Princess 01.341000.02.001 User manual

EN Instruction manual
Smart Glass Panel Heater
01.341000.02.001 / 01.341001.02.001
01.341500.02.001 / 01.341501.02.001
01.342000.02.001 / 01.342001.02.001

1
24
3
5
PARTS DESCRIPTION
1. On / O switch
2. Display
3. Touch button control panel
4. Heater
5. Feet
6. Wall bracket
6

Instruction manual
3
SAFETY
• By ignoring the safety instructions the
manufacturer cannot be held responsible for
the damage.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
• Never move the appliance by pulling the
cord and make sure the cord cannot
become entangled.
• The appliance must be placed on a stable,
level surface.
• The user must not leave the device
unattended while it is connected to the
supply.
• This appliance is only to be used for
household purposes and only for the
purpose it is made for.
• This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instructions concerning use of
the appliance in a safe way and understand
the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be
made by children without supervision.
• Children of less than 3 years should be kept
away unless continuously supervised.
• Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed
in its intended normal operating position and
they have been given supervision or
instruction concerning use of the appliance
in a safe way and understand the hazards
involved.
• Children aged from 3 years and less than 8
years shall not plug in, regulate and clean
the appliance or perform user maintenance.
• To protect yourself against an electric shock,
do not immerse the cord, plug or appliance
in the water or any other liquid.
• WARNING: In order to avoid
overheating, do not cover the heater.
• WARNING: Some parts of this product can
become very hot and cause burns.
Particular attention has to be given where
children and vulnerable people are present.
EN

Instruction manual
4
• Do not use this heater in the immediate
surroundings of a bath, a shower or a
swimming pool.
• Joists, beams and rafters shall not be cut or
notched to install the appliance.
• Please do not install the appliance close to
curtains and other combustible materials.
This could cause a fire.
• The appliance shall, under no
circumstances, be covered with insulating
material or similar material.
• The heater must not be located immediately
below a socket-outlet.
• Do not use this heater if it has been dropped.
• WARNING: The heater must not be used if
the glass panels are damaged.
• Use this heater on a horizontal and stable
surface, or fix it to the wall, as applicable.
• WARNING: Do not use this heater in small
rooms when they are occupied by persons
not capable of leaving the room on their own,
unless constant supervision is provided.
• WARNING: To reduce the risk of fire, keep
textiles, curtain, or any other flammable
material a minimum distance of 1m from the
air outlet.
• The heater needs to be installed so that the
switches and other controls cannot be
touched by a person in the bath or shower.
Installation
Foot assembly
• Before using the heater, the feet must be
fitted to the unit. (image 1)
• These are to be attached to the base of the
heater using the 8 ST12x4mm screws
provided. (image 2)
• Take care to ensure that the feet are located
correctly on the bottom end of the heater.
• The heater should stand vertically once the
feet are installed (image 3). If the heater tilts
backwards then please remove the feet and
rotate them before fitting again. (image 4)
Wall mounting
• Please note that the product must be
installed at least 15 cm from the floor and 50
cm from the ceiling.

Instruction manual
5
• First install the bracket with the provided
screws. (image 1)
• Drill the holes in the wall on each side, then
insert the plastic expanded plugs and fix the
bracket in the wall with the screws provided.
(image 2)
• Place the heater in a suitable position and
ensure that the holes are aligned with the
bracket. (image 3)
• Tighten the screws on top of the bracket.
(image 4)
BEFORE THE FIRST USE
• Place the device on a flat stable surface and ensure a minimum
of 15cm free space around the device. This device is not suitable
for installation in a cabinet or for outside use.
• Putthepower cable intothe socket.(Note: Make surethe
voltagewhich is indicated on the devicematchesthe
localvoltage beforeconnecting the device.Voltage220V-240V
50/60Hz)
• When the device is turned on for the first time, a slight odour will
occur. This is normal, ensure adequate ventilation. This fragrance
is only temporary and will disappear soon.
• During heating up and cooling down there may be some noises
caused by the heater casing expanding and contracting, this is
normal and does not indicate any fault.
EN

Instruction manual
6
DISPLAY/TOUCH BUTTON FUNCTIONS
1
2
3
4
5
7
6
1 Display
2 Temperature “+” button
3 Temperature “–“ button
4 Power button
5 Mode button
6 Timer button
7 Child lock button
USE
• Push the On/Off switch on the side of the heater to turn the heater
on.
• Press the power touch button to set the functions. The display will
show what function is active.
• Use the mode button to adjust to low or high power. The upper
symbol on the display is for high power, the lower one indicates
the low power setting.
• Press 'temperature up (+)' or 'temperature down (-)' buttons to
regulate the temperature you desired. The temperature can be
set between 15°C and 35°C.
• Press the timer button to select the desired range between 1 hour
to 24 hours. The set time will disappear after a few seconds.
• To enable the child lock HOLD down the lock button for 5
seconds and the lock symbol will appear on the display.
• To disable the child lock HOLD the lock button again for 5
seconds and the lock symbol will disappear.
• The child lock can be overridden by unplugging the heater or by
switching it off using the main ON/OFF switch on the side of the
device.

