Pride Mobility Quantum 600 SERIES User manual

QUANTUM
SERIES
Including Model: Quantum 600
32 Wedgwood Road • Bicester, Oxon OX26 4UL

SAFETY GUIDELINES
Copyright©2008
PrideMobilityProductsLtd.
INFMANU2979/RevD/February2008
QuantumRehab Dealer:_____________________________________________________________________
Address:________________________________________________________________________________
Phone Number:___________________________________________________________________________
PurchaseDate:____________________________________________________________________________
NOTE: This owner’s manual is compiled from the latest specifications and product information available
at the time of publication. We reserve the right to make changes as they become necessary. Any changes to
our products may cause slight variations between the illustrations and explanations in this manual and the
product you have purchased. The latest/current version of this manual is available on our website.
Thesymbolsbelowareusedthroughoutthisowner'smanualandonthe power chair to identify warningsandimportant
information.Itisveryimportantforyou toreadthem andunderstandthem completely.
WARNING! Indicates a potentially hazardous condition/situation. Failure to follow designated
procedures can cause either personal injury, component damage or malfunction. On the product,
this icon is represented as a black symbol on a yellow triangle with a black border.
MANDATORY! These actions should be performed as specified. Failure to perform mandatory
actions can cause personal injury and/or equipment damage. On the product, this icon is
represented as a white symbol on a blue dot with a white border.
PROHIBITED! These actions are prohibited. These actions should not be performed at any time or
in any circumstances. Performing a prohibited action can cause personal injury and/or equipment
damage. On the product, this icon is represented as a black symbol with a red circle and red
slash.
Quick Reference Information
088 609 661
WARNING! A Quantum Rehab Dealer or a qualified technician must perform the initial setup of
this power chair and must perform all of the procedures in this manual.

Quantum 600 www.quantumrehab.com 3
I. INTRODUCTION..................................................................................................................................... 4
II. SAFETY..................................................................................................................................................... 5
III. YOUR POWER CHAIR........................................................................................................................ 17
IV. ASSEMBLY............................................................................................................................................. 21
V. COMFORT ADJUSTMENTS............................................................................................................ 23
VI. BATTERIES AND CHARGING ........................................................................................................ 29
VII. CARE AND MAINTENANCE ............................................................................................................ 33
VIII.WARRANTY............................................................................................................................................ 39
CONTENTS
APPENDIX I - SPECIFICATIONS ........................................................................................................... 40

4 www.quantumrehab.com Quantum 600
I. INTRODUCTION
SAFETY
WELCOMEtoQuantumRehab,adivisionofPrideMobilityProductsCorporation(Pride).The power chair you have
purchased combines state-of-the-artcomponents with safety,comfort and styling in mind.Weare confidentthat these
designfeatureswillprovideyouwith theconveniences youexpectduringyourdailyactivities.Once youunderstandhow
to safelyoperate and care for yourpower chair,it should give you years of trouble free operationand service.
Readand followallinstructions, warningsandnotes inthismanual beforeattemptingtooperateyourpowerchairfor the
firsttime.Youmustalsoreadallinstructions,warningsandnotescontainedinany supplementalinstructional bookletsfor
thecontroller,frontriggingsand/orseatingsystemthataccompaniedyourpowerchairbeforeinitialoperation.Your safety
dependsupon you, as wellasyourdealer, carer orhealthcareprofessionalin using good judgement.
Ifthereisanyinformationin this manual which you do not understand, or if yourequire additional assistance for setup
or operation, please contact your Quantum Rehab Dealer. Failure to follow the instructions in this manual and
those located on yourpower chair can lead to personal injury and/or damage to the powerchair, including
voidingthewarranty.
PURCHASER’S AGREEMENT
Byaccepting delivery of this product,you promise thatyou will notchange, alter ormodify thisproduct or removeor
renderinoperableorunsafe anyguards,shields orothersafety featuresofthis product;fail,refuseorneglecttoinstallany
retrofitkitsfrom time to time provided by Pride to enhance or preserve the safe use ofthisproduct.
SHIPPING AND DELIVERY
Beforeusing yourpowerchair,makesure yourdeliveryis completeassome componentsmaybeindividually packaged.
Ifyoudo not receive a complete delivery,pleasecontactyourQuantumRehabDealerimmediately. Where damagehas
occurredduring transport, eithertothepackagingor content, pleasecontactthedeliverycompany responsible.
INFORMATION EXCHANGE
Wewanttohearyourquestions,commentsand suggestionsabout thismanual.We wouldalso liketohearaboutthesafety
andreliability ofyournewpower chair,and about theserviceyou received fromyourQuantumRehab Dealer.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
productsand newoptionsthat canincreaseyour ability touseand enjoyyourpower chair.Pleasefeel freetocontactus at
theaddress below:
PrideMobility ProductsLtd.
32 Wedgwood Road
Bicester, Oxon OX26 4UL
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.

