Polar Electro T316-A User manual

Model:
T316-A
Ice Maker
Instruction manual
T316-A_A5_v7_20200907.indb 1T316-A_A5_v7_20200907.indb 1 2020/9/7 14:342020/9/7 14:34

2
AU Telephone Helpline: 1300225960
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components or service panels on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• DO NOT immerse in water, or use steam/jet washers to clean
the unit.
• DO NOT cover the appliance when it is operating.
• Always carry, store and handle the appliance in a vertical
position.
• Never tilt the appliance more than 45° from the vertical.
• ONLY use drinking or potable water when making ice cubes.
• Ensure the water pressure of the connected water supply is
between 100kPa - 400kPa (14.5-58psi).
• For indoor use only.
• Replace any unused water in the tank at least once every 24
hours.
• Keep all packaging away from children. Dispose of the
packaging in accordance with the regulations of local
authorities.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
T316-A_A5_v7_20200907.indb 2T316-A_A5_v7_20200907.indb 2 2020/9/7 14:342020/9/7 14:34

3
AU
Telephone Helpline: 1300225960
• Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• If the power cord is damaged, it must be replaced by a POLAR
agent or a recommended qualified technician in order to avoid
a hazard.
• Polar recommends that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing should
include, but not be limited to: Visual Inspection, Polarity Test,
Earth Continuity, Insulation Continuity and Functional Testing.
• This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
Caution: Risk of Fire
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are the
type recommended by the manufacturer.
T316-A_A5_v7_20200907.indb 3T316-A_A5_v7_20200907.indb 3 2020/9/7 14:342020/9/7 14:34

4
AU Telephone Helpline: 1300225960
Introduction
Please take a few moments to carefully read
through this manual. Correct maintenance and
operation of this machine will provide the best
possible performance from your POLAR product.
Pack Contents
The following is included:
• Ice Maker
• Ice scoop
• Inlet/Outlet hoses
• Sealing washers
• Instruction manual
POLAR prides itself on quality and service, ensuring
that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit,
please contact your POLAR dealer immediately.
Note: Only use the hoses
supplied with the appliance.
Other hoses are not suitable and
should not be used.
Installation
Note: If the unit has not been
stored or moved in an upright
position, let it stand upright for
approximately 12 hours before
operation. If in doubt allow to
stand.
1. Remove the appliance from the packaging and
remove the protective film from all surfaces.
2. Remove the Scoop, Inlet/Outlet hoses and
Sealing Washers from the ice bin.
3. When positioning the ice maker, maintain a
distance of 10cm between the appliance and
walls or other objects for ventilation. NEVER
LOCATE NEXT TO OR NEAR A HEAT
SOURCE.
4. If necessary, adjust the screw legs of the ice
maker to make it level. The efficiency of the
ice maker can be reduced if the appliance is
unevenly located.
For all plumbing installation, it
must comply with requirements
of AS/NZS 3500.1 and
AS/NZS3500.2, and all other
Local Authority Regulations.
Installing the Drain
For T316 only:
• Please note: this model
drains via gravity - no drain
pump supplied. An optional
drain pump is required if
installing this unit lower
than the drain standpipe.
• Ensure the end of the
drainage pipe is situated
lower than the Water Outlet
valve for efficient drainage.
Gravity drain (For T316 only)
5. Connect one end of the corrugated outlet
hose to the water outlet on the rear of the ice
maker.
6. Attach the other end of the hose to a plumbed-
in stand waste pipe or container suitable for
collecting waste water.
T316-A_A5_v7_20200907.indb 4T316-A_A5_v7_20200907.indb 4 2020/9/7 14:342020/9/7 14:34

5
AU
Telephone Helpline: 1300225960
Installing the Cold Water Feed
The highest temperature for the
water to be used: 38°C
7. Place the sealing washers on the water inlet at
the back of the ice maker and attach one end
of the inlet hose.
8. Connect the other end of the inlet hose to the
water supply.
Water inlet
Water outlet
Model: T316
Drainage valve
cap
Operation
Making Ice
Note: Before using for the
first time (or after a period of
inactivity), clean the water tank,
ice basket and ice basket shelf.
Use the first ice making cycle to
flush out the system.
Discard the water and ice
created from the first cycle.
1. Ensure the door is closed fully before use.
2. Press the Power switch to the On position [I].
The RUN light illuminates and the appliance
begins the ice making process. Each ice making
cycle takes approximately 25 minutes.
3. When the cubes reach the ice sensor ice
production stops. Production resumes once ice
has been removed from the bin.
4. Press the Power switch to the Off position [O]
at any time to halt the ice making process.
Note: Ensure metal rack is
pushed as far forward as
possible against plastic ice
curtain to allow ice to fall.
Cleaning, Care &
Maintenance
• Always switch off and disconnect the power
supply before cleaning.
• Warm, soapy water is recommended for
cleaning. Cleaning agents may leave harmful
residues. DO NOT wash the base unit, instead
wipe the exterior with a damp cloth.
• A POLAR agent or qualified technician should
carry out repairs if required.
• Clean the water filter regularly with a small
brush, particularly in hard water areas. The
water filter is located just inside the water inlet
at the back of the appliance.
• If the Ice Maker is to be left unused for longer
than 24 hours, loosen the drain valve cap and
drain the water from the tank.
• The inner removable parts and water tank
should be cleaned regularly.
T316-A_A5_v7_20200907.indb 5T316-A_A5_v7_20200907.indb 5 2020/9/7 14:342020/9/7 14:34