Instruction manual
7
• Once the child lock is active you cannot operate any of the heater
touch functions.
TIP-OVER PROTECTION
• Should the heater be tipped over during use then the heater will
automatically turn off.
• If the unit has been tipped over then it cannot be turned on from
the Climate app or via a smart speaker.
• To reset the unit, place it upright on a stable surface and the
heater will automatically power on and connect to WiFi if
previously setup. In around 2 minutes the device will be ready to
be controlled via the app or smart speaker again.
CHILD LOCK AND SMART SPEAKER
• If the child lock is active then voice control from a smart speaker
will be disabled. You would need to disable the child lock to
enable voice control.
• WARNING: Ensure the device cannot be operated by
unsupervised persons.
USING THE HEATER WITH CLIMATE APP
• The heater can be used manually with its built-in controls or you
can use a smart phone or smart speaker to control it. Before you
begin, ensure the Homewizard Climate app is downloaded. The
Homewizard Climate app is available on Android and iOS.
Pair your heater to HomeWizard Climate app
• Make sure your heater is powered.
• Open HomeWizard Climate APP.
• Create an account or if you already have a HomeWizard account,
please log in using those details.
• Click "Add new Climate Device" to add a new device.
• Select the device you wanted to connect.
• Follow the instructions on the app to connect the heater.
• To control your device with voice using a smart speaker please
refer to the manufacturer's instructions on how to enable a skill
through your device.
Technical Specification
Details 341000/341001 341500/341501 342000/342001
Voltage 220-240V 220-240V 220-240V
Frequency 50/60Hz 50/60Hz 50/60Hz
Power
(maximum)
1000W 1500W 2000W
IP Code IP24 IP24 IP24
CLEANING AND MAINTENANCE
• Before cleaning, unplug the appliance and wait for the appliance
to cool down.
• Clean the appliance with a damp cloth. Never use harsh and
abrasive cleaners, scouring pad or steel wool, which damages
the device.
• Clean the two air outlets (above and below) by using a vacuum
cleaner to remove dust from inside.
EN

Instruction manual
8
DECLARATION OF CONFORMITY
• Hereby, Smartwares Europe declares that the radio equipment
type
01.341000.01.001/01.341000.02.001/01.341001.01.001/01.34100
1.02.001/01.341500.01.001/01.341500.02.001/01.341501.01.001/
01.341501.02.001/01.342000.01.001/01.342000.02.001/01.34200
1.01.001/01.342001.02.001 are in compliance with Directive
2014/53/EU
• The full text of the EU declaration of conformity is available at the
following internet address: www.princesshome.eu/doc
ENVIRONMENT
This appliance should not be put into the domestic garbage at
the end of its durability, but must be offered at a central point for the
recycling of electric and electronic domestic appliances. This symbol
on the appliance, instruction manual and packaging puts your
attention to this important issue. The materials used in this appliance
can be recycled. By recycling of used domestic appliances you
contribute an important push to the protection of our environment. Ask
your local authorities for information regarding the point of
recollection.
Support
You can find all available information and spare parts at
www.princesshome.eu!

This product is only suitable for well insulated spaces or occasional use.
Dit product is uitsluitend geschikt voor goed geïsoleerde plaatsen of voor incidenteel gebruik.
Ce produit ne peut être utilisé que dans des locaux bien isolés ou de manière occasionnelle.
Dieses Produkt ist nur für gut isolierte Räume oder für den gelegentlichen Gebrauch geeignet.
Este producto está indicado únicamente en lugares abrigados o para una utilización puntual.
Este produto é adequado apenas para espaços bem isolados espaços ou utilização ocasional.
Il presente prodotto è adatto solo a ambienti correttamente isolati o ad un uso occasionale.
Denna produkt är endast lämpad för välisolerade utrymmen eller sporadisk användning.
Ten produkt jest odpowiedni tylko do sporadycznego użytku lub do stosowania w dobrze
izolowanych pomieszczeniach.
Tento výrobek je vhodný pouze pro dobňe izolované prostory nebo obĀasné používání.
Tento výrobok je určený iba do dobre izolovaných priestorov alebo na príležitostné použitie.
Это товар подходит только для использования в хорошо изолированных помещениях
или для нерегулярного использования.
Wireless technology: Wi-Fi
Operating frequency: 2412MHz~2472MHz
Max. radio-frequency power: 17.30dBm
