PR Lighting XRLED PR-8177A User manual

1
XRLED 1500-W Framing
PR-8177A
This product manual contains important information about the safe installation and use of this projector.
Pleaseread and followtheseinstructions carefullyandkeepthismanualin asafeplaceforfuturereference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2
INDEX
1.
SAFETYANDWARNINGS ………………………………………………………………………………………
3
2.
INSTRUCTIONS……………………………………………………………………………………………………
4
3.
APPEARANCE………………………………………………………………………………………………………
5
4.
INSTALLATION……………………………………………………………………………………………………
5
5.
SETUPANDCONFIGURATION……………………………………………………………………………………
8
6.
OPERATIONMENU ………………………………………………………………………………………………
10
7.
DMXPROTOCOL …………………………………………………………………………………………………
13
8.
TECHNICALDATA…………………………………………………………………………………………………
21
9.
CIRCUITDIAGRAM&PCB CONNECTIONS ……………………………………………………………………
24
10.
COMPONENTORDERCODES……………………………………………………………………………………
30
The following items are supplied withtheprojector andplease check:
Name
Quantity
Unit
Remark
Gclamp
2
Pcs
XLRconnector
1
Set
Maleand female
Safetycord
2
Pc
User manual
1
Pc
Ω clamp
2
Pcs
Optional
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change
without notice. Whilstevery care istakeninthe preparationof themanualwereservetheright to change specificationsinthe
course of product improvement. The publishers cannot be heldresponsible forthe accuracy of the information herein, orany
consequencearisingfromthem.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / orthe unit are
in good condition before installation and use. Should there be any damage caused by transportation, consult yourdealer and
donotusetheunit.Anydamage causedby improperusewillnotbeassumedby the manufacturerand/ordealer.
Anyfuturetechnicalchangesarenotsubjecttofurthernotice.
Note: Forthe products made by Guangzhou PR lighting Ltd, the warranty forthe whole product isone yearstarting from
the delivery date but the light source isnotwithinthewarranty.

3
1. SAFETYANDWARNINGS
NOTE
Before a projector’s installation, power-on, operation and maintenance, please carefully read
the safety information hereinafter!
Thefollowingsafetysignsareusedintheusermanual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
● When unpacking , check if there istransportation damage before using the projector. Should there be any
damagecausedbytransportation,consultyourdealeranddonotuse it.
●The manufacture is not responsible for loss caused bythe user not following the manual or changing the projector
ashe/shelikes
●Please be noted that thedamagecaused by changingthe projectoratwill is not warranted.
● Do not hesitate to contact the dealer or the manufacturer if any questions or advice.
● Theprojector is forindooruseonly,IP20.
● Use only in dry locations. Keep this unit away from rain and moisture, excessive heat, humidity and dust. Do not
allowcontact withwateroranyother liquids.
●The projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while
beingoperated
●The projector is only intended for installation, operation and maintenance by qualified personnel. And the
operationmuststrictlyfollowtheproceduresinthemanual
●No repairablepartsintheprojectoranddonot opencovers for maintenanceby yourself.
●Don’t look straightly into the light sources especially for epileptics, otherwise eyes willbeburned.
●Do not connectthisdevice to any typeofdimmerpack
●After lamp switchedon, the minimumdistancebetweenthe projector and illuminated surface is 5m
●If there are visible damages on the lamp, lens and protective cover for the screen, i.e., to the extent whichaffects
itsperformancelikecrackingordeformation,pleasestop usingitandcontactthemanufacturefortheir
replacement withoriginalparts,otherwiseitsperformance willbecompromised
.
●Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a
projectorwhilecovers(housing)areoff
●Keepthelamp cleananddo nottouch itwithbarehands.
●Whileoperating it,wearprotective items.
●Anyelectricalconnectionmustbecarriedoutbyaqualifiedperson.
●Before installation,pleaseconfirm the voltage supplied matches whatisrequired fortheprojector
●Eachprojector mustbeproperlyearthedandinstalledasperrelatedelectricalstandards.
●Do notusepower cord withitsinsulatordamaged andconnect thepower cord withother cables.
●If the projector is not used or under cleaning,, please hold the plug and unplugit. Do not unplug it forcefully
orbypullingthepowercable.
●Allpower cordsmustconformtorelated safetyandregulations

