DSW SERIES SUBWOOFERS THE BEST BASS ANYWHERE

FEED FORWARD DISTORTION SUPPRESSION TECHNOLOGY
This technology maximizes acoustic output as it reduces audible distortion. Feed Forward is a zero latency system
that maximizes dynamic output of the subwoofer system, without relying on slow responding feedback techniques
or broad band dynamic compression, which squeeze the life out of the low end. What you hear is quick, precise
bass output with minimal audible distortion, even at ground shaking volume levels.
polk
technology
2DSW SERIES LOUDSPEAKERS
DSWmicroPRO
The four DSWmicroPRO Series models are Polk’s new
top-of-the-line powered subwoofers. They feature
proprietary digital engines for spectacular performance
and convenience, as well as unprecedented optimization
for room acoustic and placement conditions with features
like the Polk Room Optimizer (PRO) and Automatic Polk
Room Optimizer (AutoPRO™) systems. All DSWmicroPRO
models are compact designs, significantly smaller than
traditional subwoofers of similar performance. All four
models reflect the latest styling with their grille-free
design. And three of the models have a high-gloss black
lacquer finish for the ultimate in home theater elegance.
The DSWmicroPRO1000 is finished in satin black and
may be painted to match room décor.
DSWmicroPRO 1000, 2000, 3000, 4000
1200 Watt digital amplifiers, massive die-cast aluminum
baskets and 13 lb. motor structures.
A 2 1/2" Glass/Epoxy voice coil former wound with four
layers of heavy gauge aluminum wire to provide the highest
power handling and reliability of any home subwoofer driver
in Polk’s history.
Dual progressive roll spiders tightly control cone motion
for the ultimate in tight, detailed and musical bass.
Klippel Optimized Woofer—enabled Polk engineers to
optimize the woofer’s motor structure, voice coil alignment
and suspension for the best possible performance even
at extreme listening levels.
Bottom-mounted sub-bass radiators augment deep bass
response and output. With 60% more surface area than
a round radiator, the square shape takes full advantage
of the area available on the compact enclosure for higher
efficiency, higher output and lower distortion.
Acoustically inert 1" thick MDF enclosure panels.
Adjustable rubber carpet spike feet for mechanical stability.
12V trigger input (except DSWmicroPRO1000).
IR input (except DSWmicroPRO1000).
Universal voltage operation (120V And 220V).
DSWmicroPRO3000
DSWmicroPRO4000

AUTOPRO (AUTOMATIC POLK ROOM OPTIMIZER)
AutoPRO is an in room optimization system which measures (by means of a supplied microphone) the response peaks created
by standing waves (room modes) and flattens in-room response. AutoPRO preserves the dynamics and transient response of the
woofer system by optimizing the in-room time response of the system rather than simply equalizing the steady state response.
Polk’s unique method effectively eliminates boomy response problems while preserving dynamics and transient response for
bass performance that is tight, musical and punchy.
polk
technology
WWW.POLKAUDIO.COM 3
DSWmicroPRO1000DSWmicroPRO2000
REMOTE CONTROL
Credit card-sized remote control to adjust volume,
phase (0, 90, 180 and 270 degree settings), mute,
and select the PRO presets.
“Night” function compresses the dynamic range of
the woofer’s output so you hear all the low-level bass
detail on the program material without resorting to
loud listening.
“Reset” button on the remote restores the woofer’s
settings to factory presets.
Blue LED behind the woofer’s logo badge blinks to
confirm the subwoofer has received and responded
to the remote’s instructions.
DSWmicroPRO4000
POWERED SUBWOOFER
16 3/4" H X 15 1/2" W X 16 1/2" D (42.5CM H X 39.37CM W X 41.91CM D)
OVERALL FREQUENCY RESPONSE 19Hz - 140kHz.
DSWmicroPRO3000
POWERED SUBWOOFER
14 1/8" H X 12 1/2" W X 13 1/2" D (35.9CM H X 31.75CM W X 34.29CM D)
OVERALL FREQUENCY RESPONSE 25Hz - 200kHz.
DSWmicroPRO2000
POWERED SUBWOOFER
12 5/8" H X 11" W X 12 3/4" D (32.07CM H X 27.94CM W X 32.38CM D)
OVERALL FREQUENCY RESPONSE 29Hz - 200kHz.
DSWmicroPRO1000
POWERED SUBWOOFER
12 5/8" H X 11" W X 12 3/4" D (32CM H X 27.94CM W X 32.39CM D)
OVERALL FREQUENCY RESPONSE 29Hz - 200kHz.
SEE SPECIFICATIONS FOR MORE DETAILED PRODUCT INFORMATION.
BLACK
REMOTE CONTROL

