Premium PRN7005HW User manual


PRN7005HW
PRN7006HS


English-1
INDEX
IMPORTANT SECURITY WARNINGS................................................................................P.2
OVERVIEW.........................................................................................................................P.6
INSTALLATION...................................................................................................................P.7
DAILY USE.........................................................................................................................P.9
PROBLEM SOLVING........................................................................................................P.14

English-3English-2
IMPORTANT SAFETY SECURITY

using the appliance, read this user manual carefully, including its hints and warnings. To
avoid unnecessary mistakes and accidents, it is important to ensure that all people using
the appliance are thoroughly familiar with its operation and safety features. Save these
instructions and make sure that they remain with the appliance if it is moved or sold, so
that everyone using it through its life will be properly informed on appliance use and safety.
For the safety of life and property keep the precautions of these user’s instructions as the
manufacturer is not responsible for damages caused by omission.
CHILDREN AND VULNERABLE PEOPLE SAFETY
*This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given super vision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
*Children should be supervised to ensure that they do not play with the appliance.
*Cleaning and user maintenance shall not be made by children unless they are aged from
8 years and above and supervised.
*Keep all packaging well away from children. There is risk of suffocation.
*If you are discarding the appliance pull the plug out of the socket, cut the connection cable
(as close to the appliance as you can) and remove the door to prevent playing children to
suffer electric shock or to close themselves into it.
*If this appliance featuring magnetic door seals is to replace an older appliance having a
spring lock (latch) on the door or lid, be sure to make that spring lack unusable before you
GENERAL SECURITY
WARNING! Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING! Do not use mechanical devices or other means to accelerate the de-
frosting process, other than those recommended by the manufacturer.
WARNING! Do not damage the refrigerant circuit.
SECURITY INFORMATION
WARNING! Do not use other electrical appliances (such as ice cream makers) in-
side of refrigerating appliances, unless they are approved for this purpose by the
manufacture.

this appliance.
*The refrigerant isobutene (R600a) is contained within the refrigerant circuit of the appli-

English-4English-3
ance, a natural gas with a high level of environmental compatibility, which is nevertheless

*During transportation and installation of the appliance, be certain that none of the compo-
nents of the refrigerant circuit become damaged.

- Thoroughly ventilate the room in which the appliance is situated.


This appliance is intended to be used in household and similar applications such as:



- catering and similar non-retail applications.
WARNING! Any electrical components (plug, power cord, compressor and etc.)

*Power cord must not be lengthened.
*Make sure that the power plug is not squashed or damaged because it may overheat and

*Make sure that you can come to the main plug of the appliance.
*Do not pull the main cable.
*If the power plug socket is loose, do not insert the power plug. There is a risk of electric

*You must not operate the appliance without the lamp.
*This appliance is heavy. Care should be taken when moving it.
*Do not remove nor touch items from the freezer compartment if your hands are damp/wet,
as this could cause skin abrasions or frost/freezer burns.
*Avoid prolonged exposure of the appliance to direct sunlight.
DAILY USE
*Do not place hot foodstuffs on the plastic parts of the appliance.
*Do not place food products directly against the rear wall.
*Frozen food must not be re-frozen once it has been thawed out.
*Store pre-packed frozen food in accordance with the frozen food manufacturer’s instruc-
tions.
*Appliance’s manufacturer storage recommendations should be strictly adhered to. Refer
to relevant instructions.
*Do not place carbonated drinks in the freezer compartment as it creates pressure on the
container, which may cause it to explode, resulting in damage to the appliance.
*Ice cubes can cause frost burns if consumed straight from the appliance.
CARE AND CLEANING
*Before maintenance, switch off the appliance and disconnect the main plug from the main
socket.

English-4
*Do not clean the appliance with metal objects.

*Regularly examine the drain in the refrigerator for defrosted water. If necessary, clean the
drain. If the drain is blocked, water will collect in the bottom of the appliance.
INSTALATION
-
graphs.

if it is damaged. Report possible damages immediately to the authorized place you bought
it.
*Adequate air circulation should be around the appliance, lacking this leads to overheating.

