Polar Electro T315-A User manual

Model:
T315-A
11kg Ice Maker
Instruction manual
T315-A_A5_v3_20200827.indb 1T315-A_A5_v3_20200827.indb 1 2020/8/27 16:562020/8/27 16:56

2
AU Telephone Helpline: 1300225960
Safety Tips
• Position on a flat, stable
surface.
• A service agent/qualified
technician should carry out
installation and any repairs
if required. Do not remove
any components or service
panels on this product.
• Consult Local and National
Standards to comply with the
following:
- Health and Safety at Work
Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• DO NOT immerse in water,
or use steam/jet washers to
clean the unit.
• DO NOT cover the appliance
when it is operating.
• Always carry, store and
handle the appliance in a
vertical position.
• ONLY use drinking or potable
water when making ice
cubes.
• For indoor use only.
• Replace any unused water in
the tank at least once every
24 hours.
• Keep all packaging away
from children. Dispose of
the packaging in accordance
with the regulations of local
authorities.
• This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory or
mental capabilities, or lack
of experience or knowledge,
unless they have been given
supervision or instruction
concerning the use of the
appliance by a person
responsible for their safety.
• Polar recommends that
this appliance should be
periodically tested (at least
annually) by a Competent
Person. Testing should
include, but not be limited
to: Visual Inspection, Polarity
Test, Earth Continuity (Class
I equipment), Insulation
Continuity and Functional
Test.
• If the power cord is
damaged, it must be
replaced by a POLAR agent
or a recommended qualified
technician in order to avoid a
hazard.
T315-A_A5_v3_20200827.indb 2T315-A_A5_v3_20200827.indb 2 2020/8/27 16:562020/8/27 16:56

3
AU
Telephone Helpline: 1300225960
Warning: Risk of Fire
flammable materials
• Do not store explosive
substances such as aerosol
cans with a flammable
propellant in this appliance.
Warning: Keep
all ventilation
openings clear of
obstruction. Unit
should not be boxed
in without adequate
ventilation.
• Warning: Do not use
mechanical devices or other
means to accelerate the
defrosting process, other
than those recommended by
the manufacturer.
• Warning: Do not damage
the refrigerant circuit.
• Warning: Do not use
electrical appliances
inside the food storage
compartments of the
appliance, unless they are
the type recommended by
the manufacturer.
Introduction
Please take a few moments to carefully read
through this manual. Correct maintenance and
operation of this machine will provide the best
possible performance from your POLAR product.
The ice maker is designed to
make ice and should not be used
as storage to preserve foods,
drinks, etc.
Pack Contents
The following is included:
• Ice Maker
• Removable ice basket
• Ice scoop
• Instruction manual
POLAR prides itself on quality and service, ensuring
that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit,
please contact your POLAR dealer immediately.
Installation
Note: If the unit has not been
stored or moved in an upright
position, let it stand upright for
approximately 12 hours before
operation. If in doubt allow to
stand.
1. Remove the appliance from the packaging and
remove the protective film from all surfaces.
2. When positioning the ice maker, maintain a
distance of 10cm between the appliance and
walls or other objects for ventilation. NEVER
LOCATE NEXT TO OR NEAR A HEAT
SOURCE.
3. If necessary, adjust the screw legs of the ice
maker to make it level. The efficiency of the
ice maker can be reduced if the appliance is
unevenly located.
T315-A_A5_v3_20200827.indb 3T315-A_A5_v3_20200827.indb 3 2020/8/27 16:562020/8/27 16:56

4
AU Telephone Helpline: 1300225960
Operation
Control Panel
Hand button Ice cube size indicator
Power switch: This switch can control the
mains power supply of the appliance.
Making Ice
Note: Before using for the first
time, clean the water tank, ice
basket and ice basket shelf. Use
the first 3 ice making cycle to
flush out the system. Discard
the water and ice created from
the first 3 cycles.
Each time the appliance is refilled, the first
ice making cycle is used to reduce the water
temperature. This results in uneven ice cube
production which is perfectly normal. You may wish
to discard ice created in the first two production
cycles.
1. Lift the access lid and fill the water tank up the
level of the ice basket shelf.
2. Connect the appliance to the power and press
the START button.
3. Press the HAND button repeatedly to scroll
through the ice cube sizes. Stop when the
required size is illuminated.
Note: The ice making cycle takes between
6-12 minutes, depending on the size of
cube selected. Larger cubes will take longer
to produce.
4. The appliance will run a startup routine and
then begin ice production.
Note: If the water level is too low, the
Water Low indicator lights up and the
appliance stops working. Fill the water tank
and the appliance will restart automatically.
5. When the cubes reach the ice sensor the
appliance will stop production. Production
resumes once ice has been removed.
6. Press the STOP button at any time to halt the
ice making process.
Cleaning, Care &
Maintenance
• Always switch off and disconnect the power
supply before cleaning.
• Warm, soapy water is recommended for
cleaning. Cleaning agents may leave harmful
residues. DO NOT wash the base unit, instead
wipe the exterior with a damp cloth.
• A POLAR agent or qualified technician should
carry out repairs if required.
• Clean the water filter regularly with a small
brush, particularly in hard water areas. The
water filter is located in the pump inlet at the
bottom of the water tank, remove by pulling
out with fingers.
T315-A_A5_v3_20200827.indb 4T315-A_A5_v3_20200827.indb 4 2020/8/27 16:562020/8/27 16:56

