PMT TT3 User manual

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
1
/
22
Thermometer man.docx Rev 1.02 UK “23
USER-
MANUAL
Thermometer
TT3

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
2
/
22
Thermometer man.docx Rev 1.02 UK “23
1 SAFETY AND WARNINGS ............................................................................................................................. 3
2 WARRANTY .................................................................................................................................................... 3
3 DISCLAIMER ................................................................................................................................................... 3
4 PRECAUTIONS AND HAZARDS ................................................................................................................... 4
5 INSTALLATION ............................................................................................................................................... 4
5.1 IMPORTANT ................................................................................................................................................. 4
5.2 UNPACKING ................................................................................................................................................ 4
6 USE .................................................................................................................................................................. 4
7 WHAT IS WHAT .............................................................................................................................................. 6
7.1 START ........................................................................................................................................................ 6
7.2 MENU STRUCTURE ...................................................................................................................................... 7
7.2.1 Menu Item “Logging”.......................................................................................................................... 7
7.2.2 Men Item “Clear Logs” ....................................................................................................................... 7
7.2.3 Menu Item “Sample time” .................................................................................................................. 8
7.2.4 Menu Item “C,F,K,ADC”..................................................................................................................... 8
7.2.5 Menu Item “Edit Date”........................................................................................................................ 9
7.2.6 Menu Item “Edit Clock” ...................................................................................................................... 9
7.2.7 Menu Item “Battery” ........................................................................................................................... 9
7.2.8 Menu Item “Set Filter“ ...................................................................................................................... 10
7.2.9 Menu Item “Baud Rate” ................................................................................................................... 10
8 COMMUNICATION ........................................................................................................................................ 11
8.1 SERIAL CONNECT ...................................................................................................................................... 11
8.2 SOFTWARE TAMCOM FOR WINDOWS .......................................................................................................... 11
8.3 INSTALLING THE TAMCOM SOFTWARE IS SIMPLE. ...................................................................................... 11
8.4 STARTING TAMCOM ................................................................................................................................... 12
8.4.1 Real time session ............................................................................................................................ 12
8.4.2 Stored session ................................................................................................................................. 12
8.4.3 Zoom function .................................................................................................................................. 13
8.4.4 Saving data ...................................................................................................................................... 13
8.4.5 Printing data ..................................................................................................................................... 13
9 RS232 COMMANDS ...................................................................................................................................... 14
10 MEMORY AND LOGGING ......................................................................................................................... 16
10.1 MEMORY ............................................................................................................................................... 16
10.2 START LOGGING TEMPERATURE DATA ..................................................................................................... 16
10.3 CHANGE THE INTERVAL .......................................................................................................................... 17
10.4 BATTERY ............................................................................................................................................... 18
11 SPARE PARTS LIST ................................................................................................................................. 19
12 DIMENSIONS ............................................................................................................................................. 20
13 TROUBLE SHOOTING .............................................................................................................................. 21
13.1 DISPLAY SHOWS STRANGE CHARACTERS ................................................................................................ 21
13.2 COMMUNICATION VIA USB GIVES PROBLEMS ........................................................................................... 21
13.3 CAN'T LOAD DATA IN TAMCOM ................................................................................................................ 21
14 EC DECLARATION OF CONFORMITY THERMOMETER TT3 ............................................................... 22

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
3
/
22
Thermometer man.docx Rev 1.02 UK “23
1 SAFETY AND WARNINGS
Make sure before installing or operating the equipment to read and understand all instructions and safety
precautions listed in this manual. If there are any questions concerning the operation of the equipment or about
the information given in this manual please contact your local dealer or our sales department first.
Performance of installation, operation, or maintenance other than those described in this manual may result in a
hazardous situation and may void the manufacturer's warranty.
Never operate equipment that is not correctly installed. Unqualified personnel must not operate the equipment.
Avoid damage to the equipment, or its accessories, caused by incorrect operation.
Important:
- Disconnect the thermometer from mains when performing service, maintenance or moving the apparatus.
- Proper skilled and trained personnel are only allowed to operate this equipment,
- Take notice of warning labels and never remove them,
- Refer service and repairs to qualified technician,
- If a problem persists, call your supplier or Tamson Instruments b.v
2 WARRANTY
Tamson Instruments b.v warrants that all their manufactured equipment is free from defects in material and
workmanship, preventing the device from normal operation. Tamson Instruments b.v does not warranty that the
equipment is fit for any other use than stated in this manual. The manufacturer can only be held responsible for
the security, reliability and performance of the equipment, when operated in accordance with the operating
instructions, extensions, adjustments, changes and/or if repair is performed by Tamson Instruments b.v or
authorized persons only. This warranty is limited to one year from the date of invoicing. All equipment and
materials are subject to standard production tolerances and variations.
3 Disclaimer
For relevant measurements always an independent reference measurement is needed. Tamson can not be held
responsible for misinterpretation or consequences of an erroneous reading