4
●Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other
electrical parts’ life will be shortened .
●TheprojectorisofclassIP65,and notusedintheenvironmenthigherthanit.
●There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety
cordsuppliedthroughthesafetycord holes for safetysupport.
●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from
power mains.
●Afterrunning for30minutes, thetemperatureofthe housingoftheprojectoris45℃.After stable operation,
itstemperatureis80℃.
●While the lamp is stricken for the first time, there will be smoke and strange smell. It’s normal and does not
mean theprojector hassomedefects.
● Don’t touch the covers of the working projector(They areveryhot!)
●Do notmounttheprojectordirectlyoninflammable surface.
●Do not project the beam straightly on combustible items and the minimum distance between the
projectorandilluminateditemsis5m.
●Aprojector should be installed with good ventilationand the minimum distance between the projector
andwalls is50cm.Atthesametime,pleaseensurethefansand airinletsandoutletsareworkable.
2. INSTRUCTIONS
●CLEANINGANDMAINTENANCE
If a projector can’t start. Please check if the fuse is blown up. If it does, replace it with a new fuse with same ratings. And the
projector has over-temperature protective device. If the temperature is too high, the protective device will be triggered to shut the
projector off. When it happens, please check if the fans run normally or fan shield is blocked by dust. After the issue is solved,
restart theprojector.
The accumulationof oil, smoke and dust on the lens will compromise the light output. Cleaning a projector is very necessary to
ensure a reliable use of it. Cooling fans need tobe cleaned every15days. Internal lens, reflector and hotmirror need to be cleaned
periodicallyto optimizelightoutput.
Cleaningfrequency is to be decided by operationsand its environment. Use soft cloth and normal detergent forglass for cleaning
work. It’s advised external optical system be cleaned every 20days and internal optical systems every 30/60days. Keep lens clean
and do nottouch optical partswith bare hands.
●Beforeanymaintenanceandcleaning,please ensuretheprojectisoff thepower
●Onlyqualifiedpersonis allowedtodomaintenance
●Duringmaintenanceandbeforemaintenance,theprojector mustbeoffpower.
●To avoid internal damage, sun light or other light mustn’t penetrate into the projector via front lens
whetheritrunsornot
●Do notusealcohol or other organicsolventto clean the housingto avoiddamage.
●Do notuseany solventwithchemicalelementstocleancolorfiltersorhotmirror.

5
●LUBRICATION
Toensuresmooth movement of gobos and focus lens, it’s advised rotators’ bearings and 2 sliding bars for focus lens be lubricated
every 2 months.High qualityand high temperature lubricant/greaseisadvised..
●TROUBLESHOOTING
PROBLEM
ACTION
Theprojectorcan’t be switchedon
Check ifthe fuse is burned
Check ifthe powercord is connected well
Check if the switching power supply is bad or not connected well. A
professionaltechnicianisrequiredfortherepair
Check if the control board is connected well. .Aprofessional technician
isrequired fortherepair
Theprojectorcanbeswitchedon,buttheLED
lamp’s brightness can’t be controlled
Check if the LED driver board is connected well. A professional
technicianisrequiredfortherepair
Theprojectorcanbeswitchedonnormally,but
notcontrolledbytheDMXcontroller
Makesurethatthe fixture’s start address is right
Replaceorrepair theXLR signalcable.
Thebeamisnotbrightanditsbrightness
decreasessharply
Makesurethefansareworkingwellor fansand theirshieldsarenotblocked
bydust.
Makesurethattheinternalopticsisclean.
Theprojectimageappearsto havea halo
CarefullycleantheLEDlamp,opticallensesandother components.
HeavilyDefectiveBeam
Check if lensarein goodcondition(notcracked)
Cleandustorgreaseonthelens.
3. APPEARANCE
4. INSTALLATION
●RIGGING
During transportation, please lock the projector well; Before the use of projector please unlock the head. It’s forbidden to run the
projector withoutunlockPan andTilt
BASE
ARM
HEAD

