PLANET 5/8-Port 10/100/1000Mbps Industrial Gigabit Ethernet Switch
User's Manual
For Models: IGS-501 / IGS-801/ IGS-501T / IGS-801T
Revision: 1.0 (January, 2009)
Part No: EM-IGS-501_801_v1.0 (2350-AH0100-000)

Table Of Contents
1. INTRODUCTION ........................................................................ 6
1.1 Package Contents ............................................................... 6
1.2 How to Use This Manual ..................................................... 6
1.3 Product Features................................................................. 7
1.4 Product Specications ......................................................... 8
2. INSTALLATION .........................................................................10
2.1 Product Description ............................................................10
2.1.1 Product Overview ......................................................11
2.1.2 Switch Front Panel ....................................................11
2.1.3 LED Indicators ..........................................................12
2.1.4 Switch Upper Panel ...................................................13
2.1.5 Wiring the Power Inputs ............................................13
2.1.6 Wiring the Fault Alarm Contact...................................14
2.2 Mounting Installation..........................................................15
2.2.1 DIN-Rail mounting.....................................................15
2.2.2 Wall Mount Plate Mounting.........................................17
3. APPLICAITON ...........................................................................18
4. SWITCH OPERATION.................................................................20
4.1 Address Table....................................................................20
4.2 Learning ...........................................................................20
4.3 Forwarding & Filtering ........................................................20
4.4 Store-and-Forward .............................................................21

4.5 Auto-Negotiation................................................................21
5. TROUBLESHOOTING .................................................................22
APPENDIX A: NETWORKING CONNECTION.......................................23
A.1 Switch’s RJ-45 Pin Assignments ...........................................23
A.2 RJ-45 cable Pin Assignments ...............................................24

6
1. INTRODUCTION
1.1 Package Contents
Check the contents of your package for following parts:
Industrial Gigabit Ethernet Switch x 1
User's manual x 1
DIN rail kit x 1
Wall mount kit x 1
If any of these are missing or damaged, please contact your dealer
immediately, if possible, retain the carton including the original packing
material, and use them against to repack the product in case there is a
need to return it to us for repair.
1.2 How to Use This Manual
This Industrial Gigabit Ethernet Switch User Manual is structured as
follows:
Chapter 2 Installation
The chapter explains the feature, functionality and the physical
installation of the Industrial Gigabit Ethernet Switch.
Chapter 3 Application
The chapter explains the Industrial Gigabit Ethernet Switch application.
Chapter 4 Switch operation
The chapter explains the Industrial Gigabit Ethernet Switch transmit
operation.
Chapter 5 Troubleshooting
The chapter explains the troubleshooting of the Industrial Gigabit
Ethernet Switch.
Appendix A
This chapter contains cable information of the Industrial Gigabit
Ethernet Switch.
l
l
l
l

7
1.3 Product Features
Physical Port
5-Port 10/100/1000Base-T RJ-45 with auto MDI/MDI-X function (IGS-
501 / IGS-501T)
8-Port 10/100/1000Base-T RJ-45 with auto MDI/MDI-X function (IGS-
801 / IGS-801T)
Layer 2 Features
Complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE
802.3ab 1000Base-T Ethernet standard
Supports Auto-negotiation and 10/100Mbps half / full duplex and
1000Mbps full duplex mode
High performance Store and Forward architecture, broadcast storm
control, runt/CRC ltering eliminates erroneous packets to optimize
the network bandwidth
Prevents packet loss with back pressure (Half-Duplex) and IEEE
802.3x PAUSE frame ow control (Full-Duplex)
Backplane (Switching Fabric): IGS-501 / IGS-501T: 10Gbps, IGS-801
/ IGS-801T: 16Gbps
Integrated address look-up engine, support 8K absolute MAC
addresses
136 kilobytes on-chip frame buffer on IGS-501 / IGS-501T
176 kilobytes on-chip frame buffer on IGS-801 / IGS-801T
9K Jumbo packet size support
Automatic address learning and address aging
CSMA/CD Protocol
Industrial Case / Installation
IP-30 Metal case / Protection
DIN Rail and Wall Mount Design
12 to 48V DC, redundant power with polarity reverse protect function
and connective removable terminal block for master and slave power
-10 to 60 Degree C operation temperature on IGT-501 / IGT-801
-40 to 75 Degree C operation temperature on IGT-501T / IGT-801T
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l