DSWPRO
The all-new DSWPRO Series represents more than a signifi-
cant step forward in subwoofer performance. Rather, with the
incorporation of two proprietary Polk Audio technologies, Feed
Forward and PRO™, each of which clearly offer discernable
benefits—you might want to think of the new subwoofer
performance standard.
DSWPRO400, DSWPRO500, DSWPRO600
Klippel Optimized Woofer motor structure, voice coil alignment
and suspension for the best possible performance even at
extreme listening levels.
Class D Amplifier. The efficiency of a Class D digital amplifier
translates into high-power, and cool, reliable operation with
low distortion.
Polypropylene Cones are stiff yet lightweight for high efficiency
and real precision for tight, punchy bass.
Downward Radiating Slot Port lessens turbulence, noise and
distortion; you get all the bass—every time.
Front-Firing Application Repositionable Feet allow you to orient
the subwoofer on its “back” to turn it into a front-firing woofer
when you want to hide DSWPRO Series subs away in cabinets.
DSWPRO600
POWERED SUBWOOFER
17 1/8" H X 16 1/2" W X 16 1/2" D (43.5CM H X 41.91CM W X 41.91CM D)
OVERALL FREQUENCY RESPONSE 20Hz - 160kHz.
SEE SPECIFICATIONS FOR MORE DETAILED PRODUCT INFORMATION.
BLACK
POLK ROOM OPTIMIZER™ (PRO™)
The DSWPRO Series remote control incorporates the Polk Room Optimizer (PRO) feature, four push-button
room equalization presets that correct for room boundary effects for typical room placements: “Cabinet,”
“Corner,” “Mid-Wall” and “Mid-Room.” No matter where you place your DSWPRO Series Sub, you’re
assured great bass performance.
polk
technology
4DSW SERIES LOUDSPEAKERS
DSWPRO600

polk
technology
WWW.POLKAUDIO.COM 5
Optional grilles available for all models.
Line and speaker level inputs ensure easy hook-up
compatibility with virtually any system; Unfiltered LFE input
for use with low-pass filtered subwoofer output jacks.
Amplifier features—adjustable low-pass crossover,
phase switch and subwoofer volume control to more
easily control your bass output and the sub’s blending
characteristics with your front stage speakers.
Signal-sensing “smart amp” auto ON/OFF circuitry
“knows” when to turn itself on and off.
Rock-solid MDF enclosure construction suppresses enclosure
panel resonance for distortion-free, accurate response.
5-way binding posts give you lots of hookup versatility
and tight, snug connections.
DSWPRO subs are easily paintable to match any room.
DSWPRO500
POWERED SUBWOOFER
16 1/8" H X 15 1/2" W X 15 1/2" D (40.96CM H X 39.37CM W X 39.37CM D)
OVERALL FREQUENCY RESPONSE 23Hz - 160kHz.
SEE SPECIFICATIONS FOR MORE DETAILED PRODUCT INFORMATION.
BLACK
DSWPRO Series subwoofers come with a credit card-
sized remote control and have the following features:
•Adjust subwoofer volume
•4-button phase control (0°, 90°, 180° and 270° settings).
•4-button Polk Room Optimizer (PRO™) presets.
•Mute function.
•Night function, which compresses the dynamic range
of the woofer’s output, so you hear low-level bass
detail at lower volumes.
•Reset button restores the woofer’s settings to factory
presets. Blue LED behind the woofer’s logo badge blinks
to confirm the subwoofer has received and responded
to the remote’s instructions.
•The LED can be turned off.
DSWPRO400
SUBWOOFER
14 5/8" H X 13 3/4" W X 13 3/4" D (37.15CM H X 34.92CM W X 34.92CM D)
OVERALL FREQUENCY RESPONSE 25Hz - 160kHz.
SEE SPECIFICATIONS FOR MORE DETAILED PRODUCT INFORMATION.
BLACK
DSWPRO500 DSWPRO400

