PPE Xcelerator User manual

Xcelerators Owner’s Manual
HOT+2 E.T. RACE
2001-2007 Duramax LB7/LLY/LBZ Engines
2007-2010 Duramax LMM Engine
Rev: 2/22/13 | v17
Pacic Performance Engineering, Inc.
www.ppediesel.com
The Ultimate In Racing Calibrations!
Maximum performance designed for closed course racing applications.
SPECIAL PARTS NOTICE:
This part has been specically designed for O󰀨-Highway application only. Since the installation of this part may either impair
your vehicle’s emission control performance or be uncertied under current Motor Vehicle Safety Standards, it should not
be installed in a vehicle used on any street or highway. Additionally, any such application could adversely a󰀨ect the warranty
coverage of such an on-street or highway vehicle.

1
Xcelerators Owner’s Manual
DISCLAIMER OF LIABILITY
This is a performance product which, increases horsepower above factory specications. Additional
horsepower creates more stress on your vehicle’s drivetrain components which may result in drivetrain
failure. This product is Legal in California only for racing vehicles which may never be used on the highway.
This notice publication to engine and vehicles which are o󰀨 the public highways except where specically
noted otherwise. Federal law restricts the removal of any part of a federally required emission control
system on motor vehicles. Further, many states have enacted laws which prohibit tampering with or
modifying any required emission or noise control system. Vehicles which are not operated on public
highways are generally exempt from most regulations, as are some special interest and pre-emission
vehicles. The reader is strongly urged to check all applicable local and state laws.
Many of the parts described or listed on this website are merchandise for o󰀨-highway application only,
and are tagged with the “Special Parts Notice” reproduced here:
This agreement sets forth the terms and conditions for the use of this product. The installation of this
product indicates that the Buyer has read and understands this agreement and accepts the terms and
conditions.
Pacic Performance Engineering Inc., its distributors, employees, and dealers (the “Seller”) shall not
be responsible for this product’s improper use and service. The Buyer hereby waives all liability claims.
The Buyer hereby acknowledges no reliance on the Seller’s skill or judgment to select or furnish goods
suitable for any particular purpose and that there are no liabilities which extend beyond the description
on the face hereof, and the Buyer hereby waives all remedies or liabilities expressed or implied, arising
by law or otherwise (including without any obligation of the Seller with respect to tness, merchantability
and consequential damages), or whether or not occasioned by the Seller’s negligence.
The Seller disclaims any warranty and expressly disclaims any liability for personal injury or damages.
The Buyer acknowledges and agrees that the disclaimer of any liability for personal injury is a material
term for this agreement and the Buyer agrees to indemnify the Seller and to hold the Seller harmless
from any claim related to the item of equipment purchased. Under no circumstances will the Seller be
liable for any damages or expenses by reason of use or sale of any such equipment.
The Seller assumes no liability regarding the improper installation or misapplication of its products. It
is the installer’s responsibility to check for proper installation and if in doubt, contact the manufacturer.
The Buyer is solely responsible for all warranty issues from the manufacturer.
LIMITATION OF WARRANTY
The Seller gives Limited Warranty as to description, quality, merchantability, and tness for a particular purpose, productiveness, or any
other matter of Seller’s product sold herewith. The Seller shall not be responsible for the products proper use and service and the Buyer
hereby waives all rights other than those expressly written herein. This warranty shall not be extended, altered or varied except by a
written instrument signed by Seller and Buyer.
The Warranty is limited to one (1) year from the date of sale and limited solely to the parts contained within the products kit. All products
that are in question of Warranty must be returned prepaid to the Seller and must be accompanied by a dated proof of purchase receipt.
All Warranty claims are subject to approval by Seller.
Under no circumstances will the Seller be liable for any labor charged or travel time incurred in diagnosis for defects, removal, or
reinstallation of this product or any other contingent expenses.
Under no circumstances will the Seller be liable for any damage or expenses incurred by reason of the use or sale of any such equipment.
In the event that the Buyer does not agree with this agreement; the Buyer may promptly return this product, in a new and unused
condition in its original packaging, with a dated proof of purchase to the place of purchase within ten (10) days from date of purchase
for a full refund.
The installation of this product indicates that the Buyer has read and understands this agreement and accepts its terms and conditions.
ATTENTION: Please read instructions carefully before installing the programmer into your ve-
hicle; failure to do so may result in damage to your vehicle’s PCM!
CAUTION: No engine power limiting.
This race tuner will also reprogram engine computer to remove all limp home engine safety self
protection features such as auto power reduction or power down due to high engine
coolant temperature, low oil pressure, high or low fuel pressure, low or high boost pressure or
any sensor failure.