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
4
/
22
Thermometer man.docx Rev 1.02 UK “23
4 PRECAUTIONS AND HAZARDS
Before attempting to operate the thermometer read all
parts of this manual carefully to insure smooth operation
and avoid damage to the equipment or its accessories.
If a malfunction occurs, consult section "Trouble shooting”,
page 21. If the problem persists email use our contact form at
https://tamson-instruments.com/contact.
Never operate the equipment if not correctly installed. The
equipment must be operated only by qualified personnel.
Avoid damage to the equipment or its accessories through
incorrect operation.
5 INSTALLATION
5.1 Important
Tamson Instruments bv is not responsible for any
consequential damage or harm caused by using this
thermometer. Repairs on the electrical system of the
thermometer may only be carried out by well trained and
authorized persons.
5.2 Unpacking
Before leaving the factory Tamson products are adequately
packed to prevent damage during normal transportation.
Check the packing for external damage and make a note on
the shipping documents if any damage is found. Always retain
the cartons and packing material until the product has been
tested and found in good condition. (Transport companies
generally will not honor a claim for damage if the respective
packing material is not available for examination).
6 Use
The thermometer is a sensitive measuring device.
Prevent shock from the thermometer body or sensor.
Do not drop the thermometer housing.
Do not drop the thermometer sensor / probe.
The thermometer housing is of thermoplastic and sensitive to
heat. Prevent operating the thermometer at temperatures
higher than 50°C.
The temperature sensor is of stainless steel. Prevent
temperatures higher than 250°C at the tip of the sensor.
READ
CAREFULLY
Prevent
shock
Prevent
shock

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
5
/
22
Thermometer man.docx Rev 1.02 UK “23
The temperature sensor has silicone wire. Prevent
temperatures higher than 200°C.
Keep the thermometer away from fluid.
Keep the serial connector and sensor connector (PT100)
away from water. Corrosion of the PT100 connector will
seriously influence the calibration.
Keep sensor attached to thermometer.
Calibration will be influenced by corrosion of contacts over
time if not connected.
Prevent high
temperatures
Prevent
water and
moisture
Keep sensor
attached

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
6
/
22
Thermometer man.docx Rev 1.02 UK “23
7 What is what
1 Connector temperature sensor
2 Display
3 Battery charge indicator
4 Key: [Up]
5 Key: [Down]
6 Key: [Enter]
7 Holster for PT-100 probe
8 Foldable bracket to support upright use
9 Charging Socket 5,0 x 2,1mm
10 USB – “A” port female (for standard male type “A” connector)
7.1 Start
Switch the thermometer on, press the enter
Switch the thermometer off:
Select [Enter]
Select menu item “power down” with [Up]
Confirm [Down]
When switched on the thermometer will display the
temperature.
6
3
2
7
4
1
5
9
10
8
1

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
7
/
22
Thermometer man.docx Rev 1.02 UK “23
7.2 Menu structure
Use to step through menu
Readout
↓
Switch Off
↓
Logging
↓
Clear Logs
↓
Sample time
↓
C,F,K,ADC
↓
Edit Date
↓
Edit Clock
↓
Battery
↓
Set Filter
↓
Baud Rate
↓
Readout
If a menu item is selected and no key is pressed for six
seconds, the reading will skip back to the temperature readout
7.2.1 Menu Item “Logging”
Select item “Logging” with
Toggle logging or no logging
Start Log #
# is the session number which will be in progress and stored
after ending
The thermometer will store the temperature reading taken at
each interval selected at log time.
With the Tamcom software program the stored data can be
retrieved from the thermometer.
7.2.2 Men Item “Clear Logs”
Be careful with this one, memory will be erased

