Pioneer AVH-P6800DVD - DVD Changer With LCD Monitor User manual

Operation Manual
AV Receiver/6-Disc Changer with 7 inch Wide Display
AVH-P6800DVD
English

Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, keep this man-
ual in a safe place for future reference.
Be sure to read this
!Playable discs 8
!DVD video disc region numbers 9
!When an operation is prohibited 13
Precautions
IMPORTANT SAFEGUARDS 6
To ensure safe driving 6
To avoid battery exhaustion 7
Before You Start
Information to User 8
For Canadian model 8
About this unit 8
About this manual 9
After-sales service for Pioneer products 9
Product registration 10
Features 10
About WMA 11
About the SAT RADIO READY mark 12
To protect the LCD screen 12
For viewing LCD comfortably 12
What the marks on DVDs indicate 12
Resetting the microprocessor 13
About the demo mode 13
Use and care of the remote control 14
Customising your system
Connecting with separately sold Pioneer
products 15
Using multi-channel processor 15
Using iPod 15
Using a Pioneer navigation unit 15
Using the AVG-VDP1 (Pioneer Vehicle
Dynamics Processor) 16
Using the rear display 16
Using Bluetooth wireless technology 16
What’s What
Head unit 17
Remote control 18
Basic Operations
Turning the unit on and selecting a
source 21
Loading/Ejecting discs 22
Adjusting the flap angle 23
Adjusting the volume 23
Turning the unit off 23
Touch panel key basic operation 24
Tuner
Listening to the radio 26
Storing and recalling broadcast
frequencies 27
Introduction of advanced tuner
operation 27
Storing the strongest broadcast
frequencies 27
Tuning in strong signals 28
Playing DVD video discs
Watching a DVD video 29
Operating the DVD menu 30
Skipping back or forward to another title 30
Stopping playback 30
Pausing DVD video playback 30
Resume playback (Bookmark) 31
Frame-by-frame playback 31
Slow motion playback 31
Searching for a desired scene, starting
playback from a specified time 32
Changing audio language during playback
(Multi-audio) 32
Changing the subtitle language during
playback (Multi-subtitle) 33
Changing the viewing angle during playback
(Multi-angle) 33
Contents
En
2

Return to the specified scene 34
Automatic playback of DVDs 34
Introduction of advanced DVD video
operation 34
Repeating play 34
Selecting audio output 35
Playing Video CDs
Watching a Video CD 36
Stopping playback 37
Pausing Video CD playback 37
Frame-by-frame playback 37
Slow motion playback 37
Searching for a desired scene, starting
playback from a specified time 38
PBC playback 38
Introduction of advanced Video CD
operation 39
Repeating play 39
Selecting audio output 39
Playing CDs
Listening to a CD 40
Stopping playback 41
Pausing CD playback 41
Using CD TEXT functions 41
Introduction of advanced CD operation 42
Repeating play 42
Playing tracks in random order 42
Scanning tracks of a CD 42
Playing MP3/WMA
Listening to MP3/WMA 43
Stopping playback 44
Pausing MP3/WMA playback 44
Displaying information on MP3/WMA
file 45
Introduction of advanced built-in DVD player
(MP3/WMA) operation 46
Repeating play 46
Playing tracks in random order 46
Scanning folders and tracks 47
Multi-CD Player
Listening to a CD 48
Pausing CD playback 49
Using CD TEXT functions 49
50-disc multi-CD player 49
Introduction of advanced multi-CD player
operation 50
Repeating play 50
Playing tracks in random order 50
Scanning CDs and tracks 51
Using ITS playlists 51
Using compression and bass emphasis 52
XM tuner (GEX-P920XM)
Listening to XM Satellite Radio 53
Switching the XM channel select mode 54
Switching between the detail information
display and preset list display 54
Storing and recalling broadcast stations 54
Selecting a channel 54
Using the MyMix function 55
Displaying the Radio ID 56
XM tuner (GEX-P910XM)
Listening to XM Satellite Radio 57
Switching the XM display 58
Storing and recalling broadcast stations 58
Switching the XM channel select mode 58
Selecting a channel directly 58
Displaying the Radio ID 58
SIRIUS Satellite Radio tuner
Listening to SIRIUS Satellite Radio 59
Selecting the SIRIUS channel select
mode 60
Selecting a channel 60
Switching the display 60
En 3
Contents

