Pride Mobility Quantum Rehab J600ES Use and care manual

Parts Replacement Guide
Pride Mobility Products Ltd.
32 Wedgwood Road
Bicester, Oxfordshire OX26 4UL
Telephone: [phone]
Fax: [phone]
Web: www.pridemobility.co.uk
(Image is for illustration purposes only.)

Yo ur new Quantum Rehab PartsReplacement Guide has been compiled from the latest product information available at
the time of publication. Pride®Mobility ProductsLtd. reservesthe right to make changesand updatesto thismanual and to
the product(s) it represents. Any changes, updates, or improvementsto the product(s) may result in slight differences
between thismanual and the product youpurchased.
Thismanual coversthe removal and replacement of various mechanical and electrical componentsfor the mobility product.
Read and follow all of the instructions, warningsand notescontained in thismanual prior to performing repairsto the mobil-
ity device.
The stepslisted for each assembly will represent the proper disassembly and replacement of the components. The illustra-
tionsmay differ slightly from the itemsbeing serviced but the replacement methodswill remain consistent. Later replace-
ment instructionsmay refer back to earlier sections.
Please view the IPB for the product to obtain the part numbersfor any replacement components.
Warning symbolsare used throughout the PartsReplacement Guide to identify important safety information. All of the
symbolshave asuperscript number that will reference back to thispage to designate precautionsfor that particular
replacement step. It isvery important to read and understand them completely.
Thank youfor choosing productsfrom Quantum Rehab.
2
Copyright © 2014
Pride®Mobility ProductsLtd.
www.pridemobility.co.uk
INFMANU4664/Rev.A/110714
Mobility Products. Ltd.
WARNING! Service should be
performed by an authorized
service technician only.
WARNING! Failure to ensure
the axle key is properly re-
installed into the axle slot
can result in electronic brake
failure, personal injury, and/
or product failure.
WARNING! Do not disassem-
ble the Run Flat Wheel
assembly. Personal injury
may occur.
WARNING! Incorrect harness
placement can cause abrupt
battery disconnect and loss
of power in the event of a
sudden stop.
WARNING! Do not mix old
and new batteries. Always
replace both batteries at the
same time.
1
2
3
4
WARNING! Keep tools and
other metal objects away
from the battery terminals.
Contact with tools can cause
electrical shock.
WARNING! Do not adjust the
tension of any spring on the
power chair.
WARNING! It is strongly rec-
ommended that a second
person assist in the removal
of the seating systems.
WARNING: Any nylon insert
lock nut removed during the
disassembly or adjustment
of a component must be
replaced with a new nut.
Reuse may result in a less
secure fit.
6
7
8
5
9
www.pridemobility.co.uk
Introduction and Warnings

3
Mobility Products. Ltd.
www.pridemobility.co.uk
Table of Contents
SECTION I.
Foot Platform/Front Battery Door and Rear Electronics Door .........................................................................................6
SECTION II.
Centre Panel and Top Shroud.........................................................................................................................................7
SECTION III.
Run Flat Drive Wheel .....................................................................................................................................................8
SECTION IV.
Front/Rear Castor Assembly ...........................................................................................................................................9
SECTION V.
Articulating Beam............................................................................................................................................................10
SECTION VI.
Drive Motor......................................................................................................................................................................11
SECTION VII.
Foot Platform...................................................................................................................................................................13
SECTION VIII.
Batteries..........................................................................................................................................................................14
SECTION IX.
Joystick ...........................................................................................................................................................................15
SECTION X.
Power Module .................................................................................................................................................................16
SECTION XI.
Battery/Power Harness and Circuit Breaker ...................................................................................................................17
Required Tools & Instruments
• Imperial and Metric Spanner Set
• Imperial and Metric Socket Set
• Imperial and Metric Hex Key Set
• Calibrated Torque Spanner/Wrench
• Flathead Screwdriver
• PhillipsScrewdrivers
• Wire Cutters
• Needlenose Pliers
• Wooden Blocks
• Cableties

4
Mobility Products. Ltd.
www.pridemobility.co.uk
Chair Preparations
On/Off Key
VR2 4-Key Joystick
All of the replacement instructionsrequire safety precautionsprior to performing service to the mobility device. These
precautionsare set in place not only to ensure the safety of the technician but for the end user as well. The replace-
ment instructionsin the guide will refer back to thissection to set-up the product prior to service.
1. Turn off power to the joystick.
VR2
Joystick
3. Disconnect the joystick from the power base.
2. Place the unit in drive mode.
4. Prop up the power base with a block.

