Pride Mobility Quantum Jazzy 1400 User manual

Owner’s Manual
Unit 106
Heyford Park Camp Road
Upper Heyford, Oxfordshire OX6-3HD
www.pridemobility.com
ATTENTION:
Read everything
in this manual
before operating
your Jazzy

2 www.pridemobility.com Jazzy1400/RevC/Sept02
Copyright © 2001
Pride Mobility Products Ltd.
Please read and follow all instructions in this owner’s manual before attempting to operate your
Power Chair for the first time. If there is anything in this manual you do not understand, or if you
require additional assistance for set-up, contact your local authorized Pride provider.
Using your Pride product safely depends upon your diligence in following the warnings, cautions,
and instructions in this owner’s manual. Using your Pride product safely also depends upon your
own good judgement and/or common sense, as well as that of your provider, caregiver, and/or
healthcare professional. Pride is not responsible for injuries and/or damage resulting from any
person’s failure to follow the warnings, cautions, and instructions in this owner’s manual. Pride is
not responsible for injuries and/or damage resulting from any person’s failure to exercise good
judgement and/or common sense.
Thesymbolsbelowareusedthroughout this owner’smanual toidentify warnings and cautions.It is
very important for you to read and understand them completely.
WARNING! Failure to heed the warnings in this owner’s manual may result in personal injury.
CAUTION! Failure to heed the cautions in this owner’s manual may result in damage to your Power
Chair.
SAFETY GUIDELINES
INFMANU1733

Jazzy1400/RevC/Sept02 www.pridemobility.com 3
CONTENTS
I. INTRODUCTION ........................................................................................................................ 4
II. SAFETY ......................................................................................................................................... 6
III. EMI/RFI .......................................................................................................................................... 8
IV. THE JAZZY 1400.................................................................................................................... 10
V. ASSEMBLY................................................................................................................................. 16
VI. COMFORT ADJUSTMENTS................................................................................................ 18
VII. DISASSEMBLY ......................................................................................................................... 24
VIII.OPERATION............................................................................................................................... 26
IX. BATTERIES AND CHARGING ........................................................................................... 34
X. CARE AND MAINTENANCE ............................................................................................... 39
XI. OPTIONAL ACCESSORIES................................................................................................. 44
XII. WARRANTY............................................................................................................................... 47

4 www.pridemobility.com Jazzy1400/RevC/Sept02
I. INTRODUCTION
Welcome to Pride Mobility Products Ltd (Pride). Congratulations on the purchase of your new Jazzy Power
Chair. The Jazzy 1400 design combines the most advanced state-of-the-art components with modern, attractive
styling. We are certain that the design features and trouble-free operation of your new Jazzy Power Chair will
add convenience to your daily living.
At Pride, your safety is important to us. Please read and follow all of the instructions in this manual before
you attempt to operate your Jazzy forthe first time.These instructions were produced for your benefit.Your
understanding of these instructions is essential for the safe operation of your new Jazzy Power Chair.
Pride is not liable for damage to property or personal injury arising out of unsafe use of a Jazzy Power
Chair. Pride is also not liable for any property damage or personal injury arising out of the failure of any
person and or/user to following the instructions and recommendations set forth in this manual or any other
instructions or recommendations contained in other Jazzy related literature issued by Pride or contained on
the Jazzy Power Chair itself.
This owner’s manual is compiled from the latest specifications and product information available at the time of
publication. We reserve the right to make changes as they become necessary.Any changes to our products may
causeslightvariationsbetweentheillustrationsandexplanationsinthismanualandtheproductyouhadpurchased.
If you experience any problems with your Jazzy that your are unable to solve, or if you do not feel capable of
safely following any of the instructions and/or recommendations as contained in this manual, please contact
your authorised Pride provider for assistance.
Once you understand how to operate and take care of your Jazzy, we are certain that it will give you years of
trouble-free service and enjoyment.
Information Exchange
Wewant to hear your questions, comments,and suggestions about this manual.Wewould also like to hear about
thesafetyand reliabilityof yournewJazzy PowerChair,and abouttheservice youreceived fromyour authorised
Pride provider.
Please notify us of any change of address, so we can keep you apprised of important information about safety,
newproducts,andnewoptions that canincreaseyourabilitytouseand enjoy yourJazzy.Pleasefeelfreetowrite
us at the address below:
Pride Mobility Products Ltd.
Unit 106, Heyford Park Camp Road
Upper Heyford, Oxfordshire OX6 3HD