Switching between the detail information
display and preset list display 61
Storing and recalling broadcast stations 61
Using the MyMix function 61
Using the Game Alert function 63
Displaying the Radio ID 64
TV tuner
Watching the television 65
Storing and recalling broadcast stations 66
Introduction of advanced TV tuner
operation 66
Storing the strongest broadcast stations
sequentially 67
Playing songs on iPod
Listening to songs on your iPod 68
Browsing for a song 68
Pausing a song 69
Displaying text information on iPod 69
Displaying information on song 69
Repeating play 69
Playing songs in a random order
(shuffle) 70
Bluetooth Audio
Listening to songs on BT Audio (Bluetooth
audio player) 71
Connecting a Bluetooth audio player 72
Playing songs on Bluetooth audio player 72
Disconnecting a Bluetooth audio player 73
Displaying BD (Bluetooth Device)
address 73
Bluetooth Telephone
Hands-free phoning with cellular phones
featuring Bluetooth wireless
technology 74
Setting up for hands-free phoning 75
Basic operation of hands-free phoning 75
Introduction of advanced hands-free phoning
operation 76
Connecting a cellular phone 76
Disconnecting a cellular phone 77
Registering connected cellular phone 77
Deleting a registered phone 78
Connecting to a registered cellular
phone 78
Using the Phone Book 78
Using the Call History 80
Using preset numbers 81
Making a call by entering phone number 82
Clearing memory 82
Setting the automatic answering 82
Setting the automatic rejecting 82
Switching the ring tone 82
Echo canceling and noise reduction 83
Displaying BD (Bluetooth Device)
address 83
Audio Adjustments
Introduction of audio adjustments 84
Using balance adjustment 84
Using the equalizer 85
Adjusting loudness 86
Using subwoofer output 86
Using nonfading output 86
Using the high pass filter 87
Adjusting source levels 87
Staging for car environment 87
Digital Signal Processor
Introduction of DSP adjustments 89
Using the position selector 89
Using balance adjustment 90
Adjusting source levels 90
Using the dynamic range control 91
Using the down-mix function 91
Using the direct control 91
Contents
En
4

Using the Dolby Pro Logic II 91
Setting the speaker setting 92
Adjusting the speaker output levels 93
Selecting a cross-over frequency 94
Adjusting the speaker output levels using a
test tone 94
Using the time alignment 95
Using the equalizer 96
Using the auto-equalizer 98
Auto TA and EQ (auto-time alignment and
auto-equalizing) 98
Setup
Introduction of setup adjustments 101
Setting the AV input 101
Setting for rear view camera (back up
camera) 101
Setting the clock 102
Selecting video on rear display 102
DVD Setup
Introduction of DVD setup adjustments 103
Setting the subtitle language 103
Setting the audio language 104
Setting the menu language 104
Switching the assist subtitle on or off 104
Setting the angle icon display 104
Setting the aspect ratio 105
Setting the parental lock 105
Initial Setup
Adjusting initial settings 107
Switching the auxiliary setting 107
Setting the rear output and subwoofer
controller 107
Switching the sound muting/
attenuation 108
Mixing navigation voice/AVG-VDP1 beep and
audio sound 108
Correcting distorted sound 109
Changing languages for CAUTION 109
Resetting the audio functions 109
Entering PIN code for Bluetooth wireless
connection 109
Extending the vehicle’s antenna 110
Other Functions
Adjusting the screen 111
Selecting the background display 112
Adjusting the response positions of the
touch panels (Touch Panel
Calibration) 113
Displaying the navigation image 113
Displaying the AVG-VDP1 (Pioneer Vehicle
Dynamics Processor) 114
Using the AUX source 114
Setting remote control code type 115
Using the preprogrammed function 115
Additional Information
Troubleshooting 117
Error messages 119
Understanding auto TA and EQ error
messages 119
DVD player and care 121
DVD discs 121
CD-R/CD-RW discs 121
Dual Discs 122
MP3 and WMA files 122
About folders and MP3/WMA files 124
Using the display correctly 124
Language code chart for DVD 126
Terms 127
Specifications 130
Index 132
En 5
Contents