TABLE OF CONTENTS
2
3-5
4
6
6
7
8
9
10-11
13
14
15
16
17
18
19-20
21
22
23
24
25-26
Description and Parts & Accessories
Display and Keypad Description
Before Installing PPE Tunes
Preparing Your Vehicle for Tune Installation
Fuse Removal
OBD II Port Location
Power Levels
Installing Tune Into Vehicle ECM
Restoring Factory/Stock Tune
Calibration
Custom Changes
Current Vehicle Tuning
Data Scanning
Get Diagnostic Trouble Codes
Transmission Re-learn Procedure
Other Options
Frequently Asked Questions
Online Update
Optional Parts
Notes
Xcelerators Owner’s Manual

Xcelerators Owner’s Manual
3
2001-2010 DURAMAX HOT+2 E.T. RACE XCELERATOR
Designed to be used with PPE’s (or any) stand alone harness. If you
want the ultimate in “Program Power,” then you want the PPE Hot+2 E.T. Race
Xcelerator. The agship of the PPE line of Xcelerator Programmers, the Hot+2
E.T. Race Xcelerator is for those individuals who want the ultimate in racing
calibrations and control over your engine’s operations. The Hot+2 E.T. provides
six power levels of additional horsepower and torque and the ability to tune for
any scenario. That means an unreal 425 hp and 620 lb. ft. of torque increase
with a few simple keystrokes! This is the tuner for those who have it all on their
engine and want to get the most from those additions. The PPE Hot+2 E.T.
Xcelerator enables you to add huge power, and also remove transmission torque
limits which eliminates defueling for full power and aggressive up shifts. All of
which drastically improves elapsed times. Speaking of racing, the programmer
allows for the use of all specially formulated racing diesel fuels that are required
when participating in a particular sanctioned racing event. How about adjusting
the Speed Limiter or raising the rpm limit? No problem. Those are just some of
the choices you have with the Xcelerator Hot+2 E.T. For maximum performance
adding a Dual Fueler, racing cam, ported heads and a turbo upgrade are highly
recommended.
FEATURES:
- Eliminates the need for a body control module
- Disables ignition key security (engine will start and run in any
application)
- Engine will start and run in any hot rod/race or marine conguration
with or without a transmission
- Transmission reset and quick learn feature for faster transmission
relearn
- Speedometer corrections (for tire sizes from 27” through 44” at
¼” increments)
- Adjustable speed limiter (from 40 to 200 mph in 1 mph increments)
- Increased rev limit from 3,200 to 5,000 rpm
- Adjustable gear ratio from 2.73 to 5.13
- Read real-time date (for engine diagnostics and code clearing)
- Not compatible with emissions controlled vehicles
- Allows for the use of all specially formulated racing diesel fuels as
required by a particular sanctioned event
- Removes transmission’s torque limiting defueling for full power
aggressive racing up shifts which improves dragm strip
elapsed times
- These controllers will not operate any of the production gauges.
Aftermarket gauges are required.
- The vehicle’s factory air conditioning is disabled by the controller
- For best power, we recommend also installing a high-ow exhaust
that is 4 inch or larger