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
8
/
22
Thermometer man.docx Rev 1.02 UK “23
Pressing will now clear logs
To safely skip:
Do nothing and wait six seconds, you get back to the
temperature reading
Press to skip and the next menu item is visible
It will take some time to erase the internal memory. The
percentage clear memory is indicated incrementally.
7.2.3 Menu Item “Sample time”
When logging the temperature data, each “N-th” reading is
stored in the internal memory.
Where N can be set in seconds to
1
5
10
30
60
The temperature is not averaged over “N”. Instead the actual
temperature reading at each “N” seconds is stored.
7.2.4 Menu Item “C,F,K,ADC”
There are four ways to display the temperature
Select with and
Confirm with
C Degrees Centigrade
F Degrees Fahrenheit
K Degrees Kelvin
ADC Actual analog to digital value
This value is used to linearize the
thermometer electronical according to ITS
90

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
9
/
22
Thermometer man.docx Rev 1.02 UK “23
7.2.5 Menu Item “Edit Date”
This will set the internal date from the real time clock
Select with
Press
Use or to set day and press
Use or to set month and press
Use or to set year and press
Next menu item will be displayed
7.2.6 Menu Item “Edit Clock”
This will set the internal date from the real time clock
Select with
Press
Use or to set day and press
Use or to set month and press
Use or to set year and press
Next menu item will be displayed
7.2.7 Menu Item “Battery”
The value indicated here is the voltage of the battery
A pack containing four NiMh cells is used each having a
nominal voltage of 1.2 volts.
A voltage higher than 5.0 Volts guarantees an operating time
of 16 hrs. When using a fully charged and healthy battery.
A voltage below 3.6 Volt switches of the electronics
completely. When connected to a charger, electronics will
switch back on.

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
10
/
22
Thermometer man.docx Rev 1.02 UK “23
Replace the battery pack when after a full charge the
thermometer can not be used for more than 8 hours
Charging will take approximately 2 .. 2,5 hrs.
When fully charged, the red charging LED will switch off
7.2.8 Menu Item “Set Filter“
The filter can be averaged using a mathematical moving
average. The settings between brackets are the number of
mathematical points. Seven settings options are possible:
No [0]
Weak [36]
Very low [72]
Standard [144]
Medium [108]
Plus [180]
Strong [216]
Max [255]
This value influences the time response. For a fast time
response a filter can be best set to “Weak”.
A reading of [0] will be very nervous.
For a more stable reading a filter can be best set to
“standard [144]”
7.2.9 Menu Item “Baud Rate”
There are two baud rates available
19.200
57.600

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
11
/
22
Thermometer man.docx Rev 1.02 UK “23
8 Communication
8.1 Serial connect
The Thermometer has a USB-A connector on the right side.
Communication can be established when connecting the
thermometer to a PC or laptop using the USB connection.
Standard a USB – A to A cable is supplied
8.2 Software Tamcom for Windows
The thermometer can be connected to a Windows PC or
laptop.
If the PC has a COM port available, the thermometer can be
connected directly onto the PC or Laptop.
Use a baud rate setting on the thermometer of 57.600K
8.3 Installing the TAMCOM software is simple.
Double click the file “tamcom.zip”
Double click the executable file tamcom-setup.exe
The installation will now start.
If a com port is available, the screen will look like this

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
12
/
22
Thermometer man.docx Rev 1.02 UK “23
8.4 Starting Tamcom
When the thermometer is connected and the Tamcom
software is started, it will automatically find the thermometer.
When detected, a list of measurements in memory is
displayed. There are three options here:
1: Clear memory (remove all)
2: Select one of the measurements from memory. In this
example click on "10-7-10 2:25" or "11-4-09 23:24" to
load the measurement.
3: Display real time session.
8.4.1 Real time session
1 Temperature
2 Highest and lowest values
Delta measured
Toggle limit lines 3 Limit lines
4 Time axis
5 Store or print
8.4.2 Stored session
When selected, data is loaded from memory. A timer is
displayed (1).
When ready the graph is displayed (2).
Thermometer detected
on COM 5
Thermometer detected
on COM 5
1
2
3
1
2
3
4
5
1
2

