Pride Mobility LIFT CHAIR Series User manual

LIFT CHAIR

NOTE: This owner’s manual is compiled from the latest specifications and product information available
at the time of publication. We reserve the right to make changes as they become necessary. Any changes to
our products may cause slight variations between the illustrations and explanations in this manual and the
product you have purchased. The latest/current version of this manual is available on our website.
The symbols below are used throughout this owner's manual and on the product to identify warnings and
important information. It is very important for you to read them and understand them completely.
WARNING! Indicates a potentially hazardous condition/situation. Failure to follow
designated procedures can cause either personal injury, component damage, or
malfunction. On the product, this icon is represented as a black symbol on a yellow
triangle with a black border.
MANDATORY! These actions should be performed as specified. Failure to perform
mandatory actions can cause personal injury and/or equipment damage. On the
product, this icon is represented as a white symbol on a blue dot with a white
border.
PROHIBITED! These actions are prohibited. These actions should not be performed
at any time or in any circumstances. Performing a prohibited action can cause
personal injury and/or equipment damage. On the product, this icon is represented
as a black symbol with a red circle and red slash.
Copyright © 2014
Pride Mobility Products Corp.
INFMANU3446/Rev N/June 2014
Please fill out the following information for quick reference:
Pride Provider:
Address:
Telephone:
Purchase Date:
SAFETY GUIDELINES
LIFT CHAIR SERIES
NOTE: This product is compliant with WEEE, RoHS, and REACH directives and requirements.
NOTE: This product meets IPX4 classification (IEC 60529).
NOTE: The Lift Chair and its components are not made with natural rubber latex. Consult with the
manufacturer regarding any after-market accessories.

Lift Chair Series 3
I. INTRODUCTION ..............................................................................................................4
II. SAFETY ...........................................................................................................................5
III. YOUR LIFT CHAIR ............................................................................................................8
IV. ASSEMBLY/DISASSEMBLY .........................................................................................10
V. OPERATION ..................................................................................................................13
VI. BASIC TROUBLESHOOTING .......................................................................................15
VII. CARE AND MAINTENANCE .........................................................................................17
CONTENTS

4 Lift Chair Series
SAFETY
The product you have purchased combines state-of-the-art components with safety, comfort, and styling
in mind. Read and follow all instructions, warnings, and notes in this manual and all other accompanying
literature before attempting to operate this product for the first time. If there is any information in this
manual which you do not understand, or if you require additional assistance for setup or operation, please
contact your authorized provider. Failure to follow the instructions, warnings, and notes in this man-
ual and those located on your product can result in personal injury or product damage and will
void the product warranty.
NOTE: If you ever lose or misplace your copy of this manual, contact us and we will be glad to send
you a new one immediately.
PURCHASER’S AGREEMENT
By accepting delivery of this product, you promise that you will not change, alter, or modify this product
or remove or render inoperable or unsafe any guards, shields, or other safety features of this product; fail,
refuse, or neglect to install any retrofit kits from time to time provided to enhance or preserve the safe use
of this product.
SHIPPING AND DELIVERY
Before using your lift chair, make sure your delivery is complete as some components may be individually
packaged. If you do not receive a complete delivery, please contact your authorized provider immediately.
Where damage has occurred during transport, either to the packaging or content, please contact the
delivery company responsible.
MOTOR VEHICLE TRANSPORT
If you will be transporting your lift chair in a motor vehicle, individual components (external transformer,
etc.) should be secured against slipping. The lift chair itself must also be secured against slipping (a
possible hazard during vehicle braking).
I. INTRODUCTION

