Polaris PFT-28s User manual

PFT-28s
Wireless Transmitter (Optional)
Wireless Frequency System: 2.4GHz
Operating Distance: up to 100 meters / 300 feet
Channel: 16 channels
Sync: 1/250s
Transmitter Power: 1 x CR2032 battery
Function: Wireless Flash Trigger
(for camera speed light or studio light)
Wireless Remote Control
(for DSLR camera with remote socket)
Weight: 32g (*without battery)
Dimension: 62.6 x 39.2 x 27.1mm
(*excluding protrusions)
Safety standard CE, FCC, Canada IC
RoHS compliance
1 Slightly press the shutter mode button, the shutter mode indicator
light will ON and display the current mode
2 Press the shutter mode button again to change shutter mode
3 After finish the selecting, the shutter mode indicator will turn off
after 2 seconds
*Specifications and appearance are subject to change without notice due to improvement.
1 Turn the power of camera OFF
2 Connect the shutter release cable to the ACC socket of
transmitter and remote socket of camera body
3 Turn the power of camera ON
4 Press the test button on the transmitter
5 Half press for focus and full press for shutter release
◇Wireless Flash Trigger for camera speed light or studio light
◇Wireless Remote Control for DSLR camera with remote socket
a) Instant Shutter Release
b) BULB/Continuous Shooting
C) Shutter Release Delay
●Name of Parts:
The parts are identified as follow:
1 Shutter Release/Test button 4 Indicator light
2 Shutter mode button 5 Trigger point
3 Shutter mode indicator light 6 Battery cover
7 ACC socket
●Wired Shutter Release:
●Wired Shutter Release:
1 Turn the power of camera and receiver OFF
2 Mount the receiver to the camera hot shoe socket and
connect the shutter release cable to the ACC socket of
receiver and remote socket of camera body
3 Set the channel selector at same position on both the
transmitter and the receiver
*To use multiple camera units, be sure to set all receivers
to the same channel
4 Turn the power of camera and the receiver ON
5 Press the test button on the transmitter
6 Select Shutter Mode
(*refer to a Shutter Mode Setting Section)
7 Half press for focus and full press for shutter release
8 If the transmitter and the receiver status lights are turning
red and your camera shutter release all of the setting are
correct
●Shutter Mode Setting: ●Specifications:

FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: 1) this device may not cause harmful interference, and 2) this device
must accept any interference received, including interference that may cause undesired
operation.
IC STATEMENT
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following
two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of
the device.
Cet appareil est conforme aux CNR exempts de licence d'Industrie Canada. Son fonctionnement est soumis
aux deux conditions suivantes :
( 1 ) Ce dispositif ne peut causer des interférences ; et
( 2 ) Ce dispositif doit accepter toute interférence , y compris les interférences qui peuvent causer un
mauvais fonctionnement de l'appareil.
