PNI PMR R6 User manual

PNI PMR R6
User manual / Manual de usuario / Használati utasítás /
Manuale utente / Instrukcja obsługi / Manual de utilizare

EN
2
SAFETY INFORMATION AND WARNINGS
Read this information before using your radio.
Radio Antenna
Do not use any radio that has a damaged antenna. If a damaged antenna comes in contact with the skin, a minor burn may
result.
Unauthorized antennas, modications, or attachments could damage the radio and violate compliance. Do NOT change or
modify the antenna.
Do NOT hold the antenna when the radio is “IN USE.” Holding the antenna reduces range and may cause bodily harm.
Safety and general use in a vehicle
Check the State and Federal laws and regulations regarding the use of two way radios in the area where you drive, and
always obey them.
Do not place your radio in the area over an airbag or in the air bag deployment area. Air bags inate with great force. If a radio
is placed in the air bag eployment area and the air bag inates, the radio may be propelled with great force and cause serious
unjury to the occupants of the vehicle.
Batteries
All batteries can cause property damage and/or bodily injury such as burns if conductive material such as jewelry, keys, or
beaded chains touches exposed terminals. The material may complete an electrical circuit (short circuit) and become quite hot.
Exercise care in handling any charged battery, particularly when placing it inside a pocket, purse, or other container with metal
objects.
Do not replace batteries in a potentially explosive atmosphere. Contact sparking may occur while installing or removing
batteries and cause an explosion.
Potentially explosive atmospheres
Turn your radio OFF when in any area with a potentially explosive atmosphere. Sparks in such areas could cause an explosion
or re resulting in injury or even death.
NOTE: Areas with potentially explosive atmospheres are often, but not always clearly marked. They include fueling areas such
as below deck on boats;
fuel or chemical transfer or storage facilities; areas where the air contains chemicals or particles, such as grain, dust or metal
powders; and any other area where you would normally be advised to turn o󰀨 your vehicle engine.
Blasting caps and areas
To avoid possible interference with blasting operations, turn your radio OFF near electrical blasting caps or in a “blasting
area” or in areas posted: “Turn o󰀨 the two way radio.” Obey all signs and instructions.
Transmit and receive procedure
Your two-way radio contains a transmitter and a receiver.
To control your exposure and ensure compliance with the general population/uncontrolled environment exposure limits,
always ad here to the following procedure:
• Transmit no more than 50% of the time
• To receive calls, release the PTT button
• To transmit (talk), press the Push to Talk (PTT) button
Transmitting 50% of the time, or less, is important because the radio generates measurable RFenergy exposure only when
transmitting (in terms of measuring standards compliance). Alwayshold the radio approximately 5cm in front of your mouth with
the antenna pointing away from your head.
Electromagnetic Interference/Compatibility
Nearly every electronic device is susceptible to electromagnetic interference (EMI). To avoid the possibility of electromagnetic
interference and/or compatibility conicts, turn o󰀨 your radio in any location where posted notices instruct you to do so such
as health care facilities.
Aircraft
When instructed to do so, turn o󰀨 your radio when onboard an aircraft. Any use of a radio must be in accordance with
applicable regulations per airline crew instructions.
Medical Devices – Pacemakers
The Advanced Medical Technology Association recommends that a minimum separation of 6inches (15cm) be maintained
between a handheld wireless radio and a pacemaker. People with pacemakers should:
• ALWAYS keep the radio more than 15cm from their pacemaker when the radio is turned ON
• Not carry the radio in the breast pocket
• Use the ear opposite the pacemaker to minimize the potential for interference
• Turn the radio OFF immediately if there is any reason to suspect that interference is taking place

EN
3
Medical Devices - Hearing Aids
Some radios may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing
aid manufacturer to discuss alternatives.
Other medical devices
If you use any other personal medical device, consult the manufacturer of your device to determine if it is appropriately
shielded from RF energy.
Your physician may be able to assist you in obtaining this information.
General warnings
Never use your radio outdoors during a thunderstorm. Keep the radio out of reach of babies and young children.
INSTALLATION
1. Remove the belt clip
2. Remove the lid on the back of the appliance.
3. Insert 4 AAA batteries (not included in the package).
4. Position the batteries with the marked polarity in the battery compartment.
5. After placing the batteries in their correct position, replace the cover.
Low battery warning
On the screen of your device, in the bottom right corner is displayed icon which indicates the battery level.
In the case of a discharged battery, the device will emit a sound. If you continue to use the device even if the battery level is1,
the alert sound will continue to sound.
If the battery level drops to 0, the device screen will shut down automatically after 30 seconds. You will hear an error tone
when you press any key.
Transmitting range
The range of action depends on the environment and can be a󰀨ected by forms that can obstruct waves such as hills or
buildings.
Do not try to use two radio stations if the distance between them is less than 1.5 m, otherwise you can create a microphone.
The range of action can be inuenced by concrete structures, often leaf areas and radio equipment in operation.
DEVICE DESCRIPTION
Antenna
PTT
Microphone / earpiece
connector
LCD screen
Menu / Power
Up
Call / Lock
Mycrofon
Down
Enter
Speaker

