POSIFLEX Jiva KS-6615 Series User manual

Rev. : Original
MANUFACTURED BY: POSIFLEX TECHNOLOGIES, INC.
AN ISO-9001AND ISO-14001 CERTIFIED MANUFACTURER
6,WU-CHUAN RD.,HSIN-CHUANG
TEL: [phone] (REP.)
FAX: [phone]
(WU-KU INDUSTRIAL ZONE) http://www.posiflex.com http://www.posiflex.com.tw
TAIPEI HSIEN, TAIWAN http://www.posiflexusa.com EMAIL: [e-mail]
Jiva KS-6615 /
KS-6617 SERIES
TECHNICAL MANUAL

SOME IMPORTANT NOTES
FCC NOTES
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions manual, may cause interference to radio communications.
It has been tested and found to comply with limits for a Class A digital device pursuant to subpart J of
Part 15 of FCC Rules, which are designed to provide reasonable protection against interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely to
cause interference in which case the user at his own expense will be required to take whatever
measures to correct the interference.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than
the authorized technicians. The user should consult his/her dealer for the problem happened.
Warranty voids if the user does not follow the instructions in application of this merchandise. The
manufacturer is by no means responsible for any damage or hazard caused by improper application.
ABOUT THIS MANUAL
This manual assists the user especially the software programmer who provides the software
system for POS application to utilize the hardware of the Jiva KS series which is a member of the
POSIFLEX integrated point-of-sale terminal product family. The Jiva KS is a compact point-of-sale
system that gives the most user friendly application interface by providing a touch control LCD panel
and combines the performance and affordability of personal computers with the elegance and
reliability of business machine. The Jiva KS series also provides the built-in networking capability for
easy communication among multiple terminals in addition to the data transfer and control through
back office server.
The manufacturer of the Jiva KS series heartily apologizes to the user for reserving the right to change
or to modify this manual without notice due to the rapid and constant progress and improvement on
science and technology. The user may always obtain the most up to date information or software
utilities through any of our web sites:
http://www.posiflex.com.tw; http://www.posiflex.com; http://www.posiflexusa.com
©Copyright Posiflex Technologies, Inc., 2007
All rights are strictly reserved. No part of this documentation may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic, mechanical, photocopying, or
otherwise, without the prior written consent of Posiflex Technologies, Inc. the publisher of this
documentation.
TRADE MARKS AND SERVICE MARKS
POSIFLEX is a registered trademark of Posiflex Technologies, Inc..
Other brand and product names are trademarks and registered trademarks and service marks
of their respective owners.

i
TABLE OF CONTENTS
OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 -1
SCOPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 -1
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 -1
OPTIONAL ITEMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 -3
GENERAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -1
SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -1
POWER SOURCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -1
SYSTEM POWER ON/OFF CONTROL . . . . . . . . . . . . . . . . . .2 -1
UPS SUPPORT (battery option) . . . . . . . . . . . . . . . . . . . . . . .2 -2
12VDC POWER SUPPLY INTO SYSTEM . . . . . . . . . . . . . . . . 2 -2
OVERALL POWER OUTPUT LIMIT . . . . . . . . . . . . . . . . . . . . .2 -2
INPUT / OUTPUT PORTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -2
HDD IN BASE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -3
TOUCH PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -3
PRELOAD OS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -3
OPERATOR DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -3
AUDIO PORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -4
LED MODULE COLOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -4
EXTERIOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -4
ENVIRONMENTAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -5
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -5
COMPLIANCE APPROVALS . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -5
OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -6
SECOND DISPLAY ON REAR BASE . . . . . . . . . . . . . . 2 -6
CUSTOMER DISPLAY UPGRADE KIT . . . . . . . . . . . . . 2 -6
DRAM EXPANSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -7
UPGRADE KIT SD400T. . . . . . . . . . . . . . . . . . . . . . . . . 2 -7

