PIEGA TC Series

Quality

Reference floor-standing loudspeaker with coaxial ribbon system
TC 70 X
The TC 70 X is equipped with superfast MOM®technology (Magnetic Optimized
Motor) bass chassis. The increased transient properties of the bass loudspeakers har-
monize perfectly with our fast coaxial ribbon system, and the seamless aluminum
cabinet pressed from one block provides the technological basis for a resonance free
loudspeaker housing. The outstanding qualities of the coaxial ribbon system go
without saying. The audio press worldwide has proclaimed it a milestone in loud-
speaker construction. The qualities of the accurately designed frequency crossover
are also naturally first class.
This all together results in an exciting musical experience with a naturalness to stir all
the emotions.
Top class floor-standing loudspeaker with ribbon tweeter
TC 50
The elegant TC 50 floor-standing trapezoidal loudspeaker comes with the same
MOM®technology in the bass range and the same uncompromising housing as
the high-end model TC 70 X. The tweeter system used is the legendary LDR II
ribbon tweeter, which has been well-established for 15 years, and which still today
represents the “state of the art”, ensures an elegant and highly resolved sound.
Regardless of whether you are playing loud or soft music, large symphonic works
or the intimate music of a jazz trio, the TC 50 offers outstanding sound quality
with every musical direction for even discerning audiophiles.
Slime-line reference column loudspeaker with coaxial ribbon system
TC 30 X
The TC 30 X rounds off the TC range perfectly and fulfills every wish in this category.
The loudspeaker with the modest dimensions fits in every room, and it has a fine
and discrete presence even in small spaces. However, in no way is its performance
small-scale, and the TC 30 X offers optimum purity with extensive musicality. Two
MOM®bass woofers ensure an incredibly full sound in the bass range. Like all X
models, the TC 30 X is equipped with the coaxial ribbon system which means that
the acoustic center of midrange and tweeter excludes any disturbing interference.
Precise sound reproduction and pure musical enjoyment – hand made by PIEGA in
Horgen.
Reference compact loudspeaker with coaxial ribbon system
TC 10 X
A compact loudspeaker in terms of dimensions. In terms of technology, however, a
top performer with all the special features of the TC 70 X: The new powerful bass
chassis with MOM®technology and the unique coaxial ribbon system. A big sound
from a small cabinet – the TC 10 X turns this wish into reality. In combination with a
subwoofer like the PS 2 this speaker allows you to create a system that will leave
you lost for words even in very large rooms.
PIEGA TC Series

Model TC 70 X TC 50 TC 30 X TC 10 X
Design principle 3-way system 2 1/2-way system 3-way system 3-way system
floor-standing loudspeaker floor-standing loudspeaker column loudspeaker compact loudspeaker
Recommended 20 – 250 Watt 20 – 250 Watt 20 – 250 Watt 20 – 200 Watt
amplifier output
Sensitivity 92 db/W/m 92 db/W/m 90 db/W/m 90 db/W/m
Impedance 4 Ohm 4 Ohm 4 Ohm 4 Ohm
Frequency range 26 Hz – 50 kHz 26 Hz – 50 kHz 34Hz – 50kHz 38 Hz – 50 kHz
Equipment 2 18 cm MOM®bass 2 18 cm MOM®bass 2 15 cm MOM®bass 1 15 cm MOM®bass
1 C2 coaxial ribbon system 1 LDR tweeter 1 C2 coaxial ribbon system 1 C2 coaxial ribbon system
Connection Bi-Wiring / WBT Bi-Wiring / WBT Bi-Wiring / WBT Bi-Wiring / WBT
Dimensions (HxWxD) 102 x 26 x 29 cm 102 x 26 x 29 cm 111 x 19 x 21cm 40 x 19 x 21 cm
Weight 35 kg 31 kg 28 kg 11 kg
Finish Aluminum cabinet, Aluminum cabinet, Aluminum cabinet, Aluminum cabinet,
Front grill metal black, Front grill metal black Front grill metal black Front grill metal black
Aluminum cabinets Aluminum cabinets Aluminum cabinets Aluminum cabinets
black anodized and black anodized and black anodized and black anodized and
Front grill silver optional Front grill silver optional Front grill silver optional Front grill silver optional
TC 50
TC 30 X
287
254
1018
TC 70 X
TC 10 X
1112
186186
396
209 300
280

Service
PIEGA offers first-class service and six
Years warranty on all loudspeakers,
as well as three years on the electronics.
PIEGA SA
Bahnhofstrasse 29
CH-8810 Horgen
Telefon [phone]
Fax [phone]
[email protected]
www.piega.ch
Informationen for Exports
PIEGA SA
Bahnhofstrasse 29
CH-8810 Horgen
Telefon [phone]
Fax [phone]
[email protected]
www.piega.ch
Published Summer 2008
Subject to modifications, in particular
technical modifications and errors.
