Power Master SL Series Installation instructions

INSTALLATION AND
OWNERS MANUAL
MODEL SL
SLIDE DOOR TROLLEY OPERATORS
READ THIS MANUAL CAREFULLY
BEFORE INSTALLATION OR USE.
SAVE THESE INSTRUCTIONS.
Serial #:
Date Installed:
Your Dealer:
As of date of manufacture,
meets all ANSI/UL 325
Safety Requirements for
Vehicular door operators.

READ THESE STATEMENTS CAREFULLY AND FOLLOW THE
INSTRUCTIONS CLOSELY!
The Warning and Caution boxes throughout this manual are there to protect
you and your equipment. Pay close attention to these boxes as you follow the
manual.
WARNING
Indicates a MECHANICAL hazard
of INJURY OR DEATH. Gives
instructions to avoid the hazard.
CAUTION
Indicates a MECHANICAL hazard
of DAMAGE to your operator or
equipment. Gives instructions to
avoid the hazard.
Indicates an ELECTRICAL
hazard of INJURY OR DEATH.
Gives instructions to avoid the
hazard.
WARNING CAUTION
Indicates an ELECTRICAL hazard
of DAMAGE to your operator or
equipment. Gives instructions to
avoid the hazard.
TABLE OF CONTENTS
2
Model SL Slide Door Operator Applications– Product Features ....................................................….3
Preparation ........................................................................................................................................... 4-8
Component Identification Pictorial - Figure 1 ....................................................................... 4
Important Installation Notes (Things To Do Before/During Installation)............................. 5
Component Identification Listing - Table 1 ........................................................................... 5
Rail/Chain Assembly Instructions - Figure 2, 2A.………………………………………………..6
Trolley Assembly Instructions - Figure 3A,.……………………………..………………….........7
Operator Assembly Instructions- Figure 4,5A .................................................................... ..8
Operator Installation ............................................................................................................................... 9
Chain Routing- Figure 6 .......................................................................................................... 9
Hanger Installation- Figure 7,7A ………….. ………………………………………………. ....... 10
Hanger Layout - Figure 8,9 .................................................................................................... 12
Mounting Disconnect Assembly - Figure 10,11,12 .............................................................. 13
Setting The Limits - Figure 13 ............................................................................................... 14
Electrical Wiring Instructions................................................................................................ 15
Field Wiring - Figure 14.......................................................................................................... 16
Operation and Adjustment Instructions.............................................................................................. 17
Clutch Adjustment - Figure 15 ............................................................................................... 18
Brake Adjustment……………………………………………………………………………………..19
Fire Door Disconnect Installation .......................................................................................... 20
Testing...................................................................................................................................... 22
Maintenance .......................................................................................................................................... 23
Trouble Shooting................................................................................................................................... 24
Warranty................................................................................................................................................. 25

The purpose of this booklet is to provide
assembly, installation and operation information
concerning PowerMaster Model SL Commercial
Slide Door Operators and related Accessory
Products.
NOTE: IT IS IMPORTANT THAT THIS
INSTRUCTION MANUAL BE READ AND
UNDERSTOOD COMPLETELY BEFORE
INSTALLATION OR OPERATION IS
ATTEMPTED. IT IS INTENDED THAT THE
INSTALLATION OF THIS UNIT WILL BE DONE
ONLY BY PERSONS TRAINED AND
QUALIFIED IN THE INSTALLATION,
ADJUSTMENT AND SERVICE OF
COMMERCIAL DOORS AND DOOR
OPERATORS AND BY QUALIFIED
ELECTRICIANS.
NOTE:THE IMPORTANT SAFEGUARDS AND
INSTRUCTIONS IN THIS MANUAL CANNOT
COVER ALL POSSIBLE CONDITIONS AND
SITUATIONS WHICH MAY OCCUR DURING
ITS USE. IT MUST BE UNDERSTOOD THAT
COMMON SENSE AND CAUTION MUST BE
EXERCISED BY THE PERSON(S) INSTAL-
LING, MAINTAINING AND OPERATING THE
EQUIPMENT DESCRIBED HEREIN. DO NOT
USE THIS EQUIPMENT FOR ANY OTHER
THAN ITS INTENDED
PURPOSE - OPERATING COMMERCIAL
VEHICULAR SLIDE DOORS.
STANDARD FEATURES:
Limit Switches: Rotary limit switches, easily
adjusted over a wide range. The motor may be
removed without affecting the limit switch
adjustments.
Manual Release: Permits manual operation
of the door in the event of a power failure.
The Model SL is equipped with a manual
disconnect to aid in manual operation. Use
of this feature will not affect the limit switch
adjustment.
Control Circuit: Standard three button open,
close and stop. 24 Volts AC.
Connections For Auxiliary Entrapment
Protection Devices: Use with pneumatic
reversing door edge components or a
photoelectric beam (across the opening) device.
Constant Contact To Close: Standard
operation.
Momentary Contact To Close: Feature can be
activated by moving a wire on the terminal strip.
OPTIONAL FEATURES:
Digital Radio Controls: Open, Close and
Stop operation. Radio units are available to
control up to 27 doors from one transmitter
Digital Timer to Close: Adjustable from 0 to
17 minutes in one second intervals.
Keyless Entry System: Connection terminals
provided for hard wired or wireless keyless
entry systems.
PRODUCT FEATURES 3
Model SL Slide Door Operator Applications
Slide Door operators are intended for
commercial and industrial use on sliding doors
which use horizontal track.
Please refer to Figure 10, on page 10 for
basic installation layout of track.
A Slide Door operator when properly installed
will effectively lock the door in the closed
position.
Model SL Slide Door operators are used in
the following applications:
- Continuous Duty, Indoor Commercial
installations only
- For doors that require from 1/3 HP to 1HP
motors using single or three phase power.
- Use with foam/pneumatic reversing door
edge or photoelectric device - REQUIRED
where the 3-button station is out of sight of
the door, or any other automatic, remote or
manual control is used to activate the door.