5
Mobility Products. Ltd.
www.pridemobility.co.uk
Seating Removal
Several service applicationsrequire the removal of the seat. The illustration below outlinesthe connection pointsof the
seating system to the power base.
Euro Seat 2 Interface removal and installation
Seat removal and installation
To r que the screws to
.sMFTsLB
To r que the screws to
.sMFTsLB
To Seat Base
8

6
Mobility Products. Ltd.
www.pridemobility.co.uk
I. Foot Platform/Front Battery Door and Rear Electronics Door
1. Turn off power to the joystick.
2. Ensure the unit is in drive mode.
Tools Required:
- None
- Front Battery Door Removal/Installation:
3. Flip up the foot platform (if applicable), squeeze the release levers and lift the front battery door off of the frame.
4. Reverse step 3 for installation.
- Rear Electronics Door Removal/Installation:
5. From the rear of the unit, loosen the lower thumb screws and gently pull up on the rear door.
6. Reverse step 5 for installation.
Thumbscrew Location
at the Rear of the Unit
Thumbscrew
Rubber O-ring
Foot Platform Bracket/Front Battery Door removal
and installation
Rear Electronics Door removal and installation
1

7
Mobility Products. Ltd.
www.pridemobility.co.uk
II. Centre Panel and Top Shroud
1. Turn off power to the joystick.
2. Ensure the unit is in drive mode.
Tools Required:
- Phillips Screwdriver
- Centre Panel Removal/Installation:
3. Remove the rear electronics door. See Section I.
4. From the rear of the unit, gently pull up on the centre panel to loosen the reusable fasteners. Lift off the centre panel.
5. Reverse steps 3 and 4 for installation.
- Top Shroud Removal/Installation:
6. Remove the front battery door and the rear electronics door. See Section I.
7. Remove the centre panel
8. Remove the seating system and trapeze bars if equipped.
9. Remove the 4 screws that attach the top shroud to the main frame.
10. Reverse steps 6 to 9 for installation.
Centre Panel removal and installation Top Shroud removal and installation
1

8
Mobility Products. Ltd.
www.pridemobility.co.uk
III. Run Flat Drive Wheel
1. Turn off power to the joystick.
2. Ensure the unit is in drive mode.
3. Prop up the side of the unit being serviced.
Tools Required:
- Imperial and Metric Socket Set
- Calibrated Torque Spanner/Wrench
- 5 Spoke Hub Run Flat Drive Wheel Removal/Installation:
4. Remove the 5 lug nuts that connect the rim to the hub.
5. Pull the wheel assembly straight off of the hub.
6. Reverse steps 4 and 5 for installation. Torque the replacement lug nuts to 25 N • m (18.4 ft • lb).
To r que the lug nuts to
25 N • m (18.4 ft • lb)
3
5 Spoke Hub Run Flat Drive Wheel removal and
installation
1
***DO NOT DISASSEMBLE THE RUN FLAT WHEEL***

9
Mobility Products. Ltd.
www.pridemobility.co.uk
IV. Front/Rear Castor Assembly
1. Turn off power to the joystick.
2. Ensure the unit is in drive mode.
3. Prop up the side of the unit being serviced.
Tools Required:
- Imperial and Metric Socket Set
- Imperial and Metric Spanner Set
- Calibrated Torque Spanner/Wrench
- Flathead Screwdriver
- Needlenose Pliers
4. Pry off the castor barrel cap.
5. With a spanner and socket remove the upper nut securing the assembly in the castor barrel.
6. With needlenose pliers, remove the washer and shim from the castor barrel.
7. Slide the castor assembly out of the castor barrel.
8. Reverse steps 4 to 7 for installation. Torque the nut to 30 N • m (21.7 ft • lb).
To r que the nut to
.sMFTsLB
Washer
3HIM
Cap
9
Front or Rear Castor Assembly removal and installation
1

10
Mobility Products. Ltd.
www.pridemobility.co.uk
V. Articulating Beam
1. Turn off power to the joystick.
2. Ensure the unit is in drive mode.
3. Prop up the rear of the unit.
Tools Required:
- Metric Socket Set
- Metric Spanner Set
- Calibrated Torque Spanner/Wrench
- Flathead Screwdriver
4. Remove the hex head screw, washers, and nutsthat secures the arm to the base.
5. Reverse step 4 for installation. Torque the nut to 40 N • m (30 ft • lb).
To r que the nut to
.sMFTsLB
79
Articulating Beam removal and installation
1

11
Mobility Products. Ltd.
www.pridemobility.co.uk
VI. Drive Motor
1. Turn off power to the joystick.
2. Ensure the unit is in drive mode.
3. Prop up the side of the unit being serviced.
Tools Required:
- Imperial and Metric Socket Set
- Calibrated Torque Spanner/Wrench
- Imperial and Metric Hex Key Set
- Phillips Screwdriver
- Wire Cutters
4. Remove the 4 spoke or 5 spoke hub drive wheel. Retain
all hardware. See Section III.
5. If the replacement drive motor does not contain a
replacement hub, remove the nut and washer that secures
the hub to the motor shaft and loosen the setscrew on the
hub. Slide the hub off of the motor shaft. ***The Axle Key
may shift out of place on the motor shaft. Make sure the
Axle Key is retained.***
6. Remove the screws that connect the fender shroud to
the motor bracket.
7. Loosen the 2 setscrews that hold the freewheel release
linkage to the motor and gently pull it off the release shaft.
8. Remove the rear electronics door. See Section I.
Continued on the next page.....
Loosen
Setscrews
Fender Shroud removal and installation Freewheel Linkage removal and installation
To r que the nut to
51 N • m (37.6 ft • lb)
Axle Key
Setscrew
29
5 Spoke Hub removal and installation
1

