PORT SML-1145 User manual

Smart Lock User Manual
Model: SML-1145

Table of Contents
In the Box
Product Specications
Features
Preparing the Lock
Installation Instructions
Setting Your Passcode
Lock Records
Remote WiFi Management (Optional)
Troubleshooting
Programming Your Lock
3
6
8
9
10
13
15
19
20
22

In the Box
1.) Front Panel (1) 2.) Back Panel (1) 3.) Latch (1)
4.) Manual Key (2) 5.) Waterproof
Rubber Gasket (2)
6.) Strike (1)
7.) Strike Box (1) 8.) Bushing: M4x30mm
(2)
9.) Bushing: M5x30mm
(2)
3

10.) Sliding
Screws (2)
11.) Mortise Screws: 10x5
(For Aluminum Door) (4) 12.) Mortise
Screws: 25x4mm
(For Wooden Door)
(4)
13.) M4x30mm Screw
for Door Thickness
35mm-55mm
(1 3/8’’- 2 1/16’’) (2)
14.) M4x50mm Screw
for Door Thickness
60mm-65mm
(2 1/8’’-2 1/2’’) (2)
15.) M4x6mm Screws
(For the Back Panel
and Battery Panel) (4)
16.) M5x20mm Screw
for door thickness
35mm-40mm (1 3/8’’)
(1)
17.) M5x30mm Screw for
door thickness
40mm-45mm (1 3/4’’)
(1)
4

18.) M5x50mm Screws
for door thickness
45mm-65mm
(1 3/4’’-2 1/2’’) (1)
19.)Wi Gateway (optional)
(1)
20.) Suction Cup (1)
5

Product Specications
Model SML-1145
Materials 304 Stainless Steel & Zinc Alloy
Front Panel Lock Size 170x70x20mm (6 3/4x 2 3/4x 3/4’’)
Back Panel Lock Size 170x70x20mm (6 3/4x2 3/4x3/4’’)
Lock Weight 1.5KG (3.3 lbs)
Unlocking Methods Bluetooth
Password
Manual Key
WiFi Remote (Optional)
Finish Satin Stainless Steel (SSS)
Satin Black (SBL)
Door Types Metal
Wood
Working Voltage 6V/8x AAA Batteries
Door Thickness to Fit 1 3/8-2 1/2’’
٭Can be installed on up to 4 1/2’’ thick
door using extra long hardware, but extra
cost applies
Data Capacity 150 sets of passcodes
Working Temperature -13°F- 140°F
Working Humidity 20%-90%
Battery Replacement Warning Less than 4.5V
6

Adjustable backset latch (slide the
spindle hub to your desired backset)
(1’’)
(2 3/4’’)
(6 3/4’’)
(3 3/8’’)
(“2 3/8’’)
(3/4’’)
(2 1/4’’)
(1’’)
(2 3/8’’)
(2 3/4’’)
7

Features
Lock/Unlock
• Unlock using Passcode, Bluetooth app (iOS and Android) or
remotely using Wi-Fi (optional)
• The Linnea Smart Lock unlocks with a permanent Master
Passcode
• Bluetooth keys based on duration can be generated and shared
with guests. The mobile app can generate user passcodes, with
validity duration from One-Time, Permanent, or a Duration based
on Date-Time
• Manual key can be used to lock and unlock the door.
• Auto locking time setting option: After successfully unlocking, the
Linnea Smart Lock will re-lock after a period of time (between 5
to 120 seconds). The owner sets this function
• Voice guided lock/unlock alert
Security
• Smart Freeze: After entering the passcode wrong 5 times the
entry lock will freeze for 5 minutes
• Activity Logs: Up to 500 operational records saving in the lock
• Anti-Theft Passcode: Decoy digits can be ADDED to passcode
when entered to prevent passcode from being exposed to the
person standing next to the user
• Tamper Alarm: The lock will sound if intruders try to pry the lock
from the door
Other Features
• 304 Stainless Steel lever and panel
• 304 Stainless Steel and Zinc lock body and latch
• Easy switch from Passage mode and Privacy mode
• Emergency Power Supply through USB
• Unlimited e-key generation capability
• Only the owner can authorize administrators
• Authorized administrator cannot authorize others
• Works with Google Home
8
**Additional features can be found during the programming process