PREPARATION
4
Before starting the installation of the operator, the door
must be in good working condition. Inspect the door
and track for loose or missing hardware and test the
door manually for ease of operation. Lubricate door
rollers.
Before removing the operator powerhead from the
shipping carton, inspect the nameplate on the cover of
the operator control box to verify that it is the correct
model for the intended application and that the voltage
and phase are in accordance with electrical power
provided at the job site. The rails are shipped
separately from the power head.
ELECTRIC DOOR OPENERS ARE DESIGNED FOR
DOORS IN GOOD WORKING CONDITION, AND
PROPERLY ADJUSTED IN ACCORDANCE WITH THE
DOOR MANUFACTURER'S INSTALLATION
INSTRUCTIONS.
WARNING
REMOVE OR DISABLE ANY LOCKING
DEVICES FROM DOOR AND REMOVE ALL
ROPES.
WARNING
FIGURE 1 - COMPONENT IDENTIFICATION
OPERATOR
POWER HEAD
-8
HARDWARE
PACKAGE
-13
-1 TRACK RAILS IDLER ROLLER
ASSEMBLY
-3
-7
CHAIN TAKE-UP
BOLT
STANDARD TROLLEY
TRAVELER ASSEMBLY
-5
-2
SPREADER
BRACKET
-14
THREE
BUTTON
STATION
-10 -9
CHAIN
CONNECTING
LINK
CHAIN
DRIVE/DISCONNECT
ASSEMBLY
HANGER BRACKET
ANGLE
-6
-4
-11
-12
SWAY BRACE
SWAY BRACE
CLIP
-15
BI-PART TROLLEY
TRAVELER ASSEMBLY
BI- PART FRONT
IDLER BRACKET
-16
Rope off the area to keep personnel and
vehicles clear of the door and floor
space in the vicinity of the operator
during the installation.
WARNING

• Install only on a properly operating Slide Door.
An improperly operating door could cause
severe injury. Have a qualified service person
make any before installing the opener.
• Remove all ropes and remove or make
inoperative all locks (unless mechanically and/or
electrically interlocked to the power unit) that are
connected to the door before installing the
opener.
• Lightweight doors (fiberglass, aluminum etc.)
must be reinforced to avoid door damage.
Check the door manufacturer’s instruction
manual for a bracing procedure or the availability
or a Reinforcement Kit.
• PowerMaster Model SL Slide Door operators
are for Commercial Vehicular Slide Doors and
as such are NOT recommended for pedestrian
traffic. In installations where it is known that
pedestrians will be nearby ensure a pedestrian
door is available for entrance and exit to the
building. In addition YOU MUST install an
auxiliary entrapment protection device (reversing
door edge or photoelectric beam device) as part
of the compete operator system.
• Connect an auxiliary entrapment protection
device (reversing edge or photoelectric device
across the door opening). A device of this type
is STRONGLY ADVISED FOR ALL commercial
operator installations. An auxiliary entrapment
protection device is REQUIRED when the three
button control station is out of sight of the door
or any other automatic or manual control is
used.
• Install the opener at least 8 feet or more
above the floor.
• Do not connect the opener to the source of
power until instructed to do so.
• Locate the control station:
a) within sight of the door and;
b) at a minimum height of five feet above
the floor and;
c) away from all moving parts of the
door.
• Do not overtighten the clutch adjustment to
compensate for a poorly working door.
• Securely attach any WARNING signs or
placards to both the door and above the control
station.
• After installing the opener, all safety features
must be tested for proper operation (see page
17).
TO REDUCE THE RISK OF SEVERE INJURY
OR DEATH: READ AND FOLLOW ALL
INSTALLATION INSTRUCTIONS!
WARNING
IMPORTANT INSTALLATION NOTES
Item # Description Qty. Item # Description Qty.
1 Track Rails 2 9 Drive Chain 1
2 Spreader bracket (s) As
reqd.
10 Chain Connecting Link 2
3 Idler roller assembly (2 for Bi-part) 1 11 Sway Brace 1
4 Drive/disc. Assembly (2 for Bi-part) 1 12 Sway Brace clip 1
5 Trolley Assembly (standard) 1 13 Hardware package 1
6 Hanger bracket angle As
reqd.
14 3 Button Station 1
7 Chain Take-Up Bolt 1 15 Trolley Assembly (Bi-Part) 1
8 Operator Power head 1 16 Bi-Part Front Idler Bracket 1
TABLE 1 - COMPONENT IDENTIFICATION LISTING
5