EN
4
icons description:
88 CTCSS code. Chanegs from 1 to 38 as selected by the user
Battery level. When the bars are reduced, the battery needs to be replaced
TX Transmitting a signal.
RX Receiving a signal.
DCM Dual Watch function is tured on.
VOX VOX function is enabled.
OPERATING THE UNIT
Turning unit on/o󰀨:
1 – To turn the device on, press and hold the MENU / PWR button until a short beep sounds.
2 – To turn o󰀨 the device, hold down the MENU / PWR button until a short beep sounds.
Transmitting
The radio receives the signal continuously, as long as it is on and does not emit. When receiving a signal on the current
channel, the LCD shows “RX”.
1. Hold the PTT (Push to talk) button to speak. As soon as you start to emit, the LCD shows “TX”.
2. Hold the station in the vertical position with the microphone at a distance of 5 cm from the mouth. While holding down
the PTT button, speak in the microphone with a normal tone of voice.
3. Release the PTT button after you have nished talking.
For the other users to receive you, you must be on the same channel with them.
Lock and unlock the device
Hold the CALL key for 3 seconds to lock the device. Hold down the CALL key for 3 seconds to unlock the device
Auto scan
Press and hold the MONI key for 3 seconds to activate automatic scanning.
Press and hold the MONI key for 3 seconds to turn o󰀨 automatic scanning.
Adjusting the volume
The device has 8 preset volume levels. Levels are displayed on the screen.
Press the button to increase the volume or button to decrease the volume.
Changing the channels
You have at most 8 channels. To communicate with another device, you must be on the same channel with it.
Press the MENU / PWR button once; the current channel number will blink on the screen.
While the channel number is blinking, press the button to switch to an upper channel or the button to switch to an
lower channel. Press the PPT (Push to talk) button to conrm channel selection or the MONI button or wait up to 10 seconds
to conrm.
Changing the sub-channels
Press the MENU / PWR button twice. The number of the current sub channel will blink on the screen (1-38CTCSS-CTCSS is a
function that allows a group of people to talk to each other without hearing other users on the same channel or 1-83DCS-DCS
is a digital extension of the CTCSS). Provides 83 coded digital codes, following the 38 CTCSS codes.
While the sub-channel number is blinking, press the button to switch to a sub-channel above or the button to
switch to a channel below.
Press PTT (Push to talk) button to conrm channel setting or the MONI button or wait up to 10 seconds to conrm.
PNI PMR R6 radio is simplex, which means you can not receive while you are transmitting.
FUNCTIONS
To access and customize fthe unctions, press the MENU key.
Enable / Disable Monitor function
This feature allows users to listen to the weak signals on the current channel by pressing a button.