6
Take 2 clamps and 1 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to
each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNINGon the underside of
the base as shown above) Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning.
Always ensure that the structure that youare going to mount the projector issecure and is strongenough to supportthe weight of the
fixture.
WARNING:
●TheprojectorMUSTbeliftedorcarriedbytheHANDLESinsteadofclamps.
●.For safety the safety cord should afford 10 times the Projector’s weight.
●.Forsafety, itshouldnotbe hungby itssides.
●POWERCONNECTIONS
Connectthepowercordas follows:
L(live)=brown
E(earth)=yellow/green
N(neutral)=blue
Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each
projectorbeconnected withpower separatelyso thattheymaybeindividuallyswitched onandoff.
●The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in
accordancewiththe standardsconcerned.
●Ifanyquestionsaboutthe electrical installation,do not continuebutconsulta qualifiedelectrician.
● The lighting fixture is with waterproof power socket, it should be equipped with same IPrating power
plug.
CLAMP
SAFETY
CORD
WARMING
Please run safety cord
through 2 safety holes for
safety

7
●DMXCONTROLCONNECTION
Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with
each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the
projector)or5 pinXLRplugs andsockets.TheXLR'sare connectedasshowninthefigureabove.
Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. XLR plugs and sockets
mustn’t be connected in any way other than mentioned in the above figure. The projector accepts digital control signals in protocol
DMX512(1990).
Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second
fixture’s DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX
terminatorasshowninthefigurebelow.
●DMXTERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents
electrical noisefromdisturbingandcorruptingtheDMXcontrol signals.
The DMX terminator is simply an XLR connector with a 120(ohm) resistor connected across pins 2 and 3, which is then plugged
intotheoutputsocketonthe lastprojector in the chain.Theconnectionsare illustrated below
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain. PIN 3
PIN 2

8
●REPLACEMENTOFGOBOS
Lockthetiltandunfasten6fastfitscrewsinthefront cove. Open the cover and you’ll see the structures as the figures above.
For the replacement of color filters, use the fingersto remove the filters and place newones.
For the rotating gobos: remove the rotator by hand; remove the gobo after the tightening springforthe gobo is taken out. Place a new
gobo in the rotator and putback the spring. And ensure the springis into the narrowend of the rotator, i.e., inner ring of the rotator. At
last, usea proper tool topull the tighteningclipandput therotator backto thewheel with the helpoftheother hand.
Note:Donottouchthe colorfilters,glassgobos withbarehand.There mustbe softandcleanpaperor clothbetweenthehandandthe
glass gobo.Tightenthe6 fastfitscrewsafterthecover isput back.UnlocktheTilt.
DANGER!
BEFORETHEREPLACEMENTOFGOBOANDCOLORFILTER,THEPROJECTORMUSTBEOFF
POWER.
5.SETUPANDCONFIGURATION
●FRONTPANELOPERATION
Theconfigurationandstartaddresscanbesetconvenientlyviapushbuttonandcolortouchscreen.
To view or change its setup, touch any white area of the screen or push the key OK for more than 3 seconds to unlock the
display(While only on battery, push OK key). After the unlocking, push ►keyto enter into function menus. Each main menu has its
submenus and each submenu has a specific function. For details, please see the “OPERATION MENU” with following
the 6th point..
1. Inthepageoffunctionsetup,pushany keyof ◄, ►, ▲and ▼oricon forthefunctiondesired.
2. At2nd ,3rd and4th level menus, key ◄meansESCAPE, key ►won’t function, key OK means ENTER.Push key OK to
Rotatinggobowheel
Fixedgobowheel
Colorwheel