6
Track Assembly
1. Lay Track Angles (1) on work surface as shown in Figure #2.
2. Install track spreader brackets (2) and Front Idler Roller Assembly (3) on track using 3/8 x ¾ long
hex head bolts and 3/8 lock washers, as shown in Figure #2.
RAIL/CHAIN ASSEMBLY
3/8"
HEX NUTS
SPREADER
BRACKET
-2
SPREADER
BRACKET
-2
3/8"
WASHERS
-3
IDLER ROLLER
ASSEMBLY
3/8"
LOCK
WASHERS
3/8 X 3/4"
LG. HEX HEAD
BOLTS
SPREADER
BRACKET
-2
3/8"
WASHERS
3/8"
HEX NUTS
3/8 X 3/4"
LG. HEX HEAD
BOLTS
3/8 X 3/4"
LG. HEX HEAD
BOLTS
3/8"
LOCK
WASHERS
3/8"
LOCK
WASHERS
TRACK
ANGLE
-1
FIGURE 2
(6) 3/8 X 3/4"
LG. HEX HEAD
BOLTS
(2) 3/8"
HEX NUTS
(6) 3/8"
LOCK
WASHERS BI- PART FRONT
SPREADER ASSEMBLY
TRACK
ANGLE
-1
BI- PART FRONT
IDLER BRACKET
-16
(2) 3/8"
WASHERS
IDLER ROLLER
ASSEMBLY
-3
-3
IDLER ROLLER
ASSEMBLY
FIGURE 2A

Slide Assembly
1. Assemble top plate, lower drive plate, center drive bar and two nylon inserts using two 5/16 x 1 ¼
carriage bolts, two 5/16 lock washers and two 5/16 hex nuts as shown in Figure # 3A.
2. Install 3/8 chain take-up bolt into slide assembly using one 3/8 lock washer and two 3/8 hex nuts
as shown in Figure # 3A. (DO NOT TIGHTEN NUTS)
3. For Bi-Part Slide assembly see figure 3B.
INSTALLATION INSTRUCTIONS 7
5/16 X 1-1/4"
CARRIAGE
BOLTS
TOPPLATE TAKEUP
BOLT
3/8" HEX NUT
3/8" LOCK
WASHER
3/8" HEX NUT
5/15" LOCK
WASHER
5/15" LOCK
WASHER
5/16" HEX NUTS
NYLON INSERTS
CENTER BAR
NYLON CHAIN
DEFLECTOR
CENTER
DRIVEBAR
LOWER
DRIVEPLATE
FIGURE 3A
3/8" LOCK WASHER
NYLON
INSERT
BI-PART TROLLEY
UPPER DRIVE
PLATE
#10 SOCKET HEAD
CAP SCREWS
(3)
3/8" HEX NUT
3/8" LOCK WASHER
3/8" HEX NUT
TROLLEY
CENTER
GUIDE
DEEP
ENGAGEMENT
LOWER DRIVE
PLATE
5/16 X 1-1/4" LG.
CARRIAGE BOLTS
FIGURE 3B
Operator Assembly
1. Install trolley slide assembly on track assembly with chain take-up bolt (7) pointing away from end
of track where power head (8) will be mounted as shown in Figure # 4. Note: If Bi-part
installation, slide Bi-Part trolley slide on first.
2. Mount power head to track assembly using four 3/8 x ¾ long hex head bolts, four 3/8 lock
washers and four 3/8 hex nuts, as shown in Figure # 4.
3. Turn operator assembly over and back off chain adjustment nut to the end of the threads on chain
take-up bolt (7). See Figure # 5.
4. Layout drive chain (9) next to operator assembly work surface.
5. Thread one end of the operator drive chain around operator drive sprocket and connect to the
drive tab on the trolley slide assembly with a chain connecting link (10). See figure 5A and figure
6.
6. Thread the other end of the drive chain (9)around the idler roller assembly (3).See Figure #6.
7. Pull drive chain (9) tight up to trolley slide assembly; mark link that lines with hole on chain take
up bolt on slide assembly and cut drive chain to length. Note: If installing a bi-part operator,
drive chain (9) must pass through Bi-Part slide assembly (15) before being connected to
chain take up bolt (7) on standard slide assembly (5). See figure 5B and figure 6.