Jazzy1400/RevC/Sept02 www.pridemobility.com 5
I. INTRODUCTION
Pride Owners Club
As an owner of a Pride product, you are invited to register your product’s warranty and enroll in the Pride
Owners Club. You may do so by filling out and returning your enclosed registration card or by visiting Pride’s
web site at www.pridemobility.com. As a registered member, each time you visit our site, you will have access
to the most interactive and honest educational venue available today for people with mobility needs, their
families and friends.
From our home page, click on the button that reads “Owners Club” to enter a page dedicated to current and
potential Pride product owners. You will gain access to interviews, stories, recreation ideas, daily living tips,
product and funding information, and interactive message boards. On these message boards you are invited to
speak with other Pride customers as well as Pride representatives who are available to assist you with any
questions or concerns you may have. You will receive a free gift simply for registering with the Pride Owners
Club.
My Authorised Pride Provider is:
Name:_______________________________________________________________________________
Address:_____________________________________________________________________________
Phone Number:________________________________________________________________________
Quick Reference Information:
Jazzy Model:__________________________________________________________________________
SerialNumber:__________________________________________________________________________
Purchase Date:________________________________________________________________________
NOTE:If you ever lose or misplace your warranty card or your copy of this manual, email or write to us
and we will be glad to send you a new one immediately.

6 www.pridemobility.com Jazzy1400/RevC/Sept02
II. SAFETY
Your Jazzy 1400 is a state-of-the-art life-enhancement device designed to increase your mobility. There are
certain situations, including some medical conditions, where you will need to practice operating your Jazzy
1400 in the presence of an attendant. Below are some safety tips that are designed to help you become
accustomed to operating your new Jazzy safely.
WARNING:Your Jazzy 1400 is a motorized vehicle. When you are seated on your Jazzy 1400 and
you anticipate that you are going to be in a stationary position for an extended period of time, turn
off the power. This eliminates the possibility of unexpected chair movement and conserves
battery power.
TRANSFERS
Transferring onto and off of your Jazzy 1400 requires a good sense of balance. Be sure to have an attendant
or health care professional present while learning to properly transfer yourself. To eliminate the possibility
of injury, we ask that you verify the following before attempting a transfer:
nBe sure the power is turned off. See VIII. “Operation” in this manual.
nBe sure your Jazzy 1400 is not in freewheel mode. See IV. “The Jazzy 1400” in this manual.
nMake sure the armrests are flipped up or removed from your Jazzy.
nFlip the footrest up, or move the leg rests aside; this will help to keep your feet from “hanging up” on
the footrest or on the leg rests during the transfer.
WARNING:Avoid putting all of your weight on the footrest. This may cause the Jazzy to tip and
cause injury.
MOTOR VEHICLE TRANSPORT
Although your Jazzy may be equipped with a positioning belt, this belt was not designed with the intent of
providing proper restraint during motor vehicle transport.
nIn an effort to improve the safety of its units during motor vehicle transport, Pride has crash-tested
numerousJazzy models. However, since thereare unlimited variations of the Jazzyproduct, all variations
could not possibly be tested. Therefore, Pride recommends that Jazzy power chair users should not be
transported in vehicles of any kind while in power chairs. As of this date, there are no standards
approved for tie-down systems in a moving vehicle of any type to transport a user while in a power chair.
nAlways be sure your Jazzy 1400 is properly secured when it is being transported.
WEIGHT LIMITATIONS
Your Jazzy 1400 is rated for a maximum 180 kg (400 lbs.) weight limit. Exceeding the weight limit voids
your warranty and may result in personal injury.
PUBLIC ROADS AND PARKING LOTS
It may be difficult for motorists to see you when you are seated on your Jazzy 1400. To ensure your safety,
alwaysassumeyoucannotbeseen.Waituntilyourpathis clearoftraffic, andthenproceedwithextreme caution.