Preparing the Lock
Set up the levers to match the swing hand of the door.
Exterior Panel:
Remove the 4
screws.
• For Left Swing:
Turn lever to left
and set
• For Right Swing:
Turn lever to right
and set
Put the screws back
and tighten
Interior Panel:
Remove the 4
screws.
• For Left Swing:
Turn lever to left
and set
• For Right Swing:
Turn lever to right
and set
Put the screws back
and tighten
9

Installation Instructions
Install Latch
1) Use the template enclosed to cut
holes for the door.
٭It is important to follow the template
2) Adjust the latch to the desired
backset (2 3/8’’ or 2 3/4’’)
3) Install the latch using the 25x4mm
(Parts #12) for wood doors and
10x5mm (Parts #11) screws for
aluminum doors
Install Exterior Panel
1) Install the M4x30mm (Part #8)
bushing on the bottom two bolts next
to the spindle
2) Screw the 16x5mm (Part #10)
machine screw into the M5x30mm
threaded bushing, then insert into the
slot shown. Adjust the height based on
the distance of the smaller hole and
tighten
3) Install one of the waterproof rubber
gasket (Part #5)
4) Insert the preinstalled spindle into
the door, keeping the arrow on the
spindle facing the same direction of the
latch.
٭ The two bottom bushing next to the
spindle and top bushing need to be
inserted through the hole
simultaneously (Make sure to insert the
wire through the top hole).
10

Installing Interior Panel and Wire
1) Install the second waterproof
rubber gasket (Part #5)
2) Connect the wires to the exterior
panel wire (just plug in and click)
3) Connect the interior panel to the
exterior panel using the M4 screws
(Parts 13 and 14) (pick the desired
length based on the door thickness)
that goes through the latch and
screws onto the bushing
4) Do the same process using the M5
screws (Part #16, 17 and 18) that
goes through the top hole and
connects to the bushing. (Make sure
to tighten screws all the way so it
doesn’t slide.)
Install Interior Panel
1) Remove the glass battery cover
using the suction cup (Part #20)
2) Install the interior case using the
(4) M4x6mm screws (Parts #15)
11

Install the Battery
1) Install (8) new AAA batteries into
the battery chamber
Reinstall the Battery Cover
1) Put the battery cover back
12

Programming Your Lock
1) Search for TTLock in the App Store or Google Play to download
Login Register
Phone number/Email
Password
Login
Forgot Password?
Register
Phone Email
Country/Region American Samoa+1684
Enter your Phone number
Password between 6-20 characters
Confirm Password
Verification Code Get Code
Register
Login Register
X
18520265893
.........
Login
Forgot Password?
13

2) Register a new account with your email address or login with an
existing account (skip this step if you have an existing account)
3) Touch the glass panel to light, click “+Add Lock’’ on the app
4) The lock nearby will appear on the phone screen, click “+”
5) Rename the lock if you wish (EX: front door, back door, oce, etc.)
6) Wait for “lock added” conrmation (Often times it will be a soft sound
once conrmation is received.
7) Set up your new password, erasing the factory, generic password
٭TTLock supports multiple types of lock devices. You must rst select the lock
type. The lock needs to be added by the app, after entering the add mode.
Generally, a lock that has not been added (as long as the lock keyboard has
been touched) will enter the add mode. Locks that have already been added
need to be deleted on the app before they can be added to the app
TTLock
Press to Add Lock
+
The phone must be within 6 feet of the
Smart Lock during the Pairing process
Choose Lock Type
All Locks
Scan all types of locks
Door Lock Padlock
Safe Lock Lock
Cylinder
Parking
Lock
Bicycle
Lock
Remote
Control
Nearby Locks
BL01_63230b +
S202C_f4324e
Add Lock
Lock Name
H50
OK
14