8 INSTALLATION INSTRUCTIONS
Operator Assembly
8. Attach cut end of drive chain (9) to chain take up bolts on trolley traveler assembly with a chain
connecting link. See figure 5A.
9. Adjust chain tension using adjusting nut on chain take up bolt, to remove excess slack. See
Figure # 5A.
10. Secure adjustment using lock washer and lock nut on chain take up bolt. See Figure # 5A.
Note: Leave Bi-Part slider carriage free at this time.
11. Bolt the hanger bracket angles together as
shown in Figure 7 to form mounting brackets.
Attach the mounting brackets to the track
spreader brackets, using the 3/8” bolts, lock
washers, and nuts. (See figure 7A) Do not
tighten as the distance from the wall to the
track will have to be adjusted later.
POWER
HEAD (4) 3/8"
HEX HEAD
BOLTS
(4) 3/8"
LOCK
WASHERS
(4) 3/8"
HEX BOLTS
TRACK
ASSEMBLY
-5
STANDARD
TROLLEY SLIDE
ASSEMBLY -15
BI-PART TROLLEY
SLIDE ASSEMBLY
(WHEN REQUIRED)
FIGURE 4
DRIVE
CHAIN
-9
CHAIN
CONNECTING LINK
-10 LOCKNUT
-7
CHAIN
TAKE-UP
BOLT
LOCK
WASHER
-9
CHAIN
CONNECTINGLINK
-10
TROLLEY
ASSEMBLY
-5
DRIVE TAB
CHAIN
ADJUSTING
NUT
FIGURE 5A

BI-PART TROLLEY
ASSEMBLY
-15
TRACK
ASSEMBLY
ASSEMBLY SHOWN IN THE
INVERTED POSITION
DRIVE CHAIN
-9
FIGURE 5B
BI-PART TROLLEY
ASSEMBLY
-15
TRACK
ASSEMBLY
ASSEMBLY SHOWN IN THE
NORMAL POSITION
FIGURE 5C
DRIVE CHAIN
-9
SINGLE SLIDE
CHAIN
TAKE UP
BOLT
FRONT
IDLER POWER
HEAD
BI-PARTING SLIDE
CHAIN ROUTING LAYOUT FOR SLIDE DOOR
OPERATORS WITH IDLER SPROCKETS
FIGURE 6
INSTALLATION INSTRUCTIONS 9

INSTALLATION INSTRUCTIONS
10
56-1/2" for 8', 12', & 16' Track
32-1/2" for 10' & 14' Track
48"
(All center spacers)
Angle clip
Sway brace
Spreader
bracket
Bi-part trolley
traveler
Front idler
shaft
Left track
angle
Right track
angle
Power
head
Mounting
bracket angle
assembly
Standard
trolley traveler
46"
HANGER INSTALLATION DRAWING
FIGURE 7A
-6
HANGER
BRACKET
ANGLE
-6
HANGER
BRACKET
ANGLE
-6
HANGER
BRACKET
ANGLE
(3) 3/8" LOCK
WASHERS
(3) 3/8"
HEX NUTS
(3) 3/8"
HEX HEAD
BOLTS
FIGURE 7

INSTALLATION INSTRUCTIONS 11
TO AVOID DAMAGE TO DOOR AND OPERATOR
ENSURE ALL DOOR LOCKS ARE DISABLED.
USE AN INTERLOCK SWITCH IF A LOCK IS
REQUIRED TO RETAIN FUNCTIONALITY.
WARNING
1. For single slide doors sliding right to open
locate first angle mounting bracket 9” to left of
opening, for doors sliding left to open locate
first angle mounting bracket 9” to right of
opening. (See figure 8)
NOTE:
For bi-parting doors this measurement is 15”.
See figure 9.
2. Set the assembled operator into position and
mark the holes for the angle mounting brack-
ets on the wall, as low as possible without in-
terfering with door travel. (See figure 10) Drill
holes in wall for mounting. Through bolts are
recommended for this purpose. If wall con-
struction does not permit the ue of through
bolts, lag bolts and shields may be used.
3. Secure the assembled operator to the wall.
IMPORTANT: BE SURE OPERATOR
TRACK AND DOOR TRACK ARE PARAL-
LEL. Check that the door clears the power
head when moving. Adjust the track location
on the mounting brackets to the desired posi-
tion and tighten all bolts. It is recommended
that at least one sway brace be used between
the wall and one of the track hangers for in-
creased rigidity, especially on large or heavy
doors. See figure 7A.
4. Mount the disconnect mechanism so that the
top of the bracket is no more than 2” below
the slider carriage ( See figure 8,10, and 11.)
This mechanism may be adjusted both front
and back and up and down to align the dis-
connect pin. It may be necessary to shim be-
tween the mechanism and the door to bring
the pin out into the centerline of the track.
Note: for bi-parting doors, mount both door
disconnect mechanisms. (See figures 9,10,&
11.)
5. It is necessary on a bi-part installation to bring
the doors to a fully closed position for proper
synchronization. With both disconnect pins
engaged in their respective carriages, connect
the drive chain to the bi-part slide assembly
with the hardware provided. See figure 5C
and 7.
6. Install disconnect chain lock as shown in fig-
ure 11, so it will function as described in figure
12.

