POSIFLEX MT-4210A User manual

1
MT-4210A/R
Package Contents
MT-4210A/R………………………...(x1)
Pistol grip…………………………….(x1)
5V/15W power adaptor……...……....(x1)
Stylus………………………………...(x1)
RB-3000 Battery pack for pistol grip..(x1)
User manual………………………….(x1)
Barcode scanner user manual………..(x1)
MT-4210A/H
Package Contents
MT-4210A/H………………………...(x1)
5V/15W power adaptor……………...(x1)
Stylus………………………………...(x1)
User manual………………………….(x1)
MT-4210A is required to be charged over 8 hours when being
used for the first time.
MT-4210A
Mobile Terminal System
User Manual
12570900020 Ver. B0
http://www.posiflex.com

2
SOME IMPORTANT NOTES
FCC NOTES
This system meets industry & government requirements and applicable
standards. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions
manual, may cause interference to radio communications. It has been tested
and found to comply with limits for a Class A digital device pursuant to
subpart B of Part 15 of FCC Rules, which are designed to provide reasonable
protection against interference when operated in a commercial environment.
Operation of this equipment in a residential area is likely to cause interference
in which case the user at his own expense will be required to take whatever
measures to correct the interference.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CE CLASS A WARNING
This equipment is compliant with Class A of CISPR 32. In a residential
environment this equipment may cause radio interference.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any
person other than the authorized technicians. The user should consult his/her
dealer for the problem happening. Warranty voids if the user does not follow
the instructions in application of this merchandise. The manufacturer is by no
means responsible for any damage or hazard caused by improper application.
警告使用者
這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾，在這種情
況下，使用者會被要求採取某些適當的對策。

3
BATTERY CAUTION NOTES
Dispose of used batteries according to the instructions.
Replacement of a battery with an incorrect type that can defeat a
safeguard (for example, in the case of some lithium battery types)
Disposal of a battery into fire or a hot oven, or mechanically crushing
or cutting of a battery that can result in an explosion.
Leaving a battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of flammable
liquid or gas.
A battery subjected to extremely low air pressure that may result in an
explosion or the leakage of flammable liquid or gas.
BATTERIE ATTENTION NOTES
Jetez les piles usagées conformément aux instructions.
Remplacement d'une batterie avec un type incorrect qui peut annuler
une sauvegarde (par exemple, dans le cas de certains types de batterie
au lithium)
Mise au rebut d'une batterie dans le feu ou dans un four chaud, ou
écrasement ou coupure mécanique d'une batterie pouvant entraîner une
explosion.
Laisser une batterie dans un environnement environnant à des
températures extrêmement élevées pouvant entraîner une explosion ou
la fuite de liquide ou de gaz inflammable.
Une batterie soumise à une pression atmosphérique extrêmement basse
pouvant provoquer une explosion ou une fuite de liquide ou de gaz
inflammable.
警告
本電池如果更換不正確會有爆炸的危險，請依製造商說明書處理用過之
電池。

4
Product Feature
Ergonomic Design
Pistol grip shape handle is ergonomically designed for easy handling of the
tablet.
Extra Protection
Hand strap strengthens the stability and eases user’s fatigue during the hours of
work.
All-in-one Solution
Optional dock station equips with a built-in 3” thermal printer and various I/O
connectivity; once the tablet is integrated with the dock station, an all-in-one
POS is instantly at your disposal.
Versatile Function
MSR attachment and 1D or 2D barcode scanner built in the pistol grip; MT-
4210A offers more than just mobility but versatility.
Long Hour Operation
MT-4210A is designed with advanced power saving technology that provides
long battery life for daily operation. The pistol grip also houses a removable
battery that can vastly extend the overall operating time.
Views of MT-4210A/H
Front View
Rear View
LED Indicator
Rear Camera
Speaker
Hand strap
Expansion Slot for
Optional Attachment
Projected Capacitive
Touch Screen
Rubber Cushion
Rubber Cushion

5
Bottom Side View
Left Side View
microUSB Port
Power Button
Nano SIM Card Slot
(Only available for MT-4210A series
with 4G module)
Micro SD Card Slot
Mic-in/Line-Out
Combo Jack
Docking Station Connector
5VDC-IN Power Jack
Docking Station Locking Hole
Smart Card Reader
(Optional)

6
Loading RB-3000 Battery Pack and a Stylus into PG-200E
(for MT-4210A/R)
The MT-4210A/R working with PG-200E pistol grip supports 1D CCD
barcode scanner, 1D laser barcode scanner, and 2D imager. Before the
scanner/imager can be initiated, it is required to install the RB-3000 battery
pack and a stylus in the battery compartment inside the pistol grip. Please
follow the steps listed below to finish the installation.
1. Press down the lever and then push up the cover for battery
compartment as shown in the figure.
2. To replace the existing battery, gently push
the metal clip outwards to release the
battery. If you are installing the battery for
the first time, please skip to the next step.
3. After having the rail on the battery pack
aligned with battery clip, push down the
battery pack into battery compartment.
4. Push down the cover to close the battery
compartment.
Metal clip

