Industrial L3 Multi-Port Full Gigabit
Managed Ethernet Switch
IGS-5225-8T2S2X/IGS-5225-8P2S2X
Quick Installation Guide

Table of Contents
1. Package Contents...................................................................... 3
2. Requirements............................................................................ 4
3. Wiring the Power Inputs ............................................................ 5
4. Terminal Setup.......................................................................... 7
4.1 Logon to the Console .......................................................... 8
4.2 ConguringIPAddress ........................................................ 8
4.3 StoretheCurrentSwitchConguration................................10
5. Starting Web Management ........................................................11
5.1 LoggingintotheIndustrialManagedSwitch ........................11
5.2 SavingCongurationviaWeb .............................................13
6. Resetting the Switch to Default .................................................15
7. Customer Support ....................................................................16

3
1. Package Contents
Thank you for purchasing PLANET L3 Industrial Managed Switch,
IGS-5225-8T2S2X and IGS-5225-8P2S2X. The descriptions of these
modelsareasfollows:
IGS-5225-8T2S2X:
IndustrialL38-Port10/100/1000T+2-Port
100/1000XSFP+2-Port10GSFP+Managed
EthernetSwitch(-40~75degreesC)
IGS-5225-8P2S2X:
IndustrialL38-Port10/100/1000T802.3atPoE
+2-Port100/1000XSFP+2-Port10GSFP+
ManagedEthernetSwitch(-40~75degreesC)
“Industrial Managed Switch” mentioned in this Quick Installation
Guidereferstotheabovetwomodels.
Open the box of the Industrial Managed Switch and carefully
unpackit.Theboxshouldcontainthefollowingitems:
zTheIndustrialManagedSwitchx1
zQuickInstallationGuidex1
zDINRailKitx1
zWallMountingKitx1
zDB9 to RJ45 Interface RS232 Console Cable x 1
zDustCap(Pleaserefertothetablebelow.)
Model RJ45 Dust Cap SFPDustCap
IGS-5225-8T2S2X
9 4
IGS-5225-8P2S2X
If any of these are missing or damaged, please contact your dealer
immediately. If possible, retain the carton including the original packing
materials to enable you to repack the product in case there is a need
to return it to us for repair.

4
2. Requirements
The Industrial Managed Switch provides remote login interface for
management purposes. The following equipment is necessary for
furthermanagement:
zWorkstations running Windows XP/2003/Vista/7/8/2008/10, MAC
OS X or later, Linux, UNIX, or other platforms are compatible with
TCP/IPProtocols.
zWorkstations are installed with Ethernet NIC (Network Interface
Card)
zSerial Port Connection(Terminal)
The above Workstations come with COM Port (DB9) or USB-to-
RS232 converter.
The above Workstations have been installed with terminal
emulator, such as Hyper Terminal included in Windows XP/2003,
putty or tera term.
Serial cable -- one end is attached to the RS232 serial port,
while the other end to the console port of the Industrial Managed
Switch.
zEthernet Port Connection
Network cables -- Use standard network (UTP) cables with RJ45
connectors.
The above PC is installed with Web browser and JAVA runtime
environment plug-in.
Note
Itis recommended to use Internet Explorer 8.0 or above
toaccesstheIndustrialManagedSwitch.

5
3. Wiring the Power Inputs
The Upper Panel of the Industrial Managed Switch indicates a DC
inlet power socket and consists of one terminal block connector within
6 contacts. Please follow the steps below to insert the power wire.
1.Insert positive/negative DC power wires into Contacts 1 and 2 for
Power1,orContacts5and6forPower2.
 IGS-5225-8T2S2X: 12~48VDC, 24VAC
Input DC 12V~48V
AC 24V
DC1 DC2
Fault
1A@24V
DI1 DO0 DO1DI0 GNDGND
1 2 3 4 5 6
1 2 3 4 5 6
Figure 3-1: IGS-5225-8T2S2X Upper Panel
 IGS-5225-8P2S2X:48~56VDC
Input DC 48-56V
DI0 DI1 DO0 DO1 GND GND
DC1
+
DC2Fault
+
1A@24V
1 2 3 4 5 6
1 2 3 4 5 6
Figure 3-2: IGS-5225-8P2S2X Upper Panel

6
2. Tighten the wire-clamp screws for preventing the wires from loos-
ening.
123456
V+ V- V+ V-
Power 1 Power 2
Model Positive(+)Pin Negative(-)Pin
IGS-5225-8T2S2X
Pin1/5 Pin2/6
IGS-5225-8P2S2X
Note
The wire gauge for the terminal block should be in the
range from 12 to 24 AWG.
Please check with wire AWG Ampere spec, before
connectingPLANETIndustrialSwitch.

7
4. Terminal Setup
To congure the system, connect a serial cable to a COM port on a
PC or notebook computer and to RJ45 type serial (console) port of the
Industrial Managed Switch. The console port of the Industrial Managed
Switch is DCE already, so that you can connect the console port
directlythroughPCwithouttheneedofnullmodem.
PC/Workstation
with
Terminal emulation software
RJ45 to DB9 RS232 Cable
Serial Port
IP Address:
192.168.0.100
IGS Industrial Managed Switch
A terminal program is required to make the software connected to the
IGS-5225-8T2S2XandIGS-5225-8P2S2XIndustrialManagedSwitch.
1. Run terminal program on the OS.
2.When the following screen appears, make sure that the COM port
shouldbeconguredas:
zBaud:115200
zParity:None
zDatabits:8
zStopbits:1
zFlowcontrol:None