ii
UPS BATTERY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -7
CF CARD CONNECTOR . . . . . . . . . . . . . . . . . . . . . . . . .2 -8
CASH DRAWER CONTROL CABLE . . . . . . . . . . . . . . . 2 -8
2.5”HDD IN MAIN UNIT . . . . . . . . . . . . . . . . . . . . . . . . .2 -8
EXTERNAL CD ROM DRIVE . . . . . . . . . . . . . . . . . . . . .2 -8
PRINTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -8
PP-2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -8
PP-5600 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -8
PP-5700 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -9
PP-7000II / PP-7000L / PP-7000U . . . . . . . . . . . . . . . . . . 2 -9
PP-7700 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 -9
RELIABILITY SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . 3 -1
SYSTEM DEFINITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -1
BLOCK DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 -1
12 V DC IN CONNECTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 -2
USB0 ~USB5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 -2
LAN PORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -2
UPS BATTERY CONNECTOR . . . . . . . . . . . . . . . . . . . . . . . . .4 -3
SERIAL PORT COM1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 -3
SERIAL PORT COM2/3/4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -4
AUDIO OUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -4
MIC IN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 -4
PARALLEL PORT LPT1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 -5
VGA CONNECTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 -6
SATA CONNECTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 -6
HDD POWER CONNECTOR . . . . . . . . . . . . . . . . . . . . . . . . . . .4 -6
APPLICATION GUIDES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 -1

iii
POWER SUPPLY TO COM PORTS . . . . . . . . . . . . . . . . . . . . .5 -1
CUSTOMER DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 -1
COM1 APPLICATION COMMENT . . . . . . . . . . . . . . . . . . . . . .5 -1
CASH DRAWER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 -2
SOFTWARE SYSTEM BACKUP . . . . . . . . . . . . . . . . . . . . . . . .5 -2
SYSTEM BIOS UPDATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 -3
EXTENDED DUAL DISPLAY MODE . . . . . . . . . . . . . . . . . . . . 5 -3
PS/2 INTERFACE DEVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 -3
POWER ON/OFF CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . 5 -4
EXTERNAL POWER SWITCH . . . . . . . . . . . . . . . . . . . .5 -4
SOFTWARE SWITCH OFF . . . . . . . . . . . . . . . . . . . . . . 5 -4
FORCED SWITCH OFF . . . . . . . . . . . . . . . . . . . . . . . . .5 -5
UPS BATTERY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 -5
UPS STATUS DETECT FUNCTIONS. . . . . . . . . . . . . . . . . . . 5 -6
AUTOMATIC POWER ON CONTROL . . . . . . . . . . . . . . . . . . . 5 -8
ALARM CLOCK WAKE UP . . . . . . . . . . . . . . . . . . . . . . .5 -8
MODEM RING UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 -8
LAN WAKE UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 -8
FINGERPRINT SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 -9
POSIFLEX TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 -10
POSIFLEX POWER SWITCH MANAGER . . . . . . . . . . 5 -10
UPS BATTERY HEALTH CHECK FUNCTION . . . . . . . . .5 -10
POWER SWITCH SETTING . . . . . . . . . . . . . . . . . . . . .5 -11
UPS SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 -11
POWER OFF DELAY TIME . . . . . . . . . . . . . . . . . . . . .5 -11
POSIFLEX USB MSR MANAGER . . . . . . . . . . . . . . . . .5 -12
USE ALT-NUM EMULATION . . . . . . . . . . . . . . . . . . . .5 -12
ENABLE MSR TRACK 1 . . . . . . . . . . . . . . . . . . . . . . .5 -13
ENABLE MSR TRACK 2 . . . . . . . . . . . . . . . . . . . . . . .5 -13
ENABLE MSR TRACK 3 . . . . . . . . . . . . . . . . . . . . . . .5 -13
MSR WILL SEND THE LEADING CODE . . . . . . . . . . . .5 -13
MSR TRACK 1 LEADING CODE . . . . . . . . . . . . . . . . . .5 -13
MSR TRACK 2 LEADING CODE . . . . . . . . . . . . . . . . . .5 -13

