Pifco PH0129-9T User manual

Oil Filled Radiator
Model number: PH0129-9T
INSTRUCTION MANUAL

3
Components
Carry handle
Heat settings
Timer
Castor wheels
Radiator fins
Adjustable
thermostat
How can we help?
The PIFCO team is always interested in what
you have to say, so why not get in touch?
Call us
01909 544 570
Write to us
PIFCO Team, Sabichi Homewares Ltd,
Priorswell Road, Worksop, SB0 2BY
Email us
[email protected]
Website
www.pifco.com

54
Safety instructions
When using an electrical appliance, basic safety precautions should
always be followed, including the following:
• This appliance is not intended for use by people (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they are supervised or
given instruction concerning the use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that they do not play with
the appliance.
• Extreme caution is necessary when any heater is used by or near
children or elderly people. Never leave the heater unattended
while it is being used.
• Connect the appliance to a single phase AC supply equal to the
voltage specified on the rating plate.
• In order to avoid overheating, do not cover the heater.
• Never leave the heater unattended while it is in use. Always turn
the product to the “OFF” position and unplug it from the electrical
outlet when not in use.
• The heater must not be located immediately below an electrical
socket-outlet.
• Do not run the cord under carpeting or cover it with rugs, runners
or the like. Arrange the cord away from traffic areas and where it
will not be tripped over.
• Do not operate the heater with a damaged cord or plug, after the
heater has malfunctioned or has been dropped or damaged.
• If the supply cord is damaged, it must be replaced by a qualified
person to avoid a hazard.
• Avoid the use of an extension cord as this may cause the heater to
overheat and cause a risk of fire.
• Use the heater in a well-ventilated area. Do not insert or allow
objects to enter air intake or outlet openings.
• To prevent a possible fire, do not block air intake or outlet openings
in any manner.
• Do not use on soft surfaces, such as a bed, where openings may
become blocked. Use the heater on a flat, dry surface only.
• Do not place this heater near flammable materials, surfaces or
substances, as there may be a risk of fire. Keep materials, surfaces
or substances at least 1 metre from the front of the heater and keep
them away from the sides and rear.
• Do not use the heater in any areas where petrol, paint or other
flammable liquids are stored, e.g. garages or workshops as there
are hot, arcing and sparking parts inside the heater.
• Do not use this heater near or in the immediate vicinity of a bath,
shower or swimming pool. Never position the heater where it may
fall into a bathtub or any other vessel containing water or liquid.
• This heater is hot when in use. To avoid burns and personal injury,
do not let bare skin touch hot surfaces. Use handles when moving
the product.
• Be sure that no other appliances are in use on the same electrical
circuit as this heater, as an overload can occur.
• Regulations concerning the disposal of oil when scrapping the
appliance have to be followed.
• The heater should not be used in a room in where the floor area is
less than 5 square metres.
• The cord should not be placed near the hot surface of appliance.
• This heater is designed for indoor household use.
• Do not cover the heater as this may lead to a fire risk.

76
Instructions for use
NOTE: It is normal for the heater to emit some smell and fumes when it is turned
on for the first time or has been turned on after a long period of non-use. This will
disappear after the heater has been on for a short while.
1 Before using the radiator make sure that it is on a flat and stable surface.
2 Set all the radiator controls to “OFF” and the thermostat to the minimal
position. Insert the plug to the power supply.
3 Set the power switch to the “ON“ position.
4 Turn the thermostat control clockwise all the way round, until you hear a click.
This sound indicates that the oil heater is activated and the indicator is ON.
Continue turning the thermostat control clockwise to its highest setting.
5 When the indicator light turns ON the heater will activate. The indicator light
turns ON and OFF repeatedly during use. This is normal and shows that the
thermostat is keeping the radiator at your desired temperature.
Assembly instructions
The heater is packaged with the feet unattached. The feet must be attached before
operating the heater.
WARNING: Do not operate without feet attached. Operate the heater in an upright
position only (feet on the bottom, controls on the top). Any other position could
create a hazardous situation.
1 Fit the Castors to the support bars using the dome nuts to create the foot.
2 Turn the radiator upside-down on a scratch-free and stable surface to prevent
damage to the paint finish or the floor.
3 Fit the two feet to the radiator by placing the U bolts between the outermost
fins on each side of the radiator.
4 Securely fasten the two feet to the radiator by screwing the two wing nuts to
each U bolt. Do not over tighten, as this may cause damage to the radiator.
Once turned to the upright position, allow the oil to settle and wait for at least half
an hour before using.
4
1 2 3 4
Switch = Low Heat
Switch = Medium Heat
Both Switches = High Heat
What’s in the box
• Radiator
• 4 x castors
• 2 x support bars
• Instruction manual