IMPORTANT SAFEGUARDS
Please read all of these instructions regarding
your display and retain them for future refer-
ence.
1Read this manual fully and carefully be-
fore operating your display.
2Keep this manual handy as a reference for
operating procedures and safety informa-
tion.
3Pay close attention to all warnings in this
manual and follow the instructions care-
fully.
4Do not allow other persons to use this sys-
tem until they have read and understood
the operating instructions.
5Do not install the display where it may (i)
obstruct the driver’s vision, (ii) impair the
performance of any of the vehicle’s oper-
ating systems or safety features, includ-
ing air bags, hazard lamp buttons or (iii)
impair the driver’s ability to safely oper-
ate the vehicle.
6Do not operate this display if doing so in
any way will divert your attention from
the safe operation of your vehicle. Always
observe safe driving rules and follow all
existing traffic regulations. If you experi-
ence difficulty in operating the system or
reading the display, park your vehicle in a
safe location and make necessary adjust-
ments.
7Please remember to wear your seat belt at
all times while operating your vehicle. If
you are ever in an accident, your injuries
can be considerably more severe if your
seat belt is not properly buckled.
8Never use headphones while driving.
9To promote safety, certain functions are
disabled unless the parking brake is on,
and the vehicle is not in motion.
10 Never set the volume of your display so
high that you cannot hear outside traffic
and emergency vehicles.
WARNING
!Do not attempt to install or service your
display by yourself. Installation or servi-
cing of the display by persons without
training and experience in electronic
equipment and automotive accessories
may be dangerous and could expose you
to the risk of electric shock or other
hazards.
To ensure safe driving
WARNING
!LIGHT GREEN LEAD AT POWER CON-
NECTOR IS DESIGNED TO DETECT
PARKED STATUS AND MUST BE CON-
NECTED TO THE POWER SUPPLY SIDE
OF THE PARKING BRAKE SWITCH. IM-
PROPER CONNECTION OR USE OF
THIS LEAD MAY VIOLATE APPLICABLE
LAW AND MAY RESULT IN SERIOUS IN-
JURY OR DAMAGE.
!To avoid the risk of damage and injury and the
potential violation of applicable laws, this unit
is not for use with a video screen that is visible
to the driver.
!To avoid the risk of accident and the potential
violation of applicable laws, the front DVD or
TV (sold separately) feature should never be
used while the vehicle is being driven. Also,
rear displays should not be in a location
where it is a visible distraction to the driver.
!In some countries or states the viewing of
images on a display inside a vehicle even by
persons other than the driver may be illegal.
Where such regulations apply, they must be
obeyed and this unit’s DVD features should
not be used.
Precautions
En
6
Section
01

When you attempt to watch a DVD, Video CD
or TV while driving, the warning VIDEO VIEW-
ING IS NOT AVAILABLE WHILE DRIVING will
appear on the front display.
To watch a DVD, Video CD or TV on the front
display, park your vehicle in a safe place and
apply the parking brake.
Parking brake interlock
Certain functions (DVD/TV viewing and certain
touch panel keys) offered by this unit could be
dangerous and/or unlawful if used while driv-
ing. To prevent such functions from being
used while the vehicle is in motion, there is an
interlock system that senses when the parking
brake is set. If you attempt to use the functions
described above while driving, they will be-
come disabled until you stop the vehicle in a
safe place, and (1) apply the parking brake, (2)
release the parking brake, and then (3) apply
the parking brake again. Please keep the
brake pedal pushed down before releasing the
parking brake.
To avoid battery exhaustion
Be sure to run the vehicle engine while using
this unit. Using this unit without running the
engine can result in battery drainage.
WARNING
Do not use with vehicles that do not feature an
ACC position.
Precautions
En 7
Section
01
Precautions