9
save any changes o enter into submenus. Push key ▲or ▼to change numbers(plus or minus) or tap any item required
forchanges.
Push the left key or shortcut key X to go back to the upper level menu. If none pushed, the system will go back to initial display
automatically.
Shortcut keys: after the interface of FUNCTION MENU, the upper part is with menus for many functions. On the right, there are 4
shortcut keys, whichare←,→,lamp control or English/Chinese menus.
●DMX STARTADDRESS
Eachprojector must be givena DMX start address so that the correct projector responds to the correct controlsignals. ThisDMX start
address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the
controller. The projector has 3 DMX modes. Thereare short mode ,standard mode and extended mode. For example standard mode
has 38 channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 039, No. 3 projector’s address 077, No. 4
projector’s address115,and soon.
Launch theprojector.Press key OK more than 3seconds to unlock the display. After the unlocking, pushkey ►to enter into menus.
Afterselecting thesignof DMXsetting,push OKkeyor tap thescreen directlyand selectDMXaddressat2nd level menus.
Pushkey▲or▼or tap sign <or> to setthenumber desired.
Push OK keyto confirm.
Pushkey◄and it willreturnto the upper menu
.
Theprojector has wirelesscontrol function with wirelessreceivermoduleand antennaforremotecontrol.
Thesetupofitisbelow:
1. Enter into the projector’s menu. Select the menu “Config Settigns” via the keysof ▲and ▼
2. Select DMX control Mode---- Wireless First (Note: Do not select XLR ONLY). The DMX wireless control
function isactivated.
Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. If unlinking it, Press
“Enter” for the menu of Unlink Wireless under the upper level menu of Config Settigns.
●STAND-ALONEMODE
Operate the projector without connecting with a controller, enable the master mode through the operation panel, the
projector will run in Stand-Alone mode automatically.
DMX address can be set at any number within 512.
●MASTER/SLAVEMODE
Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First,
connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR control cable and then connect the second
fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. Eventually connect the
last fixture’s DMX output to a DMX terminator. Set 1st projector as the master and others are Slaves.
StartAddressesofallSlavesare001;OperationmodeoftheMaster can be set any mode for a Master’ and Slaves’ operation mode can
besetaccordingly.
AfterPoweredon,thegroup willruninMaster/SlaveMode

10
6. OPERATIONMENU
1st LEVEL
2ndLEVEL
3rdLEVEL
4thLEVEL
5thLEVEL
Address
DMXAddress
1-477（ShortMode）
1-474（StandardMode）
1-458（ExtendedMode）
IP Address
DefaultIPAddress
2.X.X.X/10.X.X.X
CustomIPAddress
X.X.X.X
SubNetMask
X.X.X.X
ArtNet
ArtNetUniverse
0-255
Reset
Total Reset
ReallyReset?
Confirm/Cancel
Pan&TiltReset
ReallyReset?
Confirm/Cancel
ColourSystemReset
ReallyReset?
Confirm/Cancel
GoboReset
ReallyReset?
Confirm/Cancel
Zo.Fo.Fr.Pr.Reset
ReallyReset?
Confirm/Cancel
OtherReset
ReallyReset?
Confirm/Cancel
ConfigSettings
DMXChannelMode
ShortMode
Standard Mode
ExtendedMode
ViewSelected Mode
Strobe
…..
Signal Select
XLROnly
XLRFirst
WirelessOnly
WirelessFirst
WirelessIn/XLROut
ArtnetOnly
Artnet In/XLR Out
LossofDMX
Normaltimeout
Hold LastValue
DisplayConfig
DisplayMode
OffAfterDelay
OnAlways
DisplayInvert
InvertOFF
InvertON
InvertAuto
Language Setting
English
Chinese
TouchCalibration
TemperatureUnit
CelsiusDegree