7
Connecting the Pistol Grip onto MT-4210A/R
The MT-4210A/R model is equipped with an additional pistol grip which aims
to help users grip the terminal more easily while they are operating the scanner.
Please refer to the following instructions to install the pistol grip onto the tablet.
1. To attach the pistol grip to the tablet, align the arrow head on the top
side of the pistol grip with the tail of the arrow on the rear of the
tablet.
2. After ensuring the pistol grip is well
attached to the tablet, push the pistol
grip in the direction indicated by the
arrow as shown in the figure.
3. Make sure the head of the down arrow on the pistol grip is supposed to
be aligned with the head of the arrow on the rear side of the tablet as
the below figure shows, which indicates the pistol grip is well
mounted.
4. To check how much battery capacity
remains in PG-200 pistol grip, press the
battery capacity checking button on the
pistol grip to show the current battery
capacity level through the LED
indicator.

8
Replacing the Pistol Grip with a Hand Strap Cover (Optional)
The hand strap cover is an optional peripheral designed for users to easily hold
the tablet for operation. To replace the pistol grip with a hand strap cover,
follow the steps listed below.
1. While pushing the release lever to the left
(1), slide the pistol grip in the direction
indicated by the arrow in the figure (2).
2. Pull the pistol grip off from the tablet.
3. Align the hand strap cover with the grooves
on the rear side of the table.
4. Make sure that the hand strap cover is well
attached to the rear side of the tablet.
5. Slide the hand strap cover up in the
direction indicated by the arrow until it is
clicked into place.

9
6. Fasten the hand strap cover onto the tablet
using a screw.
Replacing the Hand Strap Cover with a Pistol Grip (Optional)
Please follow the below steps to replace the hand strap cover with a pistol grip.
1. Loosen the screw to remove the hand strap
cover from the tablet.
2. Slide the hand strap cover down in the
direction indicated by the arrow.
3. Remove the hand strap cover from the rear
side of the tablet.
4. Go through the Connecting the Pistol Grip onto MT-4210A/R
section which is described previously to complete the installation of
the pistol grip onto the tablet.

10
Installing a microSD Card and a SIM Card in MT-4210A
Please follow the below steps complete the installation of a micro SD card and
a SIM card.
1. Turn off MT-4210A completely. Then, pull off the rubber cover
located on the left side of your tablet to find a micro SD card slot
and a nano-SIM card slot.
2. Have the rear of the tablet face towards you to install the microSD
card and the nano-SIM card.
2.1. To insert the microSD card into the
microSD card slot, make sure the
side with the golden finger of the
card faces downwards, and then slide
the card down into the slot.
2.2. Similarly, to install the nano-SIM
card, push the nano-SIM card into
the nano-SIM card slot with its gold
contacts facing towards you.
3. Pull off the rubber cover to close the compartment.
4. If you attempt to release a micro SD card or SIM card from the
slot, push the card with your fingertip to slide it out.
Charging the Battery
Below are some cautionary advices you need to keep in mind while you
attempt to charge the battery.
1. MT-4210A is required to be charged over 8 hours when being used for
the first time.
2. When the low battery warning message appears as shown below,
please fully charge the battery to avoid data loss.
3. When the low battery capacity indicator on the pistol grip beams or
low battery warning message appears, please charge or replace the
battery for the pistol grip immediately.

11
4. Only charge the battery with power adapter which comes with
MT-4210A. Using a different power adapter may damage your device.
5. When the battery is running very low (less than 6 percent of battery
capacity), the system will be automatically shut down to protect the
battery from being over-discharged.
Please go through the following instructions to charge MT-4210A using the
power adapter.
For MT-4210A/R
In considering the battery life could be consumed drastically under heavy
usage, you may also choose to purchase either another replacement battery,
RB-3000, for the pistol grip, or the battery charger, CS-100, for rapidly
charging the replacement battery.
1. Connect the power connector of the
power adaptor to the tablet.
2. Plug the AC power adaptor cord into an electrical outlet. In general,
the tablet battery will be charged first. Once the process of charging
the tablet is complete, the pistol grip battery will then be charged.
For MT-4210A/H
1. Find the power jack on the left side of your tablet, and then connect
the power connector of the power adaptor to it.
2. Plug the AC power adaptor cord into an electrical outlet to initiate the
charging process.
LED Status Indicator
LED status indicator is specially designed to deliver special message regarding
the current system status and battery life. The blow chart enumerates all the
possible LED indicators and its meaning for your reference.
LED Status
System Status
Descriptions
Solid blue
ON
￭System booting.
Solid Orange
ON
￭System is being charged.
Blinking Orange
ON
￭Battery charging error occurs.
OFF
ON
￭System enters sleep mode.
￭System has been booted to Android.
￭Battery is fully charged.
OFF
OFF
￭System powers off.