Information to User
Alteration or modifications carried out without
appropriate authorization may invalidate the
user’s right to operate the equipment.
For Canadian model
This Class B digital apparatus complies with
Canadian ICES-003.
About this unit
The tuner frequencies on this unit are allo-
cated for use in North America. Use in other
areas may result in poor reception.
WARNING:
Handling the cord on this product or cords asso-
ciated with accessories sold with the product
may expose you to chemicals listed on proposi-
tion 65 known to the State of California and other
governmental entities to cause cancer and birth
defects or other reproductive harm. Wash hands
after handling.
This product contains mercury. Disposal of this
material may be regulated due to environmental
considerations. For disposal or recycling informa-
tion, please contact your local authorities or the
Electronics Industries Alliance: www.eiae.org.
CAUTION:
USE OF CONTROL OR ADJUSTMENT OR
PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE.
CAUTION:
THE USE OF OPTICAL INSTRUMENTS
WITH THIS PRODUCT WILL INCREASE
EYE HAZARD.
CAUTION
!Do not allow this unit to come into contact
with liquids. Electrical shock could result.
Also, this unit damage, smoke, and overheat
could result from contact with liquids.
!Keep this manual handy as a reference for op-
erating procedures and precautions.
!Always keep the volume low enough so that
you can hear sounds from outside the vehicle.
!Protect this unit from moisture.
!If the battery is disconnected or discharged,
the preset memory will be erased and must be
reprogrammed.
Important (Serial number)
The serial number is located on the bottom of
this unit. For your own security and convenience,
be sure to record this number on the enclosed
warranty card.
Playable discs
DVD, Video CD and CD discs that display the
logos shown below can be played back on this
player.
Before You Start
En
8
Section
02

DVD video
Video CD
CD
Notes
!is a trademark of DVD Format/Logo Li-
censing Corporation.
!This player can only play back discs bearing
the marks shown above.
DVD video disc region numbers
DVD video discs that have incompatible region
numbers cannot be played on this player. The
region number of the player can be found on
the bottom of this unit.
The illustration below shows the regions and
corresponding region numbers.
About this manual
This unit features a number of sophisticated
functions ensuring superior reception and op-
eration. All the functions have been designed
for the easiest possible use, but many are not
self-explanatory. This operation manual will
help you benefit fully from this unit’s potential
and to maximize your listening enjoyment.
We recommend that you familiarize yourself
with the functions and their operation by read-
ing through the manual before you begin
using this unit. It is especially important that
you read and observe WARNINGs and CAU-
TIONs in this manual.
After-sales service for
Pioneer products
Please contact the dealer or distributor from
where you purchased this unit for after-sales
service (including warranty conditions) or any
other information. In case the necessary infor-
mation is not available, please contact the
companies listed below:
Please do not ship your unit to the companies
at the addresses listed below for repair without
advance contact.
Before You Start
En 9
Section
02
Before You Start

U.S.A.
Pioneer Electronics (USA) Inc.
CUSTOMER SUPPORT DIVISION
P.O. Box 1760
Long Beach, CA 90801-1760
800-421-1404
CANADA
Pioneer Electronics of Canada, Inc.
CUSTOMER SATISFACTION DEPARTMENT
300 Allstate Parkway
Markham, Ontario L3R OP2
1-877-283-5901
For warranty information please see the Lim-
ited Warranty sheet included with this unit.
Product registration
Visit us at the following site:
1 Register your product. We will keep the details
of your purchase on file to help you refer to
this information in the event of an insurance
claim such as loss or theft.
2 Receive updates on the latest products and
technologies.
3 Download owner’s manuals, order product
catalogues, research new products, and
much more.
Features
Touch panel key operation
It is possible to operate this unit by using
touch panel key.
DVD video playback
It is possible to play back DVD video and DVD-
R/RW (video mode).
Remember that use of this system for com-
mercial or public viewing purposes may con-
stitute an infringement on the author’s rights
protected by the Copyright Law.
Video CDs featuring PBC compatibility
It is possible to play back Video CDs featuring
PBC (playback control).
CD playback
Music CD/CD-R/RW playback is possible.
MP3 file playback
You can play back MP3 files recorded on CD-
ROM/CD-R/CD-RW (ISO9660 Level 1/Level 2
standard recordings).
!Supply of this product only conveys a li-
cense for private, non-commercial use and
does not convey a license nor imply any
right to use this product in any commercial
(i.e. revenue-generating) real time broad-
casting (terrestrial, satellite, cable and/or
any other media), broadcasting/streaming
via internet, intranets and/or other net-
works or in other electronic content distri-
bution systems, such as pay-audio or
audio-on-demand applications. An inde-
pendent license for such use is required.
For details, please visit
http://www.mp3licensing.com.
WMA file playback
You can play back WMA files recorded on CD-
ROM/CD-R/CD-RW (ISO9660 Level 1/Level 2
standard recordings).
NTSC compatibility
This unit is NTSC system compatible. When
connecting other components to this unit, be
sure components are compatible with the
same video system otherwise images will not
be correctly reproduced.
Before You Start
En
10
Section
02