Lift Chair Series 5
PRODUCT SAFETY SYMBOLS
The symbols below represent labels used on the product to identify warnings, mandatory actions, and
prohibited actions. It is very important for you to read and understand these symbols completely. Do not
remove these labels from your product. Please note that not all of the symbols may be used on your lift
chair model.
Pinch/Crush Points Hazard! Do not place objects or appendages in the path of moving
parts.
Read and follow the information in the owner’s manual.
Maximum weight capacity
Do not connect an extension cord to the AC/DC converter or the battery charger.
Electrical Hazard
Removal of grounding prong can create electrical hazard. If necessary, properly install
an approved 3-pronged adapter to an electrical outlet having 2-pronged plug access.
Do not connect the heat and massage hand control directly to the motor. Connect the
hand control directly to the junction box to prevent equipment damage.
This product has been tested and complies to IEC 60601-1-2.
Do not place objects under the footrest when lift chair is in fully reclined position. Make
sure area is clear of obstructions, including pets and small children, during operation.
Do not cover or place the external transformer under the chair. Keep in an open, well-
ventilated area free from foreign material and away from possible pinch points.
Do not place objects under lift chair. Make sure area is clear of obstructions, including
pets and small children, during operation.
Class II Equipment
II. SAFETY
Indoor Use Only. Avoid exposure to rain, snow, ice, salt, or standing water. Maintain and
store in a clean and dry environment.

6 Lift Chair Series
Degree of protection against electric shock.
Properly dispose of all electronic components, including the external transformer, hand
control, batteries, actuator motors, and wiring. Contact your authorized provider for
more information.
II. SAFETY
Green LED indicates power to the unit is on. Not applicable to all models.
Battery Door Location
Your lift chair is a state-of-the-art life-enhancement device designed to increase comfort. An extensive
variety of products are provided to best fit your individual needs. Please be aware that the final selection
and purchasing decision regarding the type of lift chair to be used is the responsibility of you, the lift chair
user, if capable of making such a decision, and/or your healthcare professional (i.e., medical doctor,
physical therapist, etc.).
MANDATORY! Read and follow the information provided in this owner’s manual
before attempting to operate your lift chair for the first time.
There are certain situations, including some medical conditions, where you will need to practice operating
the lift chair in the presence of a trained attendant. A trained attendant can be defined as a family member
or healthcare professional specially trained in assisting you with performing various daily living activities
while safely operating a lift chair.
Below are some precautions, tips, and other safety considerations that will help you become accustomed
to operating the lift chair in a safe manner.
Modifications
You should not modify, add, remove, or disable any feature, part, or function of your lift chair.
Unauthorized modifications may lead to personal injury and/or product damage and may also void your
product’s warranty.
NOTE: Use only manufacturer parts for all repairs and replacements.
Weight Limitations
Your lift chair is rated for a maximum weight capacity. Please refer to the specifications table for this limit.
MANDATORY! Stay within the specified weight capacity of your lift chair. Your
provider will not be held responsible for injuries and/or product damage
resulting from failure to observe weight limitations.

Lift Chair Series 7
The scissor and lift mechanisms are labeled as pinch/crush point hazards on your lift chair. Keep clear of
these areas and make sure the path of motion is unobstructed. See figure 3.1 for pinch/crush point
locations.
WARNING! Do not place objects or appendages in the path of moving parts.
Degree of Protection/Mode of Operation
Class II equipment/Type B protection against electric shock
Degree of protection against the ingress of solid/liquids—IPX0
Mode of operation—Maximum Duty Cycle: 2 min. ON/18 min. OFF
Storage and Operation Temperatures
Transportation or storage: -104°F/-75°C to 158°F/70°C
Operation: 50°F/10°C to 104°F/40°C
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio
frequency waves can have an adverse effect on the performance of electrically-
powered devices, such as lift chairs.
Electromagnetic and Radio Frequency Interference can come from sources such as cellular phones,
mobile two-way radios (such as walkie-talkies), radio stations, TV stations, amateur radio (HAM) trans-
mitters, wireless computer links, microwave signals, paging transmitters, and medium-range mobile
transceivers used by emergency vehicles. In some cases, these waves can cause unintended movement
or damage to the control system of electrically-powered devices. The lift chair user can help prevent
electromagnetic interference by maintaining a minimum distance between portable and mobile RF com-
munications equipment. It is recommended that at least 9 feet (3 meters) of distance be maintained
between the lift chair and any handheld equipment emitting 10 W or more of output power. Refer to the
manufacturer’s literature for the handheld device to determine the maximum output of that device.
Every electrically-powered device has an immunity (or resistance) to EMI. The higher the immunity level,
the greater the protection against EMI. Per EMC standards, this product has passed immunity testing and
is rated as a Group 1, Class B product, meaning the lift chair uses RF energy only for its internal function.
Therefore, its RF emissions are very low and are not likely to cause any interference in nearby electronic
equipment, making the lift chair suitable for use in all establishments, including domestic establishments
and hospitals.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types
of radio transmitters may cause unintended movement of your electrically-
powered device due to EMI. Exercise caution when using any of these items
while operating your lift chair.
WARNING! The addition of accessories or components to the lift chair can
increase the susceptibility of the chair to EMI. Do not modify your lift chair in
any way not authorized by your provider.
WARNING! Your lift chair itself can disturb the performance of other electrical
devices located nearby, such as alarm systems.
NOTE: If unintended motion occurs, discontinue use of the lift chair. Contact your provider to report
the incident.
II. SAFETY