Xcelerators Owner’s Manual
4
CAUTION: This race tuner will reprogram engine computer to remove all limp
home engine safety self protection features such as auto power reduction or
power down due to high engine coolant temperature, low oil pressure, high or
low fuel pressure, low or high boost pressure or any sensor failure.
*This notice pertains to engine and vehicles which are o󰀨 the public highways
expect where specically noted otherwise. Federal law restricts the removal of
any part of a federally required emission control system on motor vehicles.
Further, many states enacted laws which prohibit tampering with or modifying
any required emission or noise control system. Vehicles which are not operated
on public highways are generally exempt from most regulations, as are some
special interest and pre-emission vehicles. The reader is strongly urged to check
all applicable local and state laws.
Many of the parts described or listed on this website are merchandise for
o󰀨-highway application only, and are tagged with the “Special Parts Notice”
reproduced here:
SPECIAL PARTS NOTICE:
This part has been specically designed for OFF-Highway application only. Since
the installation of this part may either impair your vehicle’s emission control
performance or be uncertied under current Motor Vehicle Safety Standards, it
should not be installed in a vehicle used on any street or highway. Additionally,
any such application could adversely e󰀨ect the warranty coverage of such a
on-street or highway vehicle.
Available for:
2001-2007 (1110400)
2007.5-2010 (1110500)

Xcelerators Owner’s Manual
5
-Xcelerator Tuner (1)
-Xcelerator Carrying Case (1)
-OBD II Cable (1)
-Xcelerator Owners Manual (1)
-Warranty Card (1)
-PPE Power Stickers (2)
PARTS AND ACCESSORIES
- Up Button
- Down Button
- Scan/Add Button
- DTC/Subtract Button
- Yes/Enter Button
- Exit/Back Button
Keypad Functions

Xcelerators Owner’s Manual
Please read through the owners manual before installing tune in your vehicle,
failure to follow proper instructions can result in a damaged or disabled PCM.
User MUST ensure that the factory “stock” tune is in the vehicle’s PCM before
installing the Xcelerator tune. GM dealer re-ashes are the same as stock factory
tune.
Serious engine damage can occur if the Xcelerator tune is installed over a
non-factory / aftermarket performance tune.
WARNING
Do not perform any operations on Xcelerator (except live data
diagnostics) while vehicle is running. The vehicle must be
parked and engine OFF.
BEFORE INSTALLING XCELERATOR TUNES
• Turn headlights o󰀨 to prevent unecessary battery drain.
• Always have all the doors closed while installing the Xcelerator tunes, and
keep them closed until process is complete. (windows can be down before
starting installation if ventilation is needed)
• All vehicle accessories and electronics using auxilary outputs must be
• disconnected prior to connecting the programmer into your vehicle’s OBD II
port. (ipod, satellite radio, cell phone charger, GPS, etc.) These devices can
cause interference when running through the installation process.
• Do not turn on stereo, A/C, or heater while installing tune.
• Unless instructed by the Xcelerator, never turn the ignition key OFF while the
Xcelerator is plugged in the diagnostic port.
• Do not unplug the Xcelerator while it is installing the performance tune.
• Do not try to install tune on your vehicle if battery voltage is low. Charge your
battery if necessary.
• If your vehicle is attached to a trailer, make sure the brake light receptical
outlet and plug are disconnected.
PREPARING YOUR VEHICLE FOR TUNE INSTALLATION
6

Xcelerators Owner’s Manual
Remove fuses corresponding to your vehicle year specied below;
*Note:
The INFO TMNT fuse can be found by opening the driver’s side
door and removing the side panel or will be in the fuse box under
the hood.
All other fuses are located in the fuse box under the hood
(Be sure not to confuse the RDO fuse with the RDO AMP fuse!)
7
FUSE REMOVAL
Year Engine Pull Fuse Pull Fuse Pull Fuse Pull Fuse LOCATION
2001 LB7 SEO-1 SEO-2 CAB
2002 LB7 SEO-1 SEO-2 CAB
2003 LB7 TBC BATT TBC IGNITION INFO RADIO HOOD
2004 LB7 TBC BATT TBC IGNITION INFO RADIO HOOD
2004.5 LLY TBC BATT TBC IGNITION INFO RADIO HOOD
2005 LLY TBC BATT TBC IGNITION INFO RADIO HOOD
2006 LLY2 **INFO **RADIO HOOD
2006.5 LBZ **INFO **RADIO HOOD
2007 LBZ **INFO **RADIO HOOD
2007.5 LMM INFO (TMNT) RDO IPC CAB/HOOD
2008 LMM INFO TMNT RDO IPC CAB/HOOD
2009 LMM INFO TMNT RDO IPC CAB/HOOD
2010 LMM INFO TMNT RDO IPC CAB/HOOD
IMPORTANT!
**2006-2007 LLY2/LBZ ONLY pull fuses if you get a “No
Communication” error while installing your Xcelerator.

