Polar Electro CH479-A User manual

Model:
CH479-A
15kg Ice Maker
Instruction manual
CH479-A_A5_v1_20230419.indb 1CH479-A_A5_v1_20230419.indb 1 2023/4/19 14:472023/4/19 14:47

2
EN Telephone Helpline: 1300225960
Safety Instructions
• Position on a flat, stable
surface.
• A service agent/qualified
technician should carry out
installation and any repairs
if required. Do not remove
any components or service
panels on this product.
• Consult Local and National
Standards to comply with the
following:
- Health and Safety at Work
Legislation
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
• DO NOT immerse in water,
or use steam/jet washers to
clean the unit.
• DO NOT cover the appliance
when it is operating.
• Always carry, store and
handle the appliance in a
vertical position.
• ONLY use drinking or potable
water when making ice
cubes.
• For indoor use only.
• Replace any unused water in
the tank at least once every
24 hours.
• Keep all packaging away
from children. Dispose of
the packaging in accordance
with the regulations of local
authorities.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved.
• Children shall not play with
the appliance.
• Cleaning and user
maintenance shall not be
made by children without
supervision.
• If the power cord is
damaged, it must be
replaced by a POLAR agent
or a recommended qualified
technician in order to avoid a
hazard.
CH479-A_A5_v1_20230419.indb 2CH479-A_A5_v1_20230419.indb 2 2023/4/19 14:472023/4/19 14:47

3
AUEN
Telephone Helpline: 1300225960
• POLAR recommend that
this appliance should be
periodically tested (at least
annually) by a Competent
Person. Testing should
include, but not be limited
to: Visual Inspection, Polarity
Test, Earth Continuity,
Insulation Continuity and
Functional Testing.
• This appliance is intended
to be used in household and
similar applications such as:
- staff kitchen areas in
shops, offices and other
working environments;
- farm houses;
- by clients in hotels, motels
and other residential type
environments;
- bed and breakfast type
environments;
- catering and similar non-
retail applications.
• Children aged from 3 to 8
years are allowed to load
and unload refrigerating
appliances.
• When positioning the
appliance, ensure the supply
cord is not trapped or
damaged.
• WARNING: Do not locate
multiple portable socket-
outlets or portable power
supplies at the rear of the
appliance.
• Do not run the power cord
carpeting or other heat
insulators. Do not cover the
cord. Keep cord away from
traffic areas, and do not
submerge in water.
• Do not clean your ice maker
with flammable fluids. The
fumes can create a fire
hazard or explosion.
• We do not recommend the
use of an extension cord,
as it may overheat and lead
to a risk of fire. Unplug the
ice maker before cleaning,
making any repairs or
servicing.
Warning: Risk of Fire
flammable materials
• Refrigerant R600a / R290,
is natural gas with high
environmental
compatibility, but
also combustible.
When transporting and
installing, ensure that no
parts of refrigerating circuit
CH479-A_A5_v1_20230419.indb 3CH479-A_A5_v1_20230419.indb 3 2023/4/19 14:472023/4/19 14:47

4
EN Telephone Helpline: 1300225960
are damaged. Refrigerant
leaked from the refrigerating
pipes could ignite. If leaking
is detected, to avoid any
potential source of ignition
(spark, naked flames, etc.),
please open window or door,
and keep good ventilation.
• Do not store explosive
substances such as aerosol
cans with a flammable
propellant in this appliance.
Warning: Keep all
ventilation openings clear
of obstruction. Unit should
not be boxed in without
adequate ventilation.
• Warning: Do not use
mechanical devices or other
means to accelerate the
defrosting process, other
than those recommended by
the manufacturer.
• Warning: Do not damage
the refrigerant circuit.
• Warning: Do not use
electrical appliances inside the
food storage compartments
of the appliance.
Introduction
Please take a few moments to carefully read
through this manual. Correct maintenance and
operation of this machine will provide the best
possible performance from your POLAR product.
The ice maker is designed to make ice and
should not be used as storage to preserve
foods, drinks, etc.
Pack Contents
The following is included:
• Ice Maker
• Removable ice basket
• Ice scoop
• Instruction manual
POLAR prides itself on quality and service, ensuring
that at the time of unpacking the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit,
please contact your POLAR dealer immediately.
Installation
Note: Not for use in vans or trailers, food
trucks or similar vehicles.
If the unit has not been stored or moved in
an upright position, let it stand upright for
approximately 12 hours before operation.
If in doubt allow to stand.
1. Remove the appliance from the packaging and
remove the protective film from all surfaces.
2. To optimize performance and longevity, ensure
a minimum clearance of 2.5cm is maintained
between the unit and walls and other objects,
with a minimum 20cm clearance on the top.
NEVER LOCATE NEXT TO A HEAT SOURCE.
3. If necessary, adjust the screw legs of the ice
maker to make it level. The efficiency of the
ice maker can be reduced if the appliance is
unevenly located.
CH479-A_A5_v1_20230419.indb 4CH479-A_A5_v1_20230419.indb 4 2023/4/19 14:472023/4/19 14:47