Quantum 600 www.quantumrehab.com 5
II. SAFETY
PRODUCT SAFETY SYMBOLS
Thesymbols belowareused onthepower chairtoidentifywarnings, mandatoryactionsand prohibitedactions.It isvery
importantfor youtoreadand understand themcompletely.
Read and follow the information in the owner’s manual.
Maximum seating weight.
Do not use a cell phone, walkie/talkie, laptop or other radio transmitter while operating.
Avoid exposure to rain, snow, ice, salt or standing water whenever possible. Maintain and
store in a clean and dry condition.
Do not allow unsupervised children to play near the power chair while the batteries are
charging.
Keep your hands away from the tyres when driving. Be aware that loose fitting clothing
can become caught in drive tyres.
Use correct tie-down points for controller harness to prevent the harness from getting
caught in the drive tyres, pinched in the seat frame or damaged when passing through
doorways.

6 www.quantumrehab.com Quantum 600
Removal of grounding prong can create electrical hazard. If necessary, properly install
an approved 3-pronged adapter to an electrical outlet having 2-pronged plug access.
Do not connect an extension lead to the AC/DC converter or the battery charger.
II. SAFETY
Do not lift the mobility product while seated in it.
Corrosive chemicals contained in battery.
Do not lift the mobility product while seated in it.
Wear safety goggles.

Quantum 600 www.quantumrehab.com 7
II. SAFETY
Use only AGM or Gel-Cell batteries to reduce the risk of leakage or explosive conditions.
Do not connect an extension lead to the AC/DC converter or the battery charger.
Do not use batteries with different amp-hour (Ah) capacities. Do not mix old and new
batteries. Always replace both batteries at the same time.
Battery Set Configuration:
+ = Positive (Red) Terminal Post
– = Negative (Black) Terminal Post
Connect Red wires to Red Positive (+) Terminal Posts
Connect Black wires to Black Negative (–) Terminal Posts
Explosive conditions exist!
This product has been tested and passed at an immunity level of 20 V/m.

8 www.quantumrehab.com Quantum 600
Disposal and recycling - Contact your Quantum Rehab Dealer for information on proper
disposal and recycling of your Pride product and its packaging.
Locked and in drive mode.
Place unit on level ground and stand to one side when changing from drive mode to
freewheel mode or freewheel mode to drive mode.
Unlocked and in freewheel mode.
Battery charger for indoor use only.
Do not place your power chair in freewheel mode while on a decline.
Contains Lead.
Do not place your power chair in freewheel mode while on an incline.