Xcelerators Owner’s Manual
Driver side underneath dash in the center.
OBD II PORT LOCATION
Plug in OBD II cable as show below.
8

Xcelerators Owner’s Manual
9
XCELERATOR POWER LEVELS
Important:
Stock exhaust must be removed while Hot Race LMM Xcelerator is
loaded into your vehicle; the diesel particulate lter regeneration
procedure is removed and soot will accumulate in the particulate lter
and will adversely a󰀨ect the performance of your vehicle.
Recommended:
For maximum performance, use the Hot Race LMM Xcelerator with
ported heads, racing cam shafts and LMM Dual Fueler.

Xcelerators Owner’s Manual
10
Selection arrow will be on “Tune Engine” option.
Select on the keypad.
Thouroughly read message with the on the keypad.
Accept by pressing on the keypad.
Locate the OBD II diagnostic port on your vehicle.
(See page 6 for reference pictures)
INSTALLING TUNE INTO VEHICLE PCM
STEP 1
Connect the Xcelerator into vehicles diagnostic port. When prompted turn the
ignition key to the RUN position (DO NOT start engine); the Xcelerator will load
through a seris screens and stop. The main menu will load as shown:
STEP 2
Tune Engine
Current Tuning
Data Scanning
Diag. Options
STEP 3
The programmer will check your VIN #, unlock your PCM and save the vehicle’s
stock information. Do not disturb the Xcelerator or start the engine during this
download and testing process! (approx 5-10 mins.)
Any interference during the programming process (ie. opening or clos-
ing of your vehicle’s doors) may cause a communication error with your
vehicle’s PCM and will result in your vehicle not starting!
STEP 4
If you are going
past this screen
you have Read
and Agreed to
the Disclaimer
provided in the
package.
Accept Y or N

Xcelerators Owner’s Manual
The next menu will show the “Select Tune” screen, press until the arrow
is next to the “Install Tune” option.
Press to install tune.
11
The next menu will show the “Select Tune” option, press on the keypad.
STEP 5
Select Tune
Calibration
Custom Changes
Install Tune
Use or to browse through power levels.
(Power levels on page 7)
Accept power level by pressing on the keypad.
STEP 6
Choose Your
Performance Need
Tune 1
/ Y to Select
STEP 7
The Xcelerator screen will show you the tune you selected and the
settings it will be changing. Press on the keypad to continue to the next
screen.
STEP 8
Note: Text may look slightly di󰀨erent depending on the vehicle year/model.
Select Tune
Calibration
Custom Changes
Install Tune
Calibration page 12
Custom Changes page 13
Note: Text may look slightly di󰀨erent depending on the vehicle year/model.
Timing Added Yes
Fuel Added Yes
RPM Increase Yes
De-Fueling Yes
LLM Tune 1
Spd Limit 98Mph
LLM - ‘09
30.00” - 3.73

Xcelerators Owner’s Manual
12
The Xcelerator will display the following screen to conrm your installation.
You can press or to select “Install Tune” or “Return to Stock”.
STEP 8 (continued)
Install Tune
Return to Stock
/ Y to Select
Install Performance tune by pressing on the “Install Tune” option.
Note: Select “Return to Stock” option if you do not wish to continue with
installation and factory settings will be restored.
The Xcelerator will now run through a series of screens.
Any interference during the programming process (ie. opening or closing
of your vehicle’s doors) may cause a communication error with your
vehicle’s PCM and will result in your vehicle not starting!
(approx 5-10 mins.)
Final installation screen will show the following message:
Re-install fuses, installation complete.
STEP 9
Power Increased
Tu rn Key Off and
Remove the Tuner
From Your Truck
Installing Your
Selected Tuning
Accessing
Stock Data
Installing Your
Selected Tuning
Making Changes
to Stock Data
Unlocking PCM,
Do Not Disturb
or Start the
Engine.
Installing Your
Selected Tuning
DO NOT Disturb00
Please Wait for
15 Seconds

