EVO
TM4 Touch Monitor
The EVO TM4 Touch Screen Monitor features features state-of-the-art Tru-Flat Resistive
Technology. The zero bezel design eliminates the frame found on traditional monitors,
creating a seamless, smooth surface. The screen is easy to clean and is resistant to water,
dust, grease, and food build-up, making it the ideal choice for retail or restaurant settings.
The TM4’s aluminum alloy frame and stand can withstand the harshest of environments.
• 15” Tru-Flat Touchscreen support gestures
• Built in cable management keeps cords out of site
• IP54 Rating - Resistant to dust buildup and splashing water
• Sturdy die-cut aluminum alloy frame provides bump-free operation
• 3 Year Advanced Replacement Protection comes standard
Key Features

PART NUMBER EVO-TM4C
PANEL SIZE 15” TFT Active Matrix Display
Bezel Type Tru-Flat
Touch Screen 5-Wire Resistive, 50 millions taps per location
Max Resolution 1024 X 768
DISPLAY
PC Video Interface Analog RGB (VGA)
Brightness 250 nits
Colors 16.7 million colors
Controls Power on/off , auto adjustment(+/-)
Viewing Angle 1600
Housing Die Cut Aluminum
PHYSICAL
Dimensions 14.21”(W) x 9.79”(H) x 13.27”(D)
Weight 14.33 lbs
USB 1x USB 2.0 (TypeA), 1x USB 2.0 (Type B to PC)
Serial/COM 2 x COM 1 xDB-9/F (to PC), 1 x RJ-45 (to VFD)
Tilt Angle 0oto 900
Housing Color Black
Stand Style Cable Management Base
Mounting Options Desktop Placement, VESA 100mm x 100mm
ELECTRICAL
Adapter Output 36W 12 V, 3A
ENVIROMENTAL
Ingress Protection Rating IP54 - Resistant to dust buildup and splashing water
Temperature Operating 320 F to 1040 F
Humidity 5% - 95% non-condensing
WARRANTY 3 Year Limited
CERTIFICATIONS FCC Class A, CE, LVD, RoHs
OPERATING SYSTEM DOS/WIN NT 4/WIN 9X/WIN ME/WIN 2000/WIN CE/XP/VISTA/WIN 7/Linux
ACCESSORIES
EVO-MR4-U 3 Track MSR with USB interface
EVO-BR4 Inegrated Bio Reader
EVO-RD4-LCD8 Integrated Rear Display, 8.4” LCD, VGA
EVO-RD4-VFD Integrated Rear Display, VFD
EVO-XZ4-M100 Universal VESA Mount for All TouchPC & Touch Monitors
EVO Touch Monitor Specications
9.79”
13.27”
14.21”
POS-X, Inc. 1975 Midway Lane Suite O Bellingham, WA 98226
www.pos-x.com [email protected] tel [phone] fax [phone]
EVO-TM4