8 Lift Chair Series
HAND CONTROL: Containsthe controls
needed to operate the various functions
of the lift chair. Refer to the Hand Control
Quick Reference Guide for more
information on hand control options.
SCISSOR MECHANISMS (PINCH POINT):
Extend or retract to take the chair through
the various stagesof recline. See pinch
point warning for more information.
QUICK-RELEASE CONNECTOR:
Enablesthe user to detach the
hand control from the lift chair.
FOOTREST EXTENSION:
Provides3in. (8cm) of extension
and foldsup neatly when lift chair
isin the seated or lift positions;
specific to the LL575 and optional
on some other models.
LIFT MECHANISM
(PINCH POINT):
Respondsto the hand control
commandsto position the
chair in the sit and stand
positions. See pinch point
warning for more information.
BATTERIES (NOT INCLUDED):
Provide the power needed to
return the lift chair to an upright
or semi-upright position in the
event of apower failure. Must be
installed in the external transformer
if equipped with battery backup.
EXTERNAL TRANSFORMER, POWER
CORD: Connectsto astandard electrical
outlet to provide power to the lift chair; may
be equipped with an LED which will show
green to indicate power to the transformer.
Refer to the optional wall mounting diagram.
LEG LEVELERS (4): Manually
rotate up or down to stabilize
the chair before use.
BODY COMPONENTS
Lift chairs are equipped with several frame and electrical components. Typically, frame (or body) compo-
nents include a removable back pad*, removable chaise pad*, footrest, leg levelers, a lift mechanism, and
scissor mechanisms. The electrical components include the external transformer, hand control, and bat-
teries‡(not included). Refer to figure 3.1 and note that the illustrations and options listed may not reflect
the type of lift chair that you own.
Figure 3.1 Lift Chair Main Components
III. YOUR LIFT CHAIR

Lift Chair Series 9
Removable Back Pad: Attaches to the lift chair with reusable fasteners to enable the use of the bed
option on some models and to make servicing the chair more convenient.
Removable Chaise Pad: Attaches to the lift chair with reusable fasteners to make servicing the chair
more convenient.
*NOTE: The lift chair must be in the recline position in order to remove or attach the back pad, chaise pad,
or bed option mattress (LL670 only). If the lift chair is equipped with heat and massage options, you must
also disconnect the heat and massage connections before removing the back pad and/or chaise pad.
*NOTE: The LL770L bed option consists of a mattress, bedsheet, strap, and storage bag. After removing
the mattress, it is recommended that you store it in the bag provided.
‡NOTE: The batteries will provide power for only a short period of time after power is removed from
the system, so it is important to act quickly in the event of a power failure. Press and hold the UP button
(switch) on the hand control as soon as possible. Maintain a steady pressure on the button (switch) to
avoid excessive draw from the battery and achieve the most amount of lift. Keep in mind that the
amount of life the batteries will be able to provide is affected by user weight and battery condition.
WARNING! Pinch/Crush Points Hazard! Be aware that the lift mechanism and
scissor mechanisms are a pinch point on the lift chair. Keep the following items
and similar objects clear of these points when operating the lift chair:
appendages
small children
pets
wires
oxygen tubes
 loose items, including but not limited to clothing and blankets
electrical power cords
ELECTRICAL COMPONENTS
Your lift chair is equipped with a low voltage DC electrical system that reduces the standard household
alternating current of 100V AC - 240V AC to direct current (24/39V DC). The electrical components include
the external transformer, batteries (not included), and hand control. Keep these areas free from moisture at
all times.
WARNING! Keep all electrical components free from moisture at all times to
prevent shock and/or electrical hazard.
Batteries: Provide the power needed to return the lift chair to an upright or semi-upright position in the
event of a power failure. For those models equipped with a battery backup system, the batteries (not
included) must be installed into the external transformer. See IV. “Assembly/Disassembly.”
III. YOUR LIFT CHAIR