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
13
/
22
Thermometer man.docx Rev 1.02 UK “23
8.4.3 Zoom function
Use your right mouse button to select a specific part of the
graph. Keep the button pressed and move button to the left
or right. When released this part of the graph is zoomed in.
Click the "bomb" icon to return to the full graph.
1 Return from zoom
2 Save data onto hard-disk
3 Print data
8.4.4 Saving data
Apart from printing the graph can be exported in "PNG" format
(license free replacement for GIF format) and can be used in
Microsoft Word. Also available is SVG (Scalable Vector
Graphics).
Export to a spreadsheet the data is available as CSV (comma
separated value):
Time,Setpoint,Proces
Value
00:00,10,"23,863"
00:00:01,10,"23,878"
00:00:02,10,"23,889"
00:00:03,10,"23,892"
etc.
8.4.5 Printing data
Printing the graph using the print button (bottom left):
- And sub-menu "Page setup"
- And sub-menu "Appearance
1
2
3

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
14
/
22
Thermometer man.docx Rev 1.02 UK “23
9 RS232 commands
Cmd Hex Parameters Reply
ID &h 49 44 0A nnnnn <LF> Returns type
i.e. “RH02”
TV &h 54 56 0A [0] nnn.nnn[C|F] <LF> Read Temperature.
O : if present, omits C/F suffix
i.e. “20.500C”
&h 32 30 2E 30 30 30 43 0A
TV0 &h 54 56 30
0A
i.e. “23.943071363”
&h 32 33 2E 39 34 33 30 37
31 33 36 33 0A
SC &h 53 43 0A week;year;batch Serial Code
week : kalender week
Year : a=0, b=1, c=2, d=3 etc
index : 1..99
i.e. week 18, 2026, #01
“26CG01”
&h 32 36 43 39 30 38
ER aa dd <LF> read eeprom byte. aa = address
(ascii decimal), dd = result (dec)
EW aa,dd OK <LF> write eeprom byte. aa,dd =
address,data (ascii decimal)
RA nnnn <LF> Read raw ADC value. Max =
8388607
i.e. “3855634”
FV 46 56 0A version text <LF> Read firmware version
i.e. “Tamtherm 4.05”
RT 52 54 0A dd:mm:yy,hh:mm:ss To write time to the TT3
i.e. “29/03/2025,00:43:11”
is written as
“29 03 26 00 43 11”
response is "OK"
&h 52 54 32 39 30 33 32 36
30 30 34 33 31 31 0A
Values are not range
-
checked
RT 52 54 0A dd:mm:yy,hh:mm:ss To read time from the TT3
i.e. time is:
“29/03/2025,00:43:11”
TT3 output is
29/03/23,0:52:20
or
&h32 39 2f 33 2f 32 36 2C
39 3A 35 32 3A 32 30 0D
Leading zero
’
s are skipped
in output from TT3

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
15
/
22
Thermometer man.docx Rev 1.02 UK “23
FR 46 52 0A nn d0..d255 Read 256 byte flash page. nn = page
address in decimal. data returned as
256 binary bytes, with no terminator.
Note : if this command is used while
logging is enabled, spurious results
may be returned if the flash is busy
with a write. Logging should be
stopped (e.g. using the LS
command) before attempting to
download log data.
LS 4C 53 0A nnn <LF> Returns the number of log sessions
in memory. Also stops logging if
currently active
LS i.e. 1st
session:
4C 53 31 0A
nn aaa <LF> Returns flash page address of the
start of session nn. (first session is
1).
Setting n=0 returns the first unused
flash page
Note : this command may take up to
1 sec to complee due to time taken to
search through flash, depending on
flash size and content.
Thermometer operation will be
suspended during this time.
i.e. “3”
OS 4F 53 2D 31
2E 30 30 30
0A
+/-n.nnn OK<LF> Offset Setting in °C
a positive, no sign
Range -3.000 to 3.000
Negative: minus (-) sign
Three digits
i.e. 0.001 will add 0.001 degree
i.e. -0.201 will subtract 0.201 degree
OV 4F 56 0A The offset value will be displayed °C
a positive value, no sign
Range -3.000 to 3.000
Negative value: minus (-) sign
Three digits
i.e. 0.001 will add 0.001 degree
i.e. -0.201 will subtract 0.201 degree

