PCTV Dual Sat Pro PCI
Hardware

PCTV Dual Sat Pro PCI Hardware
GB February 2006
© Pinnacle Systems GmbH 2006
All rights reserved.
No part of this manual may be reproduced or transferred to other media without
explicit written permission from Pinnacle Systems GmbH, Braunschweig,
Germany.
All brand or product names are trademarks or registered trademarks of their
respective holders.
This manual was printed on chlorine-free bleached paper using solvent-free ink.
Pinnacle Systems GmbH has written this manual to the best of its knowledge,
but does not guarantee that the programs/systems will fulfill the users’ intended
applications.
The feature descriptions are not to be understood as a warranty.
Pinnacle Systems GmbH retains the right to make alterations to the contents of
this manual without obligation to inform third parties.
All quotes, sales, supply and manufacturing contracts from Pinnacle Systems
GmbH, including consulting, installation and other contractual services are
subject exclusively to the General Sales and Delivery Terms of Pinnacle
Systems GmbH.
Disposal and Recycling
Do not dispose of electric components in the garbage. Either return defective or
unwanted devices to the retailer or take them to an appropriate recycling station!

Table of Contents
Introduction...........................................................................................................1
Box Contents.........................................................................................................2
System Requirements............................................................................................3
Computer Hardware...........................................................................................3
Computer Software............................................................................................3
For Your Own Safety............................................................................................4
Hardware Installation............................................................................................5
Preparing for Installation...................................................................................5
PCTV Dual Sat Pro PCI Hardware Installation.................................................6
After Installation................................................................................................6
Connections...........................................................................................................7
Technical Data.......................................................................................................8
Bus System.........................................................................................................8
LNB Input..........................................................................................................8
Tuner..................................................................................................................8
Demodulator ......................................................................................................8
TV Format..........................................................................................................8
DiSEqC ..............................................................................................................8
LNB Feed...........................................................................................................8

1
Introduction
Congratulations on your purchase of PCTV Dual Sat Pro PCI!
From your PC you can receive TV, radio and data signals via satellite (DVB-S)
with your PCTV Dual Sat Pro PCI:
Because PCTV Dual Sat Pro PCI has a digital satellite tuner which allows
reception via a digital satellite system (satellite dish and universal LNB) of any
decoded TV and radio stations using the DVB-S standard.
Together with Pinnacle MediaCenter software, PCTV Dual Sat Pro PCI not only
offers you live TV and radio but also timeshift TV and radio, as well as quality
program recording to your hard disk and DVD recorder.
You also get access to the free information services, teletext and the electronic
program guide (EPG). These services allow simple and easy access to the
desired information at any time, as well as scheduling of the shows you wish to
record.
And now have fun with your PCTV Dual Sat Pro PCI!

Box Contents
PCTV Dual Sat Pro PCI
Installation CD
Remote control with batteries and receiver cable
(images are samples)
Quick Install Guide
PDF files on CD-ROM: user manual,
hardware operating instructions,
remote control operating
instructions
Depending on the version of your product, package contents may vary.
2

3
System Requirements
Your system must fulfill the following requirements if you want to guarantee
proper PCTV Dual Sat Pro PCI function:
Computer Hardware
Processor
Minimum: Pentium IV with 2 GHz or equivalent AMD Athlon XP
(SD only)
Recommended: Pentium IV with 2.8 GHz or equivalent AMD Athlon 64
(SD and HD)
Working Memory
Minimum: 256 MB RAM
Recommended: 512 MB RAM
Hard Disk
Minimum: IDE hard disk with master mode drivers and 5 GB free disk space
Recommended: U-DMA hard disk with 20 GB free disk space
Graphics Card
Minimum: DirectX8 compatible graphics card
Recommended: DirectX9 (or higher) compatible graphics card
Sound Card
Minimum: DirectX9 compatible sound card
Expansion Slot
PCI 2.3 compatible expansion slot
CD-ROM / DVD-ROM Drive or Recorder
Minimum: CD-ROM or DVD-ROM drive
Recommended: CD or DVD recorder
Computer Software
Windows XP (Home, Professional or Media Center Edition 2005) with the latest
service pack

For Your Own Safety
If you purchased your PCTV Dual Sat Pro PCI together with a PC and it is
already installed, skip the next few sections and continue with the section
"Connecting the Equipment".
In the interest of your own safety and the flawless functioning of your new
PCTV Dual Sat Pro PCI and computer system, note the following before
installing any hardware:
Computer components are sensitive to static charge. Divert any electrostatic
charge from your body before touching the components with your hands or
any tools.
Before opening the computer, make sure that the power plug is disconnected
from the wall outlet.
4