8
1.4 Product Specications
Model IGS-501 IGS-801
Hardware Specication
10/100/1000Base-T Ports 5 8
Dimensions (W x D x H) 135mm x 87mm x 32mm
Weight 455g 473g
Power Requirement 12~48 VDC, Redundant power with polarity
reverse protection function
Power Consumption /
Dissipation 11.9 Watts / 40BTU 13.2 Watts / 45BTU
Installation DIN rail kit and wall mount ear
Switch Specication
Switch Processing
Scheme Store-and-Forward
Address Table 8K entries
Buffer 136 kilobytes 176 kilobytes
Flow Control Back pressure for half duplex, IEEE 802.3x
Pause Frame for full duplex
Switch fabric 10Gbps 16Gbps
Throughput
(packet per second) 7.4Mpps 11.9Mpps
Jumbo Frame 9K
Network cables
10/100/1000Base-T:
Cat. 3, 4, 5, 5e, 6 UTP cable (100meters,
max.)
EIA/TIA-568 100-ohm STP (100meters,
max.)
Standards Conformance
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Full-duplex ow control
Temperature Operating: -10~60 Degree C
Storage: -10~60 Degree C
Humidity Operating Operating: 5% to 90%, Storage: 5% to
90% (Non-condensing)
Regulation Compliance FCC Part 15 Class A, CE

9
Model IGS-501T IGS-801T
Hardware Specication
10/100/1000Base-T Ports 5 8
Dimensions (W x D x H) 135mm x 87mm x 32mm
Weight 455g 473g
Power Requirement 12~48 VDC, Redundant power with polarity
reverse protection function
Power Consumption /
Dissipation 11.9 Watts / 40BTU 13.2 Watts / 45BTU
Installation DIN rail kit and wall mount ear
Switch Specication
Switch Processing
Scheme Store-and-Forward
Address Table 8K entries
Buffer 136 kilobytes 176 kilobytes
Flow Control Back pressure for half duplex, IEEE 802.3x
Pause Frame for full duplex
Switch fabric 10Gbps 16Gbps
Throughput (packet per
second) 7.4Mpps 11.9Mpps
Jumbo Frame 9K
Network cables
10/100/1000Base-T:
Cat. 3, 4, 5, 5e, 6 UTP cable (100meters,
max.)
EIA/TIA-568 100-ohm STP (100meters,
max.)
Standards Conformance
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Full-duplex ow control
Temperature Operating: -40~75 Degree C
Storage: -40~75 Degree C
Humidity Operating Operating: 5% to 90%, Storage: 5% to
90% (Non-condensing)
Regulation Compliance FCC Part 15 Class A, CE

10
2. INSTALLATION
This section describes the functionalities of the Industrial Gigabit
Ethernet Switch’s components and guides how to install it on the
desktop. Basic knowledge of networking is assumed. Please read this
chapter completely before continuing.
In the following section, the term “Industrial Gigabit Ethernet Switch”
means the IGT-501 / IGT-801 / IGT-501T / IGT-801T.
2.1 Product Description
The PLANET IGT-501 / IGT-801 / IGT-501T / IGT-801T is 5/8-Port
10/100/1000Mbps Industrial Gigabit Ethernet Switch with non-blocking
wire-speed performance and new slim type with IP 30 metal shape for
easily deployment in Heavy Industrial demanding environments.
With a 10/16Gbps internal switching fabric, the Industrial Gigabit
Ethernet Switch can handle extremely large amounts of data in a
secure topology linking to a backbone or high capacity servers.
The Industrial Gigabit Ethernet Switch has 8K MAC Address table and
offers wire-speed packets transfer performance without risk of packet
loss. The Gigabit ports with 9K jumbo packet support can handle
large amounts of data transmission in a secure topology linking to a
backbone or high-power servers. The high data throughput of the
device makes it ideal for most Gigabit environments.
All RJ-45 copper interfaces support 10/100/1000Mbps Auto-Negotiation
for optimal speed detection through RJ-45 Category 6, 5 or 5e cables.
Support standard for Auto-MDI/MDI-X that can detect the type of
connection to any Ethernet device without requiring special straight or
crossover cables.
The Flow Control function allows Industrial Gigabit Ethernet Switch
supported routers and Servers to directly connect to this device for
fast, reliable data transfer.

11
2.1.1 Product Overview
The PLANET Industrial Gigabit Ethernet Switch with 5/8 RJ-45
10/100/1000Mbps ports for high-speed network connectivity. The
Industrial Gigabit Ethernet Switch can also automatically identify and
determine the correct transmission speed and half / full duplex mode
of the attached devices with its 5/8 ports. The Gigabit port with 9K
jumbo frame feature supported, can handle extremely large amounts of
data transmission in a secure topology linking to a backbone or high-
power servers.
The Industrial Gigabit Ethernet Switch also supports Store-and-Forward
forwarding scheme to ensure low latency and high data integrity,
eliminates unnecessary trafc and relieves congestion on critical
network paths. With an intelligent address recognition algorithm, the
Industrial Gigabit Ethernet Switch could recognize up to 8K different
MAC address and enables ltering and forwarding at full wire speed.
2.1.2 Switch Front Panel
Figure 2-1 & 2-2 & 2-3 & 2-4 shows a front panel of Industrial Gigabit
Ethernet Switch.
Figure 2-1 IGS-501 front panel Figure 2-2 IGS-801 front panel

12
Figure 2-3 IGS-501T front panel Figure 2-4 IGS-801T front panel
2.1.3 LED Indicators
LED Color Function
P1 Green Lit: indicate the power 1 has power.
P2 Green Lit: indicate the power 2 has power.
FAULT Green Lit: indicate the either power 1 or power 2 has no
power.
1000 Green
Lit: indicate the Switch is successfully connecting to
the network at 1000Mbps.
Off: indicate that the Switch is successfully connecting
to the network at 10Mbps or 100Mbps.
Blink: indicate that the Switch is actively sending or
receiving data over that port.
100 Green
Lit: indicate the Switch is successfully connecting to
the network at 100Mbps or 10Mbps.
Off: indicate that the Switch is successfully connecting
to the network at 1000Mbps.
Blink: indicate that the Switch is actively sending or
receiving data over that port.

13
2.1.4 Switch Upper Panel
The upper panel of the Industrial Gigabit Ethernet Switch consist one
terminal block connector within two DC power inputs. Figure 2-5 shows
the upper panel of the switch.
Figure 2-5 shows upper panel of Industrial Gigabit Ethernet Switch.
Figure 2-5 Industrial Gigabit Ethernet Switch upper Panel.
2.1.5 Wiring the Power Inputs
The 6-contact terminal block connector on the top panel of Industrial
Gigabit Ethernet Switch is used for two DC redundant powers input.
Please follow the steps below to insert the power wire.
1. Insert positive / negative DC power wires into the contacts 1 and 2
for POWER 1, or 5 and 6 for POWER 2.
V1- V1 + V2 - V2 +

14
2. Tighten the wire-clamp screws for preventing the wires from loosing.
123456
Power 1 Fault Power 2
- + - +
Note
The wire gauge for the terminal block should be in the
range between 12 ~ 24 AWG.
2.1.6 Wiring the Fault Alarm Contact
The fault alarm contacts are in the middle of the terminal block
connector as the picture shows below. Inserting the wires, the Industrial
Gigabit Ethernet Switch will detect the fault status of the power failure,
or port link failure (available for managed model) and then forms an
open circuit. The following illustration shows an application example for
wiring the fault alarm contacts.
123456
Insert the wires into the fault alarm contacts
Note
1. The wire gauge for the terminal block should be in
the range between 12 ~ 24 AWG.
2. Alarm relay circuit accepts up to 30V, max. 3A
currents.

15
2.2 Mounting Installation
This section describes how to install the Industrial Gigabit Ethernet
Switch and make connections to it. Please read the following topics and
perform the procedures in the order being presented.
2.2.1 DIN-Rail mounting
The DIN-Rail is screwed on the Industrial Gigabit Ethernet Switch
when out of factory. When need to replace the wall mount application
with DIN-Rail application on Industrail Gigabit Ethernet, please refer
to following gures to screw the DIN-Rail on the Industrial Gigabit
Ethernet Switch. To hang the Industrial Gigabit Ethernet Switch, follow
the below steps:

16
Step 1: screw the DIN-Rail on the Industrial Gigabit Ethernet Switch.
Step 2: Lightly press the button of DIN-Rail into the track.
Step 3: Check the DIN-Rail is tightly on the track.
Step 4: Please refer to following procedures to remove the Industrial
Gigabit Ethernet Switch from the track.

17
Step 5: Lightly press the button of DIN-Rail for remove it from the
track.
2.2.2 Wall Mount Plate Mounting
To install the Industrial Gigabit Ethernet Switch on the wall, please
follows the instructions described below.
Step 1: Remove the DIN-Rail from the Industrial Gigabit Ethernet
Switch; loose the screws to remove the DIN-Rail.
Step 2: Place the wall mount plate on the rear panel of the Industrial
Gigabit Ethernet Switch.
Step 3: Use the screws to screw the wall mount plate on the
Industrial Gigabit Ethernet Switch.
Step 4: Use the hook holes at the corners of the wall mount plate to
hang the Industrial Gigabit Ethernet Switch on the wall.
Step 5: T
o remove the wall mount plate, reverse steps above.

18
3. APPLICAITON
In this paragraph, we will describe how to install Industrial Gigabit
Ethernet Switch and the installation points for the attention.
Data Collect Server
IGS-501 IGS-801T
IGS-801 IGS-501T
SGSW-24040
Human Management Interface
I/O
I/O
Distribute I/O
Control System
I/O
I/O
Field Automatic
Device
PC PC
Serial Device
Server
Field Automatic
Device
Field Automatic
Device
1000Base-T UTP
100Base-TX UTP
10/100/1000Base-T Ethernet
Cat5,6 UTP/STP Cable
ROBOT
Distribute I/O
Control System
I/O
I/O
Field Automatic
Device
I/O Devices
Robot
Installation Steps
Step 1: Unpack the Industrial Gigabit Ethernet Switch.
Step 2: Check the DIN-Rail is screwed on the Industrial Gigabit
Ethernet Switch. (Please refer to DIN-Rail Mounting section
for DIN-Rail installation If the DIN-Rail is not screwed on the
Industrial switch). If you want to wall mount the Industrial
Gigabit Ethernet Switch, then please refer to Wall Mount Plate
Mounting section for wall mount plate installation.

19
Step 3: To hang the Industrial Gigabit Ethernet Switch on the DIN-
Rail track or wall, please refer to the Mounting Installation
section.
Step 4: Power on the Industrial Gigabit Ethernet Switch. (Please refer
to the Wiring the Power Inputs section for power input) The
power LED on the Industrial Gigabit Ethernet Switch will light
up. Please refer to the LED Indicators section for meaning of
LED lights.
Step 5: Prepare the twisted-pair, straight through Category 5 cable
for Ethernet connection.
Step 6: Insert one side of Category 5 cables into the Industrial Gigabit
Ethernet Switch Ethernet port (RJ-45 port) and another side
of category 5 cables to the network devices’ Ethernet port
(RJ-45 port), ex: switch, Pc or Server. The UTP port (RJ-45)
LED on the Industrial Gigabit Ethernet Switch will light up
when the cable connected with the network device. Please
refer to the LED Indicators section for LED light meaning.
Note
Be sure the connected network devices support MDI/
MDI-X. If it does not support then use the crossover
category 5 Cable.
Step 7: When all connections are all set and LED lights all show in
normal, the installation is complete.

20
4. SWITCH OPERATION
4.1 Address Table
The Industrial Gigabit Ethernet Switch is implemented with an address
table. This address table composed of many entries. Each entry is used
to store the address information of some node in network, including
MAC address, port no, etc. This information comes from the learning
process of Industrial Gigabit Ethernet Switch.
4.2 Learning
When one packet comes in from any port. The Industrial Gigabit
Ethernet Switch will record the source address, port no. And the other
related information in address table. This information will be used to
decide either forwarding or ltering for future packets.
4.3 Forwarding & Filtering
When one packet comes from some port of the Industrial Gigabit
Ethernet Switch, it will also check the destination address besides the
source address learning. The Industrial Gigabit Ethernet Switch will
lookup the address-table for the destination address. If not found, this
packet will be forwarded to all the other ports except the port which
this packet comes in. And these ports will transmit this packet to the
network it connected. If found, and the destination address is located at
different port from this packet comes in, the Industrial Gigabit Ethernet
Switch will forward this packet to the port where this destination
address is located according to the information from address table.
But, if the destination address is located at the same port with this
packet comes in, then this packet will be ltered. Thereby increasing
the network throughput and availability.