EN
5
Using Monitor function:
To listen continuously, hold down the MONI button. A double beep will be heard, the reception remains open, allowing for both
noise and weak signals to be received. RX appears on the screen. To return to the normal reception mode, hold down the
MONI button.
Send an alert tone
To send an alert tone, briey press the CALL button twice. The alert tone will be automatically emitted for a preset factory time.
The radio returns to standby mode after the alert tone is complete. For high performance, make sure the antenna is directed
upwards.
VOX function
The VOX is an auto-emission feature that is activated by speaking in the microphone without pressing the PTT button.
The PNI PMR R6 radio has this automatic emission function. It will emit only when it detects the sound of your voice or another
sound. Activating the VOX function is not recommended if you intend to use the radio in a noisy or windy environment because
it will emit continuously.
1. Press the MENU / PWR button three times; the LCD will display VX “O󰀨”
2. Press the button or to adjust the sensitivity of the VOX function: 1, 2 or 3
3. When the VOX function is activated, the “VX” icon will be displayed on the screen
NOTE: In VOX mode, the user can speak directly into the microphone thus activating the transmission.
Select the ringtone
This function allows the user to select the ringtone melody.
1. Press the MENU / PWR button four times to select the desired ringtone
2. Press the button or to select the desired ringtone.
3. Press the push to talk (PPT) button to conrm channel setting or the MONI button or wait up to 10 seconds to conrm.
NOTE: 10 ringtones are available.
TOT function (Time out Timer)
To avoid damages caused by long emission
Press the MENU / PWR button ve times, the screen will display OF. While the OF icon is ashing, press or to
select 30 (after 30 seconds of transmission, the radio will shut down), 60 (after 60 seconds of transmission, the radio will
shut down) and OF (to disable the function).
Roger Beep function
Press the MENU / PWR button 6 times. OF icon will appear on the screen. While the OF icon is ashing, press or
to select ON or OFF. To conrm the setting, press the PTT or MONI button or wait for 10 seconds. When the radio is
on, the default setting for Roger Beep is o󰀨.
DCM (Dual Channel Monitor) function
Press the MENU / PWR button 8 times. OF icon will appear on the screen. While the OF icon is ashing, press or
to select ON (enabled) or OF (disable). In this model, the LCD will display DCM at the top when the function is on. By
default, this feature is disabled. To conrm the setting, press the PTT or MONI button or wait for 10 seconds.
TECHNICAL DETAILS:
channels 8
CTCSS Codes 38
DCS codes 83
Battery 4 x AAA
Frequency 446.00625 - 446.09375 MHz
Emission power 0.5 W
POWER VOLTAGE 6 V
Band 12.5 KHz

EN
6
TROUBLESHOOTING
PROBLEM SOLUTION
The radio does not start Check if batteries are not discharged. Make sure the
batteries are positioned correctly. Replace old batteries with
new alkaline AAA batteries (4 pcs)
The reception is weak
Press the button to increase the volume. Received
reception may also be weak due to being out of range.
The range of action is limited If you carry the radio near your body, such as in your pocket
or belt, there is a risk of getting a smaller communication
range. Change the radio position. Open areas provide the
maximum range of action, while concrete structures or
areas with thick foliage or usage in buildings or vehicles
greatly limit the transmission and reception distance. If the
low battery indicator is displayed on the screen, replace the
batteries.
Signal distortion problems The two radio are too far away from each other. Obstacles
interfere with transmission. The optimum distance for
communication is between 3 to 5 km in obstacle-free areas.
The two radio are too close. The recommended minimum
distance is 1.5 m. Increase the distance between the
devices. If you transmit, use a normal tone of voice and hold
the microphone at a distance of 5 to 7 cm from the mouth. If
you receive, reduce the volume to a comfortable level.
LIST OF EUROPEAN FREQUENCIES:
Channel Frequency Channel Frequency Channel Frequency
1 446.00625 4446.04375 7 446.08125
2446.01875 5 446.05625 8 446.09375
3446.03125 6 446.06875
CTCSS CODES
No. displayed Frequency Hz No. displayed Frequency Hz No. displayed Frequency Hz
01 67.0 14 107.2 27 167.9
02 71.9 15 110.9 28 173.8
03 74.4 16 114.8 29 179.9
04 77.0 17 118.8 30 186.2
05 79.7 18 123.0 31 192.8
06 82.5 19 127.3 32 203.5
07 85.4 20 131.8 33 210.7
08 88.5 21 136.5 34 218.1
09 91.5 22 141.3 35 225.7
10 94.8 23 146.2 36 233.6
11 97.4 24 151.4 37 241.8
12 100.0 25 156.7 38 250.3
13 103.5 26 162.2

EN
7
DCS CODES
No Code No Code No Code No Code
01 023 22 131 43 251 64 371
02 025 23 132 44 252 65 411
03 026 24 134 45 255 66 412
04 031 25 143 46 261 67 413
05 032 26 145 47 263 68 423
06 036 27 152 48 265 69 431
07 043 28 155 49 266 70 432
08 047 29 156 50 271 71 445
09 051 30 162 51 274 72 446
10 053 31 165 52 306 73 452
11 054 32 172 53 311 74 454
12 065 33 174 54 315 75 455
13 071 34 205 55 325 76 462
14 072 35 212 56 331 77 464
15 073 36 223 57 332 78 465
16 074 37 225 58 343 79 466
17 114 38 226 59 346 80 503
18 115 39 243 60 351 81 506
19 116 40 244 61 356 82 516
20 122 41 245 62 364 83 523
21 125 42 246 63 365