10 Lift Chair Series
Your lift chair may require some assembly before initial use. It may also require disassembly to make
servicing the chair more convenient. If your lift chair is a Knock-Down (KD) model, follow the instructions
in “Lift Chair Setup.”
CHAIR BACK ASSEMBLY
NOTE: If your lift chair is an Infinite model, refer to the assembly instructions provided with the chair.
For the 2-position model, the KD sleeves are located on the inside as shown in figure 4.1.
IV. ASSEMBLY/DISASSEMBLY
BARIATRIC MODEL
WALL HUGGER MODEL
3-POSITION MODEL
INFINITE MODEL HOOK AND LOOP FLAP
PROPER CLIP POSITION
2-POSITION MODEL
Figure 4.1 Lift Chair Assembly
1. Check that the locking clip on the back of the chair is in the vertical position. Reposition if necessary.
2.
Drape the hand control and cable over the chair base, then slide the back onto the base.

Lift Chair Series 11
MASSAGE
UNIT
HEAT CONNECTION
TO JUNCTION BOX
MASSAGE
UNIT
JUNCTION
BOX
For LL770 Lift Chairs, after attaching the
back per the KD instructions, fully recline
the lift chair and place the base flap over
the gap between the seat and back.
Using the reusable fasteners, secure the
base flap to the chair and then secure
the bottom-most pillow to the base flap.

Place the bolster pillow over the covered
gap, slightly wedging it between the back
and seat, and return the LL770 Lift Chair
to the seated position.
For units equipped with the heat and
massage option, connect the heat and
massage harnesses to the chair.
 The heat pad(s) and massage units have
been factory installed on your lift chair. You
should only need to connect the harnesses
to the chair. If you find any further assem-
bly is required with this system, contact
your authorized provider immediately.
*STANDARD HEAT/MASSAGE CONFIGURATION
IV. ASSEMBLY/DISASSEMBLY
NOTE: See figure 4.2 for additional instructions regarding LC770 models.
4. Connect the hand control harness to the lift chair and heat/massage harnesses (if equipped) to the
lift chair (Fig 4.3).
WARNING! Do not connect the push-button or heat/massage hand control
directly to the motor. Connect the hand control directly to the junction box to
prevent equipment damage.
5. Attach the chair-back to the hook and loop flaps on the bottom of the chair base.
Figure 4.2 LL770 Additional Assembly Figure 4.3 Harness Connections
WARNING! Be aware that the average temperature of the heating pad ranges
between 106°F - 118°F (41°C - 48°C) and can be affected by the ambient
temperature of the room and clothing worn by the user. Your provider
recommends that the heat units not be used for more than 20 minutes at a time
as prolonged exposure may have an adverse effect on sensitive skin. However,
you should consult the physician about how often you should use the heat and
massage options on your lift chair.
NOTE: Depending on chair width, you may need to slide on one side of the back at a time. If this is the
case, level the chair-back before pressing down to lock into position.
3. Push firmly on the top of the back to lock into position. You must hear a click from each side of the chair
to ensure the back is locked in properly.
NOTE: Pull up on the chair-back to ensure that it is locked in place.