INSTALLATION INSTRUCTIONS
12
DOOR OPENING9"
HANGER LAYOUT RIGHT HAND OPERATOR
32-1/2" FOR 10' & 14' TRACK
56-1/2" FOR 8', 12', & 16' TRACK 48"
(ALL CENTER SPACERS) 46"48"
(ALL CENTER SPACERS)
1-1/4"
DOOR WIDTH PLUS 4'-8" (REF)
DISCONNECT
CHAIN LOCK
FIGURE 8
15"
BI- PART INSTALLATION
DOOR OPENING
32-1/2" FOR 10' & 14' TRACK
56-1/2" FOR 8', 12', & 16' TRACK 48"
(ALL CENTER SPACERS) 46"48"
(ALL CENTER SPACERS)
1-1/4"
DOOR WIDTH PLUS 4'-8" (REF)
DISCONNECT
CHAIN LOCK
FIGURE 9

INSTALLATION INSTRUCTIONS 13
4-1/4" MIN.
6-1/4"MAX.
(AVAILABLE
ADJUSTMENT)
2" MAX.
KEEP AS NARROW
AS POSSIBLE TO
REDUCE SWAY
SUITABLE FASTENERS
BY INSTALLER
NOTE:
DISCONNECT SHAFT MUST
CLEAR TROLLEY TRAVELER
WHEN FULLY RETRACTED.
TROLLEY SLIDE
ASSEMBLY
DISCONNECT
DRIVE PLUNGER ADJUST HEIGHT OF
DISCONNECT ASSEMBLY
TO CENTER DRIVE PLUNGER
IN TROLLEY SLIDE ASSEMBLY
FIGURE 10
5-1/2"
ASREQIRED 2"MIN.
4"MAX.
DISCONNECT
CHAIN LOCK
DISCONNECT
ASSEMBLY
6-3/4"
2-1/2"
THIS DIMENSION IS
DETERMINED BY ENGAGING
DRIVE PLUNGER ON
DISCONNECT ASSEMBLY, WITH
TROLLEY SLIDE ASSEMBLY.
(SEE FIGURE )
FIGURE 11
POSITION 1
DOOR ENGAGED POSITION 2
DOOR DISENGAGED
FORMANUAL OPERATION,
PULL CHAIN AND LATCH.
DISCONNECT
CHAIN LOCK
FIGURE 12

SETTING THE LIMIT SWITCHES
1. Remove the cover on the electrical enclosure. There are
two limit nuts on the threaded limit shaft that move
laterally along the shaft as the operator opens and
closes the door. When a limit nut nears the end of the
shaft it activates a (set of) switch(es). Auxiliary switches
may also be present, they are used to control other
functions. These are mounted on a separate bracket
and should not be confused with the the OPEN and
CLOSE Limit Switches which are mounted on a bracket
secured to the base of the electrical enclosure box and
are somewhat hidden from view.
2. Manually set the door to a nearly closed position.
3. Refer to Figure 13. Depress the limit nut retaining
TO AVOID RISK OF ENTRAPMENT AND POSSIBLE
DAMAGE TO THE DOOR AND OPERATOR THE LIMITS
MUST BE ADJUSTED BEFORE APPLYING POWER TO
THE OPERATOR.
WARNING bracket away from the slots in the limit nuts. Turn the
CLOSE limit nut on the shaft until it engages the CLOSE
Limit Switch. The switch will sound an audible “click”
when engaged. If there are auxiliary present, the limit
switch will be the second “click”. Release the retaining
bracket and be sure that it engages in slots of both limit
nuts.
4. Manually raise the door to a nearly OPEN position and
repeat Step #3 with the OPEN limit nut and switch.
5. If auxiliary switches are present, the limit nut will actuate
them just prior to activating the open or close limit
switch. (This is preset at the factory.)
6. Manually move the door to a half open position to avoid
door damage due to incorrect power supply phasing.
On three phase units the door may initially run in the
wrong direction when power is first applied. With the
door in a mid position there will be time to stop the door
before damage can happen if incorrect phasing occurs.
7. A final limit adjustment will be necessary after the
connection of the power supply in order to ensure the
door stops at the proper Open and Close positions.
14 INSTALLATION INSTRUCTIONS
OPEN
LIMIT NUT
CLOSE
LIMIT NUT
OPENLIMIT
SWITCH
CLOSE
LIMIT SWITCH
LIMIT NUT
RETAINER PLATE
LIMIT SHAFT
CONTROL BOX
FIGURE 13

