charges.
4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in
anti-static bags.
CAUTION - PRODUCT DOCUMENTATION SYMBOL
Suitably qualied & trained users should ensure that the accompanying documentation is fully read
and understood before attempting to install or operate the product.
!
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O
signals (refer to the Maintenance Section).
• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or
the combined weight of the modules & chassis.
• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the
chassis and the user I/O signals.
• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.
• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on
the front of the unit.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (VIII)
RF SWITCHING MODULE 40-710
pickering
THIS PAGE INTENTIONALLY BLANK
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page 1.1
RF SWITCHING MODULE 40-710
pickering SECTION 1 - TECHNICAL SPECIFICATION
SECTION 1 - TECHNICAL SPECIFICATION
pickeringtest.com
40-710
RF Relay Module
●4 Changeover RF Relays Per Module
●Up To 2.5GHz Bandwidth in 50Ω
●Up To 1GHz Bandwidth in 75ΩSuitable
For Telecoms or Video Applications
●Tree Networks may be Constructed by
Inter-Linking Individual Modules
●VISA, IVI & Kernel Drivers Supplied for
Windows
●Supported by PXI or LXI Chassis
●3 Year Warranty
Switching Diagram for 40-710,
4 x SPDT RF Relays
NO 1
NC 1
Com 1
Relay 1
NO 2
NC 2
Com 2
Relay 2
NO 3
NC 3
Com 3
Relay 3
NO 4
NC 4
Com 4
Relay 4
Model 40-710 RF switching module has a bank of 4
individual high performance R.F. changeover switches
(50Ωor 75Ω, Bi-directional) with very low insertion
loss, suitable for handling signals up to 2.5GHz.
Applications include aerial switching, routing high
frequency signals into oscilloscopes and analysers.
Available with a choice of connectors: SMA, SMB and
Siemens 1.0/2.3 versions. In addition BNC connectors
are offered with reduced bandwidth performance
which requires a 2 slot width module.
The 75Ωversions are suitable for high frequency video
and telecommunication signals up to 1GHz.
4 x Changeover RF
Relays, 75ΩSMZ,
Type 40-710-714
ISSUE 9.1 MAY 2017
4 x Changeover RF
Relays, 50ΩSMB,
Type 40-710-514
Relay Type
The 40-710 is fitted with high reliabillty RF Relays,
these offer long life with good low level switching
performance.
Spare RF Relays are built onto the circuit board to
facilitate easy maintenance with minimum downtime.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page 1.2
RF SWITCHING MODULE 40-710
pickering
SECTION 1 - TECHNICAL SPECIFICATION
pickeringtest.com
40-710-514 (50Ω SMB) Perfomance Plots (Plots taken from typical sample showing all connecting paths for parameter)
40-710-514 (50ΩSMB) typical insertion loss
plots for all NO and NC inputs.
40-710-514 (50ΩSMB) typical VSWR
plots for all NO and NC inputs.
40-710-514 (50ΩSMB) typical isolation plots
for all NO and NC inputs.
40-710-514 (50ΩSMB) typical crosstalk plots
between neighbouring channels.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page 1.3
RF SWITCHING MODULE 40-710
pickering SECTION 1 - TECHNICAL SPECIFICATION
pickeringtest.com
40-710-704 (75ΩBNC) typical insertion loss
plots for all NO and NC inputs.
40-710-704 (75ΩBNC) typical VSWR
plots for all NO and NC inputs.
40-710-704 (75ΩBNC) typical isolation plots
for all NO and NC inputs.
40-710-704 (75ΩBNC) typical crosstalk plots
between neighbouring channels.
40-710-704 (75Ω BNC) Perfomance Plots (Plots taken from typical sample showing all connecting paths for parameter)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page 1.4
RF SWITCHING MODULE 40-710
pickering
SECTION 1 - TECHNICAL SPECIFICATION
pickeringtest.com
Product Order Codes
4x Changeover Switch, 1GHz, 50Ω, BNC
4x Changeover Switch, 2.5GHz, 50Ω, SMB
4x Changeover Switch, 2.5GHz, 50Ω, SMA
40-710-504
40-710-514
40-710-524
4x Changeover Switch, 1GHz, 75Ω, BNC
4x Changeover Switch, 1GHz, 75Ω, SMZ/Type43
4x Changeover Switch, 1GHz, 75Ω, 1.0/2.3
4x Changeover Switch, 1GHz, 75Ω, SMB
40-710-704
40-710-714
40-710-734
40-710-754
Support Products
Spare Relay Kits
Kits of replacement relays are available for the majority of Pickering’s
PXI switching modules, simplifying servicing and reducing down-time.