12 Lift Chair Series
LIFT CHAIR PLACEMENT
Your lift chair should be placed near a standard electrical outlet on dry, level ground where there is ample
room to allow for proper operation. We recommend that you have the assistance of an attendant when
positioning the lift chair to avoid the possibility of injury when lifting.
Follow these steps to position the lift chair in a safe manner:
1. Place the back of the lift chair 30 in. (76 cm) from the nearest obstruction while the chair is in the
seated position. This measurement may vary depending on model.
2. Adjust the leg levelers to stabilize the lift chair (Fig. 3.1).
3. Install the batteries into the external transformer if applicable. Refer to “Battery Installation” for more
information.
4. Position the external transformer on the floor in an open, well-ventilated area where it will not be an
obstruction or, if equipped, utilize the optional wall mount.
5. Position the low voltage connection cable where it will not be pinched between the frame and the lift
mechanism.
6. Connect the low voltage connection cable to the external transformer if it is not already connected.
7. Plug the power cord directly into the electrical outlet. Do not use an extension cord!
NOTE: If you discover a problem at any point during the setup and positioning of your lift chair, stop
and contact your authorized provider immediately. To avoid personal injury and/or product damage, do
not plug the unit into the electrical outlet until the problem is corrected and do not attempt to fix elec-
trical problems by yourself.
EXTERNAL TRANSFORMER
(TOP AND BOTTOM VIEW)
BATTERY DOOR
POWER CORD
Figure 4.4 Lift Chair Battery Backup Location
BATTERY INSTALLATION
Your lift chair may be equipped with a battery
backup system that will activate during a power
failure. The backup system is powered by two 9V
batteries (not included) that need to be installed
into the external transformer.
Follow these steps to install the batteries:
1. Unplug the external transformer power cord
from the electrical outlet.
2. Open the marked battery door on the external
transformer.
3. Install two 9V batteries into the external trans-
former (Fig. 4.4).
4. Replace the battery door.
NOTE: Always make sure the external trans-
former is equipped with two fresh 9V batteries,
since the battery backup system does not
recharge itself. Fresh batteries are defined as 9V
alkaline batteries that are replaced every time the
battery backup system is activated during a
power failure, or once a year if the battery
backup system has not been activated.
IV. ASSEMBLY/DISASSEMBLY
NOTE: If you unplug your lift chair for an extended period of time (more than one hour), remove the
batteries from the external transformer. The lift chair will draw power from the batteries even when it
is not in use.

Lift Chair Series 13
OPERATION PRECAUTIONS
There are certain precautions that should be taken during the operation of your lift chair. Read and follow these
precautions carefully in order to ensure safe lift chair operation and to prevent injury and/or product damage.
 Plug the power cord directly into the electrical outlet. Do not use an extension cord!
Do not place anything (for example, a drinking glass) on top of or near the external transformer.
If the external transformer box or hand control requires cleaning, unplug the power cord from the
electrical outlet and use a clean, dry cloth or lightly dampened cloth. Allow ample drying time before
plugging the power cord back into the electrical outlet.
Periodically check the hand control and all power cords for visible damage.
Keep the hand control away from all heated surfaces.
Ensure the hand control is out of the way before sitting in the chair.
Keep children and pets away from all moving parts while operating the lift chair.
Do not allow children to play on or operate the lift chair. Only the intended user should operate the lift
chair.
Keep the hand control locked or utilize the quick-disconnect feature on the standard hand control
when the lift chair is not in use to prevent unintended operation of the chair.
Avoid pinch points, such as the lift and scissor mechanisms. Keep hands and feet clear of these areas.
Always leave the lift chair in an upright and closed position when not in use.
Do not sit or stand on the footrest.
Do not “drop” into the lift chair when sitting if it is in a partially raised position.
PROHIBITED! Do not place objects under the lift chair. Make sure area is clear
of obstructions, including pets and small children during, operation.
WARNING! Prevent the risk of electrical shock, fire, falls, and/or being pinched.
Follow all instructions and precautions provided.
WARNING! Prevent potential equipment damage! Do not place the external
transformer under the lift chair.
WARNING! Do not cover the external transformer. Keep the transformer in an
open, well-ventilated area free from foreign material/debris to ensure proper
operation.
HAND CONTROL OPERATION
Your lift chair hand control is equipped with switches/buttons that control the movement of the chair and/
or heat and massage options. Read the following instructions for basic hand control operation. Please
refer to the Hand Control Quick Reference Guide for more detailed information on your specific hand
control.
WARNING! Do not lean on or apply downward force to the chair-back when the
lift chair is in the fully reclined position. Doing so could cause the lift chair to
tip, resulting in personal injury and/or product damage.
WARNING! Do not use the footrest as a seat, or for purposes outside its intended
use. Doing so could cause instability in the lift chair and place undue stress on
lift chair components, resulting in personal injury and/or product damage.
WARNING! Be sure to lock or disconnect the hand control when the lift chair is
not in use.
V. OPERATION