Bluetooth Management
Make sure there is no problem with Bluetooth communication. After
connecting the phone to the door lock, click “ ” to unlock (the phone (the phone
needs to be within 16 feet of the door to unlock)needs to be within 16 feet of the door to unlock)
Setting Your Passcode
Passcodes can also be used to unlock the door. After entering the
passcode, press the unlock button in the lower right corner to unlock.
Passcode can be: permanent, time-limited, single, clear, cycle and
custom.
TTLock
S31A
Touch to Unlock. Long Press to Lock
Generate Passcode
anent Timed One-Time Erase Custom Recurri
Permanent
Start Time 2020-03-06 09:00
End Time 2020-03-06 09:00
Name Enter a name for this passcode
You can Configure the Customized Passcode via
Bluetooth or Remotely via a Gateway
Set Passcode
15

٭You can share the
Passcode to other
users via WeChat, SMS,
Email, Messenger and
WhatsApp
Passcode Type Description
Permanent General Use passcode
Time-Limited Passcode with set time frame
Single Single-use short term password
Clear Generate new passcode while
deleting previous passcodes
Cycle Reguarly occuring passcode
Custom Set your own passcode and time
frame
Passcode Types
Passcode Management
All generated passwords can be viewed and managed in the password
management module. This includes a password change, password
deletion, password reset and password unlock record.
You can Configure the Customized Passcode via
Bluetooth or Remotely via a Gateway
Generate Passcode
anent Timed One-Time Erase Custom Re
Permanent
Nam 1
4-9 Digits in length
Cancel OK
Set Passcode
%
-
+
x
1 2 3
4 5 6
7 8 9
0

,
@
Generate Passcode
anent Timed One-Time Erase Custom Recurruring
Succeeded. The passcode is
25097
Complete
Share
16

Sending E Keys
1) Click on “ ” as shown in the gure below; you can send the
eKey to other users of TTLock to authorize the unlock (the receiver must
download the app and set up an account)
2) Select e-key format (timed, permanent, one-time, recurring)
3) Enter the recipent’s account of TTLock, then set the name and
eective time of the eKey. (The admin can choose to allow remote un-
locking or disallowing, authorized administrator or not, as shown below)
4) Then click “Send”. (The recipient’s account has Bluetooth unlock
permission. Only the administrator can authorize the ordinary key.)
5) After the authorization is successful, the authorized key is the same as
the administrator’s interface.
٭You can send keys, passwords, etc. to others; however the authorized
administrator can not authorize others.
Send eKey
Timed Permanent One-Time Recurring
Recipient Enter Recipient’s Account
Name Please enter a name for this eKey
Allow Remote Unlocking
Authorized Admin
Send
17
TTLock
Door Name
Touch to Unlock, Long Press to Lock
TTLock
S31A
Touch to Unlock. Long Press to Lock

Managing E Keys
1) Click “ ” to manage the eKeys you send. The key management
here refers to the Bluetooth key management.
2) After the administrator has successfully added the lock, the
administrator will have the highest rights of the lock. The administrator
can do the following:
• They can send keys to other people, specify the time limit, and select
time-limited, permanent or single-time Bluetooth key permissions
• Add management of expiring keys (reminders of expired keys)
• The administrator can manage all keys issued by them including:
* Clearing the keys
* Resetting the keys
* Sending the keys
* Adjusting the validity period of the keys
◊ Lock users about to expire (Yellow shows the number of days
remaining)
◊ Expiration Reminders are shown in red
* View unlock records of the keys
You can authorize admin
status to other users
Authorized Admin
+
Create Admin
Admin List
18

Lock Records
Click “ “ as shown below. With “Lock Records” you can view: eKeys,
saved passcodes and unlock history
eKeys
...
Li
2020.03.06 11:14-2021.03.06 11:14
Pending...
Passcodes
...
...
...
...
...
...
...
...
...
...
444335
2020.01.14 15:00- 2020.01.14 16:00 Timed
Invalid
23175003
2020.01.14 15:00 One-Time
Invalid
1
2020.01.14 10:54 Permanent Custom
Records
Refresh Records
Search
2019-07-12
18050066613
11:28:56 unlock with app success
19
TTLock
S31A
Touch to Unlock. Long Press to Lock
