Prestigio GeoVision 4500 User manual

EN-1
1. Important safety instructions ………………………………..…...
2. Accessories ………………………………………………………….
3. View of main unit …………………….……………………………...
4. Device connections ……………………….…………....................
5. Cautions on battery charging ………….……………..................
6. Getting started ………………………………………………………
7. Device Settings…………………………………………..………….
8. Bluetooth Function …………………………….…………………..
9. FM Function ………………..……………….
10. Connecting to “Navitel.Traffic”…………………...................
11. Programme interface………...……………….……...................
12. Autorouting …..…………………………….................................
13. “More” menu ……………………………………………………
14. Troubleshooting …………………………………………………….
2
3
4
6
8
9
10
11
15
16
17
21
23
24
Contents

EN-2
CAUTION
1. To reduce the risk of electric shock, do not remove the cover (or back). No
user-serviceable parts inside. Refer servicing to qualified service personnel.
2. The manufacturer should not hold responsibility for the damage caused by any
substitutions and modifications of the product without authorization from the
manufacturer or authorized unit.
WARNING
The device should not be exposed to dripping or splashing and no objects filled with
liquids should be placed on the device.
Important Safety
Instructions
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.

EN-3
Prestigio GeoVision 4500/4500BTFM/5500BTFMHD–Accessories List
ITEM NAME QTY
Car Charger 1
USB Cable 1
Stylus Pen 1
Stylish Carry Case
(GV5500BT only) 1
User Manual 1
Warranty Card 1
Driver/Document CD 1
Accessories

EN-4
Prestigio GeoVision 4500/4500BTFM/5500BTFMHD
Front and Side View
1. LCD Touch Screen
Tap the screen with touch pen or finger to select menu commands or to enter
information.
2. Battery Status Indicator
The indicator glows in bright green colour when battery is fully charged and in red
color when charging.
3. Earphone Jack
Connects to earphones or headsets.
4. microSD Slot
Receiving microSD memory card for data access or memory expansion.
5. mini USB Port
Connection to USB Cable for data access or battery charging
6. Microphone
Records sound.
View of Main Unit
1
4
3
5
6
2

EN-5
Prestigio GeoVision 4500/4500BTFM/5500BTFMHD
Rear and Top View
1. Speaker
Emits sound, voice or music.
2. Reset Button
Press to reboot the device.
3. Light Sensor
Adjust the brightness of touch screen
4. Power Button
Press to power the device ON/OFF.
View of Main Unit
1
4
2
3

EN-6
Inserting microSD Card
To insert a microSD card, place the
connector towards the device and the
card label towards the front side of
the device.
To remove a microSD card, gently
press the edge of the card to release
the safety lock and pull the card out
of the slot.
NOTE:
Please always make sure that no application is accessing the microSD
card before extraction.
Connecting to External USB Device (Charging)
Insert the USB connector into the
appropriate USB port.
Insert the other USB connector into
the USB port on PC to start charging.
Device Connections

EN-7
Connecting to Car Charger
Insert the USB connector into the
appropriate USB port.
Insert car charger connector into
vehicle 12V accessory/cigarette
socket to start charging.
NOTE:
Please connect the car charger to vehicle 12V accessory/cigarette
socket after the vehicle engine is started to protect the device from
sudden surges in current.
Device Connections

EN-8
About Rechargeable Battery
The device is equipped with a built-in rechargeable battery. Please fully charge the
battery (for at least 5 hours) before initial use. The battery status indicator glows in red
colour when charging and turns bright green colour when charging is complete. Charging
time is approximately 4 hours.
Working conditions and precautions for the rechargeable battery
Devices with new batteries should be fully charged before initial use.
It is not necessary to start charging the device before the battery is fully
discharged.
Cautions on Battery
Charging

EN-9
1. Press and hold Power Button to turn
on the device.
2. Shortly after the greeting screen is
shown, the main menu will be
displayed.
3. Tap the corresponding buttons with
touch pen included to navigate
through various functions.
4. Press and hold Power Button to turn
the device off or to allow the device to
enter sleep mode.
5. Tap Sleep icon to put the device to
sleep mode or Power Off icon to turn
the device off.
Getting Started

EN-10
In the main menu, tap on to
enter the device settings.
Tap to display other settings.
Volume Adjust sound volume, mute device, or enable warning messages.
Backlight Adjust the brightness of touch screen, enable/disable auto
backlight.
Language
Select desired language.
DateTime Set up Time Zone/Date/Time.
Calibration
Calibrate the screen when position deviation occurs.
FM transmitter
Transmit audio signals from the navigator to radio sets.
USB Set the data transmission mode between the navigator and
computer.
Factory Reset
Restore all system settings to factory default values.
Device Settings

EN-11
1. Tap on Bluetooth icon on the main
menu to start using Bluetooth
function.
2. The link status is shown at the
bottom of the interface.
3. Tap on to exit the current
function.
4. Tap on in Bluetooth interface to
start pairing with mobile phone
device with GPRS function.
5. Please make sure Bluetooth function
on mobile phone is detectable by
other devices.
6. “Connected established” will be
displayed upon the successful
pairing.
7. Tap on in Bluetooth interface to
enter the Phone Keyboard.
8. Tap on digit buttons and tap on
/ / to start Dialing,
Backspace, and enter Dial Record.
Bluetooth Function
(GeoVision 5500BTFMHD/4500BTFM)

EN-12
9. Tap on / to adjust the
volume. Tap on to end call.
10. Tap on to enter call record. Tap
on to enter keypad. Tap on
to switch the call to mobile phone or
switch it back to device.
11. The call fails to connect as
illustrated.
12. Tap on to return to Phone
Keyboard interface.
13. Calling number will be displayed
upon the Incoming Call.
Bluetooth Function
(GeoVision 5500BTFMHD/4500BTFM)

