Premium PRF735HW User manual

PRF735HW
PRF736HS
PRF737HB
Service Manual
Important Safeguards

2
TABLE OF CONTENTS
Specification
3
Safety Precautions
3
The Cooling System
4
Wire Diagram
5
Changing the Reversing Door
5
Changing the Bulb
9
Trouble Shooting
9

3
SPECIFICATION
Models
PRF735HW/ PRF736HS/ PRF737HB
Capacity
7.4 cu.ft.
Power Supply
115V/60Hz
Rated Input Power
120 W
Rated Current
1.5A
Rated Power of Lamp
10 W
Refrigerant/Amount
R600a / 1.48 oz
Net Weight
92 lbs
Unit Dimension (HxWxD)
56”x 21 1/2”x 22 3/4”
Package Dimension (HxWxD)
58”x 22 5/8”x 237/8”
Loading QTY(40HQ)
142 pcs
SAFETY PRECAUTIONS
The installation of this appliance is best carried out by 2 people.
Dispose of all packaging carefully and responsibly.
The appliance is designed for indoor use only and must be protected from rain, moisture
and extreme temperature variations.
This appliance is designed for household use. Do not use the appliance for industrial and
commercial use, or any other purpose.
The appliance MUST be positioned on a firm level base.
Do not splash water on the appliance. It may cause electrical parts to fail and result in an
electric shock.
Leave the appliance in its intended place of installation and in its correct orientation for at
least 4 hours before switching on to allow the cooling system to settle before first use or
after any transportation.
This appliance is an environmental friendly product and it contains non CFC / HFC gas
substances in the cooling system (Called R600a) and in the insulation (Called
cyclopentane) which are potentially flammable if exposed to fire. Therefore, take care not
to damage, the cooling circuit / pipes of the appliance in transportation and in use. In case
of damage do not expose the appliance to fire, potential ignition source and immediately
ventilate the room where the appliance is situated.
Do not sit, stand or place any other heavy objects on top of the appliance. This could
result in injury or damage to the appliance.
Do not allow children to play with the appliance to avoid the risk of entrapment and
suffocation.

4
Keep ventilation opening, in the appliance enclosure or in the built-in structure, clear of
obstruction
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.
This appliance is not intended for use by young children or infirm persons unless they
have been adequately supervised by a responsible person to ensure that they can use the
appliance safely. Young children should be supervised to ensure that they do not play
with the appliance.
Do not use mechanical, electrical or chemical way to speed up the defrost process not
recommended by the manufacturer.
Do not use or place other electrical products inside the appliance not recommended by
the manufacturer.
Do not store liquids in glass containers in the freezer compartment as these may shatter.
Do not store flammable materials such as alcohol, gasoline, LP gas or glue etc in the
appliance.
In case there is an inflammable gas leaking, open the window for air circulation and do
not pull out the plug or turn the temperature knob. Do not touch the appliance until the
valve of gas is turned off. Otherwise, sparks may happen.
COOLING SYSTEM

5
WIRE DIAGRAM
CHANGING THE REVERSING DOOR
Before reversing the door swing, ensure the appliance is unplugged and empty. Provide
additional support for the doors while hinges are being removed.
Do not depend on the door magnets to hold the door in place. It is recommended that two
people perform this task. DO NOT lay the appliance completely flat as this may damage the
coolant system.
TOOLS REQUIRED
Phillips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
1. Tilt the unit slightly towards the rear and
prop it securely. Two people are
required to tilt the unit during the door
reversal process.

6
2. Remove the 2 screw covers first,
then undo the screws underneath.
3. Remove the 2 screws on the back.
4. Lift the top cover away from the fridge.
5. Remove the three screws, then
remove the upper hinge that hold the
door in place. Lift the door and place
it on a padded surface to prevent it
from scratching.
6. Remove the bolt with a screwdriver and
flip the hinge bracket. Then reattach the
bolt to the hinge bracket.
180°
unscrew
unscrew

7
7. Take off the middle hinge by
removing the screws. And then lift
the lower door and place it on a
padded surface to prevent it from
scratching.
8. Move the hinge hole cover of lower
door from left side to right side.
9. Remove the screws and bottom hinge.
Then remove the adjustable feet from
both side.
Unscrew
10. Unscrew and remove the bottom
hinge pin, turn the bracket over and
replace it.
Unscrew
Screw

8
11. Refit the bracket fitting the bottom
hinge pin. Replace both adjustable feet.
Transfer the lower door to the property
position.
Screw
12. Make the middle hinge reverse the
direction 180°C, then transfer it to the
left property position. Make the middle
hinge pin in the upper hole of the lower
door, then tight the bolts.
Ensure the freezer door is aligned
horizontally and vertically, so that the
seals are closed on all sides before
finally tightening the hinge.
13. Place the upper door back on. Ensure
the fridge door is aligned horizontally and
vertically so that the seals are closed on
all sides before finally tightening the top
hinge.
14. Insert the hinge bracket and screw it
to the top of the unit.
15. Use a spanner to tighten it if necessary.
16. Put the top cover and then screw back.
17. With the doors closed, check that the
doors are aligned horizontally and
vertically and that the seals are closed on
all sides before finally tightening the
bottom hinge. Re-adjust the levelling feet
as needed.
screw
screw

9
REPLACING THE BULB
Unplug the AC power cord from the wall.
Remove the screw that holds the light bulb cover.
Remove the light bulb cover.
Unscrew the bulb.
Replace with a 10 watt bulb that is the same shape and size.
Replace the light bulb cover
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE CAUSE
Unit does not operate.
Not plugged in.
The circuit breaker tripped or a blown fuse.
The unit temperature control is set at “0” position.
Turns on and off frequently.
The room temperature is hotter than normal.
A large amount of food has been added to the
unit.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The unit does not have the correct clearances.
Vibrations.
Check to assure that the unit is level.
The unit seems to make too much noise.
The rattling noise may come from the flow of the
refrigerant, which is normal.
As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant in your
unit.
Contraction and expansion of the inside walls
may cause popping and crackling noises.
The unit is not level.
The door will not close properly.
The unit is not level.
The door was reversed and not properly installed.
The gasket is dirty or bent.
The shelves, bins, or baskets are out of position.