POWERED
SUBWOOFERS DSWmicroPRO4000 DSWmicroPRO3000
Driver Complement 1 - 12" (30.5cm) 1 - 10" (25.4cm)
Port Type Quadrilateral Fluid Coupled Bass Radiator Quadrilateral Fluid Coupled Bass Radiator
Frequency Response: Overall / -3dB Limits 19Hz - 140Hz / 24Hz - 90Hz 25Hz - 200Hz / 28Hz - 130Hz
Continuous Power (Average Output) 1200 Watts 1200 Watts
Dynamic Power 2400 Watts 2400 Watts
Crossover Frequency n/a n/a
Inputs speaker level, line, IR, AutoPRO mic, speaker level, line, IR, AutoPRO mic,
12V Trigger & LFE (unfiltered) 12V Trigger & LFE (unfiltered)
Outputs speaker level, line speaker level, line
Magnetic Shielding yes yes
Available Finish gloss black gloss black
Product Weight / Shipping Weight (+/- 3 lbs/kgs) 56.8 lbs each / 56.8 lbs each 44.7 lbs each / 44.7 lbs each
(25.8 kg each / 25.8 kg each) (20.3 kg each / 20.3 kg each)
Dimensions 16 3/4" H x 15 1/2" W x 16 1/2" D 14 1/8" H x 12 1/2" W x 13 1/2" D
42.54cm H x 39.37cm W x 41.91cm D 35.9cm H x 31.75 cm W x 34.29cm D
Feed-Forward Distortion Suppression Technology yes yes
AutoPRO In-Room Optimization System yes yes
PRORoom Boundary Presets yes yes
Remote Control yes yes
IR Input yes yes
POWERED
SUBWOOFERS DSWmicroPRO2000 DSWmicroPRO1000
Driver Complement 1 - 8" (20.32cm) 1 - 8" (20.32cm)
Port Type Quadrilateral Fluid Coupled Bass Radiator Quadrilateral Fluid Coupled Bass Radiator
Frequency Response: Overall / -3dB Limits 29Hz - 200Hz / 32Hz - 140Hz 29Hz - 200Hz / 32Hz - 140Hz
Continuous Power (Average Output) 1200 Watts 1200 Watts
Dynamic Power 2400 Watts 2400 Watts
Crossover Frequency n/a n/a
Inputs speaker level, line, IR, AutoPRO mic, speaker level, line,
12V Trigger & LFE (unfiltered) & LFE (unfiltered)
Outputs speaker level, line speaker level, line
Magnetic Shielding yes yes
Available Finish gloss black gloss black
Product Weight / Shipping Weight (+/- 3 lbs/kgs) 34 lbs each / 34 lbs each 34 lbs each / 34 lbs each
(15.4 kg each / 15.4 kg each) (15.4 kg each / 15.4 kg each)
Dimensions 12 5/8" H x 11" W x 12 3/4" D 12 5/8" H x 11" W x 12 3/4" D
32.07cm H x 27.94cm W x 32.38cm D 32.07cm H x 27.94cm W x 32.38cm D
Active Woofer 8" 8"
Sub Bass Radiator 8" x 8" 8" x 8"
Continuous Power 1200 Watts 1200 Watts
Dynamic Power 2400 Watts 2400 Watts
Feed-Forward Distortion Suppression Technology yes yes
AutoPRO In-Room Optimization System yes no
PRORoom Boundary Presets yes yes
Remote Control yes yes
IR Input yes no
DSW SERIES SUBWOOFERS PRODUCT SPECIFICATIONS