6
AU Telephone Helpline: 1300225960
Automatic Cleaning Function
This Ice Maker is featured with an automatic
cleaning function. When the appliance has
completed up to 1500 ice-making cycles (roughly
after 3-month routine use), the “CLEAN” indicator
light will flash with audible alarm, indicating the
unit needs to be cleaned. It will keep flashing and
alarming until auto-cleaning is started, during
which ice can still be made.
1. Press and hold the “CLEAN” button for 3
seconds. The water box at the top will turn
down and up. When it returns to horizontal
position, press the power switch to O(OFF
position) and unplug the machine. Make sure
no water remains in the water box.
Power switch
CLEAN button CLEAN indicator light
2. Unscrew the drainage valve cap at the right
lower part at the rear. Let the water drain from
the water reservoir thoroughly. Afterwards,
re-locate the drainage cap and screw tight.
Model: T316
Drainage valve
cap
3. Add around 3L dilute cleaner into the reservoir.
Note: Choose ice maker specific cleaner and
follow the manufacturer’s instructions.
Reservoir
4. Plug the unit and press the power switch to I
(ON position).
5. Press and hold the “CLEAN” button for 3
seconds. The “CLEAN” indicator light turns
on. The cleaner in the water reservoir will be
pumped into the water box to start cleaning.
After about 10 minutes, the water box turns
to vertical to drop the cleaner. The appliance
will repeat above procedures twice. Then, the
“CLEAN” indicator light goes out, indicating
auto-cleaning is completed. Note: A cycle
takes about 30 minutes.
6. Turn the unit off and unplug. Remove the
drainage valve cap to empty the water
reservoir.
Note: After auto-cleaning, use
the first 3 ice making cycles to
flush out the system. Discard
the water and ice created from
these initial cycles.
Notes for Descaling:
In hard water areas lime scale can build up
within the appliance after prolonged use.
We suggest installing a water softener
before inlet of water in case the supplied
water is hard. The softener could be a
mechanical filter.
To descale, always choose a suitable
descaler and follow the manufacturer’s
instructions.
POLAR recommend that this appliance
is descaled every 3 months or more
frequently in hard water areas.
T316-A_A5_v7_20200907.indb 6T316-A_A5_v7_20200907.indb 6 2020/9/7 14:342020/9/7 14:34

7
AU
Telephone Helpline: 1300225960
Troubleshooting
Fault Probable Cause Solution
The appliance is not working The unit is not switched on Check the unit is plugged in correctly
and switched on
Plug and lead are damaged Call POLAR agent or qualified
Technician
Fuse in the plug has blown Replace the fuse
Power supply Check power supply
Internal wiring fault Call POLAR agent or qualified
Technician
Ambient temperature
below 10°C
Move appliance to a warmer position
Water supply Check water supply is on and supply
hoses are not blocked
Appliance is noisy or works intermittently Power fluctuations Turn off the ice maker and restart after
3 minutes
Compressor runs but no ice is made Refrigerant leak or block in
the refrigerant system
Call POLAR agent or qualified
technician
Water low light is On Water not connected Connect ice maker to water supply
Water filter is blocked Clean water filter and restart ice maker
Water pressure too low Water pressure should be between
100kPa - 400kPa (14.5-58psi).
Call plumber to check water supply
Ice Full light is On Ice bin full Empty the ice bin
Room temperature is too
low
Move the appliance to a warmer
position
Fault light is On Water box is blocked and
cannot tilt
Or, Motor system fault
Disconnect from the power supply.
Remove some of the ice cubes and
gently tilt the water box. Restart the
ice maker after 3 minutes
If problem still persists, Call POLAR
agent or qualified Technician
Water low, ice full
and fault lights flash
together
When unit on, fault light
flashes once every 6s
Ice sensor fault, cannot
make ice
Check if ice sensor is connected
properly. If normal, call POLAR agent
or qualified technician
When unit on, fault light
is On but “RUN” light Off
When unit on, fault light
flashes twice every 6s
Ambient temperature
sensor fault, cannot make
ice
Check if ambient temperature sensor
is connected properly. If normal, call
POLAR agent or qualified technician
When unit on, ice full
light is On but “RUN”
light Off
When unit on, fault light
flashes thrice every 6s
Water temperature sensor
fault, cannot make ice
Check if water temperature sensor
is connected properly. If normal, call
POLAR agent or qualified technician
When unit on, water
low light is On but
“RUN” light Off
T316-A_A5_v7_20200907.indb 7T316-A_A5_v7_20200907.indb 7 2020/9/7 14:342020/9/7 14:34

