Installation Guide
Installationsanleitung, Guía de Instalacíon, Guida de Installazione, Guide d’Installation, Installatie gids
PMC-MM-501/502
16x 16x
3x
5mm
4x 4x
13mm
1 2
Laying the paired leg assembly first on its back and then on
its front securely install the four casters on the front and rear
of the leg assemblies using the M8 flat washers and M8 self
locking nuts supplied. Then securely install the four casters.
We recommend the two rear caster be the “locking pair”
If this is a “one man” installation find a “friendly” clear flat
wall to place one leg assembly along side. Place the lower
pan panel on top of the legs channel between the “upright”.
Next place the second leg over the lower pan panel so all
four through holes line up and loosely secure the lower pan
to the legs with the four M8 x 1.25 x 60mm “button head Al-
len head screws and M8 flat washers supplied.
x2
M6 x 12mm M8 x 10mm M5 x 6mm
x2 x4 x1
x1
x1
5/32”
5mm
2.5mm
M8 x 16mm
M8 x 60mm
M8 x 60mm M8 M8 M6 x 10mm M4 M4 M8
M8 x 20mm M8 x 30mm
x4
x4
x4 x20 x20 x20 x4 x4 x4
x4 x4 x8
13mm5/16”
Required for installation
4mm

Warranty: http://www.mounts.com/warranty
Garantie, Garantía, Garanzia, Garantie, Waarborg
www.mounts.com | North America 800.368.9700 | International [phone] | Europe [phone]
9531-060-031-00
6
5
4
3
Installation Guide
Installationsanleitung, Guía de Instalacíon, Guida de Installazione, Guide d’Installation, Installatie gids
PMC-MM-501/502
4mm 4mm
4mm
4x 4x
13mm
3 4
5 6
Repeat the same procedure with the upper rear panel to the
leg assembly with the four each “button head” Allen screws
supplied.
Now secure firmly the four lower pan “button head” screws
to the leg assembly and tighten firmly. Repeat the same pro-
cess with the front and rear upper cover panels but “don’t”
over-tighten these.
The rear oval panel cover can be installed before or after
final assembly of the cart with the four each M6 button head
Allen head screws supplied.
Loosely install the front upper cover to the front of the cart
with the four M6 x 1.0 x 10mm”button head” Allen screws
supplied.
Install the front “logo” plate to the lower panel cover with the
four each 10/32 x 1/2” “kep” nuts and flat washers supplied.

Warranty: http://www.mounts.com/warranty
Garantie, Garantía, Garanzia, Garantie, Waarborg
www.mounts.com | North America 800.368.9700 | International [phone] | Europe [phone]
9531-060-031-00
109
8
7
Installation Guide
Installationsanleitung, Guía de Instalacíon, Guida de Installazione, Guide d’Installation, Installatie gids
PMC-MM-501/502
4mm 4mm
4x 4x
5mm 4x
Two people recommended for this portion of the “mega” cart
assembly process. Raise the receiver cross bar assembly
to the desired “centerline” height and secure to the uprights
firmly with the four “button head Allen screws and flat wash-
ers supplied.
The 90 degree rotation stop can be installed to allow for left
or right rotation of the arm only. Simply remove the two M6
flat head screw to reposition the 90 degree stop plate and
reinstall
With the rear of the lower pan exposed now would be the
time to place and wire any powered support products feed-
ing the display with the power and signal cable being fed
between the front and rear upper cover panels. Power and
signal cable can also be run up through the three rubber
grommet hole in the base ob the pan as well.
Once housed the rear cover panel may now be installed
with the four “button head” Allen screws supplied. Access to
the inner pan is still available through the rear oval access
cover.
Install the lower front panel cover to the frame front and
secure to the frame assembly with the four each M6 x 1.0 x
10mm “button head” Allen head screws supplied
4x

Warranty: http://www.mounts.com/warranty
Garantie, Garantía, Garanzia, Garantie, Waarborg
www.mounts.com | North America 800.368.9700 | International [phone] | Europe [phone]
9531-060-031-00
13 14
12
11
Installation Guide
Installationsanleitung, Guía de Instalacíon, Guida de Installazione, Guide d’Installation, Installatie gids
PMC-MM-501/502
5/32”
C
L
5/32”
With the display safely positioned “face down” on a smooth
flat surface place the cross bar with brackets loosely at-
tached so the center of the round receiver is center on the
display left to right and top to bottom.
Slide the left and right mounting bracket over the left and
right mounting holes (normally four each) and firmly install
the brackets to the display with the correct length M8 x 1.25
Phillips head screw supplied. Note: measure the depth of
the threaded mounting hole to confirm the correct length of
the M8 screws from the three lengths supplied Confirm the
crossbar is still centered left to right on the rear of the dis-
play and firmly secure the bracket to the cross bar with the
four M6 x 1.0 x 10mm Allen head set screws supplied.
Eight optional use M4 - M8 plastic spacer are included in
the hardware kit if needed to create clearance between the
mounting g bracket and the display. These
spacers easily joined together for additional height is
needed as well.
Slide the left and right display mounting brackets over the
cross bar and install the left and right M6 x 1.0 x 12mm se-
curity Phillips head screws supplied into the cross bar.
