NO. Material number Name Specification Parameter Usage Unit Remark
1 0414080020002 Attached with a USB data cable USB A-母-直角=Micro USB-公[直角,150mm,不带磁环,黑色]1
2 0414130020005
ttached with a USB power cabl
USB-公-直角=Micro USB B(标识印反面)-公[直角,1.0m(32B
2A,5V+-5% 1
3 0437000020026 Holster SMBD7806,MID 保护套,PU+天鹅绒,黑色仿羊皮纹,带东欧商标/深圳奥斯比 1
4 1005000020043 Warranty Card Prestigio,保证卡,V3.1 1
5 1016000020087 Quick Guide Prestigio,PMP7079D_QUAD,快速指南,V1.0 NR 1
6 1019000020001 Legal and safe manual Prestigio_MULTIPAD,Legal And Safety Notices,V3.2 1
7
8 0101010299999 Common PE bags 110*180mm,NA,NA NR 1 Manual packing bags
9 0101050000002 Shrink film bags 270*380mm,V1.0 NR 1 Color box with shrink
10 0104020020195 gift box Prestigio,PMP7079D_QUAD,V1.0 Gift packaging, gift box
1
11 0105070020020 Cardboard sheet 220*210mm,单B瓦,双面牛卡 0.1 Side of the outer box nailing pad
12 0105070020021 Cardboard sheet 465*220mm,单B瓦,双面牛卡 0.2 Mat in carton
13 0107020020001 Other trays 1200*1000*135mm,4000Kg,深蓝色EPS+PET全新料 Sichuan word flat, singl
0.0017 Customer has specified tray
manufacturers, air transport was 600 units
/ Torr, after a good overall size of the
stackin
:1200*1000*1491mm
14 0108020020241 Printed Carton Prestigio,PMP7079D,V1.0 Carton size: 478 * 230
0.1 Carton 10 units installed
15 0109000099936 Paper Corner 1270*60*60*5mm 0.0068 Each tray with four, and for the sides of
the tray
16 0109000099961 Paper Corner 960*60*60*5mm 0.0102 Each tray with six, including four card on
the top of the tray, put the tray at the
bottom of the remaining two 1200 mm
direction so as not to take the box was
bad
17 1013010320018 Copperplate paper stickers 锂电池货物标签,120*110mm,铜版纸不干胶 NR 0.22 Carton 1 (10 sets of equipment), each
pallet 4 (600 units installed)
18 1013010320106 Copperplate paper stickers SMB-D7018,T01,NR,NR,产品颜色贴纸(直径4mm-绿色),NR,V1.0 1 According Machine color paste color box
reserved for the position of the box
19 1013120000001 Blank stickers T01,30*8mm,铜版纸不干胶 3 When an attachment on the packaging
20 1013120000004 Blank stickers BS013C,45*30mm,消银龙PET 1 Paste color box placeholder
21 1013120020000 Blank stickers BS033A,70*100mm,铜版纸不干胶 0.2 Sticker Carton (10 units), each carton
stickers 2
22 1013120020038 Blank stickers BS046A,68*110mm,铜版纸不干胶 0.02 Each tray 4 (600 units installed)
23
24 0422010020076 Outsourcing-AC adapter HKA01105021-XE,欧标,可换脚,Prestigio,USB,NR,NR,黑色/
1
25
26 0224010020118 Built-in passive antenna V099-019-A-2,FPC,2.4GHz~2.5GHz,引线I-PEX D0.81*L110(
-1dBi,50R 1
27 0226020120050 Irregular flexible circuit board 8570C,V1.0,2013.06.17 FPC,2层,0.4mm 1
28 0226020120059 Irregular flexible circuit board FPC-20130715-13(0.3mm,25p,S型异面),NR,NR(领高)1
29 0226020120061 Irregular flexible circuit board FPC-20130715-12(0.3mm,35p,L型同面),NR,NR/领高 1
30 0227000020042 speaker MA1609-2,0.7W 8Ω带线,SUR0.8-4Y-白黑54mm/红黑54mm
20Hz~20KHz 1
31 0802020020029 With the flat surface 0.5mm,6P,115mm,-40C~+80C,有折线/联益 L2.5_L2.5,L3.5-L0_L3.
1
32 0226010020347 PCB circuit board 8572C,V3.0,2013.08.28 FPC,2 Layer,0.4mm 1
33 0301020120048 PET protective film Alien SMBD7806-H04,屏保护膜0.05PET(印刷多色,不带3G,东欧Prestigio PMP7079D) 1 Sticker Machine
34 1004000000012 Warranty seal 东欧Prestigio,PMP5570C,V1.0 1 Sticker on the circuit board screws
suitable position
35 1013010220125 Plain paper stickers SMB-D7018,T02,东欧Prestigio,PMP5670C,水损贴纸7*5mm,NR,V1.0 1 Stickers circuit board suitable location
36 1013120020055 Blank stickers AU101DP11V8,10*5mm,铜版纸不干胶 1 Hardware Version stickers
37 0309020020009 Different type sponge mat SMBD7806-H07,单面,普通胶,黑色 中 1
38 0311010020016 Rules insulation pad D5*d2.7*1mm,单面背普通胶,透明 PC 5
39 0602010020045 Irregular Poron SMBD7806-H03,喇叭poron垫,ES,单面背普通胶,黑色 2
40 0610020100031 Nickel Metal Screws M1.6*2.5CMHNI(K=0.5 D=3 耐落) 4 Lock horn cover
41 0610020120000 Nickel Machine Screw M1.4*2CMHNI,(K=0.5 D=3.5耐落) 7 Lock headset plate (1) Lock Motherboard
(4) Lock port plate (2)
42 0616010020152 botton plastic SMBD7806-RE03,电源键,电镀(内部退镀)+太阳纹,银色 ABS(PA757),94HB 1
43 0616010020153 botton plastic SMBD7806-RE04,音量键,电镀(内部退镀),金属银 ABS(PA757),94HB 1
44 0616130020057 Cover plastic parts SMBD7806-RE05,喇叭盖,NR,黑色 ABS(PA757),94HB 2
PMP7079D QUAD BOM