8
4.1 Logon to the Console
Once the terminal has been connected to the device, power on the
IndustrialManagedSwitchandtheterminalwilldisplay“runningtesting
procedures”.
Then, the following message asks to log in user name and password.
The factory default user name and password are shown as follows and
theloginscreeninFigure5-1appears
UserName:admin
Password: admin
Figure 4-1: Console Login Screen
The user can now enter commands to manage the Industrial Managed
Switch. For a detailed description of the commands, please refer to the
following chapters.
Note
1. For security reason, please change and memorize
the new password after this first setup.
2. Only accept command in lowercase letter under
console interface.
4.2 ConguringIPAddress
The Industrial Managed Switch is shipped with default IP address
shownbelow:
IPAddress:192.168.0.100
SubnetMask:255.255.255.0

9
To check the current IP address or modify a new IP address for the
Switch,pleaseusetheprocedureasfollows:
Display of the current IP Address
1.Atthe“#”prompt,enter “show ip interface brief”.
2.ThescreendisplaysthecurrentIPaddressshowninFigure4-2
Figure 4-2: IP Information Screen
 CongurationoftheIPAddress
3.At the “#” prompt, enter the following command and press <Enter>
asshowninFigure4-3.
IGS-5225-8T2S2X#congureterminal
IGS-5225-8T2S2X(cong)#interface vlan 1
IGS5225-8T2S2X(cong-if-vlan)#ip address 192.168.1.100
255.255.255.0
The previous command would apply the following settings for the
IndustrialManagedSwitch.
IPAddress:192.168.1.100
SubnetMask:255.255.255.0
Figure 4-3: Conguring IP Address Screen
4.Repeatstep1tocheckiftheIPaddresshaschanged.

10
4.3 StoretheCurrentSwitchConguration
Atthe“#”prompt,enterthefollowingcommandandpress<Enter>.
#copyrunning-congstartup-cong
Figure 4-4: Saving Current Conguration Command Screen
If the IP is successfully congured, the Industrial Managed Switch will
apply the new IP address setting immediately. You can access the Web
interfaceoftheIndustrialManagedSwitchthrough thenewIPaddress.
Note
If you are not familiar with the console command or the
related parameter, enter “help” anytime in console to
getthehelpdescription.

11
5. Starting Web Management
The following shows how to start up the Web Management of the
Industrial Managed Switch. Note the Industrial Managed Switch is
congured through an Ethernet connection. Please make sure the
manager PC must be set to the same IP subnet address.
Forexample,thedefault IPaddress ofthe IndustrialManaged Switchis
192.168.0.100, then the manager PC should be set to 192.168.0.x
(where x is a number between 1 and 254, except 100), and the
defaultsubnetmaskis255.255.255.0.
IP Address:
192.168.0.x IP Address:
192.168.0.100
IGS Industrial Switch
RJ45/UTP-Cable
Figure 5-1: IP Management Diagram
5.1 Logging in to the Industrial Managed Switch
1.Use Internet Explorer 8.0 or above for Web browser and enter IP
address http://192.168.0.100 (the factory-default IP address) to
access the Web interface.
2.When the following dialog box appears, please enter the default user
name “admin” and password “admin” (or the password you have
changedbefore)asshowninFigure5-2.

12
DefaultIPAddress:192.168.0.100
DefaultUserName:admin
DefaultPassword:admin
Figure 5-2: Login Screen
3.After entering the password, the main screen appears as shown in
Figure5-3.
Figure 5-3: Web Main Screen of Industrial Managed Switch

13
4.The Switch Main Menu is shown on top of the Web page, and the
functions are shown on the left to congure the Industrial Managed
Switch.
Now, you can use the Web management interface to continue the
Switch management. Please refer to the user manual for more.
Note
If you are not familiar with Switch functions or the
related parameter, press “Help icon” anytime on the
Webpagetogetthehelpdescription.
5.2 SavingCongurationviaWeb
In the Industrial Managed Switch, the running conguration le stores
in the RAM. In the current version, the running conguration sequence
of running-cong can be saved from the RAM to FLASH by executing
save startup cong command, so that the running conguration
sequence becomes the startup conguration le, which is called
congurationsave.
To save all applied changes and set the current conguration as a
startup conguration, the startup-conguration le will be loaded
automatically across a system reboot.

14
1. Click Maintenance > Open Switch Maintenance on the left
page>PressSaveStartupCong.
2. Or you can press the “SaveConguration” button.
3. Press the “SaveConguration” button to save.

15
6. Resetting the Switch to Default
To reset the IP address to the default IP address “192.168.0.100”
and the user password to factory default mode (default password
is admin), press the hardware reset button on the front panel for
about 10 seconds. After the device is rebooted, you can login the
management Web interface within the same subnet of 192.168.0.xx
and default password. Be noted that all the previous setups will be
disappearedafterthefactorydefaultresetismade.
IGS-5225-8T2S2X
7
5
3
1
RESET
8
6
11
9
4
2
Console
115200,N,8,1
P1 P2 FAULT
11
9
I/O
12
10
12
10
ACT1000 LNK
ACT10G LNK
ACT1000 LNK
ACT100 LNK
ACT1000 LNK
ACT100 LNK
Reset Button
Figure 6-1: IGS-5225-8T2S2X/IGS-5225-8P2S2X Reset Button

16
7. Customer Support
Thank you for purchasing PLANET products. You can browse our online
FAQ resource on PLANET web site rst to check if it could solve your
issue. If you need more support information, please contact PLANET
switch support team.
PLANETonlineFAQ:
https://www.planet.com.tw/en/support/faq
Switchsupportteammailaddress:
[email protected]
IGS-5225-8T2S2X/IGS-5225-8P2S2XUser’sManual:
https://www.planet.com.tw/en/support/downloads?method=category&c1
=industrial-ethernet&p=&type=3
(Please select your switch model name from the Product Model drop-
downmenu)
Copyright ©PLANET Technology Corp. 2018.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners
