Planeta Premium Pro Series User manual

Operation and maintenance manual for
Chain Hoist PREMIUM PRO
Installation - Operation - Maintenance
© Reprint, also in extracts, only with written permission of PLANETA-Hebetechnik GmbH
01-02-09-0000-0918-03-BA-EN-PLA
IMPORTANT - READ BEFORE USE!
PLANETA-Hebetechnik GmbH •Resser Str. 17 & 23 • D-44653 Herne
Tel. [phone] • Fax [phone] • [email protected] • www.planeta-hebetechnik.de
Chain Hoist
PREMIUM PRO 1 t

Index
SAFETY 4
1. Generally 5
2. Important Notes 6
3. Special safety 6
4. Installation instructions before connecting 7
5. Operation 7
6. Maintenance and inspection 7
7. Overload safety device 8
8. Specications 9
9. Spare parts for Chain Hoist PREMIUM PRO 0,25 t – 5 t 10
10. Spare Parts List for Chain Hoist PREMIUM PRO 0,25 t – 5 t 11
11. Spare parts for Chain Hoist PREMIUM PRO 10 t 15
12. Spare Parts List for Chain Hoist PREMIUM PRO 10 t 16
13. Annual safety inspections 17
CE-DECLARATION OF CONFORMITY

4
SAFETY
1. Read before
use!
2. Do not
overload
3. Do not work
under a load!
4. Never pull the
chain from the
side!
5. Never work
with a
damaged
hoist!
6. Never lift human
with this hoist!
7. Never throw
the hoist
8. Do not wrap
the load chain
around the
load
9. NEVER
extend the
Hand lever
with a pipe!
10. Never work
up to the end
of chain
11. Never attach the
load on the tip of
the hook!
12. 11.Never
work with a
twisted or
broken chain!
13. Never work
without a
safety latch!
14. Never remove
the warning
notice

5
1. Generally
Chain hoists are for lifting of loads only.
The hoists can be attached to a trolley of any type as a travelling hoist.
Five prominent features:
– Safety in operation with minimum maintenance.
– High efciency and low hand force.
– Light weight and easy handling.
– Fine appearance with small size
– Durability in service.
Intellectual property
Hoist models, drawings and engineering are of our exclusive property. It is expressly
forbidden to copy, use or hand over to third parties such information without a specic
written permission.
Warranty
PLANETA warrants to the original user its hoists to be free of defects in material and
workmanship for a period of one year from the date of purchase. PLANETA will repair,
without cost, any product found to be defective, including parts and labor charges, or
at its option, will replace such products or refund the purchase price less a reasonable
allowance for depreciation, in exchange for the product.
If any product proves defective within its original one year warranty period, it should
be returned to any authorized PLANETA dealer, transportation prepaid with proof of
purchase or hoist data sheet / test certicate.
This warranty does not apply to products which PLANETA has determined to have
been misused or abused, improperly maintained by the purchaser; or where the
malfunction or defect can be attributed to the use of no genuine PLANETA parts.
PLANETA makes no other warranty, and all implied warranties including any warranty
of merchantability or tness for a particular purpose are limited to the duration of the
expressed warranty period as set forth above. PLANETA´s maximum liability is limited
to the purchase price of the product and in no event shall PLANETA be liable for any
consequential, indirect, incidental, or special damages of any nature arising from the
sale or use of the product, whether based on contract, tort, or otherwise.

6
2. Important Notes
– Read instruction and make it available to operators on the device before use.
– Operator must be instructed properly with the device. Never leave the device under
load unattended!
– Never exceed lifting capacity indicated on the name plate. Do not draw any pull and
lifting chains over angles.
– Do not transport persons or loads with the product over areas where persons
could be.
– Device must be checked once a year by a technical expert, in case of harder
operating conditions more often. Ask your retailer or us. The enterpriser is liable in
case of damages and has to provide test certicates.
– Check the device regarding damages, unfastened screws or twists before using it
to eliminate failures.
– Repair works on hoisting devices shall only be carried out by the manufacturer or
an instructed repair shop by using original spare parts.
– Check load carrying constructions, load securing devices, mountings, cross beams
etc. regarding load carrying capacity and condition of the required loads by a
technical expert.
– Non-observance of the instruction, improper use, and corrosion by insufcient
protection or product alterations without authority result in expiry of the warranty.
– Risk of corrosion in case of continuous contact with unfavourable atmospheric
conditions as for example high humidity or harmful environmental inuences
atmospheres with acid vapours, corrosive gases or high dust concentration cause
early wear. This effectuates no claim under warranty.
– Further information or spare part lists will kindly be provided by us or your specialist
dealer.
3. Special safety
– Read before use.
– Do not overload
– Do not work under a load
– Never pull the chain from the side
– Never work with a damaged hoist
– Never lift persons with this hoist
– Never throw the hoist
– Do not wrap the load chain around the load
– Never work up to the end of chain
– Never attach the load on the tip of the hook.
– Never work with a twisted or broken chain
– Never work without a safety latch
– Never remove the warning notice

7
4. Installation instructions before connecting
A. Before rst use
– Chain hoists with travelling trolley underlie the accident prevention regulation (UVV)
(Federal cooperative society regulations of Germany - DGUV Regulation 52).
Before the rst initiation a quality inspection by a technical expert for cranes has to
be carried out. Please contact PLANETA for it. We will kindly advise you!
– Never use the hoist below -20 degrees Celsius or above + 60 degrees Celsius.
B. Installation and testing prior to each use
– Hang hoist with the clamp into the load carrying system and turn once.
– Hand chain and load chain must hang free and be without breaks or twists.
– Chain block: Pull through hand chain one time completely without load.
– Inspection of load brake: Lift up lightly the load and hold it. If load is safe, go on lifting.
When lowering, the load shall not slide after hand chain shutdown or stop of the lever.
– If everything is performed properly, operation can be started.
– Important for devices of multiple lines: Lower block shall not be snapped through the
chain loop. This can be recognised by a twisted chain. Each second chain link is in
one row not steadily in alignment. If the welded seams of the chain links are not in
same direction the lower block must be struck back through the chain loop.
– The last chain link must be fastened on the hoist body.
5. Operation
– Brake closes independently when hanging on the minimal load
(appr. 10% of nominal load).
– Chain block is only suitable for vertical lifting and lowering.
– To move the load the hand chain is pulled up or down.
6. Maintenance and inspection
Chains and Hooks
– The chains and clamps have to be inspected continuously! Clean chain before
inspection. Lubricate load chain from time to time! Never lubricate or grease the
brake!
– Retracted chain shall not click under load.
– Check chain for tension! The internal length (t) of a worn chain link, smallest
diameter of wire (D) and length of 11 chain links (a) are measured by a slide gauge
where the chain must be tightened rmly.
– Dimensions: If the deviations of measurement exceed the values (a) in the
following table substitute chain immediately. Measure of diameter (D) shall not be
under-run and the pitch (t) of the single link not be exceeded.

8
7. Overload safety device
All spur gear chain blocks PREMIUM PRO have a
standard adjustable overload safety device from 500kg
or above. This protects the device by prohibiting lifting
more than the preset friction connection in the hand
wheel permits. The overload protection is set at the
factory. By fastening or loosening the press nut pos. 49,
the pressure on the friction disc is increased or lowered.
If the desired value is reached, the nut pos. 49 is
secured by bending one or two teeth of the tooth wheel
pos. 50 into the corresponding gap in the nut.
Capacity
Max. measurement of
Min. chain link
diameter (D)
1 chain
link (t)
11 chain
links (a)
0,25 t 12,6 mm 134,9 mm 3,6 mm
0,5 t 15,8 mm 170,0 mm 4,5 mm
1 t 18,9 mm 210,9 mm 5,4 mm
1,5 t 25,2 mm 271,9 mm 7,2 mm
2 t 25,2 mm 271,9 mm 7,2 mm
3 t 31,5 mm 352,5 mm 9,0 mm
5 t 31,5 mm 352,5 mm 9,0 mm
10 t 31,5 mm 352,5 mm 9,0 mm
20 t 31,5 mm 352,5 mm 9,0 mm
Capacity Clamp mouth opening
“G” normal – max.
0,25 t 40 – 42 mm
0,5 t 26 – 29 mm
1 t 32 – 35 mm
1,5 t 38 – 42 mm
2 t 38 – 42 mm
3 t 43 – 47 mm
5 t 48 – 53 mm
10 t 60 – 66 mm
20 t 84 – 92 mm

