Piranha 900217 User manual

Piranha Dirt Tame
r
12V Rechargeable
Wet / Dry Vacuum Cleaner
USER MANUAL
ITEM: 900217

IMPORTANT SAFEGUARDS
When using an electric appliance, basic precautions should always be followed, including the
following:
READ ALL INSTRUCTIONS BEFORE USING THIS RECHARGEABLE VACUUM
To reduce the risk of fire, electric shock, or injury:
¾This product is designed for domestic use only.
¾Do not charge this unit outdoors.
¾Close attention is necessary when used near children, pets or plants.
¾This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for their
safety.
¾Children should be supervised to ensure that they do not play with the appliance
¾Do not use with damaged cord or plug. If unit is not working as it should, has been dropped,
damaged, left outdoors, or immersed into water, return it to the distributor before continuing use.
If the charger cord is damaged, it must be replaced by the manufacturer or a similarly qualified
person to avoid a hazard.
¾Do not pull or carry by cord, use cord as a handle, close a door on the cord, or pull cord around
sharp edges or corners.
¾To disconnect charger from outlet, do not pull from cord, instead grasp the charger and pull.
¾Keep cord away from heated surfaces.
¾Do not use extension cords or outlets with inadequate current carrying capacity.
¾Do not handle plug or appliance with wet hands or attempt to vacuum liquids.
¾Do not insert any objects into openings. Do not use with any opening blocked. Keep free of dust,
lint, hair and anything that may reduce the airflow.
¾Do not vacuum over anything that is burning or smoking, such as cigarettes, matches or hot
ashes.
¾Do not attempt to change accessories while unit is running.
¾This product includes rechargeable batteries. Do not incinerate batteries or expose to high
temperatures, as they may explode.
¾Leaks from battery cells can occur under extreme conditions. If leaking occurs do not touch
battery and cease use immediately. Contact your distributor for further instructions.
¾Do not remove batteries from unit, unless disposing of the appliance.
¾Batteries must be recycled or disposed of properly.
¾Charge battery with original charger only.
¾Store your vacuum indoors in a cool, dry area.
¾Keep your work area well lighted.
¾Use only as described in this manual. Use only manufacturer’s recommended accessories.
SAVE THESE INSTRUCTIONS

DESCRIPTION
USEFUL TIPS
•While charging, ensure that the indicator light is on.
•Before being used for the first time, the appliance should be charged for 10 hours in order to
guarantee full vacuuming power.
•The appliance may be left on the charging base without any risk. The charger will heat up
slightly this is quite normal. However, it is preferable to disconnect the charger from the power
supplier if the unit is unattended for a long period of time (eg. whilst on holidays)
•Check the condition of the filter regularly, and ensure that it is firmly in place. If the appliance
loses suction power or makes an abnormal noise, check that the vacuum inlet is not blocked or
that the permanent washable filter is not blocked or full.
•In cases of abnormal operation, such as motor over heating. Stop
the appliance to correct the problem (e.g. blockages in the vacuum
inlet or accessory). If vacuumed dust falls on the floor, check to see if
the filter is full.
BATTERY CHARGING PROCEDURE
1. Plug the charging Base into a 240V/50Hz electric outlet.
2. IMPORTANT :
Make sure that the On/Off Switch is turned to the “Off”
Position before charging. Otherwise, your vacuum will
not charge.
3. Slide the vacuum downward onto the charging base making sure that
the vacuum firmly hooks onto the charging base (see figure B). Your
vacuum will begin charging and the Green LED light on the charge
Indicator will glow to show charging is taking place. If your Piranha Dirt
Tamer is completely out of power, a full recharge will take
approximately 10 Hours.

NOTE : before first use, charge your vacuum for at least 24 hours.
4. To maintain a charge, keep the Charger plugged into a standard wall outlet at all times. When
charging, the Charger may be warm to the touch. This is normal.
CHARGE AND LOW BATTERY INDICATORS
Unique LED Lights monitor the power condition of your Piranha
Dirt Tamer.
Green Light Only:
Indicates that the vacuum is charging or “On” and operating at
an acceptable level of power.
Red Light Only:
The Red light will illuminate when your vacuum is almost out of
power and needs to be recharge.
CLEANING TOOLS
Your Piranha Dirt Tamer Vacuum includes the following unique
cleaning tools that will make your cleaning tasks easier.
1. SQUEEGE
This tool has rubber edges for picking up liquid spills on
hard surfaces such as floors, bench tops, etc. Attach the
Squeegee to your vacuum by pushing the tool firmly into the Bowl Nozzle.
2. EXTENDIBLE WAND/CREVICE TOOL
This “two in one” tool works great as a long reach cleaning wand or crevice tool. To use as a long
reach cleaning wand, simply extend the tool by pooling each end of the tool in opposite
directions (the tool will expend like an accordion) and insert the larger end into the Bowl Nozzle.
The wand is then ready to clean hard to reach areas (e.g. ceiling corners, under appliances. etc).
To use as crevice tool: simply compress tool to your desired length and insert the larger end of
the tool into the Bowl Nozzle. The crevice tool is than ready to use in tight places such as
between car seats, in corners, etc.