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
16
/
22
Thermometer man.docx Rev 1.02 UK “23
10 Memory and logging
10.1 Memory
The thermometer can save up to 16 sessions.
A session can run until memory is full.
The thermometer will stop logging data
The session is ended when memory is full
10.2 Start logging temperature data
A session can be started or stopped from the menu “Logging”
Press 2 times and select “logging
Press 2 time to select “Start log #”
Where # is the session which becomes active
Press to start logging
Aboard logging menu
Wait for six seconds
Chose No logging and confirm with
When logging is active info is displayed on the 2nd line:
M# L#
Where
M is percentage memory filled with data
L is active session
When logging is active (L#) the logging must be stopped
first in order to be able to switch off the thermometer
Total Memory
The memory can use up to 32.000 measuring points

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
17
/
22
Thermometer man.docx Rev 1.02 UK “23
10.3 Change the interval
When logging with an one second interval this is
60 points per minutes
3.600 per hour
32.000/3.600 = 9 hours
The table shows the total period available for logging using
other sampling intervals
Sample time
Seconds hours of registration
1 9
5 45
10 91
30 273
60 546
Clear memory with the menu option “Clear Logs”
Connect the thermometer to the mains socket (=battery
charger). When logging for multiple hours or longer

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
18
/
22
Thermometer man.docx Rev 1.02 UK “23
10.4 Battery
Charging the battery takes approximately two hrs.
On a full charge the thermometer is capable to work sixteen
hrs.* continuously.
The thermometer can be connected permanently to the
wall socket. However repeatedly cutting power will
initiated forced charging and this may shorten the
battery’s lifetime. The red LED lights when a charging
cycle starts.
When the battery runs empty, a battery sign is displayed. If
this sign is displayed, connect the battery charger.
When the battery is being charged, the red LED on the front
will light.
The LED is switched off when the battery is full.
If the battery is charged before the battery sign is displayed,
less time is needed to charge the battery.
Do not use a charger other than supplied. Following
harms the battery’s capacity and it’s lifetime.
Higher voltage than 9V
Lower voltage than 8V
Current supply <500mA
The charger has following characteristics:
- 9V
- 600mA
- input voltage 100-240~50/60Hz
- Plug 2.0 .. 2.1 x 5mm
* based on new battery
Battery sign,
indicating low
battery
Outside =
“-“
(minus)
Inside =
“+” (Plus)
Wall socket

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
19
/
22
Thermometer man.docx Rev 1.02 UK “23
11 Spare parts list
Ordering code Image Description
10T6096 Works certificate -40 .. +150°
25T2310 PT100
24T0014 9V Adapter*
5,0x2,1mm
28T4189 Battery pack*
28T2039 USB A – A cable

VAT: NL 80 66 34 984 B01
Bank account no.: Rabobank 16 01 00 046
Chamber of commerce 27 16 95 41
IBAN Code: NL95 RABO
0160100046
T. 31 (0) 10 522 43 73
F. 31 (0) 10 521 19 41
www.tamson.com
[email protected]
P.M. Tamson Instruments bv
van 't Hoffstraat 12
2665 JL Bleiswijk
THE NETHERLANDS
Tamson Instruments bv
Page
20
/
22
Thermometer man.docx Rev 1.02 UK “23
12 Dimensions
Dimensions
Remark
Length 147 [mm]
Width 103 [mm]
Height 32 [mm]
Weight*
0.33 [kg]
Power consumption
Adapter 9V / 600mA
Accuracy
Resolution 0.001 [°C]
Accuracy better than ±0.02 [°C] With calibration
Linearity ±0.01 [°C]
Temperature drift
per year 0.001 [°C]
per [°C] ambient 0.0005 [°C]
Working condition
(ambient)
Temperature 20..30 [°C]
Humidity 10..90 [%] relative humidity
Sensor PT100
115x215mm
tip diameter 3mm