Quantum 600 www.quantumrehab.com 9
II. SAFETY
GENERAL GUIDELINES
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchair isastate-of-the-art life-enhancementdevicedesignedtoincrease mobility.Prideprovides anextensive
varietyof products tobest fitthe individualneeds ofthe powerchair user. Pleasebe awarethatthe final selection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableof makingsuchadecision, andhis/herhealthcareprofessional (i.e.,medicaldoctor, physicaltherapist,etc.).
Thecontents ofthismanualare basedontheexpectation thatamobilitydevice experthasproperlyfitted thepowerchair
totheuserandhasassistedtheprescribinghealthcareprofessionaland/ortheQuantumRehabDealerintheinstruction
processfor the use of theproduct.
Therearecertain situations,includingsomemedicalconditions,wherethepowerchair userwillneedtopracticeoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubegin usingyour powerchairduringdailyactivities,youwillprobablyencountersituationsinwhichyouwillneed
somepractice. Simplytakeyourtime and youwillsoon be infullandconfident controlasyoumanoeuvre through door-
ways,onandoffoflifts,up and down ramps and over moderate terrain.
Belowaresomeprecautions,tipsand othersafety considerationsthatwillhelpyoubecomeaccustomed tooperatingyour
powerchairsafely.
Modifications
Pridehasdesignedandengineeredyourpowerchairtoprovide maximummobilityandutility.Awiderangeofaccessories
is available from your Quantum Rehab Dealer to further customise your power chair to better suit your needs and/or
preferences.However,under nocircumstancesshouldyoumodify, add,removeordisableany feature,partorfunctionof
yourpower chair.
WARNING! Do not modify your power chair in any way not authorised by Pride. Do not use
accessories if they have not been tested or approved for Pride products.
Pre-Ride Safety Check
Gettoknowthefeelofyourpowerchairanditscapabilities.Priderecommendsthatyouperformasafetycheckbefore
eachusetomakesureyourpower chair operates smoothly and safely.
Performthefollowinginspections prior to using your power chair:
!Check for proper tyre inflation. Maintain but do not exceed 2.4 bar(35 psi,240kPa) in each tyre if equipped
withpneumatictyres.
!Checkall electrical connections. Make sure they are tight and not corroded.
!Checkallcontrollerconnections to the power base. Make sure they aresecured properly.
!Checkthe brakes. See VII. “Care andMaintenance.”
!Checkbattery charge. See VI. “Batteries and Charging.”
NOTE: If you discover a problem, contact your Quantum Rehab Dealer for assistance.

10 www.quantumrehab.com Quantum 600
II. SAFETY
Weight Limitations
Yourpower chairisrated foramaximum weightcapacity.Please refertothe specificationstableforthis limit.
MANDATORY! Stay within the specified weight capacity of your power chair. Exceeding the weight
capacity voids your warranty. Pride will not be held responsible for injuries and/or property damage
resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may affect the centre of gravity, resulting in a tip or a fall.
Tyre Inflation
Ifyourpowerchair isequippedwithpneumatictyres,youshould checkorhavetheair pressurecheckedregularly. Proper
inflationpressures willprolongthe lifeofyour tyresandhelp ensurethesmooth operationofyourpower chair.
WARNING! It is important that 2.4 bar (35 psi, 240 kPa) tyre pressure be maintained in pneumatic
tyres at all times. Do not underinflate or overinflate your tyres. Low pressure may result in loss of
control, and overinflated tyres may burst. Failure to maintain 2.4 bar (35 psi, 240 kPa) tyre pressure
in pneumatic tyres at all times may result in tyre and/or wheel failure.
WARNING! Inflate your power chair drive tyres from a regulated air source with an available
pressure gauge. Inflating your tyres from an unregulated air source could overinflate them, resulting
in a burst tyre.
Incline Information
Moreandmorebuildingshaverampswithspecified degreesofinclination,designedforeasyandsafeaccess.Someramps
mayhave turning switchbacks(180-degreeturns)that require youtohavegood cornering skillsonyour power chair.
!Proceedwithextreme caution as you approach the downgrade of a ramp or other incline.
!Takewideswings withyour powerchair’sfront wheelsaroundanytightcorners.Ifyou dothat,thepowerchair’srear
wheelswill follow a widearc,notcut the corner short,andnotbumpinto or get hunguponany railing corners.
!When driving down a ramp, keep the power chair’s speed adjustment set to the slowest speed setting to ensure a
safelycontrolleddescent.
!Avoid sudden stops and starts.
Whenclimbingan incline,trytokeepyourpowerchairmoving.Ifyoumust stop,startupagainslowlyandthenaccelerate
cautiously.When driving down an incline, set your power chair to the slowest speed setting and drive in the forward
directiononly. Ifyourpower chairstartstomove downtheinclinefaster thanyouanticipatedor desired,allowit to come
toa complete stopbyreleasingthe joystick, thenpushthejoystick forward slightlytoensurea safely controlleddescent.
WARNING! When on any sort of an incline or decline, never place the power chair in
freewheel mode while seated on it or standing next to it.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of
the incline. Drive your power chair straight up the incline. This greatly reduces the
possibility of a tip or a fall. Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas
covered with snow, ice, cut grass or wet leaves).
WARNING! Never travel down an incline rearward. Doing so may cause the power
chair to tip. Always exercise extreme caution when negotiating an incline.
WARNING! If your power chair is equipped with a reclining seatback, do not attempt
to negotiate inclines with the seat in a reclined position. Do not attempt to negotiate
obstacles with the seat in a reclined position unless an attendant is present to help
stabilise the chair. Failure to heed may result in the power chair tipping over.

Quantum 600 www.quantumrehab.com 11
II. SAFETY
Figure 1. Maximum Safe Slope (Ascending and Descending)
8.7% (5 )
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated
in figure 1, do not, under any circumstances, exceed the incline guidelines or any other
specifications presented in this manual. Doing so could cause instability in your power chair.
Priderecommendsthatthemaximumslopeofaninclineyouattempttosafelyascendordescendonyourpowerchairdoes
notexceed 8.7% (5°). Seefigure 1.
WARNING! Any attempt to climb or descend a slope steeper than 8.7% (5°) may put your power
chair in an unstable position and cause it to tip.
Freewheel Mode
Yourpower chairisequipped withtwomanual freewheelleversto allowformanual manoeuvreabilitybya trainedatten-
dant.Formore information about how to placeyour power chair intoand out of freewheelmode, see III. “YourPower
Chair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present.
WARNING! Do not attempt to personally place your power chair in freewheel mode
while seated on it. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline or
decline. This could cause the chair to roll uncontrollably on its own.
Braking Information
Your power chair isequippedwith two powerful brakesystems:
!Regenerative— useselectricityto rapidly slowthevehicle whenthejoystickreturns tothecentre/stop position.
!DiscParkBrake—activatesmechanicallyafterregenerative brakingslowsthevehicletonearstop,orwhen poweris
removedfrom the systemforanyreason.
Cornering Information
Whileyour power chair is equippedwithfrontandrearcastor wheels, excessively high corneringspeedscanstillcreate
thepossibilityof tipping. Factors which affect the possibility of tipping include, but are not limited to: cornering speed,
steeringangle (how sharply you areturning), uneven roadsurfaces, inclinedroad surfaces, ridingfrom an areaof low
tractionto an area ofhigh traction(such as passingfrom agrassy areato a pavedarea –especially athigh speedwhile
turning)and abrupt directional changes. High cornering speeds are not recommended. If you feel that you may tip over
in a corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your power chair
fromtipping.
WARNING! When cornering sharply, reduce your speed and maintain a stable centre of gravity.
This greatly reduces the possibility of a tip or fall. Always exercise common sense when
cornering.

12 www.quantumrehab.com Quantum 600
II. SAFETY
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware that it
may be difficult for traffic to see you when you are seated on your power chair. Obey all local pedestrian
traffic rules. Wait until your path is clear of traffic, and then proceed with extreme caution.
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete,blacktopor tarmac.However,Priderecognises thattherewillbetimes whenyouwillencounterother surface
types.Forthisreason,yourpowerchairis designedto performadmirablyonpackedsoil,grassandgravel.Feel freeto use
yourpowerchairsafely on lawns and in park areas.
!Reduceyour power chair’s speedwhendrivingon uneven terrainand/orsoftsurfaces.
!Avoidtallgrassthat canentangle therunninggear.
!Avoid loosely packed gravel and sand.
!Ifyou feelunsureabout adrivingsurface, avoidthatsurface.
Inclement Weather Precautions
Exposureof yourpowerchair to inclementweatherconditions shouldbeavoidedwhenever possible.Ifsuddenly caught
up in rain, snow, severe cold or heat while operating your power chair, proceed to shelter at the earliest opportunity.
Thoroughlydry yourpowerchair beforestoring,chargingor operatingyourpower chair.
PROHIBITED! Operating in rain, snow, salt, mist/spray conditions and on icy/slippery surfaces can
have an adverse affect on the electrical system. Maintain and store your power chair in a dry and
clean condition.
WARNING! Prolonged exposure to hot or cold conditions may affect the temperature of upholstered
and non-upholstered items on the power chair, possibly resulting in skin irritation.Exercise caution
when using your power chair in extremely hot or cold conditions or when exposing your power
chair to direct sunlight for prolonged periods of time.
Stationary Obstacles (Steps, Kerbs, etc.)
Proceedwithextreme caution when driving near raised surfaces, unprotectedledges and/or drop-offs (kerbs, porches,
stairs,etc.).Besure yourpowerchairistraveling perpendiculartoanykerbyou mayberequiredtonavigate. Seefigure2.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than 5 cm (2 in.) unless you have the assistance of an attendant.
WARNING! If your power chair is equipped with a kerb climber, do not attempt to climb any kerb
in excess of 5 cm (2 in.) in height. Do not approach kerbs at an angle; instead approach any kerb
you intend to ascend or descend in the forward position.
WARNING! Do not attempt to have your power chair proceed rearward down any step, kerb or
other obstacle. This may cause the power chair to tip.
KERB
KERB
Figure 2. Correct Kerb Approach Figure 3. Incorrect Kerb Approach

Quantum 600 www.quantumrehab.com 13
II. SAFETY
Stairs and Escalators
Powerchairsarenotdesignedtotravelupor down stairs or escalators.Always use a lift.
WARNING! Never use your power chair to negotiate steps or escalators.
Doors
!Determineifthe door opens toward or away from you.
!Driveyourpowerchairgentlyandslowlyforwardtopushthedooropen.Or driveyour powerchairgentlyandslowly
rearwardto pull the door open.
Lifts
Modernlifts have a dooredgesafetymechanismthat, when pushed, reopens theliftdoor(s).
!Ifyouareinthe doorway of a lift when the door(s) begin toclose, push on the rubber door edgeor allow the rubber
dooredge to contact the powerchair and thedoor will reopen.
!Usecarethat handbags, packages or power chair accessories donot become caught in liftdoors.
Lift/Elevation Products
Ifyouwillbetravelingwith yourpowerchair,you mayfind itnecessarytousea lift/elevationproduct toaidintransporta-
tion.Priderecommends that you closely reviewthe instructions, specifications andsafety information set forthby the
manufacturerofthelift/elevationproductbeforeusingthatproduct.
WARNING! Never sit on your power chair when it is being used in connection with any
type of lift/elevation product. Your power chair was not designed with such use in mind
and any damage or injury incurred from such use is not the responsibility of Pride.
Motor Vehicle Transport
Priderecommends thatyoudo notremainseated in yourpowerchair whiletravelingin amotorvehicle.The powerchair
shouldbe stowed in the bootof a caror in theback of atruck orvan with batteriesremoved and properlysecured.
WARNING! Do not sit on your power chair while it is in a moving vehicle.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Batteries should be secured in an upright position and protective caps should be
installed on the battery terminals. Batteries should not be transported with any flammable or
combustible items.
Positioning Belts
Your authorised Quantum RehabDealer, therapist(s) and otherhealthcareprofessionalsare responsible for determining
yourrequirementforapositioningbeltinordertooperateyourpowerchair safely.Typically,thepositioningbeltisnot
designedfor useasa restraining deviceina motorvehicle.
Positioningbeltsshouldbeinstalled as detailed in this manual. See V. “ComfortAdjustments.” Onceinstalled, the belt
shouldbeplacedacross the pelvis as determined by the user’s healthcare dealer.Anchor pointsof the positioning belts
shouldbe located so thata projectedside-view angleof thepelvis isbetween 30°–75°of horizontaldepending onthe
user’s weight, postureandseat cushion thickness.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely in order to reduce the possibility of a fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle.

14 www.quantumrehab.com Quantum 600
II. SAFETY
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
informationabout yourpowerchair’s batteries, seeVI.“Batteries and Charging.”
WARNING! Battery posts, terminals and related accessories contain lead and lead
compounds. Wear goggles and gloves when handling batteries and wash hands after
handling.
WARNING! Power chair batteries are heavy. See specifications table. If you are unable
to lift that much weight, be sure to get help. Use proper lifting techniques and avoid
lifting beyond your capacity.
WARNING! Always protect the batteries from freezing and never charge a frozen battery.
Charging a frozen battery may result in damage to the battery.
WARNING! Connect your battery harnesses in the proper manner. RED (+) cables must
be connected to positive (+) battery terminals/posts. BLACK (-) cables must be
connected to negative (-) battery terminals/posts. Protective caps should be installed
over all battery terminals. REPLACE cables immediately if damaged.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts, including
the armrests, seat, front riggings, controller and shrouds.
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.
Reaching and Bending
Neverreach, lean orbendwhile driving yourpowerchair. If itisabsolutelynecessary to reach,leanor bend whileseated
onyour power chair,it is important to maintaina stablecentre of gravityand keep thepower chair fromtipping. Pride
recommendsthatthe power chair user determine his/her personallimitations and practice bending andreaching in the
presenceofaqualified healthcareprofessional.
WARNING! Do not bend, lean or reach for objects if you have to pick them up from the
floor by reaching down between your knees or if you have to reach over the back of
the seat. Movements such as these may change your centre of gravity and the weight
distribution of the power chair, possibly causing your power chair to tip.
WARNING! Keep your hands away from the tyres when driving. Be aware that loose
fitting clothing can become caught in drive tyres.

Quantum 600 www.quantumrehab.com 15
II. SAFETY
Figure 4. Ideal Transfer Position
Transfers
Transferring onto and off of your power chair requires a
goodsenseofbalance.Always havean attendantor health-
careprofessionalpresentwhilelearningtoproperlytransfer
yourself.
Toeliminatethepossibilityofinjury,Priderecommendsthat
youora trained attendant perform the following tasks be-
foreattemptingatransfer:
!Turnoffthepower tothecontroller.
!Ensureyourpowerchair isnot infreewheelmode.See
III.“Your Power Chair.”
!Turnthecastorwheels toward the transfer destination
toimprovepowerchairstabilityduringtransfer.
!Make sure both armrests are flipped up or removed
fromyour powerchair.
!Flip up the foot platform or move the leg rests aside;
thiswillhelp to keep your feet from getting caught on
thefrontriggingduringthetransfer.
!Reducethedistancebetween yourpowerchairandthe
objectyou are transferringonto.
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer.
WARNING! Avoid putting all of your weight on the power chair armrests and do not use the armrests
for weight bearing purposes, such as transfers. Such use may cause the power chair to tip, resulting
in a fall from the power chair and personal injury.
WARNING! Avoid putting all of your weight on the front riggings. Such use may cause the power
chair to tip.
Prescription Drugs/Physical Limitations
Usersmustexercisecareandcommonsensewhenoperatingapowerchair.This includesawareness ofsafety issueswhen
takingprescribed orover-the-counterdrugs orwhenthe userhasspecificphysical limitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.

16 www.quantumrehab.com Quantum 600
II. SAFETY
Alcohol/Smoking
Thepowerchairuser mustexercisecareandcommonsensewhen operatinghis/herpowerchair.Thisincludes awareness
ofsafetyissueswhileundertheinfluenceofalcoholor whilesmoking.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.
WARNING! Pride strongly recommends that you do not smoke cigarettes while seated in your
power chair, although the power chair has passed the necessary testing requirements for cigarette
smoking. You must adhere to the following safety guidelines if you decide to smoke cigarettes
while seated in your power chair.
!Do not leave lit cigarettes unattended.
!Keep ashtrays a safe distance from the seat cushions.
!Always make sure cigarettes are completely extinguished before disposal.
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
Electromagneticand Radio FrequencyInterference cancome fromsources suchas cellularphones, mobiletwo-way
radios(such as walkie-talkies), radio stations, TVstations,amateurradio(HAM) transmitters, wireless computer links,
microwavesignals,pagingtransmittersandmedium-rangemobiletransceiversusedbyemergencyvehicles.Insomecases,
thesewavescancauseunintendedmovementordamagetothecontrolsystem.Everyelectrically-poweredmobilityvehicle
hasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.Thisproduct
hasbeen tested and has passed at an immunity levelof20V/m.
WARNING! Be aware that cell phones, two-way radios, laptops and other types of radio transmitters
may cause unintended movement of your electrically-powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorised by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Centre on www.pridemobility.com. If
unintended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Contact
your Quantum Rehab Dealer to report the incident.

Quantum 600 www.quantumrehab.com 17
III. YOUR POWER CHAIR
THE QUANTUM 600 POWER CHAIR
Your power chair has two main assemblies: the seat assembly andthepowerbaseassembly. See figure 5.Typically,the
seatassembly includes thearmrests,seatback and seatbase.Thepower baseassemblyincludestwo motor/brake assem-
blies,twodrivewheels, four castor wheels, two batteries and wiring harnesses. See figure 5, 6 and 7.
REAR
SHROUD
DRIVEWHEEL
Figure 5. The Quantum 600 Power Chair
FRONTRIGGING
(FOOT PLATFORM SHOWN)
CASTOR
WHEEL
MANUALFREEWHEEL
LEVER
CASTOR
WHEEL
SEAT ASSEMBLY
POWERBASE
ASSEMBLY
SEATBACK (SOLID SEATBACK SHOWN)
JOYSTICK
SEATBASE
CONTROLLER
ARMREST

18 www.quantumrehab.com Quantum 600
III. YOUR POWER CHAIR
Electrical Components
Theelectricalcomponentsarelocatedinsidethepowerbase. Themaincircuitbreakerislocatedonthefrontofthebattery
tray.Thecontrollerconnector(s)arelocatedinsidethepowerbase. See figure 7.
MotorConnectors:This is where the controller connects to the motors.
BatteryConnector: Thisis where the controller connects to the batteries.
ControllerConnector:This iswherethecontrollerconnectsto the power base. Eachcontrollerusesadifferent type of
cable.Regardlessofwhichtypeofcontrollerisused, the cable must be secured to the seat assembly and not allowed to
dragon the floor.
Figure 6. The Quantum 600 Power Base
MOTOR/BRAKE ASSEMBLY
REARSHROUDFASTENERS
TRAPEZEBARS
FRONT COVER

Quantum 600 www.quantumrehab.com 19
III. YOUR POWER CHAIR
MainCircuitBreaker:Themain circuitbreaker isa safetyfeaturebuiltintoyourpowerchair.When thebatteries andthe
motorsareheavilystrained(e.g.,fromexcessiveloads),themaincircuitbreakertripsto preventdamage tothemotorsand
theelectronics.Ifthecircuittrips, allowyourpowerchairto “rest”forapproximatelyoneminute.Next,push inthecircuit
breakerbutton, turn on the controllerandcontinuenormaloperation. If the main circuitbreakercontinuestotrip repeat-
edly, contact yourQuantumRehab Dealer.
Figure 7. Electrical Components
BATTERY CONNECTOR
MAINCIRCUITBREAKER
POWERMODULE
MOTOR
CONNECTORS

20 www.quantumrehab.com Quantum 600
Manual Freewheel Levers
Yourpower chairhas amanualfreewheelleveroneachmotor. Manualfreewheel leversenableyoutodisengagethedrive
motorsandmanoeuvre thechairmanually.
WARNING! Do not use the power chair while the drive motors are disengaged! Do not
disengage the drive motors when the power chair is on an incline or decline, as the
unit could roll on its own! Only engage the freewheel mode when on a level surface.
WARNING! It is important to remember that when your power chair is in freewheel
mode, the braking system is disengaged.
To operate the manual freewheel levers:
1. Locatethelever on top of each motor.
2. Pullupboth manual freewheelleverstoengage themotors(drivemode). See figure8.
3. Pushdownboth manual freewheelleverstodisengage themotors(freewheelmode). See figure9.
Iftheleverisdifficulttomoveineitherdirection,slightlyrockthepowerchairbackandforth.Thelevershouldthenmove
tothe desired position.
WARNING! Do not use the freewheel lever handles as tie-down points to secure this product.
III. YOUR POWER CHAIR
Figure 8. Drive Mode (Drive Engaged) Figure 9. Freewheel Mode (Drive Disengaged)