Hardware Installation
Preparing for Installation
You will need a screwdriver to install your hardware.
Divert any possible electrostatic charge from your body by touching the
casing of your PC.
Turn off your computer and all peripheral devices. Disconnect computer
from the power supply and all necessary components.
Loosen the computer cover screws and remove the cover.
Select a free (busmaster) PCI slot. Remove the slot cover on the back panel
of the computer. Make sure to keep the screws in a safe place.
5

PCTV Dual Sat Pro PCI Hardware Installation
Insert the card into the available PCI slot. Hold it firmly on the upper edge
and ease it down into the slot by applying even pressure at both ends. Press
down on the upper edge until the card fits securely in the slot.
If you cannot easily insert the card into the slot, do not use force because this
can bend and damage the contact springs on the socket connector. Instead,
remove the card and try to insert it again.
After Installation
After you have inserted the hardware, tighten the card retaining bracket
firmly on the back of the computer.
Now place the cover back onto your computer and reconnect the peripherals
and the power supply.
6

Connections
Audio-Ausgang
(zur Soundkarte)
For auto wake-up
(
internal
,
o
p
tional
)
F
7
ernbedienungs-
mpfängee r
An
Ein
mi
v
A
E
mi
tennen-
gang 2
t LNB 2
erbinden
ntennen-
ingang 1
t LNB 1
verbinden
Connect
antenna
input 1
with LNB 1
Connect
antenna
input 2
with LNB 2 Remote control
receive
r

8
Technical Data
Bus System
PCI
LNB Input
2 x 75 Ohm, F connector
Tuner
2 x Zarlink ZL 10037
Demodulator
2 x Zarlink ZL 10313
TV Format
DVB-S
DiSEqC
DiSEqC 1.1
LNB Feed
13 V / 18 V, maximum 350 mW

Konformitätserklärung nach ISO/IEC 17050-1
Declaration of conformity in accordance with
ISO/IEC 17050-1
Nr. / No 1.00
Anbieter / Supplier : Pinnacle Systems GmbH
Anschrift / Address : Frankfurter Strasse 3c
38122 Braunschweig, Germany
Produkt / Product : PCTV 4000i
Das oben beschriebene Produkt ist konform mit: / The product described above
is in conformity with:
Dokument-Nr.
Document No. Titel Title
EN 55013 : 2002
Funkstöreigenschaften von Rundfunkempfängern und verwandten Geräten der Unterhaltungselektronik
Limits and methods of measurement of radio disturbance characteristics of broadcast receivers and
associated equipment
EN 55020 : 2003 Störfestigkeit von Rundfunkempfängern und verwandten Geräten der Unterhaltungselektronik
Electromagnetic immunity of broadcast receivers and associated equipment
EN 61000-4-2 : 2001
Störfestigkeit gegen Entladung statischer Elektrizität
Electrostatic discharge immunity test
EN 61000-4-3 : 2001
Störfestigkeit gegen hochfrequente elektromagnetische Felder
Radiated, radio-frequency, electromagnetic field immunity test
EN 61000-4-4 : 2002 Störfestigkeit gegen schnelle transiente elektrische Störgrößen/BURST
Electrical fast transient/burst immunity test
EN 61000-4-5 : 2001 Störfestigkeit gegen Stoßspannungen/SURGE
Surge immunity test
EN 61000-4-6 : 2001 Störfestigkeit gegen leitungsgeführte Störgrößen, induziert durch hochfrequente Felder
Immunity to conducted disturbances, induced by radio-frequency fields
EN 61000-4-8 : 2001 Störfestigkeit gegen Magnetfelder mit energietechnischen Frequenzen
Power frequency magnetic field immunity test
EN 61000-4-11 : 2001 Störfestigkeit gegen Spannungseinbrüche, Kurzzeitunterbrechungen und Spannungsschwankungen
Voltage dips, short interruptions and voltage variations immunity tests
EN 61000-3-2 : 2001
Grenzwerte für Oberschwingungsströme
Limitations for harmonic currents
EN 61000-3-3 : 2002 Grenzwerte für Spannungsschwankungen und Flicker
Limitations of voltage fluctuations and flicker
EN 60950 : 2001 Sicherheit von Einrichtungen der Informationstechnik
Safety of information technology equipment
Dieser Erklärung liegt zugrunde: Prüfbericht(e) des EMV-Prüflabors
This certification is based on: Test report(s) generated by EMI-test laboratory
Braunschweig, 15. Februar 2006 / February 15th, 2006
......................................... .................................................
Dr. Alexander Roy Jörg Tewes
Director Hardware Engineering VP Engineering
(Rechtsverbindliche Unterschrift / Legally Binding)