EN-13
14. Tap on on Bluetooth interface
to enter Dial Record.
15. Tap on / / to view Dialed Call
list, Received Call list, and Missed
Call list. Tap on to start dialing.
16. To delete a desired phone number
on the list, select the number and tap
on . Tap on to delete all
numbers on the list.
17. Tap on in the Bluetooth
interface to redial the last dialed
number.
18. Tap on in the Bluetooth
interface to enter Setting function.
19. Tap on to reset a new PIN
code. Tap on / to select a
ring tone.
20. Tap on to enable/disable the
Bluetooth function. Tap on to
enable/disable automatic HFP
connection.
Bluetooth Function
(GeoVision 5500BTFMHD/4500BTFM)

EN-14
21. Tap on in Bluetooth interface
to enter Paired Device List function.
22. Tap on to delete mobile phone
name from the list. Tap on to
disconnect the PND (Personal
Navigation Device) from the mobile
phone. Select mobile phone name
from Paired Device List and tap on
to enter Profile list.
23. Tap on to re-connect from
previously connected mobile phone.
Tap on to disconnect the PND
(Personal Navigation Device) from
the mobile phone.
24. Tap on in Bluetooth interface to
start searching process.
25. Mobile phone name desired for
connection will be displayed on the
list when search is completed.
26. Tap on the mobile phone name and
tap on to pair. Tap on to
enter Paired Device List.
Bluetooth Function
(GeoVision 5500BTFMHD/4500BTFM)

EN-15
27. Tap on enter Phonebook.
28. Tap on to download the phone
numbers of the mobile phone to the
PND (Personal Navigation Device).
29. Tap on to dial the phone
number.
30. Tap on to delete mobile phone
name from the list.
1. Tap on Function icon on the main
menu.
2. Tap on FM icon to start using
Bluetooth function.
3. Tap on / or drag the cursor to
tune FM frequency down/up.
4. Tap on to save current FM
station.
5. Tap on to enable the FM
function.
6. Tap on to exit.
FM Function
(GeoVision 5500BTFMHD/4500BTFM)
Bluetooth Function
(GeoVision 5500BTFMHD/4500BTFM)

EN-16
7. Tap on in Bluetooth interface to
start pairing with mobile phone device
with GPRS function.
8. Please make sure Bluetooth function
on mobile phone is detectable by
other devices.
9. After successful pairing enter Profile
list and tap on Dialup Networking
Service.
10. Choose the GPRS DUN service
provider and press “Connect”.
11. After successful connection enter the
navigation software. The
“Navitel.Traffic” service will be
updated automatically upon entering.
Connecting to “Navitel.Traffic”
(GeoVision 5500BTFMHD/4500BTFM)

EN-17
No.
Name
Function
1 Compass Press the compass loon to edit map rotation mode, map view
and day/night mode.
2 Sound Press this button to turn on/off voice and sound effects.
3 Next maneuver Next maneuver on the way and distance up to it. Press this Icon
to open route options menu.
4
GPS-cursor
If GPS connection is established, displays your current location.
5 Information
panels
Displays time until the end of the trip, total route length, and
arrival time.
6 Route Route you are currently navigating displays as a wide blue line.
Program interface

EN-18
No.
Name
Function
7 Speedcam
window
When you approach a speed camera with visual warnings being
activated the window will appear In upper right comer at the
screen. This window shows you permitted speed and distance
left. Press the window to turn On/Off speed exceeding
sound warnings.
8 Search Press this button to enter the search menu and to find specific address or object (you can find more Info about Search In
~Functionality~ section)
9 Information
panel
Shows street name you are currently moving on. Available only
if GPS or GLONASS connection is established. If there is no
street name, the direction will be shown.
10
MENU
Press to enter the Main Menu.
11 Scale
Map current scale.
12 Zoom Out Decrease map scale.
13 Zoom In
Increase map scale.
14 Autoscale If you zoom In/out with ~Autozoom~ function activated, this function will deactivate for a period according to settings. Press
this button to activate ~Autozoom~ function manually.
15 Rerum to current
location
You can see the green arrow at the top of the screen if the map
was moved relative to your position. Press it to return view to
your current location.
Program interface

EN-19
No.
Name
Function
16 Speedcam
window
When you approach a speed camera with visual warnings being
activated the window will appear In upper right comer at the
screen. This window shows you permitted speed and distance
left. Press the window to turn On/Off speed exceeding
sound warnings.
17
Speed
Current speed. Available only with GPS connection established.
18 Information
panel
Shows street name you are currently moving on. Available only
if GPS or GLONASS connection is established. If there is no
street name, the direction will be shown.
19 Waypoint Waypoints are manually created by the user and display with
red flags on a map.
20 GPS
GPS connection button. Green icon - connection enabled, white
icon – function disabled. Green icon also has a dot at different
color: red - no connection, yellow - poor connection, green -
connection established.
Program interface

EN-20
No.
Name
Function
21 Track record Track record. Green icon - track record enabled, white icon
function disabled.
22 Mark on map Touch the screen with a stylus to set a mark. You can save this mark as a way point add it to the route or see object’s
characteristics the mark was set on.
23 Object of interest Different objects on map (traffic lights, metro stations, petrol
stations etc.).
24 Button panel
Button panel for easy access to object properties and
performing actions to them on map – adding waypoints and
routes. The buttons change depending on object selected or
route status.
25 “Hide”Pressing this button hides the button panel.
26 Map angle By pressing the Up/Down buttons you can regulate the map
incline.
27 Battery This icon displays the remaining battery capacity. Pressing this button displays information about the remaining percentage of
battery and free memory in МB.
Program interface