Jazzy1400/RevC/Sept02 www.pridemobility.com 7
II. SAFETY
NOTE:Many municipalities have laws concerning operating your powered wheelchair on public roads.
Be sure to check local laws before attempting to do so.
STAIRS AND ESCALATORS
Wheelchairs are not designed to travel up or down stairs or escalators.Always use an elevator. If you try to
negotiate steps or escalators, you can cause injury to yourself and to others.
STEPS AND CURBS
nNever attempt to have your Jazzy 1400 climb or descend a step or a kerb that is higher than four (4)
inches unless you have the assistance of an attendant.
nNever attempt to have your Jazzy 1400 proceed rearwards down any step, kerb, or other obstacle.
Doing so could cause your Jazzy 1400 to tip.
INCLINES AND UNEVEN TERRAIN
When climbing an incline, do not zigzag or drive at an angle up the face of the incline. Drive your Jazzy
straight up the incline. This greatly reduces the possibility of a tip or a fall. Always exercise extreme
caution when negotiating an incline.
nNever travel up or down an incline that can be potentially hazardous (for example, areas covered with
snow, ice, or cut grass).
nWhen climbing an incline, try to keep your Jazzy moving. If you must stop, start up again slowly, and
then accelerate cautiously.
When driving down an incline, do so slowly by setting the throttle control on the slowest setting and
driving in the forward direction only. If your Jazzy 1400 starts to move faster than you anticipated or
desired, allow the chair to come to a complete stop by releasing the joystick; then push the joystick slightly
forward and continue traveling slowly down the incline.
MAXIMUM RECOMMENDED INCLINE
Pride has performed extensive incline testing with the Jazzy 1400. Our results show that the maximum
incline your Jazzy 1400 can safely climb is 8.7 percent at maximum weight capacity. Five degrees is the
angle of most handicap access ramps. Any attempt to climb a steeper slope may put your Jazzy in an
unstable position.
8,7% 8,7%

8 www.pridemobility.com Jazzy1400/RevC/Sept02
III. EMI/RFI
Laboratorytestsperformedby theFoodandDrugAdministration(FDA) haveshownthatradiowavescan cause
unintendedmotionofpowered wheelchairs.Radiowavesarea formofelectromagneticenergy(EM). Whenthis
energyadverselyaffectstheoperationofanelectronicdevice,itiscalledElectromagneticInterference(EMI)
or Radio Frequency Interference (RFI).
WARNING:Radio waves may interfere with the control of powered wheelchairs.
FREQUENTLY ASKED QUESTIONS (FAQS) ABOUT EMI/RFI
The following FAQs summarize what you should know about EMI/RFI. Use this information to minimize
the risk that EMI/RFI will affect your powered wheelchair.
Where do radio waves come from?
Radio waves are emitted from the antennas of cellular phones, mobile two-way radios (such as walkie-
talkies), radio stations,TV stations, amateur radio (HAM) transmitters, wireless computer links, microwave
sources, and paging transmitters. Radio waves are a form of EM. Because electromagnetic energy is more
intense closer to the transmitting antenna (source of emission), the EM fields from two-way radios are of
special concern to powered wheelchair users.
If my powered wheelchair is affected by EMI/RFI, what kind of motion should I expect?
This is hard to predict. It would depend on a number of factors:
nStrength of the radio wave
nConstruction of the powered wheelchair
nPosition of the powered wheelchair (whether it is on level ground or on an incline)
nWhether or not the powered wheelchair is in motion
An affected wheelchair’s movement can be erratic. It may move by itself or come to a sudden stop.
Furthermore, it is possible for EMI/RFI to unexpectedly release the brakes on a powered wheelchair. Some
intense sources of EMI/RFI can even damage the control system of your Jazzy.
Is there any way to know for sure whether radio waves are responsible for the unintended motion
of my powered wheelchair?
Unfortunately, interference from radio wave sources may be difficult to recognize, since the signals from
these sources are invisible and may be intermittent. However, the FDA recommends that you report all
incidents of unintended motion or brake release to the powered wheelchair manufacturer and, if possible,
note whether there was a radio wave source nearby at the time of the incident.
Has anyone been hurt from erratic, unintended motion of powered wheelchairs?
The FDA has reports of injuries that resulted from the apparently uncontrolled motion of powered
wheelchairs. However, it is unclear how many of these incidents were actually caused by radio wave
interference.