Multi-aspect
Switching between wide screen, letterbox and
panscan display is possible.
Multi-audio
You can switch between multiple audio sys-
tems recorded on a DVD as desired.
Multi-subtitle
You can switch between multiple subtitle lan-
guages recorded on a DVD as desired.
Multi-angle
You can switch between multiple viewing an-
gles of a scene recorded on a DVD as desired.
Hands-free phoning
Using Bluetooth adapter (e.g. CD-BTB100),
this unit realizes effortless hands-free phoning
with Bluetooth wireless technology.
Bluetooth audio player compatibility
Using Bluetooth adapter (e.g. CD-BTB100),
you can control Bluetooth audio player featur-
ing Bluetooth wireless technology.
iPod®compatibility
When you use this unit with a Pioneer iPod
adapter (CD-IB100B) (sold separately), you can
control an iPod with Dock Connector.
!iPod is a trademark of Apple Computer,
Inc., registered in the U.S. and other coun-
tries.
Note
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual prop-
erty rights owned by Macrovision Corporation
and other rights owners. Use of this copyright
protection technology must be authorized by
Macrovision Corporation, and is intended for
home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is
prohibited.
About WMA
The Windows Media™logo printed on the box
indicates that this unit can play back WMA
data.
WMA is short for Windows Media Audio and
refers to an audio compression technology
that is developed by Microsoft Corporation.
WMA data can be encoded by using Windows
Media Player version 7 or later.
Windows Media and the Windows logo are tra-
demarks or registered trademarks of Microsoft
Corporation in the United States and/or other
countries.
Notes
!This unit may not operate correctly depending
on the application used to encode WMA files.
!Depending on the version of Windows Media
Player used to encode WMA files, album
names and other text information may not be
correctly displayed.
Before You Start
En 11
Section
02
Before You Start

About the SAT RADIO
READY mark
The SAT RADIO READY mark printed above
the CD loading slot indicates that the Satellite
Radio Tuner for Pioneer (i.e., XM tuner and Sir-
ius satellite tuner which are sold separately)
can be controlled by this unit. Please inquire
to your dealer or nearest authorized Pioneer
service station regarding the satellite radio
tuner that can be connected to this unit. For
satellite radio tuner operation, please refer to
the satellite radio tuner owner’s manual.
Notes
!The system will use direct satellite-to-receiver
broadcasting technology to provide listeners
in their cars and at home with crystal-clear
sound seamlessly from coast to coast. Satel-
lite radio will create and package over 100
channels of digital-quality music, news,
sports, talk and children’s programming.
!“SAT Radio”, the SAT Radio logo and all re-
lated marks are trademarks of Sirius Satellite
Radio inc., and XM Satellite Radio Inc.
To protect the LCD screen
!Do not allow direct sunlight to fall on the
display when this unit is not being used.
Extended exposure to direct sunlight can
result in LCD screen malfunction due to
the resulting high temperatures.
!When using a cellular phone, keep the an-
tenna of the cellular phone away from the
display to prevent disruption of the video by
the appearance of spots, colored stripes,
etc.
!Never touch the screen with anything be-
sides your finger when operating the touch
panel function. The screen can scratch
easily.
For viewing LCD comfortably
Due to its construction, the viewing angle of
the LCD screen is limited. You can adjust it by
changing either screen size or picture adjust-
ment.
Changing the wide screen size
By changing the screen size from 4:3 to 16:9,
you can adjust the screen so that the screen
can fit to the video image you are playing.
For details concerning operation, refer to
Changing the wide screen mode on page 111.
Changing the picture adjustment
You can make the best adjustment to the pic-
ture display by changing BRIGHT,CONTRAST,
COLOR and HUE. You can also dim or enlight
the overall picture image using DIMMER.
For details concerning operation, refer to
Changing the picture adjustment on page
111.
What the marks on DVDs
indicate
The marks below may be found on DVD disc
labels and packages. They indicate the type of
images and audio recorded on the disc, and
the functions you can use.
Before You Start
En
12
Section
02

