PXI 20 A Fault Insertion Switch Modules 40-193
ISSUE 5.1 DEC 2019
y7 Fault Insertion Channels
ySimulation of Various Types of Electrical Fault,
Enabling Rigorous Fault Testing
yChoice of 1 or 2 Fault Insertion Buses
y20 A Hot or Cold Switching
ySwitch up to 16 VDC
yVISA, IVI & Kernel Drivers Supplied for
Windows
ySupported by PXI or LXI Chassis
y3 Year Warranty
U2
U3
U4
M2
M3
M4
U5
U6
M5
M6
Stimulus/Measurement Connections
UUT Connections
Fault Insertion Bus 2
Fault Insertion Bus 1
Fault Connections
COM1
COM2
U7
M7
U1
M1
40-193-002 Fault Insertion Switch Schematic
Diagram. This version has 2 fault buses,
the 40-193-001 has 1 fault bus
Pickering’s Range of PXI Fault Insertion Switches
Model
No. Signal Channels Fault
Buses
Fault
Inputs
Max
Voltage
Max Current
or Bus Type
40-190B 74, 64 or 32 1 or 2 4 or 8 165 V 2 A
40-191A 6 2 2 40 V 30 A
40-192 6 2 2 200 V 10 A
40-193 7 1 or 2 1 or 2 16 V 20 A, 1 A min
40-194 7 1 or 2 1 or 2 16 V 20 A, no min
40-195 22 or 11 pairs — 8 or 4 150 V 1 A
40-196 10 or 5 pairs — 10 or 5 110 V 5 A
40-197A 34 or 16 4 8 300 V 2 A
40-198 20 1 or 2 3 or 6 250 V 5 A
40-199 10 1 or 2 2 250 V 10 A
40-200 4 or 8 differential 4 8 100 V CAN, FlexRay
40-201 4 or 8 differential 2 4 100 V
Ethernet/
AFDX/
BroadR-Reach
40-202 22 or 11 pairs — 22 or 11 150 V 1 A
The 40-193 is a 7-Channel Fault Insertion switch designed
for the simulation of fault conditions in automotive systems.
It is able to insert 3 different fault conditions between the
test fixture and the equipment under test:
• Open-Circuit
• Short-Circuit between UUT connections
• Short-Circuit to other signals such as Power, Ignition &
Ground via Fault Insertion Bus
Through relays on each channel enable signals to the UUT
to be held open-circuit. Fault Insertion Buses allow any
channel to be shorted to any other channel and enable
any channel to be connected to an external signal such as
Power, Ignition or Ground to simulate fault conditions.
Range Description:
• 40-193-001 7 Channels, One Fault bus.
• 40-193-002 7 Channels, Two Fault buses.
The 40-193 uses miniature automotive relays with 20 A hot
or cold switching current. All relays are normally open.
