Populas EQUITY BI-LEVEL WORKSTATION User manual

Parts Included
Leg Package:
(4) Legs (2A and 2B)
(4) Leg Top Plates
(2) Feet
(4) Toe Caps
(1) Front Hand-crank Assembly
with Gearbox
(1) Top Crank Assembly
(2) Drive Shaft Assembly
(1) Hardware Bag
Table Package:
(1) Cross Brace
(2) Table Tops
Hardware Bag with:
(2) Cross Brace Brackets
(8) 3⁄8" Cross Brace
Bracket Fasteners
(4) #8 x 13⁄4" Wood Screws
(16) 1⁄4" x 3⁄4" Fasteners
(44) #10 x 1" Screws for
Leg Top Plates
(8) 5⁄16" x 1" Fasteners
(8) 5⁄16" Lock Washer
(4) Levelers (or optional casters)
(1) 5⁄32" Allen Wrench
(1) 3⁄16" Allen Wrench
Hardware
Tools Needed:
#2 Phillips Screwdriver or
Power Driver
ASS E MBLY I NSTR UCTI ONS
ASSEMBLY INSTRUCTIONS
Computer workstation with hand-crank adjustment
EQUITY BI-LEVEL WORKSTATION
ASSEMBLY INSTRUCTIONS

STEP ONE
Unpack and identify all parts.
Place table tops upside down on padded surface and identify front edge.
STEP TWO
Identify the legs (A and B) and their
orientation as shown in the diagram.
Look at the bottom of the leg to
identify the leg letter (A or B).
Legs must be positioned in correct
orientation to operate. Shaft couplers
face inward.
STEP FOUR
Attach feet to legs using four 5⁄16" button
head fasteners and lock washers per foot.
Insert toe caps and levelers.
Shorter length of foot from leg is
toward the front.
STEP THREE
Attach leg top plates to legs using four 1⁄4"
button head fastener per plate as shown.
Leg Top Plates orientation is different
for front table surface and rear table
surface.
There are two sets of plates, (2)14”x3”
and (2)10”x3”. The long plates are for the
Rear Surface (16”), the short plates are
for the Front Surface (14”). All four plates will
line up to the corresponding pre-drilled holes.
Leg B
Leg B
Leg B
Leg A
Leg A
Leveler (x2)
Lock Washer (x4)
5⁄16" Button Head Fastener (x4)
Lock Washer (x4)
Leveler (x2)
Leg B
Leg B

STEP FIVE
Attach cross brace bracket to cross brace
using four #8 13⁄4" screws as shown.
Attach cross brace bracket to rear legs
as shown.
STEP SIX
Slide gear box over hexagonal shaft as
shown for front surface only.
Insert hexagonal shafts fully into legs
(front and rear).
Slide washer flush to connector tube and
center tube between legs.
#10 x 1 3/4" Wood Screw(x2)
#8 x13⁄4" Wood Screw (x2)
Insert fully into
leg (both sides)
Slide gear box over
hexagonal shaft as shown
3⁄8" Button Head Screw
Leg A
Leg B
Leg A
Leg B
#10 x 1” Screw (x2)

STEP SEVEN
Attach mounting plates to tabletops using
#10 x 1" screws.
Attach hand crank brackets to front table
top using #10 x 1” screws.
STEP EIGHT
Gently turn table over and adjust levelers if required.
Insert the topcrank handle through the rear table top directly into the crank tube.
Pull the front crank handle out and raise and lower table. The front crank handle slides underneath the table if desired.
Clean with soft cloth and mild cleaners suitable for furniture.
D
E
LegA
Leg B
LegA
Leg B
#10 x 1" Screw(x6)
#8 x 3/4" Screw (x4)
Detail: E
#10 x 1" Screws (x6)
#10 x 1” Screw (x4)
Detail : E
Leg A
Leg A
Leg B
Leg B
Detail : D