11
Fahrenheit Degree
Un-LinkWireless
ReallyUn-Link?
Confirm/Cancel
Defaults
RestoreDefaults?
Confirm/Cancel
OptionSettings
Pan/TiltSettings
PanDMXInvert
OFF/ ON
TiltDMX Invert
OFF/ ON
PanTiltSwap
OFF/ ON
XYFeedback
OFF/ ON
Pan/Tiltmode
Speed/Time
InvertSettings
IrisInvert
OFF/ ON
ZoomInvert
OFF/ ON
CYMInvert
OFF/ ON
CTOInvert
OFF/ ON
DimmerSettings
Gamma Curve
Gamma 2.0/2.2/2.4/2.6
LEDRefreshRate
1200/2400/4800/10000/1200
0/15000/20000/25000Hz
DimmerSpeed
Fast/Medium/SlowSpeed
FanSettings
Standard/Theatre
RestoreDefaults
RestoreDefaults?
Confirm/Cancel
Information
ViewDMXValues
Lamp Hours
ResetLamp Hours
Total Hours
Temperature
DisplayBoardXX℃/F
PanandTiltBoardXX℃/F
Driver Board1XX℃/F
Driver Board2XX℃/F
Driver Board3XX℃/F
Driver Board4XX℃/F
BladeBoardXX℃/F
FanBoardXX℃/F
LEDXX℃/F
LEDSensorXX℃/F
SoftwareVersion
DisplayBoard
System=XXX
Boot=XXX
PanandTiltBoard
System=XXX
Boot=XXX
Driver Board1
System=XXX
Boot=XXX
Driver Board2
System=XXX
Boot=XXX
Driver Board3
System=XXX
Boot=XXX
Driver Board4
System=XXX
Boot=XXX
BladeBoard
System=XXX
Boot=XXX
FanBoard
System=XXX
Boot=XXX
ElectronicSN
ElectronicSN=
************
RDMDeviceLabel
RDMDevice Label
ANSIE1.20RDM
VersionX.X
FanStatus
LEDFan
HeadFan1
HeadFan2

12
Service
ManualEffectControl
StrobeXXX
DimmerXXX
…
FactoryTest
Operation
Mode
DMXMode
ChangeOperationMode?
Confirm/Cancel
MasterMode
PresetMemory
ChangeOperationMode?
Confirm/Cancel
UserMemory1
ChangeOperationMode?
UserMemory2
ChangeOperationMode?
Stand-AloneMode
PresetMemory
ChangeOperationMode?
UserMemory1
ChangeOperationMode?
UserMemory2
ChangeOperationMode?
StaticScene
ChangeOperationMode?
User
Memories
EditUserMemory
EditUserMemory1
/
EditUserMemory2
SceneXX
（1~200Scenes）
StrobeXXX
DimmerXXX
…
DelayTimeXXX
DelayUnit
LinkToStepXXX
EditStaticScene
StrobeXXX
DimmerXXX
…
Init UserMemory
ResetUserMemory1
ResetUserMemory?
InputPassword 123
ResetUserMemory2
ResetUserMemory?
InputPassword 123
ResetStaticScene
ResetStaticScene?
InputPassword 123
Remark:
1. In the synchronous control of multiple projectors parameters can be transmitted from the master including:DMX mode,
displaysetting,operationmode(user memory);
2. allprojectorsAcceptingparameterswillautomaticallybesettoslavemode.