The relay kits for the 40-710 range is as follows:
All 50Ωversions: 91-100-096 Relay Kit 96
All 75Ωversions: 91-100-029 Relay Kit 29
For further assistance, please contact your local Pickering sales office.
Power Requirements
+3.3V +5V +12V -12V
0320mA (typ 240mA) 0 0
Mating Connectors & Cabling
For connection accessories for the 40-710 range please refer to
the 90-011D RF Cable Assemblies data sheet where a complete
list and documentation can be found for accessories, or refer to
the Connection Solutions catalog.
General Specification - All Versions
Max Switching Power: 10W
Max Switching Voltage:
30VDC
Max Switching Current: 0.5A
Nominal Switching Capacity: 0.01A, 24VDC, 10W@1.2GHz
Initial On Path Resistance:
<200mΩ
Off Path Resistance: >1x108 Ω
Thermal Offset: <20µV
Expected Life, Mechanical: >1x106 ops
Expected Life, Electrical: >3x105 ops (10mA@24VDC)
>3x105 ops ([email protected])
Switching Time: 10ms
Rise Time: <0.2ns (50Ω)
<0.3ns (75Ω)
50ΩSpecification - SMB and SMA Versions
Bandwidth: 2.5GHz
Maximum Switching Power: 10W
Isolation: Typically >27dB (0-1GHz)
Typically >17dB (1GHz-2.5GHz)
Crosstalk: Typically <-46dB (0-1GHz)
Typically <-32dB (1GHz-2.5GHz)
Insertion Loss: Typically <1.5dB (0-1GHz)
Typically <3dB (1GHz-2.5GHz)
VSWR: <1.7:1
50ΩSpecification - BNC Version
Bandwidth: 1GHz
Maximum Switching Power: 10W
Isolation: Typically >27dB (0-1GHz)
Crosstalk: Typically <-46dB (0-1GHz)
Insertion Loss: Typically <3dB (0-1GHz)
VSWR: <1.7:1
75ΩSpecification - All Versions
Bandwidth: 1GHz
Maximum Switching Power: 10W
Isolation: Typically >30dB (0-1GHz)
Crosstalk: Typically <-40dB (0-1GHz)
Insertion Loss: Typically <3dB (0-1GHz)
VSWR: <2.4:1
Mechanical Characteristics
Single slot 3U PXI (CompactPCI card). Except BNC version
which is 2-slot width.
Module weight: 240g (40-710-734)
3D models for all versions in a variety of popular file formats
are available on request.
Connectors
PXI bus via 32-bit P1/J1 backplane connector. Signals via
front panel mounted coaxial connectors, type dependant
upon product code.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page 1.5
RF SWITCHING MODULE 40-710
pickering SECTION 1 - TECHNICAL SPECIFICATION
pickeringtest.com
Programming
Pickering provide kernel, IVI and VISA (NI & Keysight) drivers
which are compatible with all Microsoft supported versions of
Windows and popular older versions. For a list of all supporting
operating systems, please see: www.pickeringtest.com/os
The VISA driver is also compatible with Real-Time Operating
Systems such as LabVIEW RT. For other RTOS support
contact Pickering. These drivers may be used with a variety of
programming environments and applications including:
Pickering Interfaces Switch Path Manager
MTQ Testsolutions Tecap Test & Measurement Suite
National Instruments products (LabVIEW, LabWindows/
CVI, Switch Executive, MAX, TestStand, VeriStand, etc.)
Microsoft Visual Studio products (Visual Basic, Visual C+)
Keysight VEE Mathworks Matlab Marvin ATEasy
Drivers for popular Linux distributions are available, other
environments are also supported, please contact Pickering
with specific enquiries.