TO PREVENT THE RISK OF PERSONAL INJURY AND/
OR DAMAGE TO DOOR OR PROPERTY, ONLY
OPERATE DOOR CONTROL WHEN DOOR IS IN
CLEAR VIEW. IF CONTROL STATION CANNOT BE
LOCATED WHERE THE DOOR IS VISIBLE OR IF ANY
OTHER DEVICE IS USED TO CONTROL THE DOOR
AN AUXILIARY ENTRAPMENT DEVICE (DOOR EDGE
OR PHOTOELECTRIC) MUST BE CONNECTED.
WARNING
TO PREVENT THE RISK OF PERSONAL INJURY OR
DEATH :
• DISCONNECT POWER AT THE FUSE BOX
BEFORE PROCEEDING.
• ELECTRICAL CONNECTIONS MUST BE
MADE BY A QUALIFIED INDIVIDUAL.
• OBSERVE LOCAL ELECTRICAL CODES WHEN
WIRING THE OPERATOR.
WARNING
NOTE: PowerMaster SL operators have been
designed and constructed for use with
voltages from 115 Volts AC to 575 Volts AC, in
single or three phase. Check the operator
nameplate label on the control box cover for
the proper voltage and phase. The application
of an improper input voltage or phase will
result in catastrophic failure to the internal
electrical components. Observe local electrical
codes when wiring the operator.
When hard wiring, observe state and local
electrical codes. A wiring diagram is attached to
the inside of the control box cover. Connect the
appropriate voltage and phase power leads to the
appropriate terminals as per the wiring diagram
and connect a ground wire to the grounding screw.
On three phase units, incorrect phasing of the
power supply will cause the motor to rotate in the
wrong direction (open when CLOSE button is
pushed and vice versa). To correct this,
interchange any two of the incoming three phase
conductors.
The wiring diagram attached inside the cover of
the control box details all of the field wiring
terminal connections for the operator. Always
connect the wires to the push-button controls and
auxiliary devices exactly as shown.
Warning: Control voltage of the operator is
24 volts AC, Class 2. Do not run the power
leads and control circuit wiring in the same
electrical conduit.
Note: All SL operators are pre-wired to accept
reversing edge components. To comply with UL
requirements, one of these systems must be
installed and wired to the operator. Refer to
Figure 14 for Edge component wiring.
For operator models not installed with reversing
edge components or photoelectric device,
ONLY ONE THREE BUTTON STATION OR A
CONTROL WIRED FOR CONSTANT
PRESSURE TO CLOSE MAY BE USED TO
CONTROL THE OPERATOR. THIS IS TO
COMPLY WITH UL SAFETY REQUIREMENTS.
IN THIS CASE THE CONTROL STATION
MUST BE LOCATED WITHIN CLEAR SIGHT
OF THE DOOR ADJACENT TO A PLACARD
(SUPPLIED WITH THE OPERATOR) WITH
THIS WORDING:
WARNING TO PREVENT
ENTRAPMENT DO NOT START DOOR
CLOSING UNLESS DOOR WAY IS
CLEAR
Operators which are equipped with a reversing
edge circuit may have one or more additional
means of control which should be wired in
accordance with the diagram supplied in the
operator. Refer to Figure 14.
RISK OF ENTRAPMENT THAT MAY RESULT IN
SERIOUS PERSONAL INJURY OR DEATH.
DISCONNECT POWER TO THE OPENER BEFORE
AND DURING INSTALLATION OF AN ACCESSORY
REVERSING DOOR EDGE OR PHOTOELECTRIC
DEVICE. DO NOT RECONNECT POWER TO OPENER
UNTIL INSTRUCTED TO DO SO. ENSURE DOORWAY
IS CLEAR BEFORE STARTING TESTING OF UNIT.
WARNING
15
ELECTRICAL WIRING INSTRUCTIONS

R3 R2 R1
RADIO
RCVR
L1 L2 L3
INCOMING LINE
NOTES:
1 - INSTALL BROWN JUMPER WIRE IF THERE IS NO STOP BUTTON OR EXTERNAL
INTERLOCK SWITCH CONNECTED TO TERMINAL STRIP.
2 - REMOVE VIOLET JUMPER WIRE WHEN TIMER DEFEAT
SWITCH IS USED.
3 - INTERNAL ORANGE JUMPER.
-MOVE THIS JUMPER FROM TERMINAL #7 TO #8 IF ALL OBSTRUCTIONS
SENSORS ARE 2-WIRE TYPE.
-REMOVE JUMPER IF 3-WIRE DEVICES ARE USED.
4 -TREADLES,PULL SWITCHES, KEY SWITCHES, PHOTO-ELECTRIC DEVICES,
ETC.MAY BE CONNECTED TO TERMINALS INDICATED.
5 -REMOTE CONTROL UNITS (EXCLUDING TREADLES AND PHOTO-ELECTRIC UNITS).
PULL SWITCHES AND SINGLE CONTACT CONTROL STATIONS MAY BE CONNECTED
TO TERMINALS INDICATED.
1 2 3 4 5 6 7 8 9 10 11 12 13 14
V
PHOTOCELL
OR 3-WIRE
AIRSWITCH
TIMER DEFEAT
SWITCH (N.C.)
(WHEN REQ'D)
EXT'L INTL'K
(WHEN REQ'D)
BR
ST OP CL
SINGLE
CONTACT
CONTROL 2-WIRE EDGE
OR AIRSWITCH
(SEE NOTE #3) OBSTRUCTION
SENSING DEVICE
OR
54
1
2
3
GND
FIGURE 14
16 INSTALLATION INSTRUCTIONS

