PowerTek PowerJack User manual

PowerJack
Installation Manual

1
Technical Information(STA)
Dimensions Frame Side&Door Side: Atype:131x25x37 mm Btype:195x25x50 mm
I/O
Use with Fail Secure/PTO Locks Only
Electrical rating Input 600mA, 24V DC, powered by Class 2 or
Class 3 power limited source.
The length of connect cable is not great than 30m.
Output 500mAƒ12V DC ƒ 250mAƒ24V DC
Max door gap: 7.0mm; Horizontal < 2mm, vertical < 2mm with door gap
5.0mm
Door side (Receive): DI X 2(REX,LLS)
Frame Side (Side): DO X 2 Solid State Relay
-60V AC/DC, 200 mA
− Door Status (Door Position)
− Error Status
DO X 2(NC/NO/COM) for Door Side DI X 2
- 30VDC,1A / 125VAC,300mA
Door Open Timer
-3 Seconds(Fix Timer)
-1~90 Seconds(by Control)
LED Indicator Bi-Color LED @ Frame Side
Operating Temperature -20℃~60℃
Package Contents
1. Door side unit
2. Frame side unit
3. M3 wood self-tapping screws*4
4. M3 metal self-tapping screws*2
5. M3 countersunk screws*8
6. Washer*6
Recommended Tools
1. Screwdriver
2. Electrodrill
3. Drill bit
4. Center chisel
5. Pencil
6. (wood)firmer chisel
7. Rotary grinding tool

2
PowerJack Dimensions
Atype
Btype

3
Installation Steps
Step1: Survey installation site
Requires depth of 47mm (1 7/8”) in both of frame and door side
Step2: Location
Apply the templates on the door side& frame side, make sure door side& frame side are aligned.
Step3: Installation in wood door or frame
a. Drill a hole for faceplate of depth of 3mm*1/8”+ and diameter25mm*1”+ in the marked place by
Electrodrill.
Align the central
line on template

4
b. Drill a hole for PowerJack of depth of 7mm*1 7/8”+ and diameter 25mm*1”+ in the markedplace.
c. Using wood chisel to even the wood on the edge

5
Make sure the unit and pocket can fit perfectly
d. Drill a wiring channel for connection to the device to be powered
e. Put the PowerJack inside the pocket to see if it fits the pocket

6
Step4 Installation in metal door or frame
a. Drill M3 countersunk screws hole according to template
b. Cut the marked pocket with metal rotary grinding tool

7
Make sure the unit and pocket can fit
perfectly
c. Put the PowerJack inside the pocket to see if it fits the space
d. Fix the M3 countersunk screws by metal gasket

8
Step5. Voltage Selection and wiring
a. Select output voltage of 12V or 24V by adjusting indicated switch
(Voltage adjustment only required to adjust door side)
b. Supply output 24 VDC to frame unit. Connect red wire to positive(+) and black wire to
negative(-)
c. Connect door side unit with the electronic device via wiring channel, connect orange wire to
positive(+) and black wire to negative(-).

9
Power Supply
24V
+[RED]
- [BLACK]
Momentry Open (3 seconds) [GREEN]
Common [YELLOW]
Hold to Open(max. 90 sec) [BROWN]
Door Status [BLUE]
Door Status [GRAY]
Error Status [YELLOW]
Error Status [WHITE]
NC1 [BLACK / WHITE]
COM1 (for switch #1) [GRAY / WHITE]
NO1 [PURPLE / WHITE]
NC2 [GREEN / WHITE]
COM2(forswitch#2)[BLACK/YELLOW]
NO2 [PINK]
SWITCH #1 [BLUE]
SWITCH #1 [GRAY]
SWITCH #2 [YELLOW]
SWITCH #2 [WHITE]
OUTPUT
Positive [ORANGE]
Negative [BLACK]
d. Sensor Wiring Diagram