iv
MSR TRACK 3 LEADING CODE . . . . . . . . . . . . . . . . . .5 -13
MSR ENDING CODE . . . . . . . . . . . . . . . . . . . . . . . . . .5 -13
TRANSMISSION INTERCHARACTER DELAY . . . . . . . . 5 -14
SEND LRC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 -14
ADDITIONAL CR . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 -14
RESET TO ENGLISH DEFAULTS . . . . . . . . . . . . . . . . .5 -14
RESET TO NON-ENGLISH DEFAULTS . . . . . . . . . . . . .5 -14
POSIFLEX USB TOUCH MANAGER . . . . . . . . . . . . . . .5 -15
POSIFLEX USB TOUCH MANAGER . . . . . . . . . . . . . . .5 -15
USB TOUCH CALIBRATOR . . . . . . . . . . . . . . . . . . . . . 5 -16
USB TOUCH EDGE ACCELERATION TOOL . . . . . . . . .5 -16
USB TOUCH RIGHT BUTTON TOOL . . . . . . . . . . . . . . .5 -16
RS232 TOUCH DRIVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 -17
SOFTWARE COMMAND INDEX . . . . . . . . . . . . . . . . . . . . . . . .5 -19
HARDWARE DETAILS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -1
MAIN BOARD (KS-6615A). . . . . ..... . . . . . . . . . . . . . . . . . . 6 -1
COMPONENT SIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -1
SOLDER SIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -2
JUMPERS AND CONNECTORS . . . . . . . . . . . . . . . . . .6 -3
On component side . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -3
On solder side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 -5
JUMPER SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -5
CMOS data control . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -5
Panel power select . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -5
VGA port +12 V DC supply select . . . . . . . . . . . . . . . . . . 6 -5
LAN chip control enable/disable . . . . . . . . . . . . . . . . . . .6 -6
Software awareness of UPS status ..................6 -6
COM1/COM2+5V DC supply select . . . . . . . . . . . . . . . .6 -6
COM3/COM4 +5V DC supply select . . . . . . . . . . . . . . . .6 -6
USB touch setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 -7
CF ADAPTOR CARD (KS602A). ..... . . . . . . . . . . . . . . . . . .6 -8

v
COMPONENT SIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -8
SOLDER SIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -8
CONNECTORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 -8
On component side . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -8
On solder side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 -8
RS232 TOUCH CONTROL CARD (KS604A). . . . . . . . . . . . . . . .6 -9
COMPONENT SIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -9
SOLDER SIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -9
CONNECTORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 -9
On component side . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -9
On solder side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 -9
SDVO ADAPTOR CARD (KS608A) ... . . . . . . . . . . . . . . . . . . 6 -10
COMPONENT SIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -10
SOLDER SIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -10
CONNECTORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 -10
On component side . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -10
On solder side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 -10
SERVICE AND SPARE PARTS . . . . . . . . . . . . . . . . . . . . . . . . . .7 -1
SERVICE GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 -1
SIDE MOUNT UPGRADE KIT . . . . . . . . . . . . . . . . . . . . 7 -1
BASE MOUNT UPGRADE KIT . . . . . . . . . . . . . . . . . . . .7 -2
BASE INSTALLED DEVICES . . . . . . . . . . . . . . . . . . . . .7 -3
REPLACE BASE INSTALLED 2.5”HDD . . . . . . . . . . . . 7 -3
2.5” HDD & SDRAM IN MAIN UNIT . . . . . . . . . . . . . . . . 7 -4
OPEN THE MAIN UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . 7 -4
SEPARATE FRONT BEZEL ASSEMBLY . . . . . . . . . . .7 -5
CF READER SLOT ADAPTOR CARD . . . . . . . . . . . . . .7 -6
17”LCD PANEL MODEL . . . . . . . . . . . . . . . . . . . . . . . . .7 -6
IR TOUCH PANEL MODEL . . . . . . . . . . . . . . . . . . . . . . .7 -7
REPLACE MAINBOARD . . . . . . . . . . . . . . . . . . . . . . . . . 7 -7
SPARE PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 -9