14 Lift Chair Series
V. OPERATION
Follow these steps to properly sit in your lift chair:
1. Make sure that the lift chair is in the standing position.
2. Back into the lift chair and sit in the center of the seat.
3. Activate the DOWN button (switch) to lower the lift chair to a comfortable seated position.
Follow these basic steps to operate your lift chair from the seated position:
1. Activate the UP button (switch) to raise your lift chair to the standing position.
2. Activate the DOWN button (switch) to lower the lift chair to a comfortable seated position.
Follow these steps to recline your lift chair from the seated position:
1. Activate and hold the DOWN button (switch) until comfortably reclined.
2. Activate and hold the UP button (switch) to return to an upright, seated position. Release the button
(switch) when the lift chair reaches a comfortable seated position.
Follow these steps to properly stand up from your lift chair:
1. Activate and hold the UP button (switch) to raise your lift chair.
2. Release the button (switch) when the lift chair reaches a height where you can stand up comfortably.
WARNING! Do not attempt to stand up until you can stand safely, are steady on
your feet, and can bear weight. Pride recommends the use of assistance aids
and/or an attendant for enhanced stability.
Trendelenburg Position (LL770)
Elevate the footrest, and then recline the seatback until your feet are elevated higher from the ground than
your head. Please refer to the Hand Control Quick Reference Guide for more detailed information on your
specific hand control.
"Zero Gravity" Position (LL770)
Elevate the footrest, and then recline the seatback until your thighs and lower legs are positioned slightly
higher than your torso (body in V-like position). Please refer to the Hand Control Quick Reference Guide
for more detailed information on your specific hand control.

Lift Chair Series 15
Your lift chair may require occasional troubleshooting. The following troubleshooting tips and FAQs
should summarize what you need to know about your lift chair. If at any time you do not feel comfortable
performing the troubleshooting steps listed in this manual, contact your authorized provider for service.
Please have the model number, serial number, and nature of the problem when calling.
DUAL MOTOR TIMING
NOTE: If your dual motor lift chair is equipped with a heat/massage option and/or was manufactured
prior to May 17, 2011 and does not move when the hand control is pressed, the motors may be out-of-
sync.
Follow these steps to reset the motor timing:
1. Activate the hand control on the lift chair. If there is no movement in either direction, check if the
motors are out-of-sync and that the pressure-sensitive safety switch has been activated. Out-of-sync
motors will show one motor extended farther than the other and a pinched safety switch (Fig. 6.1).
2. If the motors are out-of-sync, disconnect one of the two red safety switch plugs from the motor control
box (Fig. 6.1).
3. Activate the UP position on the hand control until your chair reaches the full lift position. This will reset
the motor position and correct the timing (Fig. 6.1).
4. Reconnect the red safety switch plug into the motor control box (Fig. 6.1).
NOTE: In order to preserve the correct motor timing, it is recommended to extend the lift chair to the
full lift position when getting in and out of the chair.
VI. BASIC TROUBLESHOOTING
MOTOR CONTROL BOX
SAFETY SWITCHESMOTORSMOTORS
Out-of-sync Motors In-sync Motors
SAFETY
SWITCHES
Figure 6.1 Dual Motor Timing

