Product Manual: PXP-60HF Poskom Co.,
Ltd.
8
Guidance and Manufacturer’s Declaration – Electromagnetic Emission
The PXP-60HF is intended for use in the electromagnetic environment specified below. The customer or the user
of the PXP-60HF should assure that it is used in such an environment.
Immunity test IEC 60601
Test level Compliance level Electromagnetic environment -
guidance
Electrostatic Discharge
(ESD) acc.
IEC 61000-4-2
±6 kV
Contact
±8kV
Air
±6kV
Contact
±8kV
Air
Floors should be wood, concrete or
ceramic tile. If floors are covered
with synthetic material, the relative
humidity should be at least 30%.
Electrical fast transient/
bursts acc. IEC 61000-4-4
±2kV
for Power supply
lines
±1kV
for I/O lines
(input/output)
±2kV
for Power supply lines
±1kV
for I/O lines
Mains power quality should be that
of a typical commercial or hospital
environment.
Surges acc.
IEC 61000-4-5
±1kV
differential mode
±2kV
common mode
±1kV
differential mode
±2kV
Common mode
Mains power quality should be that
of a typical commercial or hospital
environment.
Voltage dips, short
interruptions and voltage
variations on power supply
input lines acc. IEC 61000-
4-11
< 5% Ut
(>95% dip in Ut )
for 0,5 cycle
40% Ut
(60% dip in Ut )
for 5 cycles
70% Ut
(30% dip in Ut )
for 25 cycles
<5% Ut
(>95% dip in Ut )
For 5 s
<5% Ut
(>95% dip in Ut )
for 0,5 cycle
40% Ut
(60% dip in Ut)
for 5 cycles
70% Ut
(30% dip in Ut)
for 25 cycles
<5% Ut
(>95% dip in Ut)
for 5 s
Mains power quality should be that
of a typical commercial or hospital
environment. If the user of the PXP-
60HF requires continued operation
during power mains interruption, it is
recommended that the PXP-60HF
be powered from an interruptible
power supply or a battery.
Power frequency (50/60
Hz) magnetic field acc. IEC
61000-4-8
3 A/m 3 A/m
Power frequency magnetic fields
should be at levels characteristic of
a typical location in a typical
commercial or hospital environment.
NOTE Ut is the AC mains voltage prior to application of the test level.