Xcelerators Owner’s Manual
13
RESTORING FACTORY/STOCK TUNE
• We recommend restoring the stock tune whenever the vehicle goes in for
service.
• The stock tune can be installed at any time using the “Back to Stock” feature.
This feature will take PPE tune out and reset the vehicle ECM (Engine Control
Module) to factory/stock.
• It is recommended to return Xcelerator back to stock when doing a software
update.
Locate the OBD II diagnostic port on your vehicle.
STEP 1
STEP 2
Tune Engine
Current Tuning
Data Scanning
Diag. Options
Selection arrow will be on “Tune Engine” option.
Press on the keypad to go down to “Diag.
Options”(Diagnostic Options) press .
STEP 3
The Xcelerator will now display “Return truck Back to Stock” press on the
keypad. Xcelerator will display a series of screens, please wait.
STEP 5
From the “Diagnostic Options” menu press on the keypad to go down to
“Back to Stock” and press .
STEP 4
Return Truck
Back to Stock
Select Y or N
Returning Truck
Back to Stock
DO NOT DisturbXX
Please Wait for
15 Seconds
Back to Stock
Tu rn Key Off and
Remove the Tuner
From Your Truck
Connect the Xcelerator into vehicles diagnostic port. When prompted turn the
ignition key to the RUN position (DO NOT start engine); the Xcelerator will load
through a seris screens and stop. The main menu
will load as shown:

Xcelerators Owner’s Manual
14
CALIBRATION
Calibrations can be modied after selecting power level when installing a tune.
Modify speed limiter, adjust tire size, adjust axle ratio, and remove security.
Press go to “Calibration”. Press to see calibration menu options.
Select Tune
Calibration
Custom Changes
Install Tune
Speed Limiter
Adj Tire Size
Adj Axel Ratio
Remove Security
Use or to browse through calibration options.
Choose option and press to change.
SPEED LIMITER
Adjust your vehicle’s speed limiter from 40mph to 200mph in 1mph increments.
Use or to increase/decrease speed limiter.
Press once desired limit is set.
(Note: Pressing YES will take you back to calibration menu)
ADJUST TIRE SIZE
This option lets you adjust for tires ranging from 25” to 44.75”. If a tire size is
selected over 35” an ABS / break light will be triggered, requiring a custom ABS
calibrtation via GM TECH2 scanner for: 2001 - 2007 LB7, LLY, LBZ only. The
LMM is not compatiable with tire size of 35” to 44.75”. Call PPE for details.
Use or to increase/decrease tire size.
Press once desired size is set.
(Note: Pressing YES will take you back to calibration menu)
ADJUST AXEL RATIO
Adjust your vehicle’s gear ratio from 2.73 to 5.13 (ie. 2500 HD gear ratio is 3.73)
Use or to increase/decrease tire size.
Press once desired size is set.
(Note: Pressing YES will take you back to calibration menu)
REMOVE SECURITY
Remove security is used for applications where OEM steering column and key
security system is not used. (ie. engine swaps into custom vehicles/marine)
After all calibrations are set press to go back to “Select Tune” menu.

Xcelerators Owner’s Manual
Use or to browse through custom changes options.
Choose option and press to change.
CUSTOM CHANGES
Custom changes can be modied after selecting power level when installing a
tune. Modify timing, Fuel, RPM increase, and De-Fueling.
Press go to “Custom Changes”.
Press to see custom changes menu options.
Yes Timing
Yes Fuel Added
Yes RPM Increase
Yes De-Fueling
Select Tune
Calibration
Custom Changes
Install Tune
Note: We recommend not moding these settings if you want maximum
performance and fuel economy. (Exception when stacking the PPE Xcelerator)
TIMING
Increase your vehicle’s timing.
Use or to toggle On or O󰀨 (Yes/On No/O󰀨).
(Note: Pressing YES or NO will take you back to custom changes menu)
FUEL
Increase your vehicle’s fuel.
Use or to toggle On or O󰀨 (Yes/On No/O󰀨).
(Note: Pressing YES or NO will take you back to custom changes menu)
RPM Increase
Increase your vehicle’s RPM.
Use or to toggle On or O󰀨 (Yes/On No/O󰀨).
(Note: Pressing YES or NO will take you back to custom changes menu)
DE-FUELING (Hot+2 ET only)
Toggle De-Fueling On/OFF.
Use or to toggle On or O󰀨 (Yes/On No/O󰀨).
(Note: Pressing YES or NO will take you back to custom changes menu)
15