*Wherever possible the spacers of the product should be against a wall to avoid touching
or catching warm parts (compressor, condenser) to prevent possible burn.
*The appliance must not be located close to radiators or cookers.
*Make sure that the main plug is accessible after the installation of the appliance.
SERVICE
* Any electrical work required to do the servicing of the appliance should be carried out by

* This product must be serviced by an authorized Service Center, and only genuine spare
parts must be used.
ENERGY SAVING


* Make sure food don’t touch the back of the compartment(s)
* If electricity goes off, don’t open the door(s)



* Some accessories, such as drawers, can be removed to get larger storage volume and
lower energy consumption.
ENVIRONMENT PROTECTION
This appliance does not contain gases which could damage the ozone layer, in ei-
ther its refrigerant circuit or insulation materials. The appliance shall not be discard-

gases: the appliance shall be disposed according to the appliance regulations to obtain
from your local authorities. Avoid damaging the cooling unit, especially the heat exchanger.
The materials used on this appliance marked by the symbol are recyclable.

English-5
The symbol on the product or on its packaging indicates that this product may not
be treated as household waste. Instead it should be taken to the appropriate
collection point for the recycling of electrical and electronic equipment. By ensuring that
this product is disposed correctly, you will help prevent potential negative consequences
for the environment and human health, which could otherwise be caused by inappropri-
ate waste handling. For more detailed information about recycling of this product, please
contact your local council, your household waste disposal service or the shop where you
purchased the product.
PACKAGING MATERIALS
The materials with the symbol are recyclable. Dispose the packaging in a suitable
collection container to recycle it.
DISPOSAL OF THE APPLIANCE
1. Disconnect the main plug from the main socket.
2. Cut off the main cable and discard it.

English-6
OVERVIEW
shelves
shelf
Crisper
Door
Rack
Door
Rack
Feet
Chill
Compartment

INSTALLATION
Space Requirements
* Select a location away from direct sunlight exposure.
* Select a location with enough space for the doors to open easily.
759%
* Leave enough space to install the refrigerator on the leveled surface.
* Leave right, left, back and superior area space when installing. This may help for power
saving and maintain a lower energy bill.
Level the refrigerator
Leveling per unit
For this, adjust both feet
Levelers
A front of the unit
If the unit is not leveled, the doors and sealed
line up
Magnetics
Will not be properly covered.
980
910
INSTALLATION
English-7

POSITIONING
Install this appliance at a location where the ambient temperature corresponds to the cli-
mate class indicated on the rating plate of the appliance:
Location: The appliance should be installed well away from sources of heat such as radia-
tors, boilers, direct sunlight etc. Ensure that are can circulate freely around the back of the
cabinet and the wall unit must be at least 100 mm. Ideally, however, the appliance should
not be positioned below overhanging wall units. Accurate leveling is ensured by one
or more adjustable feet at the base of the cabinet.
Warning!^''`$%'
plug must therefore be easily accessible after installation.
English-8

DAILY USE
℃
English-9

FIRST USE
Cleaning the interior

with lukewarm water and some neutral soap so as to remove the typical smell of a brand
new product, then dry thoroughly.
Important!
DAILY USE
Freezing fresh food:
*The freezer compartment is suitable for freezing fresh food and storing frozen and
deep-frozen food for a long time.
*Place the fresh food to be frozen in the freezer compartment.

plate.
*The freezing process lasts 24 hours: during this period do not add other food to be frozen.
Storing frozen food:
-
partment let the appliance run at least 2 hours on the higher settings.
Important! In the event of accidental defrosting, for example the power has been off for
longer than the value shown in the technical characteristics chart under “rising time”, the
defrosted food must be consumed quickly or cooked immediately and then re-frozen (after
cooked).
Thawing:
Deep-frozen or frozen food, prior to be used, can be thawed in the fridge compartment or
at room temperature, depending on the time available for this operation. Small pieces may
even be cooked still frozen, directly from the freezer. In this case, cooking will take longer.
Ice-cube:
This appliance may be equipped with one or more ice-cube to produce ice.
English-10

ACCESSORIES
Movable shelves
The walls of the refrigerator are equipped
with a series of runners so that the shelves
can be positioned as desired.
Positioning the door balconies
To permit storage of food packages of
various sizes, the door balconies can be
placed at different heights. To make these
adjustments proceed as follows: gradually
pull the balcony in the direction of the ar-
rows until it comes free, then reposition as
required.

English-11

To help you make the most of the freezing process, here are some important hints:

* The freezing process takes 24 hours. No further food to be frozen should be added during


* Prepare food in small portions to enable it to be rapidly and completely frozen and to

* Wrap up the food in aluminum foil or polythene and make sure that the packages are

* Do not allow fresh, unfrozen food to touch food which is already frozen, thus avoiding a


* Water ices, if consumed immediately after removal from the freezer compartment, can

* It is advisable to show the freezing in date on each individual pack to enable you removal

* It is advisable to show the freezing in date on each individual pack to enable you to keep
tab of the storage time.
Hints for storage of frozen food
To obtain the best performance from this appliance, you should:

be sure that frozen foodstuffs are transferred from the food store to the freezer in the short-

necessary.