NOTE: It is now necessary to turn on the power in order to run the Opener to check for
proper operation and limit settings. Before doing so, ensure that all mounting hardware are
installed and properly tightened, that all electrical connections are per local code requirements, and
that proper wiring practices have been followed. Also, double-check that all ropes and istallation
support hardware have been removed from the door and that the doorway is clear.
IMPORTANT SAFETY INSTRUCTIONS FOR OWNER
•NEVER let children operate or play with door controls. Keep the Remote Control away from
children.
•ALWAYS keep a moving door in sight and keep people and objects away from the door area
until the door is completely closed. NO ONE SHOULD CROSS THE PATH OF A MOVING
DOOR.
•TEST THE DOOR OPENER’S REVERSING FEATURE (where applicable) MONTHLY.
•After adjusting the force setting, if equipped with a clutch, or the limit of travel, ALWAYS
RETEST the Opener. Failure to ADJUST THE OPENER PROPERLY may result in SERIOUS
INJURY OR DEATH.
•DO NOT over adjust the force setting (clutch) to compensate for a poorly working door. See
figure 15 for procedure to check the door operation and for proper clutch adjustment.
•SAVE THIS INSTRUCTION MANUAL AND GIVE TO THE END USER.
TO REDUCE THE RISK OF SEVERE INJURY OR
DEATH: READ AND FOLLOW ALL INSTRUCTIONS!
WARNING
FAILURE TO TEST REVERSING SYSTEM COULD
RESULT IN DEATH OR SERIOUS INJURY. TEST
THIS SYSTEM ONCE A MONTH.
WARNING MOMENTARY CONTACT: Button can be pushed
and then released and door will keep moving or
stop without maintaining pressure on the button.
CONSTANT PRESSURE: Constant pressure is
required on the button in order for continued door
movement. When the button is released the door
will stop and possibly reverse to full open
depending on wiring type.
DOOR EDGE/PHOTOELECTRIC INPUT: The
operator wiring provides for input from an optional
pneumatic or electric door bottom edge or
photoelectric device that will cause a closing door
to stop and may reverse it to open depending on
the wiring type.
WIRING TERMS
17
OPERATION AND ADJUSTMENT INSTRUCTIONS
AVOID ELECTROCUTION:
DO NOT ROUTE LOW VOLTAGE WIRES IN
SAME CONDUIT AS HIGH VOLTAGE WIRES.
FOLLOW ALL LOCAL ELECTRICAL CODES or
THE NATIONAL ELECTRICAL CODE (NEC).
WARNING

CLUTCH ADJUSTMENT
The clutch serves to protect the door, the electric
operator and other equipment from undue stress
or damage caused by starting forces and/or an
obstruction to the door. It should be set no
tighter than is necessary to smoothly and
consistently move the door throughout its full
range of travel. When properly set, it will slip
freely if the door should encounter an
obstruction, and it should be possible to stop the
travel of the door by hand.
WARNING: Before adjustment remove
power to the operator.
1. Remove cotter pin from slotted hex nut and
clutch shaft.
2. Back off slotted hex nut until there is
insufficient tension on clutch spring to permit
clutch to drive door.
3. Tighten slotted hex nut gradually until there is
just enough tension on spring to permit operator
to move door smoothly, but to allow clutch to slip
if door is obstructed.
4. Be sure cotter pin is reinstalled each time
operator is tested for clutch adjustment and that
it is locked in place on completion of adjustment.
CAUTION NEVER COMPRESS CLUTCH
SPRING BEYOND POINT LIMITED BY THE
DESIGN OF THE OPERATOR OR REPLACE IT
WITH A HEAVIER SPRING.
Due to changing conditions of the door and
normal wear, it may be necessary to occasionally
readjust the clutch to obtain dependable
operation.
WARNING: BEFORE DOING SO BE CERTAIN
THAT THE DOOR IS IN GOOD WORKING
CONDITION, AND THAT THE CLUTCH IS NOT
SLIPPING BECAUSE OF LOOSE OR MISSING
HARDWARE, OR THE DOOR BINDING IN THE
TRACK. ANY SERVICE REQUIRED TO THE
DOOR, DOOR SPRINGS OR DOOR
OPERATOR MUST BE PREFORMED BY A
QUALIFIED PROFESSIONAL DOOR
INSTALLER.
The clutch pad will wear during normal operation
and should be replaced when it becomes difficult
or impossible to sufficiently tighten the clutch to
obtain smooth operation of the door when it is in
good working condition. To replace the clutch
pad, first loosen the motor mounting bolts and
remove the V-belt then the clutch adjusting nuts,
spring and clutch pulley. Check condition of V-
belt before reassembly and replace if required.
After reassembly, adjust clutch as described
RISK OF ENTRAPMENT THAT MAY RESULT
IN SERIOUS PERSONAL INJURY OR DEATH.
DISCONNECT POWER TO THE OPENER
BEFORE SERVICING OR MAKING
ADJUSTMENTS. ENSURE DOORWAY IS
CLEAR BEFORE STARTING TESTING OF
UNIT.
WARNING
OPERATION AND ADJUSTMENT INSTRUCTIONS
18
DO NOT STAND IN FRONT OF DOOR TO
TEST REVERSING EDGE. USE A
CORRUGATED BOX OR SIMILAR OBJECT.
WARNING
IMPROPER ADJUSTMENT OF CLUTCH
SETTING COULD CAUSE ENTRAPMENT,
INJURY OR DEATH. SET CLUTCH ADJUSTMENT
FOR JUST ENOUGH FORCE TO OPERATE THE
DOOR RELIABLY, BUT NO STRONGER. Contact
a service professional to correct any binding,
sticking or other door problems. DO NOT OVER-
ADJUST CLUTCH SETTING TO COMPENSATE
FOR A POORLY WORKING DOOR.
WARNING

