PMV Positioner storage and handling procedures
PMV Positioners are precision instruments which should be stored and
handled accordingly to avoid problems or damage.
Appropriate precautions should be taken to protect units while in storage.
Warehouse storage
Stored in original PMV shipping containers, units should be stored in an
environmentally controlled area, i.e. clean, cool (15-26°C, 6~80°F) and dry,
out of direct sunlight or weather exposure.
Field storage
Note: Once air supply to the positioner is connected and turned on, internal
air bleed will prevent the ingress of moisture and protect the unit from
corrosion. It is recommended that the air supply be left on at all times.
• If units are installed immediately, tum, and leave on, the air supply.
• If positioner must be stored outdoors, tighten all covers which may
loosened in shipment, make sure all open enclosure entry points are sealed.
Positioners should be wrapped and sealed air and watertight with desiccant
insidetheplastic,unitsshouldbesecurelycoveredwithanopaquecoverand
not exposed to direct sunlight, rain or snow.
Potential damage mechanism
Whenunitsarestoredinhot,humidclimates,thedailyheating/coolingcycle
will cause air to expand/ contract and be drawn in and out of the positioner
housing.
Dependentonthelocaltemperaturevariations,humidity,dewpointsandthe
time in storage condensation could occur and accumulate inside causing
erractic operation or failure due to water or corrosion. The potential for
condensationdamage is especiallyhigh in southernclimates and aggravated
if units are exposed to direct sunlight.
For further assistance, please contact your nearest PMV office.

P-1500/P-1700-manual from PMV 14321-99.6
– 4 –
Function
The positioning is based on the principle of balanced forces. One force is
originatedbythesignalpressuretransmittedthroughbellows(25)onbalance
arm (19). The otherforce is from the feed back spring (14) and is proportional
to the level of the lower arm (8).
The lower arm (8) level is determined by the position ofthe cam (6) which is
secured to the spindle (2). The spindle (2) is activated by the cylinder rod.
When these two forces are equal, the balance arm (19) isinacentralneutral
position, as is the spool (30). There is a slight leakage of air past the close
tolerances between the pilot valve parts (29 and 30). A small flow runs from
supply Spast the pilot valve ports into the cylinder through
connections C1 and C2. Another small flow leaks out into the positioner
housing.
The PMVPositioner without cover.For figures of components see EXPLODED
DRAWING on page?)
Assume an equilibrium position
If the control pressure is increased the bellows (25) will be deflected
downwords, compressing the spring (14). The end of the balance arm (19)
moves the spool (30) in the bore of the valve body (29) guiding the
supplyairtotherightside ofthe pistonand, at thesame time, exhaustsair from
the left side of the piston through connection C1 into the positioner housing.
Thecylinderpistonmovestotheleft”rotating the spindle(2)withthecam (6)
clockwise” forcing the lower arm (8) upward compressing the feed-back
spring(14).Thesemotionswillcontinueuntiltheadditionalforcefromspring
(14) on the balance arm (19) overcomes the additional force from the bellows
(25).Thebalancearm(19)willthenreturntoitsneutral,centreposition,aswill
the spool (30). There will be no futher motion. Cylinder position is stable at
this new position.
There is only one cylinder position for each signalpressure value. If an
external force acts upon the cylinderpiston rod, it will move momentarily in
the direction of the force. The cam (6), lower arm (8), spring (14), balance arm
(19) and spool (39) will move so that the pressure difference created in the
cylinder will counter-balance the external force.