vi
ASSEMBLY DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 -14

KS-6615 / KS-6617 series Technical Manual 1 -1
OVERVIEW
SCOPE
The Jiva KS-6615 / KS-6617 series is a series of fully integrated PC based
Point-Of-Sale terminals. This series provides excellent performance for Point-Of-Sale,
Hospitality and Kiosk systems with a Celeron CPU of Mobile 1.5 GHz in 479-ball
Micro-FCBGA package with Intel 910GMLE + ICH6M chipset inside an Aluminum
alloy enclosure without any exhaust fan. This series also provides a touch control panel
over the 15” or 17”LCD panel integrated on the top surface of the system. In short,
this series engages modular design for numerous advanced hi-tech applications in
robust integrated construction.
FEATURES
lCPU: Celeron M 1.5 GHz
lData storage device: SATA HDD 2.5” 40 GB in base or SATA HDD 2.5”
40 GB in main unit or CF card.
lFan free structure with vertical fin Aluminum main unit casing against
hostile environment
lAn advanced slim base or wall mount without base design. The slim base
supports 2nd LCD display or pole mount customer display, storage room
for 2.5”HDD and optional UPS battery. The wall mount utilizes the CF
card or 2.5”HDD in main unit for data storage device.
lSupport WinXP Pro, WEPOS, Windows Vista and Linux environment
lHigh quality 15” TFT active matrix LCD panel with 1024 x 768 resolution
(XGA) for KS-6615; 17” TFT active matrix LCD panel with 1280 x 1024
resolution (SXGA) for KS-6617
lVertical type LCD panel with easy tilt angle adjustment from 15° to 70°
lExtra long life touch panel that endures 35 million touches at same spot or
optional InfraRed type touch sensor giving maximum clarity
lEasy maintenance, spill proof and multipurpose construction
lVarious I/O ports supported, including:

KS-6615 / KS-6617 series Technical Manual 1 -2
a. 4serial ports with DB9 connectors, each with capability for +5V DC
power support
b. 1parallel port
c. 6USB ports (4 in I/O area and 2 in side cover for instant service use)
d. 1proprietary USB port for side mount kit such as SD-400T
e. 1 LAN port 100 Base-TX / 1000 base-T Ethernet
f. 1 external VGA monitor port
g. 1 CR port for control over max. 2 cash drawers
h. 1 Mic. in 1 line out
i. 1 SATA port and 1 HDD power connector
j. 1 internal SATA port for optional HDD in main unit
k. 1 UPS battery connector (for optional UPS battery in base)
l. 1 DC 12 V 4 pin lock type power input connector
lPreprogrammed timer wake up function
lCOM port MODEM ring up function
lLAN wake up function
lBuilt-in UPS function with battery low detect and alarm to support the
system from intermittent power failure (battery itself is an option)
lAccidental power off protection –The power switch is safely located in
left side cover, and this power switch can be defined as a “ON” switch only
through software command
lSoftware power off makes full featured remote control through LAN or
MODEM possible
lTouch control functions: left/right button, double click, drag & drop
lTouch sound can be enabled or disabled or adjust pitch by software
control
lHigh resolution touch sensor controller: 1024 X 1024
lDDR2SODIMM memory can extend to 1GB in 1module
lDynamic video memory technology up to 128 MB
lIntegrated structure for various optional upgrade kits
lSupports power saving by suspension mode
lLCD panel brightness control by hardware push button “+”& “-”