16 Lift Chair Series
FREQUENTLY ASKED QUESTIONS
What if my lift chair does not operate at all?
Ensure the external transformer is plugged into a properly wired electrical outlet.
Check the circuit breaker box connected to the electrical outlet to ensure the outlet is receiving power.
Ensure the low voltage connection cable is plugged into the external transformer.
Ensure that all cables are connected properly.
What if my lift chair operates in one direction only?
Check the up and down buttons or toggle switch on the hand control to make sure they do not stick.
If the buttons or switch are sticking in either position, the hand control may need to be replaced.
Contact your authorized provider for further assistance.
What if my lift chair stops during a lifting cycle?
 Your lift chair is equipped with an internal thermal shutoff switch located inside the external transformer
that prevents the motor control box from overheating. If the thermal shutoff activates, allow the lift chair
to remain in a stationary position for 10 minutes to allow the motor to cool, then resume normal operation.
If you notice the motors overheating frequently, contact your authorized provider.
There may have been a power failure and/or there are no batteries in the external transformer or the
batteries have no charge. Always make sure there are fresh 9V batteries in the external transformer
if equipped with battery backup.
Check the circuit breaker box connected to the electrical outlet to ensure the outlet is receiving power.
What if the heat and massage options on my lift chair do not function?
Ensure the junction box is connected properly to the external transformer and that there is power to
the transformer. A green LED will light on the transformer to indicate power.
Ensure the heat and massage units are connected properly at the rear of the lift chair.
 Ensure the hand control is connected properly to the lift chair. If connected properly, any LEDs on the
hand control will be lit.
If any of the LEDs do not light, contact your authorized provider for further assistance.
What if my lift chair is rocking from corner to corner after I position the chair?
The floor may be uneven or the carpet may be affecting chair position. Adjust the leg levelers in the area
where the chair is rocking. See III. “Your Lift Chair” for instructions on leveling your chair.
Where can I place the external transformer box?
 On the floor away from heat sources in an open, well-ventilated area where it will not be an obstruction.
On the wall away from heat sources utilizing the optional external transformer wall mount. Refer to the
Wall Mount Diagram Product Insert provided with your lift chair.
Where do I find the serial number on my lift chair?
You can find the serial number in two locations—one is near the rear of the motor on the steel lift mech-
anism, the second is attached to the frame below the scissor mechanisms. The model number for your
lift chair is printed below the serial number bar code.
Who do I call for service?
Contact your authorized provider for service.
VI. BASIC TROUBLESHOOTING

Lift Chair Series 17
Your lift chair will require routine maintenance checks. You can perform some of these checks, but others
may require assistance from an authorized provider. By following the maintenance checks in this section
as scheduled, you can help ensure your lift chair gives you years of trouble-free operation. If you have
any questions regarding your lift chair’s care, contact your authorized provider.
FABRIC CARE
Inspect the fabric on a regular basis for any pulls, tears, or gaps.
Choose the right methods to clean the fabric on your lift chair. Before cleaning your lift chair, consult
your authorized provider for cleaning codes.
WARNING! Fabric should not be allowed to come in direct contact with any type
of heat source (e.g., a space heater or cigarette). Personal injury or fire damage
may occur.
WARNING! Your provider strongly recommends that you do not smoke
cigarettes while seated in or using your lift chair, although the lift chair has
passed the necessary testing requirements for cigarette smoking. You must
adhere to the following safety guidelines if you decide to smoke cigarettes
while seated in or using your lift chair.
 Do not leave lit cigarettes unattended.
 Keep ashtrays a safe distance from the lift chair.
 Always make sure cigarettes are completely extinguished before disposal.
NOTE: Do not use solvent-type cleaners to spot clean. Do not saturate the fabric. Prevent damage to
the fabric; do not expose the lift chair to direct sunlight.
ELECTRONICS CARE
Inspect all wiring harnesses to make sure they are not damaged or frayed.
If damage is present, unplug the lift chair and contact your authorized provider for service.
Keep all electronics free from moisture and temperature extremes. Lift chairs are intended for
indoor use only!
WARNING! Even though the lift chair has passed the necessary testing
requirements for ingress of liquids, you should keep electrical connections
away from sources of dampness, including direct exposure to water or bodily
fluids and incontinence. Check electrical components frequently for signs of
corrosion and replace as necessary.
DISPOSAL AND RECYCLING
Your lift chair must be disposed of according to applicable local and national statutory regulations. Con-
tact your local waste disposal agency or authorized provider for information on proper disposal of lift chair
packaging, metal frame components, fabric, electronic components, and batteries.
WARNING! Plastic bags are a suffocation hazard. Dispose of plastic bags
properly and do not allow children to play with them.
VII. CARE AND MAINTENANCE

