Pico Macom XUV User manual

XUV
55 Channel Input Range
470-806 MHz (TV UHF 14-69)
37 Channel Output Range
54-300MHz (TV VHF 2-36)
47dBmV output with built-in 20dB
gain improves carrier-to-noise
performance
BTSC stereo compatibility for
pass-through of stereo signals
Internal DIP switch controlled
PLL-design guarantees precise
frequency locking for solid
drift-free operation
Test point enables easy system
monitoring
Lab re-tunable for easy system
setup
UL Approved
The Pico Macom XUV is a professional grade, very cost effective phase-
locked loop synthesized channel converter which translates a single UHF
channel to VHF. When used with a band-pass filter (Pico Macom BPF), the
unit’s excellent frequency stability and skirt selectivity make the XUV ideal for
adjacent channel headend systems. The unit can be reconfigured to any
channel within band by qualified service centers. With 20 dB of built-in gain,
the XUV can be used in smaller cable systems without the cost of additional
amplification. In medium to larger systems, improved selectivity and automatic
gain control are achieved when the XUV is followed by a single channel band-
pass filter and strip amplifier (Pico Macom’s BPF and XBS). Pico Macom
backs up this product with its industry leading 5-year limited warranty.
XUV
Single Channel UHF to VHF Converter
Single Channel UHF to VHF Converter
www.picomacom.com
Headend & Electronics
355 Parkside Drive San Fernando, CA 91340
Ph: 818-493-4300 Toll Free: 800-421-6511 Fax: [phone]
A-39
Rev. 12/02

XUV
Gain: 20 dB
Bandwidth: 6 MHz
Skirt Selectivity: ±6 Channels: -60 dB
±3 Channels: -50 dB
±2 Channels: -25 dB
Maximum Output: 47 dBmV
Channel Conversions:
UHF Input: Channels 14-70
VHF Output: Channels 2-13, A-I, J-W
Frequency Stability: ±5 kHz
Noise Figure: 12 dB
Return Loss: Input: 14 dB (on channel)
Output: 14 dB (on channel)
Impedance: 75 Ohms
Product Specifications
SINGLE CHANNEL CONVERTER
XUV
CH- TO
TEST
POINT
-20 dB
VHF OUT 120VAC
60Hz 10W
UHF IN
600 W MAX
Front View
Rear View
Single Channel UHF to VHF Converter
XUV – Channel –Channel
Specifications
Ordering Information
General
Power Input: 108-120 Vac 60 Hz, 3 W
Operating Temperature: -10° to 50° C
Mounting: Single 19˝ Rack Space
Dimensions: 19˝(L) x 3˝(D) x 13/4˝(H)
Weight: 4.0 lbs.
Connectors: “F” type
Output Test Point: -20 dB
www.picomacom.com
A-40
Rev. 12/02 355 Parkside Drive San Fernando, CA 91340
Ph: 818-493-4300 Toll Free: 800-421-6511 Fax: [phone]
Specifications Subject to Change © Copyright 2003 Pico Macom, Inc.