KS-6615 / KS-6617 series Technical Manual 1 -3
OPTIONAL ITEMS
Note: The “∗” marked items in the following list means that option must be set
prior to shipment from the factory. The rest items can be set by the
dealers.
a) *Optional model to be without touch panel or with IR touch panel
b) 2nd HDD or CF memory card reader
c) DDR2 SODIMM memory expansion up to 1 GB max.
d) Internal UPS battery
e) SD-400T integrated to right side of LCD panel to contain MSR with
software controllable parameters and optional optical fingerprint sensor.
f) Pole mount 2 by 20 VFD or LCD customer display through COM port or
USB port or base mount 2nd LCD monitor
g) Preload WinXP Pro or WEPOS
h) Wall mount bracket WB-6000V, WB-6300, WB-6600, WB-6800 etc.

KS-6615 / KS-6617 series Technical Manual 2 -1
GENERAL SPECIFICATION
SYSTEM
lCPU: Intel Celeron M 1.5 GHz (1 MB L2 cache)
lDDR2SODIMM : 512 MB (expandable to 1GB)
lBuilt-in 2.5”SATA interface HDD 40 GB above in base
POWER SOURCE
Item Specification
Voltage range of adaptor input 100 ~ 240 V AC
Load limit of adaptor input 2.5A max.
Input frequency 47 / 63 Hz
Voltage output 12 V DC
Output current 6.6 A
Inrush current 50A @ 110V / 100A @220V
Total Power Consumption
Nominal Maximum
60 W 80W
SYSTEM POWER ON/OFF CONTROL
lOne main power ON/OFF slide switch inside the touch open cover, this
switch can be programmed as “ON” only
lSystem can be waked up after each power off by any of the preset timer or
a remote COM port MODEM call or LAN wakeup packet
lSystem can be switched off by software command through local or remote
program control
lForced power off when switch is ON/OFF or when switch is ON only with
prolonged effort
lPower OFF to ON duration: 10 seconds min.

KS-6615 / KS-6617 series Technical Manual 2 -2
UPS SUPPORT (battery option)
lSupports system operation for up to 30 min. depending on loading
condition
lLED panel turns on green when adaptor power stand-by
lLED panel flashes in blue and system beeps when UPS battery starts
working and discharging, and LED panel flashes rapidly when UPS near to
end
lWorking on UPS battery status can be detected through COM1 status port
12VDC POWER SUPPLY INTO SYSTEM
lO / P : 12 +/-1 V DC 6.6 Amp.
lI / P : 110 VAC/2.5A or 240 VAC/1.2A max., 47 ~ 63 Hz
OVERALL POWER OUTPUT LIMIT
lAll COM ports: + 5 V DC / 1Amp max. total + 12 V DC / 1 Amp. max.
lAll USB ports: + 5 V DC / 0.5 Amp. max. for each port
lVGA port: + 12 V DC / 1 Amp. max.
lHDD power: + 5 V DC / 2 Amp. max., + 12 V DC / 1 Amp. max.
INPUT / OUTPUT PORTS
l4x serial communication ports. All serial communication ports can supply
DC +5V through pin 9 under overall power output limit. Default setting is
standard RI signal input at this pin for all ports.
l1 x parallel port
l6x USB ports
l1 x proprietary USB port for side mount upgrade kit
l1 x LAN port (Ethernet 10 base T and 100 base T and 1 Gbps)
l1 x VGA display port for external monitor display
l1 x CR port in RJ11 jack for control over max. 2 cash drawers
l1 x 3.5Fmono jack for Mic. in and 1 x 3.5Fstereo jack for line output
l1 x SATA port for HDD in base
l1 xHDD power connector