P-1500/P-1700-manual from PMV 14321-99.6
– 5 –
The PMV Rotary Positioner
1. To zero the positioner
The zeroing screw is
accessible from the outside.
Backoffthescrewandmove
the cover to one side. Fig 1
Adjust by means of a
screwdriver. The adjusting
screw is provided with a
friction brake and need not
therefore be locked after
adjustment. Fig 2
Air preparation
ThePMVRotaryPositionercanworkwithsupply
pressureup to 10 bar (150 psi). In order to obtain
satisfactory operation and high reliability, the
positioner should be fed with dry, clean oil free
air.
Byconnectingtheairsupplytothepositionervia
a filter 25 microns which is placed as close to the
positioner as possible, the required air quality is
received.
For large pressure variations of the supply air, a
pressure regulator should be mounted between
filter and positioner in order to eliminate the
fluctuations.
Installation
The supply air shall be connected to the port S.
The control pressure shall be connected to port I
while ports C1 and C2 are connected to the
connections of the cylinder.
2. To adjust the Control
Pressure Range
2.1 General
The top end of the spring is
provided with an adjusting
nut.The effective length
of the spnng can be varied by
turning the spring relative to
the nut . For any fixed control
range the actuator will move
more if the effective length of
the spring is increased. Fig 3
A. Long travel
B. Short travel
After the spring length has
been adjusted, the spring
guide must be turned in
relation to the nut so that its
underside is not in contact
with the end of the spring.
Fig 4
A. Incorrect
B. Correct
Figure 1
Figure 2
Figure 3
Figure 4
A B
A B

P-1500/P-1700-manual from PMV 14321-99.6
– 6 –
2.2Toincreasetheactuatortravel
IMPORTANT: Always start
from zero! Make zero
adjustment (se 1). Adjust
slowlythecontrolpressureto
the top value and check the
movement of the actuator.
Should you need moretravel:
Back off the locking screw
which locks the spring to the
adjusting nut. Fig 5
Turn the spring clockwise to
increase the effective length
of the spring. Tighten the
screw. Fig 6
After making an adjustment
of the effective spring length
you must again start by ma-
kingzeroadjustments.Should
large adjustments be nec-
essaryyoumustrearrangethe
position of nut relative to the
spnng guide in order to be
abletomakezeroadjustments
Fig 7
Back off the locking screw
which locks the adjusting nut
to the spring guide.
Turnthespring andthespring
guideanticlock-wiseuntilthe
end of spring is almost in
contactwiththe flatof thetop
spring guide.
Fig 8
Tighten screw (16).
Besurethecontrolpressureis
adjusted to minimum value.
When the zero is correctly
adjusted tum once more the
controlpressureslowlytotop
value and check the
movement of the actuator.
Make further adjustments if
necessary – N.B. a/ways go
back and startfrom the zero
position.
Fig 9
2.3 To reduce the actuator
travel
IMPORTANT: Always start
from zero! Make zero
adjustment (see I. above).
Adjust the control pressure
signal to the top value slowly
and check the movement of
theactuator.Shouldyouneed
less travel:
Please notice: Should large
adjustments be required you
must rearrange the position
of the nut relative to the top
spring guide in order to be
able to reduce the effective
length of the spring
Back off the locking screw.
Fig 10
Turn the spring and the top
spring guide clockwise to
allow space for the free end
of the spring when reducing
the amount of effective
spring length.
Fig 11
Figure 5
Figure 6
Figure 7
Figure 8
Figure 9
Figure 10
Figure 11

P-1500/P-1700-manual from PMV 14321-99.6
– 7 –
Tighten the screw and back
off screw.
Fig 12
Turnthespringrelativetothe
nut for less effective spring.
Fig 13
Tighten the screw and make
zero adjustment (make sure
the control pressure signal is
at zero level). Adjust once
morethecontrolpres-suresig-
nal to top level and check the
movement of the actuator.
Make further adjustments if
necessary.
Fig 14
N.B. After adjustments are
completed please make sure
that screws and are securely
fastened. If these screws are
not accessible, see Section 2.4
below.
3. To change the action
3.1Tochangefromvalveopening
on increasing signal to valve
closing on increasing signal, or
vice- versa, proceed as follows:
Shut off supply and instru-
mental air.
As standard, the positioner is
fitted with an intermediate
piece.
Fig 15
Reverse the flexible tubing
between the positioner ports
Cl and C2.
Removethepositionercover.
Thescrewscanbeleftpartially
threaded into the cover.
Remove the nut that fastens
the cam to the spindle.
Fig 16
Invert the cam, position it to
the desired signal range,
(stamped on the cam lobes),
and install the nut but do not
tighten the nut yet.
Fig 17
Turn on the supply and in-
strumental air.
Make sure the actuator is in
thepositioncorrespondingto
the minimum signal (fully
open for units piped to close
on increasing signal or fully
closed on units piped to open
on increasing signal).
Figure 12
Figure 13
Figure 14
Figure 15
Figure 16
Figure 17
2.4 To turn the top spring guide (18) through 120 degrees
The spring guide can be fitted in three positions in
relationtothebalancearm.Bycompressingthespring,
the spring guide will be released from the balance
arm, and the spring and spring guide can be turned
through 120 degrees in either direction. The spring
guide,nutandspringcanthusalwaysbefittedsothat
the locking screws and will he accessible.