18 Lift Chair Series
(This page intentionally left blank.)
(Cette page a été laissée vierge intentionnellement.)

Lift Chair Series 19
(This page intentionally left blank.)
(Cette page a été laissée vierge intentionnellement.)
Lift Chair Serie 18

20 Lift Chair Series
Votre fauteuil auto-souleveur doit subir des vérifications de routine. Vous pouvez faire certaines
inspections vous-même tandis que d’autres inspections peuvent exiger que votre détaillant autorisé les
exécute. En suivant la liste des vérifications, vous pouvez vous assurez que votre fauteuil auto-souleveur
vous procurera plusieurs années de service sans problème. Si vous avez des questions concernant
l’entretien votre fauteuil auto-souleveur, contactez votre détaillant autorisé.
SOINS DU RECOUVREMENT
Inspectez le recouvrement pour voir s’il y a des fils tirés, des fentes ou des déchirures.
Prenez la bonne méthode pour nettoyer le recouvrement de votre fauteuil auto-souleveur. Avant de
commencer le nettoyage, consultez votre détaillant autorisé pour connaître la bonne méthode.
MISE EN GARDE! Le recouvrement ne doit jamais être mis en contact direct
avec une source de chaleur telle qu’une chaufrette ou une cigarette sous peine
de vous blesser et/ou de provoquer un incendie.
MISE EN GARDE! Votre détaillant autorisé recommande fortement de ne pas
fumer lorsque vous prenez place ou que vous faites fonctionner votre fauteuil
auto-souleveur, même si votre fauteuil auto-souleveur a réussi les tests
d’exposition à la cigarette. Si vous décidez de fumer dans votre fauteuil auto-
souleveur, vous devez respecter les consignes suivantes:
 Ne laissez-pas de cigarette allumée sans surveillance.
 Gardez les cendriers à distance du fauteuil auto-souleveur.
 Assurez-vous de bien éteindre les cigarettes avant d’en disposer.
NOTE: N’utilisez pas de nettoyeur à base de solvant pour enlever une tache. Ne saturez-pas le tissu.
Ne placez pas le fauteuil en plein soleil afin de prévenir les dommages au recouvrement.
ENTRETIEN DES COMPOSANTES ELECTRONIQUES
Inspectez tous les fils pour déceler des dommages ou de l’usure.
Si vous décelez des dommages, débranchez le fauteuil et contactez votre détaillant autorisé pour le
faire réparer.
 Gardez les composantes électroniques bien au sec, loin de toute humidité et dans un endroit tempéré.
Les fauteuils auto-souleveurs sont conçus pour l’utilisation à l’intérieur seulement!
MISE EN GARDE! Même si votre fauteuil a réussi les test d’exposition aux
liquides, gardez votre fauteuil à l’abri des sources d’humidité tel que
l’exposition directe à de l’eau et les liquides corporels. Inspectez les
composantes électriques fréquemment et remplacez-les si vous décelez de la
corrosion.
MISE AU REBUT ET RECYCLAGE
Votre fauteuil auto-souleveur doit être mis au rebut en respectant les lois et règlements de votre
municipalité. Contactez votre organisme local ou votre détaillant autorisé pour obtenir les informations
sur la mise au rebut et le recyclage des pièces de métal, de bois, de plastique, batteries et l’emballage
de votre fauteuil.
MISE EN GARDE! Les sacs de plastique sont dangereux pour les jeunes enfants.
Assurez-vous d’en disposer de façon sécuritaire.
VII. SOINS ET ENTRETIEN
17 Lift Chair Serie