5
AUEN
Telephone Helpline: 1300225960
Operation
Control Panel
Ice cube size indicator
Power switch: This switch can control the
mains power supply of the appliance.
Making Ice
Note: Before using for the first time, clean
the water tank, ice basket and ice basket
shelf. Use the first 3 ice making cycle to
flush out the system. Discard the water and
ice created from the first 3 cycles.
Each time the appliance is refilled, the first
ice making cycle is used to reduce the water
temperature. This results in uneven ice cube
production which is perfectly normal. You may wish
to discard ice created in the first two production
cycles.
1. Lift the access lid and fill the water tank up the
level of the ice basket shelf.
2. Connect the appliance to the power and press
the START button.
3. Press the SELECT button repeatedly to scroll
through the ice cube sizes. Stop when the
required size is illuminated.
Note: The ice making cycle takes between
7-18 minutes, depending on the size of
cube selected. Larger cubes will take longer
to produce.
4. The appliance will run a startup routine and
then begin ice production.
Note: If the water level is too low, the
Water Low indicator lights up and the
appliance stops working. Fill the water tank
and the appliance will restart automatically.
5. When the cubes reach the ice sensor the
appliance will stop production. Production
resumes once ice has been removed.
6. Press the STOP button at any time to halt the
ice making process.
Cleaning, Care &
Maintenance
• Always switch off and disconnect the power
supply before cleaning.
• Warm, soapy water is recommended for
cleaning. Cleaning agents may leave harmful
residues. DO NOT wash the base unit, instead
wipe the exterior with a damp cloth.
• Clean the water filter regularly with a small
brush, particularly in hard water areas. The
water filter is located in the pump inlet at the
bottom of the water tank, and can be removed
by pulling out with fingers.
• If the appliance is to be left unused for longer
than 24 hours, loosen the drain screw and
drain the water from the tank.
• The inner removable parts and water tank
should be cleaned regularly.
CH479-A_A5_v1_20230419.indb 5CH479-A_A5_v1_20230419.indb 5 2023/4/19 14:472023/4/19 14:47

6
EN Telephone Helpline: 1300225960
Troubleshooting
A qualified technician must carry out repairs if required.
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly
and switched on
Plug or lead is damaged Replace Plug or lead
Mains power supply fault Check mains power supply
Appliance is noisy or
works intermittently
Power fluctuations Turn off the ice maker and restart after 3
minutes
Ice cubes are sticking
together
Ice making cycle is too long Reset the ice cube size and restart the
appliance
Water tank temperature is too low Empty water tank and refill
Compressor runs but no
ice is made
Refrigerant leak or block in the
refrigerant system
Consult a qualified technician
Descaling
For the best water quality, Polar recommend that a
water filter is installed to the mains water supply,
particularly in hard water areas. Doing so will
reduce the build up of limescale and contaminants
in the water tank thus maintaining energy
efficiency and prolonging the life of the appliance.
To de-scale the appliance:
• Switch off and disconnect the power supply.
• Remove the ice basket and water filter for
cleaning.
• Add dilute cleaner into the water tank. (Note:
Choose ice maker specific cleaner and follow
the manufacturer’s instructions.)
• Clean the water box, evaporator (metal) and
water tank with a soft brush.
EvaporatorWater box
• Loosen the drain screw to drain the solution.
• Flush out the system thoroughly with clean
water to remove any cleaner residue.
• Re-locate all removable parts.
Note: After descaling, use the first 3 ice
making cycles to flush out the system.
Discard the water and ice created from
these initial cycles.
POLAR recommend this appliance is
descaled monthly or more frequently in
hard water area.
To avoid contamination of ice, please respect
the following instructions:
• Opening the door for long periods can cause a
significant increase of the temperature in the
compartments of the appliance.
• Clean regularly surfaces that can come in
contact with ice and accessible drainage
systems.
• Clean water tanks if they have not been used
for 48h.
• If the refrigerating appliance is left empty for
long periods, switch off, defrost, clean, dry,
and leave the door open to prevent mould
developing within the appliance.
CH479-A_A5_v1_20230419.indb 6CH479-A_A5_v1_20230419.indb 6 2023/4/19 14:472023/4/19 14:47