POWERED
SUBWOOFERS DSWPRO600 DSWPRO500 DSWPRO400
Driver Complement 1 - 12" (30.5cm) 1 - 10" (25.4cm) 1 - 8" (20.32cm)
Port Type Downward Radiating Slot Port Downward Radiating Slot Port Downward Radiating Slot Port
Frequency Response: Overall / -3dB Limits 20Hz - 160kHz / 25Hz - 125Hz 23Hz - 160kHz / 30Hz - 125Hz 25Hz - 160kHz / 30Hz - 125Hz
Continuous Power (Average Output) 250 Watts 200 Watts 180 Watts
Dynamic Power 500 Watts 400 Watts 360 Watts
Crossover Frequency n/a n/a n/a
Inputs speaker level, line, speaker level, line, speaker level, line
& LFE (unfiltered) & LFE (unfiltered) & LFE (unfiltered)
Outputs speaker level, line speaker level, line speaker level, line
Magnetic Shielding yes yes yes
Available Finish black black black
Product Weight / Shipping Weight (+/- 3 lbs/kgs) 45 lbs each / 51 lbs each 41 lbs each / 47 lbs each 30 lbs each / 35 lbs each
(20.4 kg each / 23.15 kg each) (18.6 kg each / 21.31 kg each) (13.6 kg each / 15.9 kg each)
Dimensions 17 1/8" H x 16 1/2" W x 16 1/2" D 16 1/8" H x 15 1/2" W x 15 1/2" D 14 5/8" H x 13 3/4" W x 13 3/4" D
43.5cm H x 41.91cm W x 41.91cm D 40.96cm H x 39.37cm W x 39.37cm D 37.15cmHx34.92cm W x 34.92cm D
Driver Complement 12" long throw, magnetically shielded 10" long throw, magnetically shielded 8" long throw, magnetically shielded
Feed-Forward Distortion yes yes yes
proRoom Boundary Presets yes yes yes
Remote Control yes yes yes
We’re fanatics when it comes to providing you useful, accurate information that can help you evaluate our products. But as we all know, we live in an imperfect world. At least some of us do.
That’s why performance specifications and product dimensions are subject to change without notice. For the most current specifications see our website, www.polkaudio.com/home.

8DSW SERIES LOUDSPEAKERS
DSW SERIES SUBWOOFERS THE BEST BASS ANYWHERE
Polk Audio is an award-winning designer and manufacturer of high performance audio products
and the largest audio brand of Directed Electronics, Inc. (NASDAQ,DEIX). Founded in 1972 by three
Johns Hopkins University graduates, Polk Audio holds over 50 patents for advances in audio
design and technology. Polk’s products include loudspeakers and electronic components for
home, auto and marine applications, the first satellite radio home component tuner, the world’s
first audiophile-grade active IP-addressable loudspeaker, the first THX®Ultra2 Certified in-ceiling
loudspeaker and I-Sonic®—the first Entertainment System to include HDTM Radio, XM®Connect
& Play capability and a DVD player. Polk products are available through authorized specialist
consumer electronics retailers worldwide. For more information and the location of a Polk
retailer or distributor in your area, visit www.polkaudio.com or call us at 1-800-377-7655 (USA
and Canada). Outside of North America call [phone].
Polk Audio is a Directed Electronics company which trades on NASDAQ under the symbol DEIX. Investor information can be found at http://investor.directed.com.
Polk Audio, Polk, PowerPort, Dynamic Balance, F/X, Atrium, Big Speaker Sound Without The Big Speaker, High Velocity Compression Drive, Acoustic Resonance Control, ARC Port, Casket Basket,
I-Sonic, SurroundBar & SDA are registered trademarks of Britannia Investment Corporation used under license by Polk Audio, Incorporated. Polk Audio Designs & miDock are trademarks of
Britannia Investment Corporation used under license by Polk Audio, Incorporated.
POLK AUDIO
5601 METRO DRIVE
BALTIMORE, MD 21215
WWW.POLKAUDIO.COM
CUSTOMER SERVICE:
800-377-7655 (USA & CANADA)
410-358-3600 (WORLDWIDE)
COPYRIGHT© APRIL 2008
ALL RIGHTS RESERVED.