KS-6615 / KS-6617 series Technical Manual 2 -3
l1 x 4 pin 12 V DC power input jack
l1 x UPS connector for 2.3AH/12V or above Lead Acid battery
l1 x internal SATA port for optional HDD in main unit
HDD IN BASE
l40 GB or above operating up to SATA 1 (150 MB/s)
TOUCH PANEL
lExtremely endurable life survives minimum 35,000,000 touches at same
spot
lTouch control interface: USB (optional RS232 interface for IR type)
lSensor type: resistive (InfraRed type optional)
lResolution: 1024 x 1024
lCalibration: initial calibration at setup only, no re-calibration required for
day to day power on/off
lDriver support: Win 2000, Win XP
PRELOAD OS
lOption between Win XP Pro and WEPOS
OPERATOR DISPLAY
MODEL KS-6615 KS-6617
Display Type COLOR TFT 15” LCD COLOR TFT 17” LCD
View area 304.1 X 228.1 mm 337.9 X 270.3 mm
Internal Interface LVDS Dual channel LVDS
through SVDO adaptor
Luminance 200 cd/m2min 200 cd/m2min
Resolution 1024 X 768 1280 X 1024
Video memory size up to 128 MB dynamic memory
Tilt angle 15°~ 70°

KS-6615 / KS-6617 series Technical Manual 2 -4
15”85.1/89.4T
17”89.8/94.1T
AUDIO PORT
l3.5 Ø mono jack for Mic. In
l3.5 Ø stereo jack for audio line out
lOutput audio power 2.0 W x 2 (in stereo signal to internal speakers in back
cover)
lBandwidth 350 Hz ~ 12 KHz
LED MODULE COLOR
lType: blue/green dual color (blue for power on; green for stand by)
lIndication coverage: system ON/OFF status, external power status, UPS
battery monitoring
EXTERIOR
l15”GEN. 5 SLIM BASE MODEL DIMENSIONS:
LCD @ 15°:378 mm (W) x321 mm (D) x362 mm (H) or
14.9”x 12.6” x 14.3”
LCD @ 70°: 378 mm (W) x 304 mm (D) x294 mm (H) or
14.9” x 12.0” x 11.6”
l17”GEN. 5 SLIM BASE MODEL DIMENSIONS:
LCD @ 15°:426 mm (W) x326 mm (D) x418 mm (H) or
16.8”x 12.8” x 16.5”
LCD @ 70°: 426 mm (W) x 354 mm (D) x319 mm (H) or
16.8”x 13.9” x 12.6”
lMAIN UNIT DIMENSIONS (for WALL MOUNT MODEL):
15”:378 mm (W) x85.1 mm (D) x312 mm (H) or
14.9”x 3.35” x 12.3”
17”: 426 mm (W) x 89.8 mm (D) x370 mm (H) or
16.8”x 3.54” x 14.6”
lWEIGHT:
NET WEIGHT 15” 17”
w/ Gen.5 Slim base 9.7 kg (21.4 lbs) t. b. d.
G.W. w/G5 slim 13.1 kg (28.9lbs)

KS-6615 / KS-6617 series Technical Manual 2 -5
ENVIRONMENTAL
lTEMPERATURE RANGE (excl. UPS battery):
Operating: 0°C~ +40°C or 32°F ~ 104°F
Non-operating: -20°C ~ +60°C or -4°F ~ +140°F
lTEMPERATURE RANGE for UPS battery:
Operating: 0°C~ +40°C or 32°F ~ 104°F
Non-operating: -20°C ~ +40°C or -4°F ~ +104°F
lHUMIDITY RANGE:
Operating: 20%RH ~ 80%RH, non-condensing,
max. wet bulb 26°C (78.8°F)
Non-operating: 10%RH ~ 80%RH, non-condensing,
max. wet bulb 28.9°C (84.0°F)
ACCESSORIES
lUser’s manual: 1 copy
lPower adapter 12 V DC 6.6 A plus power cord
lProduct Information CD or Recovery CD of preloaded OS
lCOM1 terminator
COMPLIANCE APPROVALS
lWhole system meet CE, FCC class A standard
(meet IEC1000-4-2/-3/-4/-5/-6/-8/-11)
lPower supply is UL, VDE approved
lRoHS
lWEEE