9
8. Specications
TYPE PREMIUM PRO... 0,25 0,5 1 1,5 2 3 5 10 20 30
Capacity t 0,25 0,5 1 1,5 2 3 5 10 20 30
Standard lift m 3 3 3 3 3 3 3 3 3 3
Min. headroom (A) mm 259 309 373 460 460 553 630 900 1033 1320
Hand chain force daN 22 24 30,5 36 36 37 39 39,5 40,5 47 x 2
Hand chain operation
length
m 2,5 2,5 2,5 2,5 2,5 2,5 2,5 2,5 2,5 2,5
Number of chain falls 1 1 1 1 1 1 2 4 8 12
Chain size mm 4 x 12 5 x 15 6 x 18 8 x 24 8 x 24 10 x 30 10 x 30 10 x 30* 10 x 30 10 x 30
B (Dimensions) mm 95 114 152 190 190 240 240 391 955 690
C mm 99,4 110 139 150 150 158 158 166 169 435
D mm 30 33 40 52 52 62 72 85 110 106
E mm 22 22 28 33 33 37 44 60 70 80
F mm 2,5 2,5 2,5 2,5 2,5 2,5 2,5 2,5 2,5 2,5
Weight with 3m lift kg 4,2 5,7 10,8 16,8 17,1 26,2 40 62 160 350
Weight for 1m additional lift kg 0,35 0,55 0,78 1,4 1,4 2,2 4,4 8,8 17,6 21,6
* Grade 100 Subject to technical changes!
Chain Hoist PREMIUM PRO 0,25 - 3 t Chain Hoist PREMIUM PRO 5 t Chain Hoist PREMIUM PRO 10t

10
9. Spare parts for Chain Hoist PREMIUM PRO 0,25 t – 5 t
Chain Hoist PREMIUM PRO 0,25 - 3 t Chain Hoist PREMIUM PRO 0,25 - 3 t Chain Hoist PREMIUM PRO 5 t
Chain Hoist PREMIUM PRO 5 t