Jazzy1400/RevC/Sept02 www.pridemobility.com 9
III. EMI/RFI
Are all powered wheelchairs susceptible to EMI/RFI?
Each make and model of chair differs in its ability to resist electromagnetic interference. That is, each has
a particular level of “immunity” to interference, measured in volts per meter (V/m). A higher immunity
level offers greater protection. In other words, a powered wheelchair that has a high immunity level is less
likely to be affected by a strong radio source than is a powered wheelchair that has a low immunity level.
What is the FDA doing about the problem?
The FDA has written to the manufacturers of powered wheelchairs and requested that they test their new
products to be sure that they provide a reasonable degree of immunity against EMI/RFI. The letter states
that powered wheelchairs should have an immunity of at least 20 V/m. This provides a reasonable degree
of protection against the common sources of EMI/RFI. The Jazzy 1400 meets or exceeds an immunity level
of at least 20 V/m.
The FDA has also requested that these manufacturers clearly label their products with the immunity level,
or state that the immunity level is not known. The labeling and informational material supplied with the
poweredwheelchair must explain whatthe immunity level means, and the labeling or informational material
mustwarnusersabout the possibility of EMI/RFI and how to avoid it.Inaddition,theFDA has recommended
thatmanufacturers establish an educational program toinformpowered wheelchair users and their caregivers
about the problems associated with EMI/RFI, and about the actions that can be taken to minimize the risk
ofEMI/RFI.TheFDArequested that manufacturers of poweredwheelchairs have these actions implemented
by December 2, 1994.
What can I do to find out if my powered wheelchair is likely to be affected by EMI/RFI?
If you’ve had your powered wheelchair for a long time and haven’t experienced any unintended motion, it
is not likely that you will have problems in the future. Nevertheless, it is always possible that problems
couldariseifyouareclose to a sourceofradiowaves.Therefore,itisveryimportanttobealertto this possibility.
What can I do to reduce the risk that my powered wheelchair could be affected by EMI/RFI?
Here are some precautions you can take:
nDo not turn on or use hand-held personal communications devices such as citizens band (CB) radios
and cellular phones, while the powered wheelchair is on.
nBe aware of nearby transmitters (such as radio or TV stations and hand-held or mobile two-way radios)
and try not to come close to them. For example, if you are in a powered wheelchair with an immunity
level of 20 V/m, you should remain at least three feet from a hand-held two-way radio and ten feet from
a mobile two-way radio.
nBe aware that adding accessories and/or components, or modifying the powered wheelchair, may make
it more susceptible to interference from radio wave sources. There is no easy way to evaluate their
effect upon the overall immunity of the powered wheelchair.
What should I do if my powered wheelchair moves unexpectedly?
If unintended motion or brake release occurs, turn the powered wheelchair off as soon as it is safe to do so.
If my powered wheelchair moves unexpectedly, where should I report this?
Call Pride at [phone] to report the incident.

10 www.pridemobility.com Jazzy1400/RevC/Sept02
Figure 1.The Jazzy 1400
REARCASTER
WHEEL
JOYSTICKCONTROLLER
ANTI-TIPWHEEL
DRIVEWHEEL
SEATBACK
ARMRESTS
BODYSHROUD
POWERBASEASSEMBLY
SEATASSEMBLY
IV. THE JAZZY 1400
YourJazzy1400hastwomainassemblies: the seat and thepowerbase.Seefigures1and2.Thereisavarietyof
seatingoptionsthataredesignedtoaccommodatemostusers.Typically,theseatingassemblyincludesthearmrests,
theseatback,theseatbase,andthejoystickcontroller.Your Jazzyseatmayalsohavesomeoptionalaccessories
attached to it such as a basket, a cane/crutch holder, a cup holder, or a power seat switch. See XI. “Optional
Accessories”inthismanual.
The power base is the heart of your Jazzy 1400. The power base assembly includes a frame, two drive
wheels, two anti-tip wheels, two rear caster wheels, harness connectors,and a body shroud. See figure 2 for
a full rear view.