13
7. DMXPROTOCOL
Short
mode
Standard
mode
Extended
mode
FunctionDescription
Decimal
Low
DecimalHigh
1
1
1
Strobe
Close
0
0
Pulsestrobespeedfromslowtofast
1
127
Strobespeedslowtofast
128
255
2
2
2
Dimmer
Close
0
3
Dimmerfromdarkto light(0-100%)
4
255
3
3
Dimmer Fine
Finedimmer
0
255
3
4
4
CYMMacro
ThefollowingfunctionscanbeusedafterCMY,CTO,andColorWheels1
andColorWheel2
NoFunction
0
9
ColourMacro 1
10
11
ColourMacro 2
12
13
ColourMacro 3
14
15
ColourMacro 4
16
17
ColourMacro 5
18
19
ColourMacro 6
20
21
ColourMacro 7
22
23
ColourMacro 8
24
25
ColourMacro 9
26
27
ColourMacro 10
28
29
ColourMacro 11
30
31
ColourMacro 12
32
33
ColourMacro 13
34
35
ColourMacro 14
36
37
ColourMacro 15
38
39
ColourMacro 16
40
41
ColourMacro 17
42
43
ColourMacro 18
44
45
ColourMacro 19
46
47
ColourMacro 20
48
49
ColourMacro 21
50
51
ColourMacro 22
52
53
ColourMacro 23
54
55
ColourMacro 24
56
57
ColourMacro 25
58
59
ColourMacro 26
60
61

14
ColourMacro 27
62
63
ColourMacro 28
64
65
ColourMacro 29
66
67
ColourMacro 30
68
69
ColourMacro 31
70
71
ColourMacro 32
72
73
ColourMacro 33
74
75
ColourMacro 34
76
77
ColourMacro 35
78
79
ColourMacro 36
80
81
ColourMacro 37
82
83
ColourMacro 38
84
85
ColourMacro39
86
87
ColourMacro 40
88
89
ColourMacro 41
90
91
ColourMacro 42
92
93
ColourMacro 43
94
95
ColourMacro 44
96
97
ColourMacro45
98
99
ColourMacro 46
100
101
ColourMacro 47
102
103
ColourMacro 48
104
105
ColourMacro 49
106
107
ColourMacro 50
108
109
ColourMacro 51
110
111
ColourMacro 52
112
113
ColourMacro 53
114
115
ColourMacro54
116
117
ColourMacro 55
118
119
ColourMacro 56
120
121
ColourMacro 57
122
123
ColourMacro 58
124
125
ColourMacro 59
126
127
ColourMacro 60
128
129
ColourMacro 61
130
131
ColourMacro 62
132
133
ColourMacro63
134
135
ColourMacro 64
136
137
ColourMacro 65
138
139
ColourMacro 66
140
141
ColourMacro 67
142
143
ColourMacro 68
144
145
ColourMacro 69
146
147

15
ColourMacro 70
148
149
ColourMacro 71
150
151
ColourMacro72
152
153
ColourMacro 73
154
155
ColourMacro 74
156
157
ColourMacro 75
158
159
ColourMacro 76
160
161
ColourMacro 77
162
163
ColourMacro 78
164
165
ColourMacro 79
166
167
ColourMacro 80
168
169
ColourMacro81
170
171
ColourMacro 82
172
173
ColourMacro 83
174
175
ColourMacro 84
176
177
ColourMacro 85
178
179
ColourMacro 86
180
181
ColourMacro 87
182
183
ColourMacro 88
184
185
ColourMacro 89
186
187
ColourMacro90
188
189
ColourMacro 91
190
191
ColourMacro 92
192
193
ColourMacro 93
194
195
ColourMacro 94
196
197
ColourMacro 95
198
199
CMYcolourmixingfromslowtofast
200
255
4
5
5
Cyan
Cyan (Linear0-100%)
0
255
6
CyanFine
Cyanin16Bitprecision
0
255
5
6
7
Yellow
Yellow(Linear0-100%)
0
255
8
Yellow Fine
Yellowin16Bitprecision
0
255
6
7
9
Magenta
Magenta(Linear0-100%)
0
255
10
MagentaFine
Magentain 16Bitprecision
0
255
7
8
11
CTO
Linear adjust fromhigh to low
0
255
12
CTOFine
CTOin 16 Bitprecision
0
255