11
10. Spare Parts List for Chain Hoist PREMIUM PRO 0,25t – 5 t
Component parts PREMIUM PRO 0,25 t
Item Qty. Description Part-No.
1 8 Locking nut Z0200101 Piece
2 1 Gear box cap Z0200102 Piece
3 1 Washer Z0200103 Piece
4 2 Gear wheel Z0200104 Piece
5 1 Driving shaft Z0200105 Piece
6 1 Center gear wheel Z0200106 Piece
8 1 Right side plate Z0200108 Piece
9 1 Top hook pin Z0200109 Piece
12 2 Chain guide roller Z0200112 Piece
14 1 Load Chain sprocket Z0200114 Piece
15 5 Hand chain Z0200115 m
16 1 Left side plate Z0200116 Piece
17 1 Chain stripper Z0200117 Piece
18 1 Chain suspension Z0200118 Piece
19 1 Split pin Z0200119 Piece
20 1 Pin Z0200120 Piece
21 3 Load chain Z0200121 m
22 1 Name plate Z0200122 Piece
23 1 Brake seat Z0200123 Piece
25 1 Ratchet disk Z0200125 Piece
26 4 Name plate rivet Z0200126 Piece
27 1 Split pin Z0200127 Piece
28 1 Castle nut Z0200128 Piece
29 1 Hand wheel cover Z0200129 Piece
76 1 Dust protection cover Z0200176 Piece
Complete parts PREMIUM PRO 0,25 t
Item Qty. Description Part-No.
46 1
Top load hook assem-
bly, Item 31, 33 (2x),
34 (2x), 35 (2x), 47
Z0200146 Set
47 1 Safety latch assembly,
Item 36, 37, 38, 39 Z0200179 Set
48 1
Load hook assembly,
Item 32, 41 (2x),
42, 43,
44 (2x), 45 (2x), 47
Z0200178 Set
49 1 Friction plates assem-
bly, Item 24 (2x) Z0200149 Set
50 1
Overload protection
assembly, Item 51,
52, 53, 54, 55, 56
Z0200150 Set
70 1
Ratchet Pawl assem-
bly, Item 10 (2x), 11
(2x), 13 (2x)
Z0200170 Set
72 1 Locking set assembly,
Item 7, 30 (2x) Z0200172 Set
Component parts PREMIUM PRO 0,5 t
Item Qty. Description Part-No.
1 8 Locking nut Z0200201 Piece
2 1 Gear box cap Z0200202 Piece
3 1 Washer Z0200203 Piece
4 2 Gear wheel Z0200204 Piece
5 1 Driving shaft Z0200205 Piece
6 1 Center gear wheel Z0200206 Piece
8 1 Right side plate Z0200208 Piece
9 1 Top hook pin Z0200209 Piece
12 2 Chain guide roller Z0200212 Piece
14 1 Load Chain sprocket Z0200214 Piece
15 5 Hand chain Z0200215 m
16 1 Left side plate Z0200216 Piece
17 1 Chain stripper Z0200217 Piece
18 1 Chain suspension Z0200218 Piece
19 1 Split pin Z0200219 Piece
20 1 Pin Z0200220 Piece
21 3 Load chain Z0200221 m
22 1 Name plate Z0200222 Piece
23 1 Brake seat Z0200223 Piece
25 1 Ratchet disk Z0200225 Piece
26 4 Name plate rivet Z0200226 Piece
27 1 Split pin Z0200227 Piece
28 1 Castle nut Z0200228 Piece
29 1 Hand wheel cover Z0200229 Piece
76 1 Dust protection cover Z0200276 Piece
Complete parts PREMIUM PRO 0,5 t
Item Qty. Description Part-No.
46 1
Top load hook assem-
bly, Item 31, 33 (2x),
34 (2x), 35 (2x), 47
Z0200246 Set
47 1 Safety latch assembly,
Item 36, 37, 38, 39 Z0200247 Set
48 1
Load hook assembly,
Item 32, 41 (2x),
42, 43,
44 (2x), 45 (2x), 47
Z0200248 Set
49 1 Friction plates assem-
bly, Item 24 (2x) Z0200249 Set
50 1
Overload protection
assembly, Item 51,
52, 53, 54, 55, 56
Z0200250 Set
70 1
Ratchet Pawl assem-
bly, Item 10 (2x), 11
(2x), 13 (2x)
Z0200270 Set
72 1 Locking set assembly,
Item 7, 30 (2x) Z0200272 Set
Not listed items are only available in the module!