8
AU Telephone Helpline: 1300225960
Technical Specifications
Model Voltage Power Current Bin
storage
Max Ice Making
Capacity Refrigerant Dimensions
H x W x D mm Weight
T316-A 220-240V 50Hz 178.5W 1.3A 3.5kg 20kg/24 hours R600a 38g 590 x 380 x 477 24.8kg
Electrical Wiring
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with
regulatory standards and specifications set by international, independent, and federal
authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
T316-A_A5_v7_20200907.indb 8T316-A_A5_v7_20200907.indb 8 2020/9/7 14:342020/9/7 14:34

DECLARATION OF CONFORMITY
•Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
•Declaración de conformidad • Declaração de conformidade
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento
Model • Modèle • Modell • Modello
• Modelo • Malli
G-Series Countertop Ice Machine 20kg Output
G-Series Under Counter Ice Machine 50kg Output
T316
GL192
Application of Territory Legislation &
Council Directives(s)
Toepassing van Europese Richtlijn(en)
• Application de la/des directive(s) du
Conseil • Anwendbare EU-Richtlinie(n)
• Applicazione delle Direttive
• Aplicación de la(s) directiva(s) del
consejo • Aplicação de directiva(s) do
Conselho
Low Voltage Directive (LVD) 2014/35/EU -
recast of 2006/95/EC
EN 60335-1:2012 + AC:2014 + A11:2014 +
A12:2017
EN 60335-2-24:2010 +A1:2019 +A2:2019
EN 62233:2008
Electro-Magnetic Compatibility (EMC)
Directive 2014/30/EU - recast of
2004/108/EC
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
Restriction of Hazardous Substances
Directive (RoHS) 2015/863 amending Annex
II to Directive 2011/65/EU
Electrical Safety
IEC 60335-1:2010 + A1:2013
EN 60335-2-24:2010 +A1:2012
Electromagnetic Compatibility
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante • Nome do fabricante
Polar
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift des
Herstellers • Indirizzo del produttore •
Dirección del fabricante • Morada do
fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
42 North Point
Business Park
New Mallow Road
Cork
Ireland
15 Bagdally Road,
Campbelltown
NSW 2560
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation,
Directive(s) and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und Norm(en)
entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y estándar(es)
arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es)
Directiva(s) e Norma(s)
Date • Data • Date • Datum • Data • Fecha • Data
26th February 2020
Signature • Handtekening • Signature • Unterschrift
Firma • Firma • Assinatura
Full Name • Volledige naam • Nom et prénom •
Vollständiger Name • Nome completo
•Nombre completo • Nome por extenso
Ashley Hooper
Josie Holt
Position • Functie • Fonction • Position • Qualifica
•Posición • Função
Technical & Quality Manager
Commercial Manager/
Responsible Supplier
T316-A_A5_v7_20200907.indb 9T316-A_A5_v7_20200907.indb 9 2020/9/7 14:342020/9/7 14:34

T316-A_A5_v7_20200907.indb 10T316-A_A5_v7_20200907.indb 10 2020/9/7 14:342020/9/7 14:34

T316-A_A5_v7_20200907.indb 11T316-A_A5_v7_20200907.indb 11 2020/9/7 14:342020/9/7 14:34

T316-A_A5_v7_20200907
http://www.polar-refrigerator.com/
T316-A_A5_v7_20200907.indb 12T316-A_A5_v7_20200907.indb 12 2020/9/7 14:342020/9/7 14:34
Other manuals for T316-A
1
Table of contents
Other Polar Electro Ice Maker manuals

Polar Electro
Polar Electro CH478 User manual

Polar Electro
Polar Electro CH479-A User manual

Polar Electro
Polar Electro T316-A User manual

Polar Electro
Polar Electro CH479 User manual

Polar Electro
Polar Electro T316 User manual

Polar Electro
Polar Electro GK031-A User manual

Polar Electro
Polar Electro T315-A User manual

Polar Electro
Polar Electro PIM9W User manual

Polar Electro
Polar Electro G620-A User manual

Polar Electro
Polar Electro UA026 User manual