BRAKE ADJUSTMENT
The solenoid brake on the SL operator is adjusted
at the factory. If it appears that the brake needs
adjustment due to excessive coasting of the door
proceed as follows:
1. Turn off power to the operator.
2. Loosen lock nut.
3. Tighten adjustment nut to increase spring
pressure.
4. Secure adjustment nut with lock nut.
5. Turn on power and test operator.
6. If more braking is required, repeat steps 1
through 5.
7. If solenoid does not pull in or makes a buzzing
sound when fully retracted, the brake spring is
too tight.
ALWAYS DISCONNECT POWER TO THE
OPERATOR BEFORE SERVICING,
CONNECTING ACCESSORY DEVICES OR
MAKING ADJUSTMENTS.
WARNING
19
OPERATION AND ADJUSTMENT INSTRUCTIONS
IMPROPER ADJUSTMENT OF CLUTCH
SETTING COULD CAUSE ENTRAPMENT,
INJURY OR DEATH. SET CLUTCH ADJUSTMENT
FOR JUST ENOUGH FORCE TO OPERATE THE
DOOR RELIABLY, BUT NO STRONGER. Contact
a service professional to correct any binding,
sticking or other door problems. DO NOT OVER-
ADJUST CLUTCH SETTING TO COMPENSATE
FOR A POORLY WORKING DOOR.
WARNING
SOLENOID
MOTOR
BRAKE ADJUSTMENT BOLT LOCK NUT
ADJUSTMENT NUT
TURN CLOCKWISE TO INCREASE DRIVE FORCE.
TO ADJUST REMOVE COTTER PIN AND TURN NUT
1/4 TURN AT A TIME UNTIL DOOR OPENS AND
CLOSES SMOOTHLY. TO MAINTAIN PROTECTION OF
EQUIPMENT DO NOT OVER TIGHTEN. REPLACE
COTTER PIN TO SECURE ADJUSTMENT.
CLUTCH ADJUSTMENT
FIGURE 15

OPERATION AND ADJUSTMENT INSTRUCTIONS
20
1. Mount disconnect assembly to door as
shown in figures10 & 11 of manual. To
determine correct mounting height on door,
place disconnect assembly directly under
trolley traveler leaving 1/2” clearance
between trolley traveler and plunger. Mark
hole location on door. Extend plunger until
spring is fully compressed. Make sure
plunger has a good engagement in trolley
traveler and is not obstructed from fully
compressing the spring. Make Height
adjustments as necessary.
Note: Installation for Bi-Part fire slide door is
shown on next page.
A. When doors are open fused link must
extend into door opening.
B. When doors are closed fused link
support arms must slide past each other.
To accomplish this the disconnect
assemblies must be mounted at different
heights on each door as allowed by their
individual trolley travelers. They may also
be adjusted to separate depths off the door.
2. Adjust drive plunger to center of trolley
traveler, (see figure 10) unless offset is
required for bi-part installation.
3. Install chain lock as shown.
4. Adjustment collars are preset at the factory
but may be moved to make adjustments if
necessary.
FIRE DOOR DISCONNECT INSTALLATION
DRIVE PLUNGER
ADJUSTMENT
COLLARS
FUSED LINK
1 PULL CHAIN DOWN TO
EXTEND DRIVE PLUNGER
INTOTROLLEY TRAVELER.
2 LATCH CHAIN IN CHAIN LOCK
TO SECURE ENGAGED POSITION
OF DRIVE PLUNGER.