Do not exceed the storage period indicated by the food manufacture.
Hints for fresh food refrigeration
To obtain the best performance:
* Do not store warm food or evaporating liquids in the refrigerator

Refrigeration hints

*Make (all types): wrap in polythene bags and place on the glass shelves above the veg-
etable drawer.
* For safety, store in this way only one or two days at the most.
*Cooked foods, cold dishes, etc...: these should be covered and may be placed on any
shelf.
*Fruit and vegetables: these should be thoroughly cleaned and placed in the special draw-
er(s) provided at the bottom.
*Butter and cheese: these should be placed in special airtight containers or wrapped in
English-12

aluminum foil or polythene bags to exclude as much air as possible.
*Milk bottle: these should have a cap and should be stored in the balconies on the door.
Bananas, potatoes, onions and garlic, if not packed, must not be kept in the fridge.
Cleaning
For hygienic reasons the appliance interior, including interior accessories, should be
cleaned regularly.
Caution! The appliance may not be connected to the main during cleaning. Danger
of electrical shock! Before cleaning switch the appliance off and remove the plug
from the main, or switch off or turn out the circuit breaker or fuse. The appliance must be
dry before it is placed back into service.
Important! Ethereal oils and organic solvents can attack plastic parts, for example, lemon
or orange juice, butyric acid, cleanser that contain acetic acid.
*Do not allow such substances to come into contact the appliance parts.
*Do not use any abrasive cleaners
* Remove the food from the freezer. Store them in a cool place, well covered.
*Switch the appliance off and remove the plug from the main, or switch off or turn out the
circuit breaker of fuse.
*Clean the appliance and the interior accessories with a cloth and lukewarm water. After
cleaning wipe with fresh water and rub dry.
*After everything is dry place appliance back into service.
English-13

Caution!
of competent person must do the troubleshooting that is not in this manual.
Important! There are some sounds during normal use (compressor, refrigerant circula-
tion).
PROBLEM SOLVING
English-14

Español-1
ÍNDICE
INFORMACIÓN DE SEGURIDAD.......................................................................................P.2
PARTES DE LA REFRIGERADORA...................................................................................P.6
INSTALACIÓN.....................................................................................................................P.7
USO DIARIO.......................................................................................................................P.9
SOLUCIÓN DE PROBLEMAS...........................................................................................P.14

Español-2
INFORMACIÓN DE SEGURIDAD
En interés de su seguridad y para asegurar el uso correcto, antes de instalar y primero
de utilizar el aparato, lea este manual del usuario, incluidos los consejos y advertencias.
Para evitar errores y accidentes innecesarios, es importante asegurarse de que todas
las personas que utilicen el aparato estén perfectamente al tanto con sus características
de operación y seguridad. Guardar estas instrucciones y no olvide mantenerlas junto al
aparato en caso de su desplazamiento o venta para que quienes lo utilicen a lo largo de
su vida será informado adecuadamente sobre el uso del aparato y la seguridad. Por la
seguridad de vidas y bienes guardar este manual de instrucciones por que el fabricante
no se hace responsable de los daños causados por omisión.
LOS NIÑOS Y LAS PERSONAS VULNERABLES POR SU SEGURIDAD
* Este aparato puede ser utilizado por niños de 8 años o más y las personas con capaci-
dades físicas, sensoriales o mentales reducidas o falta de experiencia y conocimiento, si
se les ha dado la supervisión de la instrucción sobre el uso del aparato por una persona
responsable de su seguridad.
* Los niños deben ser supervisados para asegurarse de que no jueguen con el aparato.
* En la limpieza y el mantenimiento, el usuario no debe dejar que los niños esten cerca
a menos que sean de edades comprendidas entre 8 años y por encima y supervisados.

