Pifco P42001 Mounting instructions

MODEL P42001
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
1200W
HALOGEN HEATER
This product is only suitable for well insulated spaces or occasional use.
www.pifco.co

2
CUSTOMER SUPPORT TEAM: [phone]
TECHNICAL DATA
Description: Halogen Heater
Model: P42001
Rated Voltage: 220 - 240V
Frequency: ~ 50Hz
Power consumption: 1200W
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
RK Wholesale LTD Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.

3
www.pifco.co
WARNING:
This Appliance MUST be Earthed
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the mains lead of this appliance
may not correspond with the coloured markings
identifying the terminals in your plug, please
proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable). The
wire labelled blue is the neutral and must be
connected to the terminal marked [N].
The wire labelled brown is the live wire and must
be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the letter
[E].
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it o of the mains lead
and immediately dispose of it in a safe manner.
Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of an electric
shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neutral
(Blue)
Live
(Brown)

4
CUSTOMER SUPPORT TEAM: [phone]
HIGH VOLTAGE HOT SURFACE DO NOT COVER
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• If the supply cord or appliance
is damaged, stop using
the appliance immediately
and seek advice from the
manufacturer, its service
agent or a similarly qualied
person.
• DO NOT let the cord hang
over the edge of a table or
counter or let it come into
contact with any hot surfaces.
• DO NOT carry the appliance
by the power cord.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer
apart from those supplied
with this product. DO NOT
use extension cords with the
appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• Switch o at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• Switch o and unplug before
tting or removing tools/
attachments, after use and
before cleaning.
• Close supervision is
necessary when any
appliance is used by or near
children.
• Children should not play with
the appliance.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Take care when any appliance
is used near pets.
• DO NOT use this product
for anything other than its
intended use.
• This appliance is for
household use only.

5
www.pifco.co
• Please ensure that the
appliance is used on a stable,
level, and heat resistant
surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• This appliance is for
household use only.
• DO NOT use the appliance
outdoors.
• DO NOT carry the appliance
by the power cord.
• Always ensure that the heater
is placed on a rm level
surface.
• Ensure that the heater is not
positioned close to curtains,
furniture or any combustible
materials as this could create
a re hazard.
• The heater must not be
located immediately below a
mains socket outlet.
• DO NOT cover the heater as
this may lead to a re risk.
• DO NOT obstruct any of the
openings of the heater.
• DO NOT insert any object
through any openings on the
heater.
• Check from time to time for
accumulated dust.
• DO NOT use the heater
in areas where ammable
liquids are stored or where
ammable fumes may be
present.
• DO NOT operate the heater
on a timer, or leave on
overnight.
• When not being used, please
unplug the heater from the
mains socket.
• Keep the mains lead away
from the hot body of the
heater and ensure that it is
not pulled tight between the
socket and the heater.
• DO NOT use the heater in the
immediate surroundings of a
bath, a shower, a swimming
pool or similar indoor
locations.
• Always unplug the heater
and allow it to cool before
moving it from one location to
another.
• DO NOT attempt to dismantle
or repair any part of the
heater. This should only be
done by a qualied service
agent.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.

6
CUSTOMER SUPPORT TEAM: [phone]
2
3
1
WHAT’S IN THE BOX
Instruction Manual
Halogen Heater
1. Control Panel
2. Halogen Heating Elements
3. Oscillating Base
BEFORE FIRST USE:
1. Remove your appliance from the packaging.
2. Assemble the appliance as described opposite.
3. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.

7
www.pifco.co
ASSEMBLY
Assemble the body frame and the base plate
together as follows:
1. Remove the buttery nuts from the lower
part of the body frame.
2. Insert the power cord through the slot
placed in the middle part of the base and
then assemble the body frame to the base
plate.
3. Secure the body frame to the base plate
by means of the two buttery nuts (which
were previously removed).
4. Insert the power cord through the suitable
slots and then x it by the clamp.
USING YOUR APPLIANCE
1. Place the heater on a at, stable surface,
away from combustible materials, e.g.
curtains, furnishings etc.
2. Unwind the power cord and plug the
heater into a mains outlet and switch on.
3. Select appropriate switch for 1 to 3
elements. Press the oscillation (TURN)
switch to make the heater sweep from
side to side for wider heat distribution.
4. When you are nished using the heater
switch o the all elements.
5. Allow the heater to fully cool and unplug
from the mains supply before carrying or
cleaning
TILT SWITCH
The heater is equipped with a safety tilt switch.
This will switch the heater o if it tips over.
CLEANING AND CARE
• Be sure to switch o power supply at
the wall socket and disconnect the plug
before commencing cleaning.
• Wait for the heater to cool down fully
before commencing cleaning.
• Clean the grilles from dust.
• ONLY clean the body of the heater with a
damp cloth.
• DO NOT ALLOW water into the appliance.
• Never use soap or chemicals which may
damage the housing of the heater.
• Allow sucient drying time before
operating again.
• When the unit is not in use we
recommend that the heater is re-packed
in its original packaging and stored in a
cool, dry place.
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER SUCH AS
MOTOR UNITS OR PLUGS.
PLEASE SEE CLEANING SECTION FOR
FURTHER INSTRUCTIONS.

8
CUSTOMER SUPPORT TEAM: [phone]
Model Identier(s): P42001
Item Symbol Valve Unit Item Unit
Heat Output Type of heat input for electric storage, local space
heaters only (select one)
Nominal heat
output Pnom 1,2 kW Manual heat charge with integrated thermostat N/A
Minimum heat
output (indicative) Pmin 0 kW Manual heat charge control with room and/or outdoor temperature feedback N/A
Maximum
continuous heat
output
Pmax, c 1,2 kW Electronic heat charge control with room
and/or outdoor temperature feedback N/A
Auxiliary electricity
consumption Fan assisted heat output N/A
At nominal heat
output elmax N/A kW Type of heat output/room temperature control (select one)
At minimum heat
output elmin N/A kW Single stage heat output and no room temperature control No
In standby mode eISB N/A kW Two or more manual stages, no room
temperature control No
With mechanic thermostat room temperature
control Yes
With electronic room temperature control No
Electronic room temperature control plus day
timer No
Electronic room temperature control plus
week timer No
Other control options (multiple selections possible)
Room temperature control with presence
detection No
Room temperature control with open
window detection No
With distance control option No
With adaptive start control No
With working time limitation No
With black bulb sensor No
Contact Details: Imported by RK Wholesale LTD., Berryhill Road, Stoke-on-Trent ST4 2NL

9
www.pifco.co
NOTES

10
CUSTOMER SUPPORT TEAM: [phone]
NOTES

11
www.pifco.co
NOTES

0519.V7
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are oering you an extra 2 year peace of mind.
*To receive your extra guarantee period, register your appliance online
within 28 days of purchase by visiting:
www.pifco.co
Make sure to retain your original receipt.
Need help?
For advice, spares and returns.
Call:[phone]
8.30am to 6.00pm Monday-Friday
Visit: www.pifco.co
Distributed throughout the UK by RK Wholesale LTD
