BORN TO PERFORM
GeForce®GTX 760 XLR8 by PNY is the new graphics card of choice for gamers—a powerful graphics
card that gives you the fast, smooth, quiet gaming you’re looking for in all your favorite titles. It’s packed
with next-gen features like NVIDIA GeForce Experience™ and GPU Boost 2.0 that let you crank up the
settings in today’s most graphics-intensive games.
PACKAGE INCLUDES
• GeForce®GTX 760 2GB graphics card
• Quick Installation Guide
• Installation DVD, which includes:
- Detailed installation guide
- NVIDIA®Graphics Drivers
- NVIDIA®GeForce®Demos
- PhysX™System Software
• DVI-to-VGA adapter
• 6-pin PCIe to Molex Power Adapter
KEY FEAURES
• NVIDIA®GPU Boost 2.0
• NVIDIA®Adaptive Vertical Sync
• NVIDIA®TXAA Technology
• NVIDIA®FXAA Technology
• NVIDIA®Surround™
• Support for four concurrent
Displays* including:
- Two Dual-Link DVI
- HDMI 1.4b
- DisplayPort 1.2
• Microsoft®DirectX®11.1 (fe atu re 11_0)
• NVIDIA®PhysX®technology
• NVIDIA®3D Vision®-Ready
• NVIDIA®SLI®-Ready
• NVIDIA®Shield™-Ready
• NVIDIA®CUDA®technology
• PCI Express 3.0 support
• OpenGL 4.3 support
• OpenCL
™support
REQUIREMENTS
• PCI Express compliant motherboard
with one dual-width x16 graphics slot
• Two 6-pin PCI Express supplementary
power connectors
• Minimum 500W or greater system
power supply (with a minimum
12V current rating of 30A)
• 300 MB of available hard-disk space
• 2GB system memory
(4GB or higher recommended)
• Microsoft Windows 8, Windows
7, Windows Vista, or Windows XP
Operating System (32 or 64-bit)
• DVD-ROM drive or Internet
connection for installation
• DVI, HDMI, DisplayPort or VGA
compatible monitor
PRODUCT SPECIFICATIONS
GPU GeForce®GTX 760
CUDA Cores 1152
Core Speed 980 MHz
Boost Speed 1033 MHz
MemorySize 2048 MB GDDR5
Memory
Interface 256-bit
Memory
Frequency 6008 MHz (effective)
TDP 170W-Active
SLI 3-Way SLI
Multi-Screen 4 Concurrent Screens*
NVIDIA 3D Surround**
Outputs Two Dual-Link DVI, HDMI
1.4b, DisplayPort 1.2
Resolution 2560×1600 (Digital)
Power Input 2 ×6-pin Aux Input
Bus Type PCI-Express 3.0 16×
UPC 751492567068
Card Dimensions 9.5 ˝× 4.376 ˝ Dual-Slot
Box Dimensions
& Weight
12.5 ˝ × 6.38 ˝ × 2.63 ˝
2.15 lbs.
GPU Boost
2048 MB
GDDR5
PhysX™
by NVIDIA
TXAA
Anti-Aliasing Adaptive V-Sync Lifetime
Warranty***
* 4- & 3- Screen Support only in Windows 8, Windows 7 and Windows Vista.
Windows XP or earlier version will only support dual monitors.
** NVIDIA®3D SURROUND requires additional hardware, please see http://www.NVIDIA.com/get3d for detail information
*** PNY One-Year warranty will be extended to Lifetime of the original purchaser upon completion of product registration.
Product must be registered on PNY’s website http://www.pny.com within 90 days of purchase.
Features and specifications subject to change without notice.
GEFORCE®GTX 760 2GB VCGGTX7602XPB