* Si usted va a desechar el aparato tire de la clavija de la toma de corriente, corte el cable
de conexión (tan cerca del aparato como pueda) y retire la puerta para evitar que los niños
jugar o sufran una descarga eléctrica o cerrando a sí mismos en ella.
* Este aparato cuenta con un sello de puerta magnética para reemplazar un aparato más
antiguo con cierre de muelle (pestillo) en la puerta o tapa, asegúrese de hacer el cierre
de muelle inservible, antes de deshacerse del viejo electrodoméstico. Esto evitará que se
convierta en una trampa mortal para un niño.
SEGURIDAD GENERAL
Advertencia! mantenga las aberturas de ventilación en el recinto del
aparato o en la estructura construida, sin obstáculos.
Advertencia! no utilice dispositivos mecánicos u otros medios para acelerar
el proceso de descongelación, que no sean los recomendados por el fabricante.
Advertencia! no dañar el circuito refrigerante.
Advertencia! No utilice otros aparatos eléctricos (como máquinas de hacer hela-
dos) en el interior de los aparatos de refrigeración, a menos que estén aprobados


Español-3
-
able en este aparato.
*El refrigerante isobutano (R600a) es un contenido dentro del circuito de refrigerante del
aparato, un gas natural con un alto nivel de compatibilidad medioambiental, aunque es

*Durante el transporte y la instalación del aparato tener la certeza de que ninguno de los
componentes del circuito de refrigerante este dañado.
- Evitar las llamas y fuentes de ignición abiertas
- Ventilar bien la habitación en la que el aparato se encuentra
-
quier daño en el cable puede causar un cortocircuito, un incendio y/o descargas eléctricas.
Este aparato está destinado para ser utilizado en el hogar y otras aplicaciones similares,
tales como:

- Casas de campo y para los clientes en hoteles, moteles y otros entornos de tipo


- Restauración y aplicación similar no menor.
Advertencia! Los componentes eléctricos (enchufes, cables de alimentación, com-
presores, etc.) deben ser sustituidos por un agente de servicio autorizado o person-

* Cable de alimentación no debe ser alargado.
* Asegúrese de que el cable de alimentación no esté roto o el enchufe de alimentación
dañado puede recalentarse y provocar un incendio.
* Asegúrese de que se puede llegar a el enchufe del aparato.
* No tire del cable de red.
* La toma de corriente está suelto, no inserte la clavija de alimentación. Existe el riesgo de
una descarga eléctrica o un incendio.
* No debe utilizar el aparato sin la lámpara.
* Este aparato es pesado. Se debe tener cuidado cuando lo mueva.
* No extraiga ni toque los artículos en el congelador si sus manos están húmedas ya que
esto podría causar abrasiones de la piel o de la helada/quemaduras del congelador
* Evitar la exposición prolongada del aparato a la luz solar directa.
USO DIARIO
* No coloque nada caliente en la parte plástica del aparato.
* No coloque el producto directamente contra la pared trasera.
* Alimentos congelados no debe ser recongelado una vez que ha sido descongelados.
* Tienda de pre-empaquetado de alimentos congelados de acuerdo con las instrucciones
del fabricante de alimentos congelados
* Las recomendaciones de almacenamiento de la fabrica deben ser estrictamente res-
petados. Consulte las instrucciones pertinentes.
* No coloque bebidas gaseosas en el congelador, ya que crea la presión en el envase, ya

Español-4
que puede ocasionar que explote, y podría dañar el aparato.
* Los hielos pueden causar quemaduras si se consumen directamente desde el dispos-
itivo.
CUIDADO Y LIMPIEZA
* Antes del mantenimiento, apague el aparato y desconecte el enchufe de la toma de
corriente.
* No limpie el aparato con objetos metálicos

plástico
* Examinar periódicamente el desagüe en el refrigerador por agua descongelada.
Si es necesario, limpie el desagüe. Si el desagüe está obstruido, el agua se
acumula en la parte inferior del aparato.
INSTALACIÓN
Importante! Para la conexión eléctrica siga cuidadosamente las instrucciones dadas en

* Desembalar el aparato y comprobar si hay daños en ella .No conecte el aparato si está
dañado. Reportar posibles daños de inmediato al lugar donde lo compró o en un centro
autorizado.
* Circulación de aire adecuada debe ser alrededor del aparato, la falta de esto conduce a
-
tes a la instalación.
* Siempre que sea posible el producto debe estar contra la pared para evitar que se
alcance o toquen las zonas cálidas (compresor, condensador) para evitar posibles que-
maduras.
* El aparato no debe ser situado cerca de radiadores u hornos.
* Asegúrese de que el enchufe sea accesible después de la instalación del aparato.
SERVICIO
*Cualquier trabajo eléctrico requerido que tenga que ver con el mantenimiento del aparato
debe ser realizada por un electricista o técnico especializado.
* Este producto debe ser reparado por un centro de servicio autorizado, y sólo repuesto
originales debe ser utilizado.
EL AHORRO DE ENERGÍA


* Asegúrese que los alimentos no toque la parte posterior de los compartimientos (S)
* Si la electricidad se apaga, no abra la puerta (S)
* No abra la puerta (S) con frecuencia.