12
Component parts PREMIUM PRO 1 t
Item Qty. Description Part-No.
1 8 Locking nut Z0200301 Piece
2 1 Gear box cap Z0200302 Piece
3 1 Washer Z0200303 Piece
4 2 Gear wheel Z0200304 Piece
5 1 Driving shaft Z0200305 Piece
6 1 Center gear wheel Z0200306 Piece
8 1 Right side plate Z0200308 Piece
9 1 Top hook pin Z0200309 Piece
12 2 Chain guide roller Z0200312 Piece
14 1 Load Chain sprocket Z0200314 Piece
15 5 Hand chain Z0200315 m
16 1 Left side plate Z0200316 Piece
17 1 Chain stripper Z0200317 Piece
18 1 Chain suspension Z0200318 Piece
19 1 Split pin Z0200319 Piece
20 1 Pin Z0200320 Piece
21 3 Load chain Z0200321 m
22 1 Name plate Z0200322 Piece
23 1 Brake seat Z0200323 Piece
25 1 Ratchet disk Z0200325 Piece
26 4 Name plate rivet Z0200326 Piece
27 1 Split pin Z0200327 Piece
28 1 Castle nut Z0200328 Piece
29 1 Hand wheel cover Z0200329 Piece
76 1 Dust protection cover Z0200376 Piece
Complete parts PREMIUM PRO 1 t
Item Qty. Description Part-No.
46 1
Top load hook assem-
bly, Item 31, 33 (2x),
34 (2x), 35 (2x), 47
Z0200346 Set
47 1 Safety latch assembly,
Item 36, 37, 38, 39 Z0200347 Set
48 1
Load hook assembly,
Item 32, 41 (2x),
42, 43,
44 (2x), 45 (2x), 47
Z0200348 Set
49 1 Friction plates assem-
bly, Item 24 (2x) Z0200349 Set
50 1
Overload protection
assembly, Item 51,
52, 53, 54, 55, 56
Z0200350 Set
70 1
Ratchet Pawl assem-
bly, Item 10 (2x), 11
(2x), 13 (2x)
Z0200370 Set
72 1 Locking set assembly,
Item 7, 30 (2x) Z0200372 Set
Component parts PREMIUM PRO 1,5 t
Item Qty. Description Part-No.
1 8 Locking nut Z0200401 Piece
2 1 Gear box cap Z0200402 Piece
3 1 Washer Z0200403 Piece
4 2 Gear wheel Z0200404 Piece
5 1 Driving shaft Z0200405 Piece
6 1 Center gear wheel Z0200406 Piece
8 1 Right side plate Z0200408 Piece
9 1 Top hook pin Z0200409 Piece
12 2 Chain guide roller Z0200412 Piece
14 1 Load Chain sprocket Z0200414 Piece
15 5 Hand chain Z0200415 m
16 1 Left side plate Z0200416 Piece
17 1 Chain stripper Z0200417 Piece
18 1 Chain suspension Z0200418 Piece
19 1 Split pin Z0200419 Piece
20 1 Pin Z0200420 Piece
21 3 Load chain Z0200421 m
22 1 Name plate Z0200422 Piece
23 1 Brake seat Z0200423 Piece
25 1 Ratchet disk Z0200425 Piece
26 4 Name plate rivet Z0200426 Piece
27 1 Split pin Z0200427 Piece
28 1 Castle nut Z0200428 Piece
29 1 Hand wheel cover Z0200429 Piece
76 1 Dust protection cover Z0200476 Piece
Complete parts PREMIUM PRO 1,5 t
Item Qty. Description Part-No.
46 1
Top load hook assem-
bly, Item 31, 33 (2x),
34 (2x), 35 (2x), 47
Z0200446 Set
47 1 Safety latch assembly,
Item 36, 37, 38, 39 Z0200447 Set
48 1
Load hook assembly,
Item 32, 41 (2x),
42, 43,
44 (2x), 45 (2x), 47
Z0200448 Set
49 1 Friction plates assem-
bly, Item 24 (2x) Z0200449 Set
50 1
Overload protection
assembly, Item 51,
52, 53, 54, 55, 56
Z0200450 Set
70 1
Ratchet Pawl assem-
bly, Item 10 (2x), 11
(2x), 13 (2x)
Z0200470 Set
72 1 Locking set assembly,
Item 7, 30 (2x) Z0200472 Set
Not listed items are only available in the module!