Mark Meaning
2Indicates the number of audio sys-
tems.
2Indicates the number of subtitle lan-
guages.
3Indicates the number of viewing an-
gles.
16 : 9 LB Indicates the picture size (aspect ratio:
screen width-to-height ratio) type.
1
ALL
Indicates the number of the region
where playback is possible.
When an operation is prohibited
When you are watching a DVD and attempt to
perform an operation, it may not be performed
because of the programming on the disc.
When this happens, the icon appears on
the screen.
!The icon may not appear with certain
discs.
Resetting the microprocessor
Pressing RESET lets you reset the micropro-
cessor to its initial settings.
The microprocessor must be reset under the
following conditions:
!Prior to using this unit for the first time
after installation
!If the unit fails to operate properly
!When strange or incorrect messages ap-
pear on the display
1 Turn the ignition switch OFF.
2 Press RESET with a pen tip or other
pointed instrument.
RESET button
Notes
!When using with navigation unit or AVG-
VDP1, if you press RESET, be sure ACC OFF is
selected. If ACC ON is selected, correct opera-
tion may not be possible even if you press
RESET.
!After completing connections or when you
want to erase all memorized settings or return
the unit to its initial (factory) settings, switch
your engine ON or set the ignition switch to
ACC ON before pressing RESET.
About the demo mode
Important
The red lead (ACC) of this unit should be con-
nected to a terminal coupled with ignition switch
on/off operations. If this is not done, the vehicle
battery may be drained.
Before You Start
En 13
Section
02
Before You Start

The feature demo automatically starts when
you select the source OFF. The demo con-
tinues while the ignition switch is set to ACC
or ON. To cancel the feature demo, press and
hold ENTERTAINMENT (ENT). To restart the
feature demo, press and hold
ENTERTAINMENT (ENT) again. Remember
that if the feature demo continues operating
when the car engine is turned off, it may drain
battery power.
Use and care of the remote
control
Installing the battery
Slide the tray out on the back of the remote
control and insert the battery with the plus (+)
and minus (–) poles pointing in the proper di-
rection.
!When using for the first time, pull out the
film protruding from the tray.
WARNING
Keep the battery out of the reach of children.
Should the battery be swallowed, immediately
consult a doctor.
CAUTION
!Use only one CR2025 (3 V) lithium battery.
!Remove the battery if the remote control is not
used for a month or longer.
!Do not recharge, disassemble, heat or dispose
of the battery in fire.
!Do not handle the battery with metallic tools.
!Do not store the battery with metallic materi-
als.
!In the event of battery leakage, wipe the re-
mote control completely clean and install a
new battery.
!When disposing of used batteries, please
comply with governmental regulations or en-
vironmental public institutions’rules that
apply in your country/area.
Using the remote control
Point the remote control in the direction of the
front panel to operate.
!The remote control may not function prop-
erly in direct sunlight.
Important
!Do not store the remote control in high tem-
peratures or direct sunlight.
!Do not let the remote control fall onto the
floor, where it may become jammed under the
brake or accelerator pedal.
Before You Start
En
14
Section
02

Connecting with separately
sold Pioneer products
Connecting with other Pioneer products, you
can create the best audio-visual environment
for enjoying music and movie in car. This sec-
tion describes available options that can be con-
trolled by this unit.
Using multi-channel processor
When using this unit with a Pioneer multi-
channel processor, you can enjoy the atmo-
sphere and excitement provided by DVD movie
and music software featuring 5.1 channel re-
cordings.
For details concerning operation, refer to Intro-
duction of DSP adjustments on page 89.
!Manufactured under license from Dolby La-
boratories. “Dolby”,“Pro Logic”, and the
double-D symbol are trademarks of Dolby
Laboratories.
!“DTS”and “DTS Digital Surround”are regis-
tered trademarks of Digital Theater Sys-
tems, Inc.
Using iPod
When you use this unit with a Pioneer iPod
adapter (CD-IB100B) (sold separately), you can
control an iPod with Dock Connector.
For details concerning operation, refer to Play-
ing songs on iPod on page 68.
!iPod is a trademark of Apple Computer,
Inc., registered in the U.S. and other coun-
tries.
!iPod adapter supports only an iPod with
Dock Connector.
Using a Pioneer navigation
unit
When you use this unit with the Pioneer DVD
navigation unit, make sure that you use the
map disc CNDV-30 or later. This manual ex-
plains the operations with the combined use
of them.
If you do not use the map disc CNDV-30 but
use an older version with the navigation unit,
this unit may have some failures or inconve-
niences as follows:
!ENTERTAINMENT (ENT) button and WIDE
button cannot function as V.D.P. MENU
button and POS button.
!NAVI (navigation unit), such as DVD video
from the combined Pioneer navigation unit
with DVD video playback, cannot be se-
lected as a source.
!In NAVI MIX, the settings other than ALL
cannot be selected.
!Voice-recognition control system of the
combined Pioneer navigation unit may not
function properly with this unit. The voice
operation for navigation can be used, but
the voice operation related to AV equip-
ment cannot be used.
!Route guidance of the combined Pioneer
navigation unit may not function properly
when some other source images are dis-
played. Guidance by voice can be obtained,
but on guidance by display (e.g. switching
to an enlarged map of an intersection) can-
not be obtained.
Customising your
system
En 15
Section
03
Customising your system

