Broadband 5-1000MHz
frequency range
Vertical port design allows close
mounting in lock boxes for easy
access of cable connections
1-inch centered 1/2˝ long precision
machined F-connector threads
ensure improved port-to-connector
interface and accommodate external
security devices
Standard TSB-series splitters feature
an epoxy-sealed back cover that
provides effective EMI-RFI shielding
>-90dB reducing signal ingress
TSB-SB-series feature a solder-back
cover-plate providing maximum
EMI-RFI shielding >-130dB and
eliminating signal ingress to guar-
antee distortion-free pictures
Silver-coated zinc-alloy diecast
housing ensures excellent ground
bonding and long corrosion-free
service life in indoor/outdoor
applications
Capacitor coupling circuitry at all
ports provides effective DC voltage
blocking
Internal seizing pins provide
improved connectivity to connector
center lead
Mounting tabs with provided
mounting screws enables easy
installation
Cast-in integrated ground block
with convenient 3-way mounting
screws (Slotted, Hex, Phillips)
enables cost-effective installations
Performance tests conducted con-
forming with SCTE standards IPS
TP-201, 202, 203, 406
Manufactured to high performance standards, TruSpec’s TSV-series 1GHz professional-
grade CATV splitters provide excellent performance rivaling competitors’ equivalent
models. Applications range from residential to MDU installations in international and
domestic cable distribution systems.The vertical-port design ideally suits these splitters
for applications where limited space is available such as lock boxes and utility closets.
Our advanced printed board circuitry includes special ferrite core material guaranteeing
minimal insertion loss, optimal isolation and return loss to 1GHz ensuring high-quality
analog or digital signal transfer.TSV series F-port threads are precision machined,
ensuring easy connector installation and removal, and improved port-to-connector
interface.The silver-plated zinc alloy cast case features mounting tabs and cast-in
ground block enabling easy and cost efficient installations. TSV series are optionally
available in >90dB epoxy-backed or >130dB solder-backed versions. Each TSV splitter
is individually tested at the factory to comply with precise quality standards.
1GHz 90dB/130dB EMI CATV Vertical Splitters
TSV Series
TSV
Series
1GHz 90dB/130dB EMI CATV Vertical Splitters
TSV-2
TSV-2SB TSV-3
TSV-3SB
TSV-4
TSV-4SB
TSV-6
TSV-6SB
TSV-8
TSV-8SB
TESTED

TSV Series
Product Specifications
1GHz 90dB/130dB EMI CATV Vertical Splitters
INPUT
-130dB EMI
TSV-2SB
5-1000MHz
OUT
-3.5dB
OUT
-3.5dB
TRU SPEC
OUT
-7.0dB
OUT
-7.0dB
INPUT
OUT
-7.0dB
-100dB EMI
TSV-3SB
5-1000MHz
TRU SPEC
OUT
-7.0dB
OUT
-7.0dBINPUT
OUT
-7.0dB
OUT
-7.0dB
-100dB EMI
TSV-4SB
5-1000MHz
TRU SPEC
INPUT
INPUT
OUT
-10.0dB
OUT
-10.0dB
OUT
-10.0dB
OUT
-10.0dB
OUT
-10.0dB
OUT
-10.0dB
-130dB EMI5-1000MHz
TSV-6SB
TRU SPEC
TSV-2
TSV-2SB
TSV-3
TSV-3SB
TSV-4
TSV-4SB
TSV-6
TSV-6SB
INPUT
INPUT
OUT
-10.7dB
OUT
-10.7dB
OUT
-10.7dB
OUT
-10.7dB
OUT
-10.7dB
OUT
-10.7dB
OUT
-10.7dB OUT -10.7dB
-130dB EMI5-1000MHz
TSV-8SB
TRU SPEC
TSV-8
TSV-8SB
TSV-2 2-Port Vertical Splitter 90dB EMI Epoxy-Backed
TSV-3 3-Port Vertical Splitter 90dB EMI Epoxy-Backed
TSV-4 4-Port Vertical Splitter 90dB EMI Epoxy-Backed
TSV-6 6-Port Vertical Splitter 90dB EMI Epoxy-Backed
TSV-8 8-Port Vertical Splitter 90dB EMI Epoxy-Backed
TSV-2SB 2-Port Vertical Splitter130dB EMI Solder-Backed
TSV-3SB 3-Port Vertical Splitter130dB EMI Solder-Backed
TSV-4SB 4-Port Vertical Splitter130dB EMI Solder-Backed
TSV-6SB 6-Port Vertical Splitter130dB EMI Solder-Backed
TSV-8SB 8-Port Vertical Splitter130dB EMI Solder-Backed
Ordering Information
Start 5.000 Mhz Sto
p
1 000.000 Mhz
dB
-3
-4
-5
1:
-7
-8
-9
-10
-11
1:Transmission /M Log Mag 1.0 dB/ Ref -6.00 dB C
Meas1: Mkr6 1000.000 Mhz
-7.690 dB
A
B
C
D
TSV-2 and TSV-2SB
Insertion Loss (In-Out) : 3.5dB Typical Trace A
Return Loss (Output): 27dB Typical
Isolation (Out-Out): 33dB Typical
Dimensions: 2.3˝ (L) x 1.5˝ (W) x 1.1˝(H)
TSV-3 and TSV-3SB
Insertion Loss (In-Out): 3.5dB Typical Trace A
7.0dB Typical Trace B
Return Loss (Output): 24dB Typical
Isolation (Out-Out): 33dB Typical
Dimensions: 3.3˝(L) x 1.5˝(W) x 1.1˝(H)
TSV-4 and TSV-4SB
Insertion Loss (In-Out): 7.0dB Typical Trace B
Return Loss (Output): 23dB Typical
Isolation (Out-Out): 32dB Typical
Dimensions: 3.3˝(L) x 1.5˝(W) x 1.1˝(H)
TSV-6 and TSV-6SB
Insertion Loss (In-Out): 9.0dB Typical Trace C
Return Loss (Output): 29dB Typical
Isolation (Out-Out): 37dB Typical
Dimensions: 3.3˝(L) x 2.7˝(W) x 1.1˝(H)
TSV-8 and TSV-8SB
Insertion Loss (In-Out): 10.4dB Typical Trace D
Return Loss (Output): 28dB Typical
Isolation (Out-Out): 38dB Typical
Dimensions: 3.3˝(L) x 2.7˝(W) x 1.1˝(H)
Specifications
INSERTION LOSS Typical