16
8
9
13
ColourWheel
Continualpositioning
index0-360°
0
63
positioning
White
64
67
White/Color1(UV)
68
71
Color1(UV)
72
75
Color1(UV)/Color2(Red)
76
79
Color2(Red)
80
83
Color2(Red)/Color 3(Pink)
84
87
Color 3(Pink)
88
91
Color 3(Pink)/Color 4(Orange)
92
95
Color 4(Orange)
96
99
Color 4(Orange) /Color5(Green)
100
103
Color 5(Green)
104
107
Color 5（Green））/Color 6（Blue）
108
111
Color 6(Blue)
112
115
Color6(Blue)/ White
116
119
White
120
127
Clockwiserainboweffectrotationspeed fromslowto fast
128
191
Anti-clockwiserainboweffectrotationspeedfromslowto fast
192
255
10
14
Color WheelFine
ColorContinualpositioningin16Bitprecision
0
255
9
11
15
Iris
LinearIrisfromsmalltobig0-100%
0
255
16
Irisin16 bit
Irisin16bitprecision
0
255
10
12
17
IrisMacro
IrisMacro disabled
0
10
IrisMacro1: frombigto smallwithspeedfromslowtofast
11
74
IrisMacro2: fromsmallto bigwithspeedfromslowto fast
75
138
IrisMacro3:Iriscontractsfromslowto fast
139
202
IrisMacro4(Macro1 atrandom)withspeedfromslowtofast
203
210
IrisMacro5(Macro2 atrandom)withspeedfromslowtofast
211
218
IrisMacro6(Macro3 atrandom)withspeedfromslowtofast
219
226
Open
227
255
11
13
18
Fixedgobowheel
White
0
15
Gobo1
16
31
Gobo2
32
47
Gobo3
48
63
Gobo4
64
79

17
Gobo5
80
95
Gobo6
96
111
Gobo7
112
127
Clockwiserotationfromslowto fast
128
149
Anti-clockwiserotation fromslowtofast
150
171
Gobo1shakefromslowto fast
172
183
Gobo2shakefromslowto fast
184
195
Gobo3shakefromslowto fast
196
207
Gobo4shakefromslowto fast
208
219
Gobo5shakefromslowto fast
220
231
Gobo6shakefromslowto fast
232
243
Gobo7shakefromslowto fast
244
255
12
14
19
Rotatinggobowheel
White
0
31
Gobo1
32
47
Gobo2
48
63
Gobo3
64
79
Gobo4
80
95
Gobo5
96
111
Gobo6
112
127
Clockwiserotationfromslowto fast
128
143
Anti-clockwiserotation fromslowtofast
144
159
Gobo1shake fromslowto fast
160
175
Gobo2shakefromslowto fast
176
191
Gobo3shakefromslowto fast
192
207
Gobo4shakefromslowto fast
208
223
Gobo5shakefromslowto fast
224
239
Gobo6shakefromslowto fast
240
255
13
15
20
Rotatinggobowheel rotation
Indexing0-360°
0
128
Clockwiserotationfromslowto fast
129
188
Stop
189
195
Anti-clockwiserotation fromslowtofast
196
255
16
21
Rotatinggobowheelrotationin16bit
Rotatinggobo wheelfinerotation
0
255
14
17
22
Framingblade1left
Framingblade1leftlinearlyclosingfrombigto small
0
255
23
Framingblade1leftin16bit
Framingblade1leftfineadjustment
0
255
15
18
24
Framingblade1 right
Framingblade1rightlinearlyclosingfrombigto small
0
255
25
Framingblade1 rightin16bit
Framingblade1rightfineadjustment
0
255