Xcelerators Owner’s Manual
Locate the OBD II diagnostic port on your vehicle.
(See page 6 for reference pictures)
CURRENT VEHICLE TUNING
STEP 1
STEP 2
Tune Engine
Current Tuning
Data Scanning
Diag. Options
• Current tuning option will show the current tune installed into your vehicle.
Selection arrow will be on “Tune Engine” option.
Press on the keypad to go down to “Current Tuning” press .
STEP 3
Screen will load showing your vehicles current tune, calibrations,
and custom changes.
16
Press on the keypad to go back to main menu.
Connect the Xcelerator into vehicles diagnostic port. When prompted turn the
ignition key to the RUN position (DO NOT start engine); the Xcelerator will load
through a seris screens and stop. The main menu will load as shown:

Xcelerators Owner’s Manual
Locate the OBD II diagnostic port on your vehicle.
(See page 6 for reference pictures)
DATA SCANNING
STEP 1
STEP 2
Tune Engine
Current Tuning
Data Scanning
Diag. Options
• View real-time engine date while vehicle is running.
Selection arrow will be on “Tune Engine” option.
Press on the keypad to go down to “Data Scanning” press .
STEP 3
View real-time engine data for speed mph, engine temperature, engine rpm, air
lter intake temperature, intake manifold air temperature, throttle percent, mass
air ow, barometric pressure, manifold turbo boost pressure plus more.
17
Press on the keypad to go back to main menu.
Connect the Xcelerator into vehicles diagnostic port. When prompted turn the
ignition key to the RUN position (DO NOT start engine); the Xcelerator will load
through a seris screens and stop. The main menu will load as shown:

Xcelerators Owner’s Manual
18
Locate the OBD II diagnostic port on your vehicle.
(See page 6 for reference pictures)
GET DIAGNOSTIC TROUBLE CODES
STEP 1
STEP 2
Tune Engine
Current Tuning
Data Scanning
Diag. Options
• View and clear vehicle’s Diagnostic Trouble Codes from vehicle’s OBD II port
Selection arrow will be be on “Tune Engine” option.
Press on the keypad to go down to “Diag.
Options”(Diagnostic Options) press .
Selection arrow will be on “Get DTC’s” option. Press on the keypad to get
your vehicles Diagnostic Trouble Codes.
If there is no DTC codes, you will see the following screen press
to go back.
Getting a code and you dont know what it means? DTC codes can be
referenced online at www.PPEDIESEL.com/dtc
(Note: Pressing will clear DTC’s and take you back to “Diag.
Options” menu)
STEP 3
Get DTC’s
Reset Auto Tran
Back to Stock
Other Options
No DTC Codes Set
Press any Button
to Continue. . .
Connect the Xcelerator into vehicles diagnostic port. When prompted turn the
ignition key to the RUN position (DO NOT start engine); the Xcelerator will load
through a seris screens and stop. The main menu will load as shown:

Xcelerators Owner’s Manual
Locate the OBD II diagnostic port on your vehicle.
(See page 6 for reference pictures)
TRANSMISSION RE-LEARN PROCEDURE
STEP 1
Connect the Xcelerator into vehicles diagnostic port and turn the ignition key to
the RUN position (DO NOT start engine); the Xcelerator will load through a few
screens and stop the at the main menu shown:
STEP 2
Tune Engine
Current Tuning
Data Scanning
Diag. Options
• Allows vehicle to reset transmission and rapidly adjust to new power levels
• Recommended after installing a new power level
• Recommended after installing any transmission upgrades (ie. Clutches,
Torque Converter, and Shift Kit)
• Transmission feels like it is not shifting properly
Selection arrow will be be on “Tune Engine” option.
Press on the keypad to go down to “Diag.
Options”(Diagnostic Options) press .
STEP 3
Get DTC’s
Reset Auto Tran
Back to Stock
Other Options
Selection arrow will be on “Get DTC’s” option.
Press on the keypad to go down to “Reset Auto Tran” press .
19
