POLA HP10 User manual

HP10
SL 3.0
These settings refer to the mode operation of the system and must be made on
initial start-up.
Press - / + together for at least one second: the message C.O.S.t. will be
displayed.
Press than repeatly CLEAR until interested variable's message is displayed
(see table below) : variable value and related message will be displayed.
Press + or - to set a new value and then CLEAR to confirm.
The next system constant will then appear.
You can press CLEAR for a least two second to escape and return to the Run
Mode
COSt PROGRAMMING (System constants)
Handbook
*2) You can correct the readings on the various sensors (+ or -).
*1) tEnP =1 : °C Temperature range.
tEnP =2 : °F Temperature range.
MAIN SETTINGS (Run Mode).
MAXIMUM TEMPERATURE RECORDING VIEW.
Press + :
This message will be displayed followed by
° Maximum temperature recording.
MINIMUM TEMPERATURE RECORDING VIEW.
Press + :
This message will be displayed followed by
° Minimum temperature recording.
MEMORY CLEAR.
Press CLEAR for more two seconds:
This message will be composed on display before
clearingoperation.
Thermometer with recorder
.sseMeulaVgninaeMetoN
PnEt 1= )F°2=,C°1=(noitatneserpererutarepmeT )1*
Et.dA °0.0 )-o+(noitcerrocrosneserutarep
mettupnIC° )2*
HP10
SL 3.0
These settings refer to the mode operation of the system and must be made on
initial start-up.
Press - / + together for at least one second: the message C.O.S.t. will be
displayed.
Press than repeatly CLEAR until interested variable's message is displayed
(see table below) : variable value and related message will be displayed.
Press + or - to set a new value and then CLEAR to confirm.
The next system constant will then appear.
You can press CLEAR for a least two second to escape and return to the Run
Mode
COSt PROGRAMMING (System constants)
Handbook
*2) You can correct the readings on the various sensors (+ or -).
*1) tEnP =1 : °C Temperature range.
tEnP =2 : °F Temperature range.
MAIN SETTINGS (Run Mode).
MAXIMUM TEMPERATURE RECORDING VIEW.
Press + :
This message will be displayed followed by
° Maximum temperature recording.
MINIMUM TEMPERATURE RECORDING VIEW.
Press + :
This message will be displayed followed by
° Minimum temperature recording.
MEMORY CLEAR.
Press CLEAR for more two seconds:
This message will be composed on display before
clearingoperation.
Thermometer with recorder
.sseMeulaVgninaeMetoN
PnEt 1= )F°2=,C°1=(noitatneserpererutarepmeT )1*
Et.dA °0.0 )-o+(noitcerrocrosneserutarep
mettupnIC° )2*

HP10
SX TEMP. PROBE
*Other power voltage if you required
230V LINE *
At delivery this processor is ready programmed with the following (variable) settings.
To return to these settings at any time:
Power off the processor, press CLEAR key and keep it pressed giving power on: release CLEAR
key when on the screen appear boot message.
tEnp=1 Ad.tE=0.0
PRESET PROGRAMS
INSTALLATION
How to connect the sensors
Connectthesensorsprovidedasshown in the diagram. For remote
connections use a standard 0.5-square millimetre two-pole wire for
each sensor, taking great care over the connections, by insulating
and sealing the joins carefully. -O.C.- is displayed when the
temperature sensor wiring is open, -S.C.- is displayed when the
temperature sensor wiring is short circuit.
How to connect the line
Connect 230V line on terminals L-N.
Protect supply with adequate fuse.
HP10
SX TEMP. PROBE
*Other power voltage if you required
230V LINE *
At delivery this processor is ready programmed with the following (variable) settings.
To return to these settings at any time:
Power off the processor, press CLEAR key and keep it pressed giving power on: release CLEAR
key when on the screen appear boot message.
tEnp=1 Ad.tE=0.0
PRESET PROGRAMS
INSTALLATION
How to connect the sensors
Connectthesensorsprovidedasshown in the diagram. For remote
connections use a standard 0.5-square millimetre two-pole wire for
each sensor, taking great care over the connections, by insulating
and sealing the joins carefully. -O.C.- is displayed when the
temperature sensor wiring is open, -S.C.- is displayed when the
temperature sensor wiring is short circuit.
How to connect the line
Connect 230V line on terminals L-N.
Protect supply with adequate fuse.
As it company policy to continually improve the products the Manufacturers
reserve the right to make any modifications thereto without prior notice. They
cannot be held liable for any damage due to malfunction.
19.07.06
As it company policy to continually improve the products the Manufacturers
reserve the right to make any modifications thereto without prior notice. They
cannot be held liable for any damage due to malfunction.
19.07.06