Jazzy1400/RevC/Sept02 www.pridemobility.com 11
IV. THE JAZZY 1400
Figure 2. Rear View
Figure 3. Remote Plus Controller Connector Figure 4. Europa Remote Controller Connector

12 www.pridemobility.com Jazzy1400/RevC/Sept02
Specifications
Suspension: FullsuspensionwithActive-Trac
Rear Suspension
DriveWheels: 36 cm (14in.),pneumatic(solidtyresare optional)
CastersWheels: 20cm(8 in.),solid,reararticulating
Anti-tipWheels: 15 cm (6 in.),solid,front mounted
Maximum Speed: 7.2 km/h (4.5 mph)
Brakes: “Intelligent Braking,” electronic regenerative, disc park brake
GroundClearance: 7.5cm(3in.)
TurningRadius: 54.5 cm(21.5 in.)
OverallSize: Length: 103cm(40.5in.)
Width:65cm(25.4in.)
SeatingOptions: Euro Seat
VersaTilt
Medium-BackSeat
High-Back Seat
Reclining Seat
PowerElevatingOption
Drivetrain: Two motor, mid-wheel
Batteries: Two 12-volt, Group 24 batteries (NF-22 batteries for the power
seat option)
Range: Up to 40 km (25 miles)
BatteryCharger: 5-amp Onboard
5-ampoff-board(optional)
Electronics: 70-amp P & G Remote Plus Controller
70-amp Dynamic Europa Remote Controller
WeightCapacity: 180 kg/400 lbs./28 Stone
(146kg/325lbs./23 Stone w/hi-speed motors)
ComponentWeights: Base: 58 kg (128 lbs.)
Seat: 20 kg (29 lbs.)
Batteries:24kg (53.5 lbs. each
Warranty: Lifetimelimitedwarrantyonframe
Two-year warranty on electronics
Eighteen-month warranty on drive motors
IV. THE JAZZY 1400

Jazzy1400/RevC/Sept02 www.pridemobility.com 13
UTILITY TRAY
The utility tray is located on the rear of your Jazzy 1400. See figure 5. A section of the utility tray is
exposed through the body shroud. The utility tray consists of the ammeter, the battery charger lead, charger
fuses, the main circuit breaker, light connectors (optional equipment), and the controller connectors. See
figures 3 through 5.
nAmmeter:The ammeter displays the charger’s current
outputinamps.Formoreinformation,seeIX.“Batteries
and Charging” in this manual.
nBattery charger lead: This is the AC power lead for
the battery charger.
nMain circuit breaker: This is a safety feature built
intoyourJazzy 1400.Whenthe batteries and the motors
are heavily strained (e.g., from excessive loads), the
main circuit breaker will trip to prevent damage to the
motors and to the electronics. If the circuit trips, allow
your Jazzy to “rest” for approximately one minute.
Then, push in the circuit breaker button, turn on the
joystick controller, and continue normal operation. If
the main circuit breaker continues to trip repeatedly,
contact your authorised Pride provider.
nController harness connectors: This is where the
joystick connects to the motors, batteries, and charger.
Your Jazzy is equipped with a Remote Plus or Europa Remote controller. See figures 3 and 4.
nOptional lighting harness connector: This is where the optional lighting harness connects to the
controller. If a full lighting package is used, an additional 4-pin plug is located in the rear utility tray.
nOptional power seat connector: This is for the power seat switch.
FREEWHEEL LEVERS
For your convenience, your Jazzy 1400 is equipped with one freewheel lever. See figures 6 and 7. This
lever allows you to disengage the drive motors and maneuver the chair manually.
WARNING:DO NOT use your Jazzy 1400 while the drive motors are disengaged unless you are in
the presence of an attendant. DO NOT disengage the drive motors when your Jazzy 1400 is on an
incline. The chair could roll down on its own, causing injury!
IV. THE JAZZY 1400
MAINCIRCUIT
BREAKER
Figure 5. UtilityTray
BATTERY
CHARGERLEAD AMMETER