P-1500/P-1700-manual from PMV 14321-99.6
– 8 –
Position the cam as shown.
The ballbearing should not
ride up on the inactive por-
tion of the cam.
Fig 18
NOTE: The cam will turn
slightly with the nut as it is
tightened.Besuretoallowfor
thatslightclock-wiserotation.
4. To clean the valve body
Remove the four screws and
remove the cover.
Remove the screws.
Fig 21
Carefully remove the valve
body.Fit so that the spool
slideseasilyanddoesnotbind
against the balance arm.
Fig 22
Remove the screw retaining
the intermediate piece.
Wash the components and
blowthemcleananddrywith
compressed air. Check that
ports Cl and C2 are clean.
Certain adapters incorporate
filters which cannot be remo-
ved. Such adapters should be
replaced, if necessary.
Check that the O-rings are in
good condition.
Fig 22
Figure 19
Figure 21
Figure 22
Figure 20
Figure 18

P-1500/P-1700-manual from PMV 14321-99.6
– 9 –
Fittheintermediatepieceand
tighten the screw lightly.
Fig 23
Checkthatthebottomedgeof
the intermediate piece is
slightly(0.5-1mm)outsidethe
face in the casing.
Fig 24
Fitthe valvebody with spool.
Take care not to damage the
groove in the spool for the
balance arm.
Fit the screws with the
washers.Pressthevalvebody
against the inter-mediate
piece. Back off I the screw.
Press hard and tighten the
screws. Tighten the screw.
Fig 25
Adjust the starting point by
means of the screw.
Fig 26
5. To replace the bellows
Remove the cover. Remove
the spring with its adjusting
nut and spring guide by
compressingthespring.Rem-
ove the screws and remove
the balance arm. Turn the
bellows back and forth while
with-drawing it out of its
mounting.
Before fitting, the length of
the bellows must be
measured. The length should
be 35mm and should be
adjustedif necessaryby stret-
ching or compressing the
bellows.
Check that the O-ring is in
good condition and take care
when compressing the
bellows while fitting it into
place.
Fig 27
N.B. Hold the part of the
bellowstowhich theO-nngis
fitted when pressing in the
bellows, since the dimension
35 mm may otherwise alter.
Refit the balance arm and the
spring.
6. To zero the indicator
Remove the four screws and remove the cover.
Back off the locking screw and zero the indicator.
Replacethecovertocheckthesettingoftheindicator.
Make fine adjustments if necessary.
Tighten the locking screw. Do not tighten screw too
hard, otherwise the indicator will crack.
Mount the cover and tighten the four screws.
Figure 23
Figure 24
Figure 25
Figure 26
Figure 27

P-1500/P-1700-manual from PMV 14321-99.6
– 10 –
Exploded drawing

P-1500/P-1700-manual from PMV 14321-99.6
– 11 –
Dimension drawing P1500/P-1700

P-1500/P-1700-manual from PMV 14321-99.6
– 12 –
14321/99.6 Ekvator
Distributor
(The information in this manual is subject to change without notice.)
PMV GmbH
Postfach 2310
D-41554 Kaarst
GERMANY
Tel: [phone]
Fax: [phone]
Palmstiernas Svenska AB
Box 21
SE-663 21 Skoghall
SWEDEN
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: www.palmstiernas.se
SUBSIDIARIES:
PMV Controls Ltd
Headlands Business Park
Ringwood
Hampshire BH24 3PB
ENGLAND
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Palmstiernas Instrument AB
Tulegatan 15
SE-113 53 Stockholm
SWEDEN
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: www.pmvpositioners.com
(The information in this brochure is subject to change without notice.)
PMV Regeltechnik GmbH
Losensteinleiten 7
A-4493 Wolfern
AUSTRIA
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
PMV-USA, Inc
1440 Lake Front Circle
Unit 160
The Woodlands, Texas 77380
USA
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: www.pmvusa.com