KS-6615 / KS-6617 series Technical Manual 2 -6
OPTIONS
SECOND DISPLAY ON REAR BASE
Model Number LM6101 LM6201
Display Type COLOR TFT 12.1”
Interface VGA
View area 245.8 X 184.3mm 246 X 184.5mm
Luminance 175 cd/m2400 cd/m2
Backlight CCFL x 1 CCFL x 2
Contrast Ratio 500 : 1 500 : 1
Resolution 1024 X 768 (XGA) 800 X 600 (SVGA)
Color depth 18 bits true color (262,144)
Tilt angle Stand straight (as 0°) to backward till touching main unit
Swivel angle Left 45°and right 45°
Power Source DC 12 V in VGA
CUSTOMER DISPLAY UPGRADE KIT
MODEL Number PD2501PD2602 PD305 PD306 /U
Display Media VFD LCD
Number of rows 2
Characters per row 20
Character width (mm) 7.2 5.25 6
Character height (mm) 11.25 9.03 9.66
Character format 5 X 7
Character code pages 14 1
International character sets
12 1
Command modes 62
Display color Green (505 nm) w/ Blue
filter
Dark blue / Yellow green
Background

KS-6615 / KS-6617 series Technical Manual 2 -7
Display area (mm x mm) 193 x 39 157.05 x
22.86 142.8 x 20.64
Display head size (mm) 260 x 65 x
83
197 x 56 x
58
217 x 80.5 x
28.5
196.7 x 57.5
x 39.6
Mounting method Pole mount on base Base mount
Pole on base
Pole height (mm) 430 200 N. A. 200
Horizontal slide (mm) N. A.
Horizontal rotation 330º 270º +/-45º270º
Inclined viewing angle 15º, 30º, 45º
15º, 30º, 45º
0º~ 90º15º, 30º, 45º
Signal interface RS232 RS232 or
USB RS232 RS232 or USB
Power source (5 V DC) in DB9 in DB9 or
USB in DB9 in DB9 or USB
DRAM EXPANSION
lDDR2 SODIMM in 1socket up to total 1GB max.
UPGRADE KIT SD400T
lFunctions include: MSR, optical type finger print sensor
lMSR:
Reader type: ISO 2 tracks (track 1 + track 2) or ISO 3 tracks (track 1 +
track 2 + track 3) or JIS I/II
Characteristic parameters of ISO readers can be set via software
AAMVA/CA DMV format supported in ISO 3 tracks model
lOptical fingerprint sensor:
Detection area: 14.6 x 18.1 mm (nominal at center)
Gray scale : 8 bits (256 levels)
Resolution : 512 dpi (average x, y over the field)
UPS BATTERY
l2.3 AH/12V lead acid battery

KS-6615 / KS-6617 series Technical Manual 2 -8
CF CARD CONNECTOR
lAccepts Compact Flash Memory Card type II
lOccupies IDE primary channel
CASH DRAWER CONTROL CABLE
l2 in 1 cash drawer control cable 20863023800 for independent
control over two cash drawers of CR3100 or CR3200 or CR4000
2.5”HDD IN MAIN UNIT
l40 GB or above
lSATA 1 (150 MB/s)
EXTERNAL CD ROM DRIVE
l24 x speed
lUSB interface
lSlim type
PRINTER:
lPP-2000
1. 2-station receipt/journal/validation printer
2. Dot matrix 9 pin
3. Bi-directional printing
4. Auto cutter provides full cut and partial cut
5. Auto-detect between RS232 and EPP interface
lPP-5600
1. Dot matrix impact 9 pin
2. Bi-directional printing
3. Friction feed type
4. 40 columns for 16.9 CPI
5. Accepts paper width 76 mm
6. Prints on ordinary or up to 3-fold carbonless copy paper