14 www.pridemobility.com Jazzy1400/RevC/Sept02
IV. THE JAZZY 1400
To put the Jazzy 1400 in freewheel mode:
At the top of the freewheel/drive-motor lever is a release switch. To lift the freewheel/drive-motor lever,
hold the lever while pressing the release switch with your thumb. Lift up on the lever. If the lever is
difficult to move, rock your Jazzy back and forth slightly. The lever should then move to the desired
position. With the lever in the raised position, let go of the release switch. The Jazzy is now in freewheel
mode. See figure 6.
To engage the drive motors:
Push down on the freewheel/drive-motor lever until it locks into place in the lowered position. The release
switch at the top of the lever will “click” and lock the lever in place. The drive motors on the Jazzy are now
engaged. See figure 7.
NOTE:It is important to remember that when your Jazzy 1400 is in freewheel mode, the braking system is
disengaged.
If a lever is difficult to move in either direction, rock your Jazzy 1400 back and forth slightly. The lever
should then move to the desired position.
Figure 6. Freewheel Mode Figure 7. Drive Motors Engaged
LEVERUP LEVERDOWN

Jazzy1400/RevC/Sept02 www.pridemobility.com 15
IV. THE JAZZY 1400
ACTIVE-TRAC SYSTEM
Your Jazzy 1400 is equipped with an Active-Trac System (ATS). ATS is a suspension system designed to
make your Jazzy traverse different types of terrain and obstacles while maintaining smooth operation.With
ATS, the front anti-tip wheels work in conjunction with the motor suspension to help you maneuver over
obstacles in excess of three (3) inches in height.
As the front anti-tip wheels come in contact with an obstacle, the front anti-tip wheel assembly is drawn
upward while the motor suspension is moved downward. This reduces the possibility of the Jazzy 1400
becoming “hung up.”
ATS also helps in normal operating conditions. For instance, when you release the joystick, your Jazzy
begins to slow down.As your Jazzy slows, the front anti-tip wheels automatically lower toward the ground.
This reduces the forward tip that typically happens when center-wheel-drive chairs slow and come to a stop.
REAR SUSPENSION
Your Jazzy is equipped with Rear Suspension. See figure 8. This suspension system works in conjunction
with the ATS and is also designed to maintain a smooth ride when driving over rough terrain and up and
down kerbs. This system works by allowing the caster forks to respond to weight transfers and abrupt
terrain. The rear caster wheels will pivot as you drive over obstacles. This system also compensates for the
lowering of the front anti-tip wheels.
Figure 8. Rear Caster Beam

16 www.pridemobility.com Jazzy1400/RevC/Sept02
V. ASSEMBLY
VERSA SEAT ASSEMBLY
The Versa Seat is standard equipment on the Jazzy 1400. For assembly, please refer to the instruction
manual supplied with the Versa Seat.
OPTIONAL SEATING ASSEMBLY
To reduce the possibility of shipping damage, some Jazzy 1400 seats are removed from the power base, and
the seat-backs are removed from the seat assemblies before the Jazzy is shipped. The joystick may also be
removed from the armrest. The following is a set of instructions to help you quickly and easily prepare your
Jazzy 1400 for use.
Parts List Quantity
Figure 9. Seat-Back Assembly
Figure 10. RearTowers
SLIDESEAT
ONTOTOWERS
ATTACH
SEAT-BACK
HERE
Phillips-headseat-backmounting screws 4
Seat-back 1
20-cm wire ties 4
NOTE:Because of the variety of optional seating configurations,
the Jazzys in the assembly photographs may differ slightly from the
product you purchased.
SEAT-BACK ASSEMBLY
The seat-back mounts to the back hinges with four (4) Phillips-head
screws. You may install the seat-back before or after you install the
seat to the power base.
To mount the seat-back to the hinge:
1. Line up the hinges with the holes in the seat-back. See figure 9.
2. Insert the seat-back mounting screws through the hinge and into
the seat-back.
3. Use a Phillips screwdriver to tighten the four screws.
SEAT INSTALLATION (SEAT WITH H-FRAME)
The standard seat installation method incorporates the seat frame (H-
frame) and four (4) adjustable seat posts located on the power base.
To install the seat:
1. Position the seat on the rear seat towers. See figure 10.
2. Push the seat back and down until the latches engage on the front
seat towers. See figure 11.
3. Plug the controller cable into the connector on the utility tray.
See figure 12.