7
AUEN
Telephone Helpline: 1300225960
Fault Probable Cause Solution
Water low
indicator is lit
Water level is low or tank is empty Refill water tank and restart
Water filter is blocked Clean water filter and restart appliance
Ice Full
indicator is lit
Ice basket full Empty the ice basket
Room temperature is too low Move the appliance to a warmer position
+
Water and Ice
Full indicators
flash together
Water box is blocked and cannot
tilt
Disconnect from the power supply.
Remove some of the ice cubes and
gently tilt the water box by hand. Restart
the appliance after 3 minutes
Ice full indicator flashes
once every 4 seconds
Condenser sensor fault Check the sensor connection. If normal,
consult a qualified technician
Ice full indicator flashes
twice every 4 seconds
Ice full sensor fault Check the sensor connection. If normal,
consult a qualified technician
Ice full indicator flashes
thrice every 4 seconds
High condenser temperature due
to fan fault
Check the fan connection. If normal,
consult a qualified technician
Ice cubes are melting Leaving ice in the appliance for
too long time
Transfer ice cubes to a freezer
Technical Specifications
Note: Due to our continuing program of research and development, the specifications herein may be
subject to change without notice.
Model Voltage Power Current Water Tank
Volume
Bin
Storage
Max. Ice Making
Capacity
CH479-A 220-240V~
50Hz
100W 1.08A 3.9 litres 2kg 15kg/24 hours
Model Refrigerant Dimensions
H x W x D mm Weight
CH479-A R600a 28g 414 x 360 x 398 15.2kg
Ice making capacity
(kg/24h)
Ice making time
(min)
Water temperature
(°C)
Ambient temperature
(°C)
14.79 13.29 10 20
13.5 14.32 10 25
12.12 17.03 10 30
8.56 23.2 10 43
15.44 13.22 5 20
13.9 14.3 5 25
12.29 16.65 5 30
8.79 23.08 5 43
CH479-A_A5_v1_20230419.indb 7CH479-A_A5_v1_20230419.indb 7 2023/4/19 14:472023/4/19 14:47

8
EN Telephone Helpline: 1300225960
Electrical Wiring
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
CH479-A_A5_v1_20230419.indb 8CH479-A_A5_v1_20230419.indb 8 2023/4/19 14:472023/4/19 14:47

DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo
Model • Modèle • Modell • Modello
• Modelo
C-Series Countertop Ice Machine 11kg Output
C-Series Countertop Ice Machine 15kg Output
CH478 (-E & -A)
CH479 (-E & -A)
Application of Territory Legislation
& Council Directives(s)
Toepassing van Europese
Richtlijn(en) • Application de la/des
directive(s) du Conseil • Anwendbare
EU-Richtlinie(n) • Applicazione delle
Direttive
• Aplicación de la(s) directiva(s) del
consejo
Low Voltage Directive (LVD) - 2014/35/EU
Electrical Equipment (Safety) Regulations 2016
(BS) EN 60335-1:2012 +A11:2014 +A13:2017
+A1:2019 +A14:2019
(BS) EN 60335-2-24:2010 +A1:2019 +A2:2019
+A11:2020
(BS) EN 62233:2008
Electro-Magnetic Compatibility (EMC) Directive
2014/30/EU - recast of 2004/108/EC
Electromagnetic Compatibility Regulations 2016
(S.I. 2016/1091)
(BS) EN IEC 61000-6-1:2019
(BS) EN 61000-6-3:2007 +A1:2011
Restriction of Hazardous Substances Directive
(RoHS) 2015/863 amending Annex II to Directive
2011/65/EU
Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic
Equipment Regulations 2012 (S.I. 2012/3032)
Electrical Safety
IEC 60335-1:2010 +A1:2013
+A2:2016
IEC 60335-2-24:2010 +A1:2010
+A2:2017
EN 62233:2008
Electromagnetic Compatibility
EN IEC 61000-6-1:2019
EN 61000-6-3:2007 +A1:2011
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante
Polar
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s)
and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und
Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y
estándar(es) arriba mencionadas.
Date • Data • Date • Datum • Data •
Fecha • Data
13th January 2023
Signature • Handtekening •
Signature • Unterschrift Firma •
Firma
Full Name • Volledige naam • Nom
et prénom • Vollständiger Name •
Nome completo • Nombre completo
Ashley Hooper
Eoghan Donnellan
Brendan Denmeade
Position • Functie • Fonction •
Position • Qualifica • Posición
Technical & Quality
Manager
Commercial Manager/
Importer
Commercial Manager/ Responsible
Supplier
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift
des Herstellers • Indirizzo del
produttore • Dirección del fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
Unit 9003,
Blarney Business Park,
Blarney,
Co. Cork
Ireland
15 Bagdally Road,
Campbelltown
NSW 2560
DocuSign Envelope ID: 9B553A82-5955-442D-A8CE-F1E669F04AAC
CH479-A_A5_v1_20230419.indb 9CH479-A_A5_v1_20230419.indb 9 2023/4/19 14:472023/4/19 14:47

CH479-A_A5_v1_20230419.indb 10CH479-A_A5_v1_20230419.indb 10 2023/4/19 14:472023/4/19 14:47

CH479-A_A5_v1_20230419.indb 11CH479-A_A5_v1_20230419.indb 11 2023/4/19 14:472023/4/19 14:47

CH479-A_A5_v1_2023/04/19
http://www.polar-refrigerator.com/
CH479-A_A5_v1_20230419.indb 12CH479-A_A5_v1_20230419.indb 12 2023/4/19 14:472023/4/19 14:47