13
Component parts PREMIUM PRO 2 t
Item Qty. Description Part-No.
1 8 Locking nut Z0200501 Piece
2 1 Gear box cap Z0200502 Piece
3 1 Washer Z0200503 Piece
4 2 Gear wheel Z0200504 Piece
5 1 Driving shaft Z0200505 Piece
6 1 Center gear wheel Z0200506 Piece
8 1 Right side plate Z0200508 Piece
9 1 Top hook pin Z0200509 Piece
12 2 Chain guide roller Z0200512 Piece
14 1 Load Chain sprocket Z0200514 Piece
15 5 Hand chain Z0200515 m
16 1 Left side plate Z0200516 Piece
17 1 Chain stripper Z0200517 Piece
18 1 Chain suspension Z0200518 Piece
19 1 Split pin Z0200519 Piece
20 1 Pin Z0200520 Piece
21 3 Load chain Z0200521 m
22 1 Name plate Z0200522 Piece
23 1 Brake seat Z0200523 Piece
25 1 Ratchet disk Z0200525 Piece
26 4 Name plate rivet Z0200526 Piece
27 1 Split pin Z0200527 Piece
28 1 Castle nut Z0200528 Piece
29 1 Hand wheel cover Z0200529 Piece
76 1 Dust protection cover Z0200576 Piece
Complete parts PREMIUM PRO 2 t
Item Qty. Description Part-No.
46 1
Top load hook assem-
bly, Item 31, 33 (2x),
34 (2x), 35 (2x), 47
Z0200546 Set
47 1 Safety latch assembly,
Item 36, 37, 38, 39 Z0200547 Set
48 1
Load hook assembly,
Item 32, 41 (2x),
42, 43,
44 (2x), 45 (2x), 47
Z0200548 Set
49 1 Friction plates assem-
bly, Item 24 (2x) Z0200549 Set
50 1
Overload protection
assembly, Item 51,
52, 53, 54, 55, 56
Z0200550 Set
70 1
Ratchet Pawl assem-
bly, Item 10 (2x), 11
(2x), 13 (2x)
Z0200570 Set
72 1 Locking set assembly,
Item 7, 30 (2x) Z0200572 Set
Component parts PREMIUM PRO 3 t
Item Qty. Description Part-No.
1 8 Locking nut Z0200601 Piece
2 1 Gear box cap Z0200602 Piece
3 1 Washer Z0200603 Piece
4 2 Gear wheel Z0200604 Piece
5 1 Driving shaft Z0200605 Piece
6 1 Center gear wheel Z0200606 Piece
8 1 Right side plate Z0200608 Piece
9 1 Top hook pin Z0200609 Piece
12 2 Chain guide roller Z0200612 Piece
14 1 Load Chain sprocket Z0200614 Piece
15 5 Hand chain Z0200615 m
16 1 Left side plate Z0200616 Piece
17 1 Chain stripper Z0200617 Piece
18 1 Chain suspension Z0200618 Piece
19 1 Split pin Z0200619 Piece
20 1 Pin Z0200620 Piece
21 3 Load chain Z0200621 m
22 1 Name plate Z0200622 Piece
23 1 Brake seat Z0200623 Piece
25 1 Ratchet disk Z0200625 Piece
26 4 Name plate rivet Z0200626 Piece
27 1 Split pin Z0200627 Piece
28 1 Castle nut Z0200628 Piece
29 1 Hand wheel cover Z0200629 Piece
76 1 Dust protection cover Z0200676 Piece
Complete parts PREMIUM PRO 3 t
Item Qty. Description Part-No.
46 1
Top load hook assem-
bly, Item 31, 33 (2x),
34 (2x), 35 (2x), 47
Z0200646 Set
47 1 Safety latch assembly,
Item 36, 37, 38, 39 Z0200647 Set
48 1
Load hook assembly,
Item 32, 41 (2x),
42, 43,
44 (2x), 45 (2x), 47
Z0200648 Set
49 1 Friction plates assem-
bly, Item 24 (2x) Z0200649 Set
50 1
Overload protection
assembly, Item 51,
52, 53, 54, 55, 56
Z0200650 Set
70 1
Ratchet Pawl assem-
bly, Item 10 (2x), 11
(2x), 13 (2x)
Z0200670 Set
72 1 Locking set assembly,
Item 7, 30 (2x) Z0200672 Set
Not listed items are only available in the module!

14
Component parts PREMIUM PRO 5 t
Item Qty. Description Part-No.
1 8 Locking nut Z0200701 Piece
2 1 Gear box cap Z0200702 Piece
3 1 Washer Z0200703 Piece
4 2 Gear wheel Z0200704 Piece
5 1 Driving shaft Z0200705 Piece
6 1 Center gear wheel Z0200706 Piece
8 1 Right side plate Z0200708 Piece
9 1 Top hook pin Z0200709 Piece
12 2 Chain guide roller Z0200712 Piece
14 1 Load Chain sprocket Z0200714 Piece
15 5 Hand chain Z0200715 m
16 1 Left side plate Z0200716 Piece
17 1 Chain stripper Z0200717 Piece
18 1 Chain suspension Z0200718 Piece
19 1 Split pin Z0200719 Piece
20 1 Pin Z0200720 Piece
21 3 Load chain Z0200721 m
22 1 Name plate Z0200722 Piece
23 1 Brake seat Z0200723 Piece
25 1 Ratchet disk Z0200725 Piece
26 4 Name plate rivet Z0200726 Piece
27 1 Split pin Z0200727 Piece
28 1 Castle nut Z0200728 Piece
29 1 Hand wheel cover Z0200729 Piece
76 1 Dust protection cover Z0200776 Piece
Complete parts PREMIUM PRO 5 t
Item Qty. Description Part-No.
47 1 Safety latch assembly,
Item 36, 37, 38, 39 Z0200747 Set
49 1 Friction plates assem-
bly, Item 24 (2x) Z0200749 Set
50 1
Overload protection
assembly, Item 51,
52, 53, 54, 55, 56
Z0200750 Set
57 1
Top load hook
assembly, Item 40, 47,
58 (2x), 59, 60 (3x), 61
(4x), 62
Z0200757 Set
63 1
Load hook assembly,
Item 47, 64 (2x),
65, 66,
67 (2x), 68 (2x), 69
(2x), 71, 73 (2x)
Z0200763 Set
70 1
Ratchet Pawl assem-
bly, Item 10 (2x), 11
(2x), 13 (2x)
Z0200770 Set
72 1 Locking set assembly,
Item 7, 30 (2x) Z0200772 Set
Not listed items are only available in the module!