Using the AVG-VDP1 (Pioneer
Vehicle Dynamics Processor)
This unit can be used as the display unit for
the AVG-VDP1 (sold separately) product.
Using the rear display
Combining this unit with a rear display (sold
separately), you can display the selected
source on the rear display so passengers in
rear seats can comfortably view the same
image with the front or they can watch the dif-
ferent image (i.e. image from AVG-VDP1) inde-
pendently.
For details concerning operation, refer to Se-
lecting video on rear display on page 102.
!When a Pioneer Vehicle Dynamics Proces-
sor (AVG-VDP1) is connected to this unit,
the AVG-VDP1 can be displayed on the rear
display. (Refer to page 102.)
Important
NEVER install the rear display in a location that
enables the driver to watch the DVD or TV while
driving.
Using Bluetooth wireless
technology
Playing a Bluetooth audio
player using with Bluetooth
adapter (e.g. CD-BTB100)
If you connect Bluetooth adapter (e.g. CD-
BTB100) to this unit, you can control Blue-
tooth audio player via Bluetooth wireless tech-
nology.
For details concerning operation, refer to Blue-
tooth Audio on page 71.
!Even though your audio player does not
contain a Bluetooth wireless technology
module, you can still control it using a
Bluetooth adapter sold on the market.
Hands-free phoning using with
Bluetooth adapter (e.g. CD-BTB100)
If you use Bluetooth adapter (e.g. CD-BTB100),
you can connect a cellular phone featuring
Bluetooth wireless technology to this unit for
hands-free, wireless calls, even while driving.
For details concerning hands-free phoning op-
eration, refer to Hands-free phoning with cellu-
lar phones featuring Bluetooth wireless
technology on page 74.
Customising your
system
En
16
Section
03

Head unit
1BAND button
Press to select among three FM bands and
one AM band and to cancel the control
mode of functions.
2RESET button
Press to return to the factory settings (initial
settings).
3Signal receptor
Receives signals from a remote control.
4c/dbuttons
Press to do manual seek tuning, fast for-
ward, reverse and track search controls.
5VOLUME
Press to increase or decrease the volume.
6SOURCE button
This unit is turned on by selecting a source.
Press to cycle through all the available
sources.
7ENTERTAINMENT (ENT) button
Press to display the entertainment menu.
8WIDE button
Press to select a desired mode for enlarging
a 4:3 picture to a 16:9 one.
9V.ADJ button
Press and hold to display the picture adjust-
ment menu.
aOPEN button
Press to slide down or up the LCD panel.
What’s What
En 17
Section
04
What’s What

Remote control
Button names AVH mode DVD mode with remote control
code AVH
1
Remote control
selection
switch
Switch to change the setting of the remote control. For details, refer to Setting remote con-
trol code type on page 115.
2 SOURCE button Press to cycle through all the available sources. Press and hold to turn the source off.
3ATTbutton Press to quickly lower the volume level, by about 90%. Press once more to return to the ori-
ginal volume level.
4VOLUME but-
tons Press to increase or decrease the volume.
5
AUDIO button Press to change the audio language during DVD playback.
SUB TITLE but-
ton Press to change the subtitle language during DVD playback.
ANGLE button Press to change the viewing angle during DVD playback.
6 RETURN button Press to display the PBC (playback control) menu during PBC playback.
a
2
3
k
l
j
f
g
h
4
d
e
c
b
8
6
5
7
i
1
9
What’s What
En
18
Section
04