Jazzy1400/RevC/Sept02 www.pridemobility.com 17
Figure 11. Front SeatTowers
LOCKSEAT INTO
PLACEHERE
Figure 12. Controller Cable
Figure 14. Power Seat Actuator
(Shroud and Batteries Removed for Clarity)
POWERSEATACTUATOR
Figure 13.Joystick
SLIDEJOYSTICKINTOBRACKET
SETSCREW
V. ASSEMBLY
4. Plug thepowerseatswitchcable (ifsoequipped)into the
connectorontheutilitytray.
5. Secure the controller cable to the armrest receiver with
one or more wire ties.
6. Route the cable to ensure that the cable cannot be
pinched in the seat hinge.
JOYSTICK INSTALLATION
Depending on the various configurations and options you
have chosen for your Jazzy, it may have been shipped
without the Remote Plus joystick installed in the armrest.
To install the joystick:
1. Use a 3/16-in. hex key to loosen the setscrew. See
figure 13.
2. Slide the joystick mounting bracket into the armrest,
to the desired position.
3. Retighten the setscrew by turning it clockwise.
POWER SEAT OPTION INSTALLATION
Your Jazzy may be equipped with the power seat option.
While the seat itself may be any one of the styles offered
for this model, the way the seat base attaches to the Jazzy
power base is different.
To install the power seat:
l. Align the seat shaft to the hole in the actuator. See
figure 14.
2. Rotatetheseattotheforwardpositionuntilitlockstightly.
PLUGINCONTROLLER
CABLEHERE

18 www.pridemobility.com Jazzy1400/RevC/Sept02
VI. COMFORT ADJUSTMENTS
AfterbecomingfamiliarwithyourJazzy’soperation,youmayfindtheneedtomakesomeadjustmentstoincrease
yourcomfort,such asseatheightand angle,armrestheightand angle,footrestheightandangle,andthejoystick’s
position.
CAUTION:If your Jazzy 1400 was configured at your Pride provider or service center, please
consult your health care professional before changing the seat position or making any other
adjustment. Someadjustments maydegrade yourJazzy’sperformanceandsafety bychangingits
center of gravity.
SEAT HEIGHT AND ANGLE
If your Jazzy 1400 is equipped with the standard Versa Seat, refer to the “Versa Seat Adjustment and
Installation Guide.” If your Jazzy is equipped with optional seating, refer to the following information.
To change the seat height:
1. Remove the seat. See VII. “Disassembly” in this manual.
2. Remove the ball detent pin from each seat tower. See
figure 15.
3. Raise or lower each seat tower to the desired position.
4. Install the ball detent pin into each seat tower.
5. Install the seat.
To change the seat angle:
Raise or lower only the front or only the rear seat towers.
NOTE:We suggest setting the rear towers one notch lower
than the front towers to enhance the performance of your
Jazzy 1400.
ARMREST WIDTH (OPTIONAL)
(MEDIUM AND HIGH-BACK ONLY)
To change the armrest width:
1. Locate the two knobs on the armrest receiver bracket.
See figure 16.
2. Loosen the knobs and slide the armrests in or out to the
desired width.
3. Tighten the knobs.
LOOSENKNOBTO
MOVEARMREST
Figure 15. SeatTower Pin (Optional)
SEATTOWERPIN
Figure 16. ArmrestWidth (Optional)