15
11. Spare parts for Chain Hoist PREMIUM PRO 10 t

16
12. Spare Parts List for Chain PREMIUM PRO 10t
Component parts PREMIUM PRO 10 t
Item Qty. Description Part-No.
1 8 Locking nut Z0200801 Piece
2 1 Gear box cap Z0200802 Piece
3 1 Washer Z0200803 Piece
4 2 Gear wheel Z0200804 Piece
5 1 Driving shaft Z0200805 Piece
6 1 Center gear wheel Z0200806 Piece
8 1 Right side plate Z0200808 Piece
9 1 Top hook pin Z0200809 Piece
12 2 Chain guide roller Z0200812 Piece
14 1 Load Chain sprocket Z0200814 Piece
15 5 Hand chain Z0200815 m
16 1 Left side plate Z0200816 Piece
17 1 Chain stripper Z0200817 Piece
18 1 Chain suspension Z0200818 Piece
19 1 Split pin Z0200819 Piece
20 1 Pin Z0200820 Piece
21 3 Load chain Z0200821 m
22 1 Name plate Z0200822 Piece
23 1 Brake seat Z0200823 Piece
25 1 Ratchet disk Z0200825 Piece
26 4 Name plate rivet Z0200826 Piece
27 1 Split pin Z0200827 Piece
28 1 Castle nut Z0200828 Piece
29 1 Hand wheel cover Z0200829 Piece
76 1 Dust protection cover Z0200876 Piece
Complete parts PREMIUM PRO 10 t
Item Qty. Description Part-No.
47 1 Safety latch assembly,
Item 36, 37, 38, 39 Z0200847 Set
49 1 Friction plates assem-
bly, Item 24 (2x) Z0200849 Set
50 1
Overload protection
assembly, Item 51,
52, 53, 54, 55, 56
Z0200850 Set
70 1
Ratchet Pawl assem-
bly, Item 10 (2x), 11
(2x), 13 (2x)
Z0200870 Set
72 1 Locking set assembly,
Item 7, 30 (2x) Z0200872 Set
74 1
Top load hook
assembly, Item 47, 77,
78, 79, 80, 81, 82 (3x),
83 (3x)
Z0200874 Set
75 1
Load hook assembly,
Item 47, 84, 85 (2x),
86, 87, 88, 89 (2x), 90,
91 (2x)
Z0200875 Set
Not listed items are only available in the module!

17
13. Annual safety inspections
Type of test Date Name & Signature
the examiner Result

CE-Declaration of Conformity
in the sense of 2006/42/EC Guidelines, Appendix II A, 2004/108/EG,
Appendix I and 2006/95/EG, Appendix III
We herewith declare that the
PLANETA-Hebetechnik GmbH, Resser Straße 17, 44653 Herne
that the partly completed machinery
Chain Hoist Model PREMIUM PRO
in payload range 250 kg – 30.000 kg
which was developed for lifting and lowering of loads, in the standard version, including
load capacity control and meets the basic requirements for the following EC directives,
as applicable for the delivered scope:
EG-Maschine-Directive 2006/42/EG
Authorized for the compilation of the relevant technical documentation
Dipl.-Ing. Matthias B. Klawitter, CE-Koordinator,
PLANETA-Hebetechnik GmbH, Resser Straße 17, 44653 Herne
Herne, 08.06.2016 PLANETA-Hebetechnik GmbH
Dipl.-Ing. Christian P. Klawitter
(General Manager)
For the completion, installation and commissioning according to the operating
instructions is responsible
Location
Date
Person in charge
Company

Notes

Your responsible supplier
© PLANETA-Hebetechnik GmbH
