MicroburstTM Center/Surround Ensemble
MB5000
Owner’s Manual
2004 PINNACLE LOUDSPEAKERS

We appreciate your choosing Pinnacle’s Microburst speakers for use in your Home
Theater & audio system. These unique speakers will provide you with surprisingly
powerful and satisfying sound from a stylish & compact package. Please read this
manualcompletelytoensurethebestpossible performance from yourHomeTheater or
sound system.
SPEAKER PROTECTION:
One special feature of the Microburst speakers is an overload protection circuit
designed to help protect the speaker from accidental overload. This protection circuit
will automatically attenuate the overall output of a speaker when it senses excessive
volume level. If you hear this protection circuit engaging, (and it will be obvious when
this occurs), please turn down your receiver’s volume. Your speaker will quickly return
to its normal operation.
CONNECTIONS:
Complete all wire connections in your Home Theater/Sound system before powering
up your receiver. Be sure to observe proper polarity for all speaker wire connections:
receiver PLUS (red terminal) to speaker PLUS, receiver MINUS (black terminal) to
speaker minus.For the best results, we recommend 12, 14 or 16 gauge wire; consult
your dealer for options.
To connect your speaker wire to your speaker's binding posts, twist the bare wire
strands together tightly, then insert through the hole which becomes visible when the
knurled knob is screwed counterclockwise. The wire must then be secured by
screwing the knob back clockwise until snug. Remember, loose strands of wire may
cause short circuits. Upon completion, gently tug at all connections to ensure they are
fastened securely and re-check for correct polarity.
LIMITED TRANSFERABLE WARRANTY
WHAT IS COVERED: All Pinnacle Microburst speakers are covered by this warranty
for a period of seven (7) years from the date of the original purchase. The warranty
covers all necessary parts and labor to return the speaker to proper working order.
Cabinet surfaces, grille assembly, and other exterior parts subject to normal wear and
tear are not covered except where an inherent structural defect becomes evident.
Parts replacement and labor will be performed at the discretion of the company
(Pinnacle Loudspeakers) and will be provided free of charge unless (in the opinion of
our service department, service representatives, or engineering department) the
speaker system has failed due to abuse or negligent operation. Any latent defect
attributable to error in manufacture will always be covered by this warranty.
WHAT IS NOT COVERED:This warranty will be void and no free services performed
if we or any party acting as our agent determines that the speaker system in question
has had any of its loudspeaker elements (woofer, midrange, tweeter, etc.) or internal
circuitry removed or tampered with in any way whatsoever without express prior
authorization from Pinnacle. Furthermore, if the speaker system is not found to be
defective a service charge will be levied. In either case the minimum charge will be
$30.00. An additional charge will be applicable for same day service if requested
(subject to feasibility). This charge will always be in effect even if the actual parts and
labor are covered by this warranty. Any damage caused to the speaker system from
improper use is not covered by warranty. Pinnacle Loudspeakers reserves the right
to make the final determination of whether or not a particular speaker system has
been damaged by abuse or excessive overload.
TO OBTAIN SERVICE: To obtain service under this warranty, either contact your
Pinnacle dealer or us directly at [phone] or [email protected].
You may also write us at 1 Fairchild Court, Suite 140, Plainview, NY 11803. If you
ship your speakers you are responsible for packing and shipping insurance. The
freight must be prepaid. We will, however, pay return freight charges on any returned
speaker that qualifies for in-warranty service. Sorry, we cannot accept any collect
freight charges. You must include a note, attached to the unit, with your name, phone
number or email address, and return shipping address (no Post Office boxes),
indicating the nature of the problem you are experiencing. For warranty service you
must also include a copy of your sales receipt. If the speaker returned to us or our
agents for service proves not eligible for warranty repairs or is not found to be
defective, then you will have to pay return freight charges. Please be sure to pack any
items you ship us carefully since we cannot be held responsible for damages incurred
during shipping. This warranty may be transferred to a subsequent owner, but will not
be in effect for a period greater than seven (7) years from the date of the original
purchase. SAVE THIS CERTIFICATE AND YOUR SALES RECEIPT. YOU MAY
NEED THEM TO OBTAIN SERVICE UNDER THE PROVISIONS OF THIS LIMITED
WARRANTY.