18
16
19
26
Framingblade2left
Framingblade2leftlinearlyclosingfrombigtosmall
0
255
27
Framing blade2leftin16bit
Framingblade2leftfineadjustment
0
255
17
20
28
Framingblade2 right
Framingblade2rightlinearlyclosingfrombigto small
0
255
29
Framingblade2 rightin16bit
Framingblade2rightfineadjustment
0
255
18
21
30
Framingblade3left
Framingblade3leftlinearlyclosingfrombigto small
0
255
31
Framingblade3leftin16bit
Framingblade3leftfineadjustment
0
255
19
22
32
Framingblade3 right
Framingblade3rightlinearlyclosingfrombigto small
0
255
33
Framingblade3rightin16bit
Framingblade3right fineadjustment
0
255
20
23
34
Framingblade4left
Framingblade4leftlinearlyclosingfrombigto small
0
255
35
Framingblade4leftin16 bit
Framingblade4leftfineadjustment
0
255
21
22
36
Framingblade4 right
Framingblade4rightlinearlyclosingfrombigto small
0
255
37
Framingblade4rightin16bit
Framingblade4right fineadjustment
0
255
22
25
38
Framingmodulerotation
Framing moduleindexing(0-360degrees)
0
127
Stop
128
Framingmoduleclockwiserotationfromslowtofast
129
188
Stop
189
195
Framing moduleanti-clockwiserotation fromslowtofast
196
255
39
Framing module rotationin16bit
Framingmodulefinerotation
0
255
23
26
40
Prism
No Prism
0
16
Prism
17
255
24
27
41
Prismrotation
Prismindex
0
127
Prismstops
128
Rotationspeed fromslowto fast
129
191
Stoprotating
192
Reverse rotationspeed fromslowto fast
193
255
25
28
42
EffectWheel
No effect wheel
0
19

19
Effectwheelin
20
255
26
29
43
EffectWheelRotation
Forwardsrotationfromslowto fast
0
127
Reverserotationfromslowto fast
128
255
27
30
44
Frost
LightFrostfrom0%to100%
0
255
28
31
45
Focus
Linearly focusing
0
255
46
FocusFine
Focusin16precision
0
255
29
32
47
Zoom
Linearly zooming
0
255
48
ZoomFine
Zoomin 16 Bitprecision
0
255
30
33
49
Pan
Panmovement
0
255
31
34
50
PanFine
Panmovementin16bitprecision
0
255
32
35
51
Tilt
Tiltmovement
0
255
33
36
52
Tiltfine
Tilt movement16bitprecision
0
255
34
37
53
Pan/Tiltspeed
FastSpeedMode
0
1
Pan&Tiltspeedfromfasttoslow
2
255
35
38
54
Power/Specialfunctions
No function:
0
4
Reserved
5
19
Toactivatefollowingfunctions,stayinDMX valueforatleast 5s
GraphicdisplayOn
20
24
GraphicdisplayOff
25
29
Reserved
30
44
Reserved
45
46
Fanstandardmode
47
48
Fantheatermode
49
50
Reserved
51
52
Fastspeeddimmer
53
54
Midspeeddimmer
55
56
Slowspeeddimmer
57
58
Gamma curve2.0
59
60
Gamma curve2.2
61
62
Gamma curve2.4
63
64

20
Gamma curve2.6
65
66
LEDrefreshrate1200Hz
67
68
LEDrefreshrate2400Hz
69
70
LEDrefreshrate4800Hz
71
72
LEDrefreshrate10000Hz
73
74
LEDrefreshrate12000Hz
75
76
LEDrefreshrate1500Hz
77
78
LEDrefreshrate20000Hz
79
80
LEDrefreshrate25000Hz
81
82
Reserved
83
89
Pan/Tiltspeed mode
90
94
Pan/Tilttimemode
95
99
Reserved
100
129
Reserved
130
139
Pan/Tiltreset
140
149
Coloursystemreset
150
159
Gobo wheelsreset
160
169
Reserved
170
179
Zoom/focus/frost/prismreset
180
189
Others(Iris/effectwheel/Framing module)reset
190
199
Totalreset
200
209
Reserved
210
229
Reserved
240
255
Note:
1. The DMXchannelpriorityfrom hightolow:Focus,Zoom,Prism, Frost;
2. While the higher priority DMX channels are in use, lower ones won’t work;