12
Mobility Products. Ltd.
www.pridemobility.co.uk
VI. Drive Motor
9. Disconnect the desired motor harness from the power
module.
10. Carefully cut the cableties that may secure the motor
harness to the main battery harness.
11. Remove the 6 screws that connect the motor assembly
to the motor bracket.
12. Connect the replacement motor assembly to the motor
bracket with the screws retained from step 11. Torque the
screws to 7 N • m (5 ft • lb).
13. Route the motor harness and reconnect to the power
module. Secure with cableties.
14. Reverse steps 4 to 8 to complete installation. Torque
the lug nuts to 25 N • m (18.4 ft • lb).
Cabletie and Harness routing locations Motor removal and installation
VR2
Right Motor
Harness Left Motor
Harness
Motor Harness removal and installation

13
Mobility Products. Ltd.
www.pridemobility.co.uk
VII. Foot Platform
1. Turn off power to the joystick.
2. Ensure the unit is in drive mode.
Tools Required:
- Metric Socket Set
- Metric Spanner Set
3. To ease service, remove the front battery door with the foot platform attached. See Section I.
4. Remove the hardware that connects the footplate height adjustment bracket to the front battery door. Torque the
hardware to 25 N • m (18.4 ft • lb).
5. Reverse steps 3 and 4 for installation.
To r que the hardware to
.sMFTsLB
9
Foot Platform removal and installation
1

14
Mobility Products. Ltd.
www.pridemobility.co.uk
VIII. Batteries
1. Turn off power to the joystick.
2. Ensure the unit is in drive mode.
Tools Required:
- Metric Socket Set
- Metric Spanner Set
3. Remove the front battery door. See Section I.
4. Disconnect the quick disconnect harnesses and remove the batteries.
5. Following the battery wiring diagram on the inside of the front battery door and one battery at a time, remove the bat-
tery harness and attach it to the replacement battery.
6. Place the batteries back inside the unit.
7. Reconnect the quick disconnect harnesses and replace the front battery door.
56
4
Battery removal and installation
1

15
Mobility Products. Ltd.
www.pridemobility.co.uk
IX. Joystick
1. Turn off power to the joystick.
2. Ensure the unit is in drive mode.
Tools Required:
- Phillips Screwdriver
- Wire Cutters
3. Disconnect the joystick harness from the bus extension cable that is located near the back of the unit. Cableties may
need to be cut to free the joystick cable.
4. Flip up the armrest and remove the 2 mounting screws on the mounting bracket.
5. Reverse steps 3 and 4 for installation. Replace any cableties.
VR2
Joystick
VR2
Joystick Harness removal and installation Joystick removal and installation
1

16
Mobility Products. Ltd.
www.pridemobility.co.uk
X. Power Module
1. Turn off power to the joystick.
2. Ensure the unit is in drive mode.
Tools Required:
- Phillips Screwdriver
3. Remove the rear electronics door. See Section I.
4. Remove the 2 screws that secure the power module to
the frame.
5. One at a time, disconnect the motor, power, bus, and
PTO/run plug harnesses and connect them to the replace-
ment power module.
6. Reverse steps 3 and 4 to complete installation.
VR2
Left Motor
Right Motor
Power/Battery
Tilt & Recline
Actuators
PTO
Bus Cable
Harness removal and installation
VR2
Power Module Hardware removal and installation
1

17
Mobility Products. Ltd.
www.pridemobility.co.uk
XI. Battery/Power Harness and Circuit Breaker
1. Turn off power to the joystick.
2. Ensure the unit is in drive mode.
3. Disconnect the joystick and all harnesses
that connect to the power base.
Tools Required:
- Phillips Screwdriver
- Wire Cutters
- Imperial and Metric Spanner Set
4. Remove the seat or seating system.
5. Remove the front battery door and the rear electronics
door. See Section I.
6. Disconnect the battery quick disconnect harnesses and
remove the batteries. See Section IX.
7. Remove the top panel and the top shroud. See Section
II.
8. Disconnect the battery harness from the power module.
9. Pull back the boots on the circuit breaker to remove the
2 screws and lock washers that attach the battery harness
to the circuit breaker.
10. Make note of the wiretie locations and cut the wireties
that secure the battery harness to the main frame and the
other harnesses.
11. Route the replacement battery harness through the
centre of the unit and connect to the power module and
the circuit breaker.
12. Apply all replacement wireties
13. Reverse steps 3 to 7 to complete installation.
14. To remove the circuit breaker, unscrew the reset button
cover and disconnect the battery harness from the rear.
See step 9.
To Po w e r
Module
Reset Button
Cover
4
Circuit Breaker Harness removal and installation Cabletie and Harness routing locations
Power/Battery
Harness
R-Net PLPM
or VR2
Battery Harness location at the power module
1

Pride Mobility Products Ltd.
32 Wedgwood Road
Bicester, Oxfordshire OX26 4UL
Telephone: [phone]
Fax: [phone]
Web: www.pridemobility.co.uk
(Image is for illustration purposes only.)