HOME THEATER SETUP: (4 MB2000 Satellites, 1 MB3000 Center)
All Microburst Satellite Speakers are identical. You may choose any one for front or
rear positions.
•Connect your left & right main speakers to your receiver's left & right main (front
speaker) outputs. Connect your left & right surround speakers to your receiver’s
left & right surround (rear speaker) outputs.
•Connect your center speaker to your receiver’s center channel speaker output.
VERY IMPORTANT!
Be sure your receiver’s center, main & surround channel modes are all set to SMALL
(NORMAL). This will allow for the greatest bass impact from your system.
RECOMMENDED MAIN AND CENTER SPEAKER PLACEMENT:
•The best distance between the main speakers is dependent upon room
conditions, size, and the proximity of the listening area to the speakers; usually 6-
12 feet is appropriate. A bit of experimentation is in order, but smaller rooms will
better tolerate closer spacing between the speakers.
•We recommend you place your center speaker horizontally on top of (or just
below) your TV.
RECOMMENDED SURROUND SPEAKER PLACEMENT:
Behind you, equally spaced to your left and right, facing towards the front of the room.
One general rule of thumb: try to position speakers so that the tweeter's level is fairly
close to your ear level in your normal listening position. High frequencies are much
more directional than lows so it is best that your ears are within a fairly direct path to
the tweeter's output.
After completing all connections, turn the system on, then GRADUALLY increase the
volume level. If there is no sound, distorted sound, or if the amplifier shuts itself down
after a few seconds, IMMEDIATELY TURN THE VOLUME DOWN and turn the
system off. Then re-check your wiring for accuracy and for possible shorts at the
connecting terminals (adjacent bare wires touching each other). When everything
sounds fine, keep the volume reasonably low while you familiarize yourself with your
system's various controls and operations modes.

WALL-MOUNTING:
1) There is an insert on the back of your Microburst speaker which will allow it to attach
to a standard (1/4” shaft) pivoting wall mount bracket. Contact your dealer for further
details. Follow the bracket manufacturer’s mounting instructions.
2) A flush, wall mounting option is also available using the keyhole on the back of the
speaker. The instructions below are written for rooms of standard construction, which
include most residential and business office environments. Such environments are
typically constructed with wooden studs behind the walls that will securely accept the
enclosed screws. If you cannot or do not want to mount into a stud, use the enclosed
wall anchors or consult with your local hardware store for your best mounting options.
Tools Required:
#2 Philips head screwdriver bit or hand screwdriver
Drill (electric or cordless)
1/8" bit (or 1/4” if not mounting into a stud)
Stud Finder
INSTRUCTIONS:
1) Determine where you want to mount your speaker and then, using the stud
finder, find the closest stud. If this location is not acceptable you will need to use
the enclosed wall anchors to mount the speaker where there is no stud.
2) Mark a spot on the wall at the desired mounting location.
3) If mounting into a stud: Drill a 2" deep pilot hole with an 1/8” bit at the marked spot.
Screw the mounting screw into the hole.
4) If not mounting into a stud: Drill a 2” deep pilot hole with a 1/4” bit at the marked
spot. Insert a wall anchor into the hole until it is flush with the wall (this may require
gently tapping it with a hammer), then screw the mounting screw directly into it.
5) Be sure the screw is inserted straight (perpendicular with wall and parallel with
floor). Leave the screw sticking out from the wall ~3/8”.
6) Hang the speaker on the screw head.
That’s it. Enjoy!
MB2000 & MB3000 SPECIFICATIONS:
Features:
Nylon reinforced cabinetry
Hardware in place for wall mounting
Gold plated binding posts
Automatic Overload Protection Circuit
Video Shielded
7 Year Transferable Warranty on parts & labor
Designed in the USA
System Type:
MB2000 Satellite: 2-Way, 2 element, Acoustic Suspension
MB3000 Center: 2-Way, 3 element, Acoustic Suspension
MB2000 Satellite Component Drivers:
1" liquid cooled Mylar dome tweeter
3" polymer cone woofers with butyl surrounds
MB3000 Center Component Drivers:
1" liquid cooled Mylar dome tweeter
(2) 3" polymer cone woofers with butyl surrounds
Frequency Response: 120 -20 kHz (+/-3 dB)
Crossover Frequency: 4 kHz
System Power: 200 Watts
Sensitivity: 88 dB @ 1 Watt / 1 Meter (2.83 Volts Pink Noise)
Nominal Impedance: 8 Ohms
Dimensions:
MB2000 Satellite: 3 7/8" Wide x 6 3/4" High x 4 1/8" Deep (with grill)
MB3000 Center: 10 1/4" Wide x 4" High x 4" Deep (with grill)
Cabinet Construction: Structurally reinforced nylon / plastic extrusion
Weight:
MB2000 Satellite: 5 lbs. per pair
MB3000 Center: 4 lbs. each