Operating/Storage Conditions
Operating Conditions
Operating Temperature:
Humidity:
Altitude:
0°C to +55°C
Up to 90% non-condensing
5000m
Storage and Transport Conditions
Storage Temperature:
Humidity:
Altitude:
-20°C to +75°C
Up to 90% non-condensing
15000m
PXI & LXI Chassis Compatibility
Compatible with all chassis conforming to the 3U PXI and
3U cPCI specification. Compatible with Legacy and Hybrid
peripheral slots in a 3U PXI Express chassis.
Compatible with Pickering Interfaces LXI Modular Chassis.
For information on driving your switching solution in an LXI
environment refer to the LXI Product Guide.
PXI & CompactPCI Compliance
The module is compliant with the PXI Specification 2.2. Local
Bus, Trigger Bus and Star Trigger are not implemented.
Uses a 33MHz 32-bit backplane interface.
Safety & CE Compliance
All modules are fully CE compliant and meet applicable EU
directives: Low-voltage safety EN61010-1:2001,
EMC Immunity EN61000-6-1:2001, Emissions EN55011:1998.
Please refer to the 200 page
Pickering Interfaces “Connection
Solutions” catalog for the full list
of connector/cabling options,
including drawings, photos and
specifications. Available in either
print or as a download.
Alternatively our web site has
dynamically linked connector/
cabling options, including pricing,
for all Pickering PXI modules.
Ever wondered what PXI is all
about?
Pickering Interfaces’ “PXImate”
explains the basics of PXI
and provides useful data for
engineers working on switch
based test systems.
The PXImate is available free
on request from the Pickering
website.
“The Big PXI Catalog” gives
full details of Pickering’s entire
range of PXI switch modules,
instrument modules and
support products.
At over 500 pages, the Big
PXI Catalog is available on
request or can be downloaded
from the Pickering website.
The “PXI
Module Map”
- a simple fold-
out selection
guide to all
Pickering’s
1000+ PXI
Modules.
The “Cables &
Connectors
Map” - outlines
the cable and
connector
options
available
for all PXI
Modules.
Latest Details
Please refer to our Web Site for Latest Product Details.
www.pickeringtest.com
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page 1.6
RF SWITCHING MODULE 40-710
pickering
SECTION 1 - TECHNICAL SPECIFICATION
THIS PAGE INTENTIONALLY BLANK
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page 2.1
RF SWITCHING MODULE 40-710
pickering SECTION 2 - TECHNICAL DESCRIPTION
SECTION 2 - TECHNICAL DESCRIPTION
FUNCTIONAL DESCRIPTION
A functional block diagram is provided in Figure 2.1. The RF Switching Module is powered by +12V and +5V
inputs via Compact PCI connector J1. The interface to the user test equipment is via the front panel mounted
BNC, SMA, SMB, SMZ/Type 43, or Siemens 1.0/2.3 Version connectors. The module comprises a PCB populated
with changeover RF relays. The relays are energised via control signals from relay driver U10. The relay driver is
addressed by PCI bridge U1, via output register U8, to output the required signal. PCI Bridge U1 is congured by
EEPROM U2.
Figure 2.1 - RF Switching Module: Functional Block Diagram
RELAY
DRIVER
U10
MODULE
CONFIGURATION
U5, U6 AND U7
PCI BRIDGE
U1
PCI BRIDGE
CONFIGURATION
U2
TERMINATING
RESISTORS
R4 TO R15
COMPACT PCI
BUS
CONNECTOR
J1
+12V
0V
RELAY COILS
RELAY CONTACTS
NO
NO
NO
NO
NC
NC
NC
NC
C
C
C
C
OUTPUT
REGISTER
U8
+5V
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page 2.2
RF SWITCHING MODULE 40-710
pickering
SECTION 2 - TECHNICAL DESCRIPTION
THIS PAGE INTENTIONALLY BLANK
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page 3.1
RF SWITCHING MODULE 40-710
pickering SECTION 3 - INSTALLATION
Page 3.1
REED RELAY MODULE 40-110/115/120/125
pickering SECTION 3 - INSTALLATION
kg
PREOPERATION CHECKS (UNPACKING)
1. Check the module for transport damage and report any damage immediately to Pickering Interfaces.
Do not attempt to install the product if any damage is evident.