Jazzy1400/RevC/Sept02 www.pridemobility.com 19
Figure 19. Swing-Away Joystick
(Forward Position)
Figure 20. Swing-Away
Joystick (Retracted Position)
Figure 17. Armrest Angle
Adjustment
TURNTHISSCREWTOCHANGEARMRESTANGLE
Figure 18. Joystick Extension
LOOSEN THISSETSCREW
TOADJUSTJOYSTICK
LOCKINGNUT
LOCKS
ADJUSTMENT
SCREWIN
PLACE
VI. COMFORT ADJUSTMENTS
ARMREST ANGLE
(MEDIUM/HIGHBACK/RECLINER)
You can adjust the armrest angle to fit your specific needs. See
figure 17.
To change the armrest angle:
1. Lift the armrest straight up so that it is perpendicular to the
floor.
2. Use a 7/16-in. spanner to loosen the locking nut. See figure
17.
3. Use a 5/32-in. hex key to loosen the adjusting screw.
4. Turn the screw clockwise to raise the front of the armrest, or
turnthescrewcounterclockwise tolowerthefrontofthe armrest.
5. Lock the adjusting screw into place by tightening the locking
nut.
ARMREST HEIGHT (OPTIONAL)
Your Jazzy may be equipped with height-adjustable armrests.
To change the armrest height:
1. Remove the ball detent pin from the armrest.
2. Move the armrest up or down to the desired height.
3. Align the holes and insert the ball detent pin.
4. For permanent positioning, tighten the setscrew.
JOYSTICK EXTENSION
The joystick control can easily slide out away from the armrest, or
in toward the armrest. See figure 18.
To extend the joystick:
1. Use a 3/16-in. hex key to loosen the setscrew.
2. Slide the joystick mounting bracket into or out of the armrest
to the desired position.
3. Tighten the setscrew by turning it clockwise.
SWING-AWAY JOYSTICK
Your Jazzy may be equipped with a swing-away joystick. This
option enables you to move the joystick from the front of the
armrest to the side of the armrest without disconnecting it. See
figures 19 and 20.

20 www.pridemobility.com Jazzy1400/RevC/Sept02
VI. COMFORT ADJUSTMENTS
FOOTREST HEIGHT (OPTIONAL)
The footrest height is easily adjusted to one of six different
heights, in 2.54-cm increments.
To raise or lower the footrest:
1. Remove the 3/8-in. bolt and nut from the footrest. See figure 21.
2. Raise or lower the footrest to the desired height.
3. Install the 3/8-in. bolt and nut into the footrest and tighten.
FOOTREST ANGLE (OPTIONAL)
You can adjust the angle of the footrest with a 3/16-in. hex
spanner. See figure 22.
To adjust the footrest angle:
1. Turn the setscrew clockwise to raise the front of the footrest.
2. Turn the setscrew counterclockwise to lower the front of the
footrest.
SWING-AWAY FOOTRESTS (OPTIONAL)
Swing-awayFootrests(SFRs)areanoption.Theyenableyoutomove
the leg rest to the side before you transfer on or off of your Jazzy.
To move the SFRs:
1. Push in the release lever. See figure 23.
2. Move the SFRs.
ELEVATING LEG RESTS OPTION
ElevatingLeg Rests (ELRs) offeraninfinite range of adjustment
for the leg angle and a footrest adjustment range of 30–48 cm.
To adjust the ELR angle:
1. Press the release lever. See figure 24.
2. Move the leg rest to the desired angle.
To adjust the ELR leg rest height:
1. Remove the two screws from the side of each leg rest
extension. See figure 25.
2. Loosen the bolt on the side of each leg rest extension.
3. Slide the leg rest in or out to the desired length.
4. Tighten the bolt and reinstall the two screws.
Figure 21. Footrest Height
REMOVETHISNUT AND BOLT TO
RAISEOR LOWER THEFOOTREST
Figure 22. Footrest Angle
TURNTHISSETSCREW TO
CHANGEFOOTRESTANGLE
Figure 23. Swing-Away Footrests
SFRRELEASELEVER