5
AU
Telephone Helpline: 1300225960
• If the appliance is to be left unused for longer
than 24 hours, loosen the drain screw and
drain the water from the tank.
• The inner removable parts and water tank
should be cleaned regularly.
Descaling
In hard water areas lime scale can build up
within the appliance after prolonged use.
We suggest installing a water softener
before inlet of water in case the supplied
water is hard. The softener could be a
mechanical filter.
To de-scale the appliance:
• Switch off and disconnect the power supply.
• Remove the ice basket and water filter for
cleaning.
• Add dilute cleaner into the water tank. (Note:
Choose ice maker specific cleaner and follow
the manufacturer’s instructions.)
• Clean the water box, evaporator (metal) and
water tank with a soft brush.
EvaporatorWater box
• Loosen the drain screw to drain the solution.
• Flush out the system thoroughly with clean
water to remove any cleaner residue.
• Re-locate all removable parts.
Note: After descaling, use the first 3 ice
making cycles to flush out the system.
Discard the water and ice created from
these initial cycles.
POLAR recommend this appliance is
descaled monthly or more frequently in
hard water area.
Troubleshooting
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly
and switched on
Plug and lead are damaged Call POLAR agent or qualified Technician
Fuse in the plug has blown Replace the plug fuse
Power supply Check power supply
Internal wiring fault Call POLAR agent or qualified Technician
Appliance is noisy or
works intermittently
Power fluctuations Turn off the ice maker and restart after 3
minutes
Water
indicator is lit
Water level is low or tank is empty Refill water tank and restart
Water filter is blocked Clean water filter and restart appliance
Ice Full
indicator is lit
Ice basket full Empty the ice basket
Room temperature is too low Move the appliance to a warmer position
+
Water and Ice
Full indicators
flash together
Water box is blocked and cannot
tilt
Disconnect from the power supply.
Remove some of the ice cubes and
gently tilt the water box by hand. Restart
the appliance after 3 minutes
Ice cubes are sticking
together
Ice making cycle is too long Reset the ice cube size and restart the
appliance
Water tank temperature is too low Empty water tank and refill
Compressor runs but no
ice is made
Refrigerant leak or block in the
refrigerant system
Call POLAR agent or qualified technician
T315-A_A5_v3_20200827.indb 5T315-A_A5_v3_20200827.indb 5 2020/8/27 16:562020/8/27 16:56

6
AU Telephone Helpline: 1300225960
Technical Specifications
Model Voltage Power Current
Water
Tank
Volume
Bin
Storage
Ice Making
Capacity Refrigerant Dimensions H x W x D mm Weight
T315-A 220-240V
50Hz
100W 0.8A 2 litres 1 kg 11kg/24 hours R600a 31g 380 x 305 x 380 12.2 kg
Electrical Wiring
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with
regulatory standards and specifications set by international, independent, and federal
authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
T315-A_A5_v3_20200827.indb 6T315-A_A5_v3_20200827.indb 6 2020/8/27 16:562020/8/27 16:56

DECLARATION OF CONFORMITY
Equipment Type
Manual Fill Ice Cube Maker
Model
T315-A
Legislation
Electrical Safety
Electromagnetic Compatibility
Standards
AS/NZS 60335.1:2011 +A1:2012 +A2:2014 +A3:2015 +A4:2017
AS/NZS 60335.2.24:2010 +A1:2012 +A2:2018
AS /NZS CISPR 14.1:2013
Producer Name
Polar
Producer Address
15 Badgally Road,
Campbelltown,
NSW 2560
I, the undersigned, hereby declare that the equipment specified above conforms to the above Legislation and Standard(s).
Date
24th April 2019
Signature
Full Name
Ashley Hooper
Position
Technical & Quality Manager/ Responsible Supplier
T315-A_A5_v3_20200827.indb 7T315-A_A5_v3_20200827.indb 7 2020/8/27 16:562020/8/27 16:56

T315-A_A5_v3_20200827
http://www.polar-refrigerator.com/
T315-A_A5_v3_20200827.indb 8T315-A_A5_v3_20200827.indb 8 2020/8/27 16:562020/8/27 16:56