2. Position the chassis relative to any other equipment the module(s) will connect with. Ensure the chassis is not
connected to the electrical supply.
3. Ensure that the designated area for the chassis containing the module is of at and solid construction to
withstand and support the combined weight of the module(s) and chassis.
SECTION 3 - INSTALLATION
!
Refer to the Warnings and Cautions at the front of this manual
Modular products require installation in a suitable PXI/LXI chassis. The module is designed for indoor use only.
Figure 3.1 - Installing the Module into a PXI/cPCI/LXI Chassis
PXI / LXI Chassis
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page 3.2
RF SWITCHING MODULE 40-710
pickering
SECTION 3 - INSTALLATION
Page 3.2 REED RELAY MODULE 40-110/115/120/125
pickering
SECTION 3 - INSTALLATION
SOFTWARE INSTALLATION
First install the appropriate Pickering PXI switch card drivers by running the installer program Setup.exe (provided
in a compressed zip le), either from the CD-ROM supplied, or by downloading the latest version from our website
pickeringtest.com - the recommended method. Setup is accompanied by a ReadMe le containing
additional installation information. A single installation covers all cards in the System 40, System 45 and System
50 ranges.
When installation completes, the installed drivers’ ReadMe le is offered for display. It can also be displayed
later using a shortcut on the Programs>>Pickering menu.
If you are not a LabVIEW user you should choose the “full” version, and once that has been installed run
the LabVIEW Runtime Engine installer via the shortcut on the Programs>>Pickering menu. In the absence of
LabVIEW the Runtime Engine is required to support the Pickering Test Panels application.
!
HARDWARE INSTALLATION
ELECTRICAL CONNECTION (CHASSIS)
1. The chassis must be electrically installed in accordance with local regional electrical codes by a qualied
engineer.
2. The chassis must be grounded.
Electrostatic discharge can damage the components on the module. To avoid such damage in handling the
board refer to page VII.
Ensure that there is adequate ventilation.
The module should be installed in accordance with the following procedure:
1. Ensure that the system is turned OFF but still connected to mains so that it remains grounded.
2. Choose an appropriate slot in the rack.
3. Remove the blanking plate for the chosen slot.
4. Ensure that the injector/ejector handle is in its downward position. Align the module with the card guides on
the top and bottom of the slot.
Do not raise the injector/ejector handle whilst inserting the module as the module will not insert properly.
5. Hold the handle whilst slowly sliding the module into the card guides until the handle catches on the injector/
ejector rail (refer to Figure 3.1).
6. Raise the injector/ejector handle until the module rmly seats into the backplane. The front panel of the
module should be ush with the front panel of the chassis.
7. Secure the front panel of the module using both screws to the chassis front panel mounting rails.
8. In a system employing a remote control interface to connect an external controller to a PXI chassis or to link
multiple chassis, power-up the system as follows:
a. For a system comprising an external controller and one chassis, power up the chassis before powering up
the external controller.
b. For a system comprising more than one chassis, turn ON the last chassis in the system followed by the
penultimate, etc, and nally turn ON the external controller or chassis containing the system controller.
9. For Pickering Interfaces modular LXI installation there is no requirement to use any particular power up
sequence.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page 3.3
RF SWITCHING MODULE 40-710
pickering SECTION 3 - INSTALLATION
Page 3.3
REED RELAY MODULE 40-110/115/120/125
pickering SECTION 3 - INSTALLATION
Figure 3.3 - General Soft Front Panel Selector
TESTING OPERATION
After installation of the hardware and Pickering PXI Driver software package start the General Soft Front
Panel (GSFP) using the desktop icon or via the Start menu (Start Menu-> Pickering Interfaces Ltd ->
General Soft Front Panel).
A selector panel will appear, listing all installed Pickering PCI, PXI or LXI switch cards and resistor cards. Click
on the card you wish to control, and a graphical control panel is presented allowing operation of the card.
Panels can be opened simultaneously for all the installed cards.
More details how to use the GSFP can be found in the manual, via menu Help\Manual
Figure 3.2 - General Soft Front Panel Icon
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