12
Powering ON/OFF MT-4210A
Powering ON MT-4210A
To power on MT-4210A for the first time, connect the power adapter to
the MT-4210A and then keep pressing the power button of the machine for
around 5 seconds. If the terminal falls into the sleep mode after remaining
idle for a specific period of time, push the power button to wake the device
up.
Powering OFF MT-4210A
To power off MT-4210A, press and hold the power button for around 2
seconds and then tap Power off.
In the case the system cannot be successfully powered off, you
need to press and hold the power button for at least 14 seconds.
In the case the system halts for unknown reasons, you are advised
to hold down the button until a system shutdown is initiated.
Operating TA-220/300 Magnetic Stripe Reader (Optional)
MT-4210A model also offers MSR solutions. As optional items, TA-220/300
both allow you to integrate built-in MSR into MT-series tablet. However, TA-
220 mainly supports MSR with RFID but TA-300 is an attachment combined
with three-track MSR and fingerprint sensor.
Please go through the following instructions on how to operate magnetic stripe
reader provided via TA-220/300.
1. Have the side with the magnetic stripe of a card
face the touch panel of the tablet.
2. Swipe the magnetic stripe card along the track
of the reader from top to bottom or from
bottom to top.

13
Operating the 1D/2D Scanner (for MT-4210A/R)
MT-4210A/R model is equipped with an optional
1D CCD, 1D Laser, or 2D scanner that features
1D barcode and/or 2D image scanning. It also
supports two types of USB interfaces, USB HID
or USB Virtual COM, and the scanner is
generally set to USB HID mode by default. For
more detailed information, please refer to the
barcode scanner user manual.
Mounting TA-500 onto MT-series Tablet (Optional)
TA-500 is an external battery pack kit mainly
designed to provide extra battery life to MT-
series tablet. For the detailed installation
instructions, please refer to TA-500 user
manual.
Performing System Recovery
For MT-4210A model with preloaded operating systems, you are NOT
encouraged to recover your system without the help of the system integrators.
Please be advised to contact your service center for further assistance with
system recovery.
Installing Optional Upgrade Kits
Posiflex MT-4210A can work with multiple optional upgrade kits, such as
MSR, Smart Card Reader and the like. For the detailed instructions, refer to
the user manual related to each peripheral devices.

14
Specifications
MT-4210A
CPU
ALLWINNER A83T processor (Octa-core, 2.0 Ghz),
PMIC AXP813
DRAM Memory
2GB DDR3 (on-board RAM)
OS
Android 6.0
Display
10.1" 1280 x 800 LCD, 400 nits
Touch Screen
P-CAP touch with multi-touch support
Storage
16GB eMMC
I/O
Micro-SD card slot (non OTG USB Port) x1,
Nano-SIM slot x1, Micro-USB port x1, DC-in jack x1,
Docking port x1, Audio jack x1
Wireless connectivity
1. WiFi IEEE 802.11b/g/n/ac + BT 4.0
2. Optional 4G module (M.2 form factor, USB I/F)
Power Supply
5V/15W power adaptor
Camera
5M pixels (rear facing camera)
Sensors
G-sensor, Ambient Light sensor
Audio
Built-in speaker x1 + Mic-in/Line-out combo jack x1
USB Port
Micro USB x1 (non OTG USB Port)
SIM Card Slot
Yes, Nano card slot
DC-in Jack
Yes
Button
Power button x1
Battery Pack
3.7V/ 4800 mAh, 17.76 Wh
LED Indicator
Blue color LED x 1
Orange color LED x 1
Housing Construction
Al-Mg die casting
Dimensions
260.7 (L) x 175.0 (W) x 16.8 mm (D)
Weight
800g
Optional Item
Smart Card Reader
IDTECH MiniSmart II
4G comm.
Full band 4G module
Sunlight readable
Sunlight readable panel display

15
Attachment
TA-210
Side attachment with JIS2 three-track MSR
TA-220
Side attachment with USB three-track MSR and RFID
TA-300
Side attachment with USB three-track MSR and finger
print sensor
TA-500
2nd battery pack kit
PG-200E
Pistol grip with 2nd battery pack and 1D barcode scanner
/2D imager
DS-110
Dock Station: USB 2.0 x 3 + GbE x 1 + Serial Port x 2 +
CR Port x 1 + DC-in + 2" WiFi Printer x 1
DS-200 / 210 / 220/ 300
/ 310 / 320
Dock Station: USB 2.0 x 3 + GbE x 1 + Serial Port x 2 +
CR Port x 1 + 3" WiFi Printer x 1
※ The product information and specifications are subject to change without
prior notice. To get the detailed information on the MT-4210A, please
check this model from Posiflex Global Website.

16
<MEMO>