98
This model is also fitted with a 24hr timer which has been spilt into 96 segments
around its dial, each segment is the equivalent to 15 minutes of time.
TIMER OPERATION
The heater has 3 operational modes.
Timer mode - in this central position the timer will switch the heater on and off
at times set by the user (see setting the timer below).
Continuous mode - this allows the heater to be turned on continuously
bypassing the timer.
Off - in the position the timer continues to run but no power will be fed to
the heater.
Timer
SETTING THE TIMER
1 Set the heater to Timer mode (clock symbol).
2 Rotate the outer ring of the timer in a clockwise direction
until the current time is lined up with the arrow,
i.e. if the timer being set is 8pm, rotate the outer ring until
the number 20 is in line with the arrow.
3 To set the timer schedule, pull the segments outwards
toward the outer ring for ON and pull inwards for OFF.
4 When setting, the heater will operate each day during
the times programmed.
NOTE: The heater must always be plugged into a power socket, the element
switches must be in the ON position and the thermostat must be suitably set to
ensure the heater will come on.
NOTE: When using timer mode, due consideration should be given to the fact that
the heater may come on whilst unattended.
Cleaning and maintenance
• Before cleaning always switch off the radiator and remove the plug from the
electrical socket.
• Ensure that the unit is cool enough to work on.
• To remove the dust, wipe the appliance with a dry cloth.
• Never use abrasive powders or solvents.
• If the heater shows any signs of wear or damage disconnect immediately from
the mains supply, DO NOT use it - have it checked by a suitably qualified person.
WARNING:
Do not immerse any electrical part of the appliance in water such as motor
units or plugs. Please see cleaning section for further instructions.
Spares
Accessories and spare parts for your product can be found at www.pifco.com

1110
Model: PH0129-9T
Heat output Type of heat input for electric storage,
local space heaters only (select one)
Auxiliary electricity
consumption
Type of heat output/room
temperature control (select one)
Other control options (multiple selections possible)
Item
Nominal
heat output
Minimum heat
output (indicative)
Maximum continuous
heat output
At nominal
heat output
At minimum
heat output
In standby mode
Symbol
Pnom
Pmin
Pmax, c
elmax
elmin
elSB
Item
Manual heat charge
with integrated thermostat
Manual heat charge control with room
and/or outdoor temperature feedback
Electronic heat charge control with room
and/or outdoor temperature feedback
Fan assisted heat output
Single stage heat output
and no room temperature control
Two or more manual stages,
no room temperature control
With mechanic thermostat room
temperature control
With electronic room temperature
control
Electronic room temperature control plus
day timer
Electronic room temperature control plus
week timer
Room temperature control with presence
detection
Room temperature control
with open window detection
With distance control option
With adaptive start control
With working time limitation
With black bulb sensor
Contact details: PIFCO, 5 Wadsworth Rd, Perivale, Middlesex, UB6 7JD
Unit
No
No
No
No
Yes
No
No
No
No
No
No
No
No
Yes
No
No
Unit
kW
kW
kW
kW
kW
kW
Valve
2.0
N/A
0.8
N/A
2.0
0
WASTE ELECTRICAL RECYCLING:
This symbol indicates the product is classed as Electrical or Electronic
Equipment and should not be disposed of with other household waste.
The Waste Electrical and Electronic (WEEE) Directive
has been introduced across the EU:
• To recycle waste electrical products using the best available recovery
and recycling techniques.
• To minimise the impact to on the environment
• To treat any hazardous substances
• To avoid increasing landfill
WEEE product should be disposed of by handing it over at a designated
collection point. For more information about where to drop off your waste
product for recycling please contact you local authority.
Technical details
Model: PH0129-9T
Dimensions: H54.5cm x W24cm x D41.5cm
Power: 800W / 1200W / 2000W
Weight: 7.35 KG
Country of origin: China
Sabichi Homewares Ltd
5 Wadsworth Road, Perivale
Middlesex, UB6 7JD

1312
Warranty
This product is guaranteed for 1 year from the date of original purchase.
If the product fails within this period due to faulty materials or workmanship,
it will be repaired, replaced or refunded at our discretion.
Proof of purchase will be required.
This warranty applies only to:
• Product installed and used in accordance with the instructions contained
in this manual.
• Product used for domestic purposes only.
• Product purchased in the UK and Ireland.
This warranty does not cover:
• Cosmetic damage.
• Normal wear and tear or consumable parts.
• Incorrect voltage supply or power surges.
• Customer misuse, modifications or adjustments.
• Products with unreadable or removed serial numbers.
PIFCO disclaims any liability for incidental or consequential loss or damages.
In the event of a problem please contact our customer support team for assistance.
When contacting PIFCO please provide:
• Product model number. Model can be found on the product rating label.
• Date of purchase.
• Complete description of the problem.
This information will help our team assist you more quickly.
Help Line: 01909 544 570
Opening Hours: Monday - Friday, 9am – 5pm
Email: [email protected]

www.pifco.com