3. UPHOLSTERY BRUSH
This tool is used for picking up dirt and dust debris from upholstery, tables, etc. Attach the
upholstery brush to your vacuum by pushing the tool firmly into the Bowl Nozzle with the brush
facing down.
DIRT FINDING HEADLIGHT
Your Piranha Dirt Tamer vacuum is equipped with a unique Dirt Finding Headlight which allows you to
easily see dirt and dust under furniture or in dark corners. The Headlight will operate when the vacuum is
switched “On”.
REPLACEMENT LAMP FOR HEADLIGHT
The lamp in your Piranha Dirt Tamer Headlight will last for years of normal household use.
LAMP REPLACEMENT INSTRUCTION
1. Insert the tip of a flat head screwdriver into the slot at the front of
the lamp and twist to remove the lamp cartridge.
2. Remove the used lamp cartridge with your fingers.
3. Insert a new replacement lamp cartridge.

HOW TO USE
Remove the vacuum from the charging base and slide the On/Off Switch to the “On” position to operate.
Slide the On/Off switch to the “Off” position between cleaning tasks to conserve power.
PICKING UP DRY DEBRIS
Use your vacuum for picking up dirt, dust, food crumbs, etc. from counters, bare floors, rugs, car interiors,
upholstered furniture, etc. After dry pickup, empty and clean the Bowl and Foam filter before picking up
liquid or wet spills.
NOTE: If using HEPA Filter in place of Foam filter, shake loose or brush off any dust or debris from the
HEPAfilter if you notice any build up.
DO NOT WASH OR RINSE THE HEPA FILTER, as this may damage the HEPA material.
If the HEPA Filter accidently gets wet from vacuuming wet spills, remove the HEPA Filter and dry it
thoroughly before reinstalling it back into the vacuum.
PICKING UP LIQUIDS OR WET DEBRIS
Use your vacuum to pick up liquids or wet debris. For ideal performance, we recommend the use of the
foam filter for liquid debris.
1. For Liquids pickup, insert the squeegee into the Bowl Nozzle and pull
the Squeegee through the liquid.
2. Do not fill the Bowl beyond the end of the Pre Filter (Before the Motor
Filter). If there is any liquid in the Bowl, Hold the Bowl Nozzle Down to
avoid leakage. Tipping the Bowl Nozzle Up may cause the liquid to
enter the motor fan are.
3. After Picking up perishable spills (e.g. Milk, Juice, etc.) empty your
vacuum’s Bowl and Pre Filter immediately and thoroughly clean the
Bowl, Pre Filter, Filter Cover and Foam Filter to prevent mold and
mildew from forming.
MAINTANANCE
EMPTYING/CLEANING PRE-FILTER AND BOWL
Liquids, dirt and debris (Wet and Dry) picked up by your vacuum will
collect in the Pre-Filter and Bowl. To empty/clean these parts please
follow these steps:
a. Holding the Bowl with one hand and the Handle/Housing with the
other, depress the Bowl Latch and swing the bowl away from the
Handle/Housing.
b. While Holding the Bowl in one hand, remove the Pre-Filter with
your other hand by grasping the pull tab on top of the Pre-Filter
with your fingers. Empty any dirt, debris, or liquid from the Bowl
and Pre-Filter into the sink or wastebasket.
c. Rinse or hand wash the Pre-Filter, Bowl and Filter Cover with
Water (if needed, with warm soapy water).
NOTE: The Pre-Filter, Bowl and Filter Cover can be washed in the
Dishwasher (top rack only
d. Allow the Pre-Filter, Bowl and Filter Cover to dry before reinstalling them back into the vacuum.

MAINTANACE / FILTER REPLACEMENT
CLEANING/REPLACING FOAM AND HEPA FILTERS
To remove/replace the filter (either foam or HEPA) from the vacuum, please
follow these steps:
a. Remove the Filter cover from the vacuum handle/housing.
b. Remove the Filter from the vacuum handle/housing.
Clean the Filter as follows:
Foam Filter Cleaning:
Wash the Foam Filter in warm, soapy water until clean. Allow the Foam
Filter to dry before reinserting into the Handle/Housing.
NOTE: Use only mild soap. Avoid detergents, chemical cleaners or solvents
as these may damage the plastic.
HEPA Filter Cleaning:
Use your finger to lightly clean the paper surface of the HEPA Filter, clearing
off any dirt, dust and hair.
NOTE 1: Do not wash the HEPA Filter. Water will permanently damage the filter.
NOTE 2: Under normal household use, the HEPA Filter will last 6 – 12 months
c. Insert either side of the Clean Filter (or if necessary a new filter) into the Handle/Housing then
snap-on the Filter Cover and reattach the Bowl to the Handle/Housing (making sure that the
Pre-Filter is inserted into the Bowl).
NOTE: Filters should be replaced periodically to provide best performance or when the filter has
been damaged.
CLEANING THE VACUUM HOUSING
Clean the vacuum’s Handle/Housing with damp cloth. Never immerse the Handle/Housing in water.

GUARANTEE
WHAT’S COVERED
H. E. Group Pty Ltd guarantees Piranha Dirt Tamer 12V Cordless Hand Vacuum for a full replacement for
a period of 12 months from the date of purchase, which is only valid with the presentation of the original
proof of purchase receipt. This guarantee covers materials and workmanship defects only.
WHAT IS NOT COVERED
This guarantee does not apply to defects arising from abuse, alteration or unreasonable use of the
product. In addition, it does not cover general deterioration due to usage.
This guarantee does not apply to the accessories and due to general deterioration.
WHAT H. E. GROUP PTY LTD WILL DO
H. E. Group Pty Ltd will replace the product, if a defect is discovered whilst under the guaranteed
period, subject to verification of defect or malfunction, date and proof of purchase.
CUSTOMER CARE
All enquiries may be directed to our friendly customer service team on toll free number
1800 079 124 or via email [email protected]