Button names AVH mode DVD mode with remote control
code AVH
7a/bbutton
(DISC)Press to select the next/previous disc.
8
Remote control
operation mode
switch
Switch the operation mode between AVH,DVD and TV modes. Normally, set to AVH.For
details, refer to Using the remote control operation mode switch on the next page.
9
BOOKMARK
button/PGM
button
Press to operate the preprogrammed functions
for each source. (Refer to Using the prepro-
grammed function on page 115.)
Press to turn the bookmark function on
or off. For details, refer to Resume play-
back (Bookmark) on page 31.
10 DIRECT button Press to do direct XM/SIRIUS channel select. Not used.
11 REAR.S button Not used.
12 DISPLAY but-
ton Press to select different displays. Not used.
13
ENTERTAIN-
MENT (ENT)
button
Press to display the entertainment menu. Not used.
14 0–10 buttons,
CLEAR button
Press 0–10 to input numbers. Buttons 1–6can
operate the preset tuning for the tuner or disc
changing for DVD player or multi-CD player.
Press CLEAR to clear the input numbers.
Press to select a menu on the DVD top
menu.
15 BACK button Press to return to the previous display. Not used.
16 BAND button
Press to select among three FM bands and one
AM band and to cancel the control mode of
functions.
Press to switch mode between MP3/WMA and
audio data (CD-DA) when playing discs with
MP3/WMA and audio data (CD-DA) such as CD-
EXTRA and MIXED-MODE CDs.
Press to switch mode between MP3/
WMA and audio data (CD-DA) when
playing discs with MP3/WMA and
audio data (CD-DA) such as CD-EXTRA
and MIXED-MODE CDs.
17
PLAY/PAUSE
(f) button Press to switch sequentially between playback and pause.
REVERSE (m)
button Press to perform fast reverse.
FORWARD
(n) button Press to perform fast forward.
PREVIOUS
(o) button Press to return to the previous track (chapter).
NEXT (p)
button Press to go to the next track (chapter).
STEP (r/q)
button
Press to move ahead one frame at a time during DVD/VideoCD playback. Press and hold
for one second to activate slow playback.
STOP (g) but-
ton Press to stop playback.
What’s What
En 19
Section
04
What’s What

Button names AVH mode DVD mode with remote control
code AVH
18 AUTO PLAY
button Press to turn the DVD auto-playback function on or off.
19 a/bbutton
(FOLDER)Press to select the next/previous folder.
20 Joystick Move to do fast forward, reverse and track search
controls. Click to recall MENU.
Move to select a menu on the DVD
menu.
21
MENU button Press to display the DVD menu during DVD playback.
TOP MENU
(TOP.M) button Press to return to the top menu during DVD playback.
Using the remote control
operation mode switch
There are three remote control operation
modes on the remote control.
AVH mode operation
When operating this unit by remote control,
the mode is normally switched to AVH.
!The joystick on the remote control can per-
form the same operations as the one on
the head unit. Furthermore, the joystick
can perform the same operations as the
touch panel keys a,b,cand d.
!1–6can perform the same operations as
the preset tuning keys P1—P6 and the disc
selection keys 01–06.
—If you want to select a disc located at 7
to 12 by using buttons 1–6, press and
hold the corresponding numbers, such
as 1for disc 7, until the disc number ap-
pears in the display.
DVD mode operation
If you switch the mode to DVD, the joystick
and 0–10 operations are changed for DVD
player.
%When you want to operate the follow-
ing functions, switch the mode to DVD:
!When operating the DVD menu by using
the joystick. (Refer to Operating the DVD
menu on page 30.)
!When operating the PBC menu by using
0–10. (Refer to Watching a Video CD on
page 36.)
!When specifying title by using 0–10. (Refer
to Specifying title on page 32.)
TV mode operation
TV operations available with a Pioneer TV tuner
(e.g. GEX-P5700TV) can be controled with AVH
mode. TV mode is not used with this unit.
!For details concerning operation, refer to
the TV tuner’s operation manuals.
What’s What
En
20
Section
04
