Pro-Form 110 R User manual

Serial Number
Decal (under frame)
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Model No. 831.21942.2
Serial No.
Write the serial number in the space
above for reference.
BIKE EXERCISER
User’s Manual
• Assembly
• Operation
• Maintenance
• Part List and Drawing
Sears, Roebuck and Co.
Hoffman Estates, IL 60179

2
WARNING DECAL PLACEMENT
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, call
1-888-533-1333 and request a free replacement
decal. Apply the decal in the location shown.
Note: The decal(s) may not be shown at actual size.
TABLE OF CONTENTS
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
PART IDENTIFICATION CHART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
HOW TO USE THE EXERCISE BIKE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
FCC INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
MAINTENANCE AND TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
EXPLODED DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
ORDERING REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
90 DAY FULL WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover

3
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your exercise bike before using your exercise bike.
Sears assumes no responsibility for personal injury or property damage sustained by or through the
use of this product.
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
2. Use the exercise bike only as described in
this manual.
3. It is the responsibility of the owner to ensure
that all users of the exercise bike are ade-
quately informed of all precautions.
4. The exercise bike is intended for home use
only. Do not use the exercise bike in a com-
mercial, rental, or institutional setting.
5. Keep the exercise bike indoors, away from
moisture and dust. Do not put the exercise
bike in a garage or covered patio, or near
water.
6. Place the exercise bike on a level surface,
with a mat beneath it to protect the floor or
carpet. Make sure that there is at least 2 ft.
(0.6 m) of clearance around the exercise bike.
7. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
8. Keep children under age 12 and pets away
from the exercise bike at all times.
9. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the exercise bike. Always wear
athletic shoes for foot protection.
10. The heart rate monitor is not a medical
device. Various factors may affect the accu-
racy of heart rate readings. The heart rate
monitor is intended only as an exercise aid
in general.
11. The exercise bike should not be used by
persons weighing more than 250 lbs.
(113 kg).
12. Always keep your back straight while using
the exercise bike; do not arch your back.
13. The exercise bike does not have a freewheel;
the pedals will continue to move until the
flywheel stops. Reduce your pedaling speed
in a controlled way.
14. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
IMPORTANT PRECAUTIONS

4
BEFORE YOU BEGIN
Thank you for selecting the new PROFORM®110
R exercise bike. Cycling is an effective exercise for
increasing cardiovascular fitness, building endurance,
and toning the body. The 110 R exercise bike provides
a selection of features designed to make your workouts
at home more effective and enjoyable.
For your benefit, read this manual carefully before
you use the exercise bike. If you have questions after
reading this manual, please see the back cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Handlebar
Console
Accessory Tray
Heart Rate Monitor
Seat
Leveling Cap
Backrest
Length: 5 ft. (152 cm)
Width: 1 ft. 9 in. (53 cm)
Pedal
Wheel
Handlebar

5
M10 x 85mm Screw (54)–2
M8 x 48mm
Screw (58)–2
M8 x 40mm
Screw (26)–3
M6 x 38mm
Screw (42)–4
M4 x 16mm
Screw (56)–5
M8 x 20mm
Screw (55)–6
M10 x 20mm
Screw (61)–6
M8 x 120mm Bolt (64)–1
M8 Jam Nut
(62)–1
PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included. If a part is missing, please call 1-888-533-1333.

6
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you complete all assembly steps.
• To identify small parts, see page 5.
• In addition to the included tool(s), assembly
requires the following tools:
one Phillips screwdriver
one adjustable wrench
Assembly may be easier if you have your own set
of wrenches. To avoid damaging parts, do not use
power tools.
ASSEMBLY
1. Identify the Front Stabilizer (32) and orient it as
indicated by the sticker.
While a second person lifts the front of the
Frame (1), attach the Front Stabilizer (32) with
two M10 x 85mm Screws (54).
1
32
1
54
2
2. Identify the Rear Stabilizer (31) and the Carriage
Rail (9), and orient them as shown.
Attach the Rear Stabilizer (31) to the Carriage
Rail (9) with three M8 x 40mm Screws (26). 26
9
31

7
3
4
5
31
25
24
14
14
56
9
3
15
25
3
3. Identify and orient the Stabilizer Shield (15) as
shown.
Press the Mushroom Fasteners (25) on the
underside of the Stabilizer Shield (15) into the
Rear Stabilizer (31).
4. Identify and orient the Seat Carriage (3) as
shown. Loosen the Adjustment Knob (14) if nec-
essary. Then, slide the Seat Carriage onto the
Carriage Rail (9).
5. Tighten the Adjustment Knob (14) on the Seat
Carriage (3).
Attach a Carriage Bumper (24) to the underside
of the Carriage Rail (9) with an M4 x 16mm
Screw (56).
9

8
6
7
8
6. Slide the Carriage Rail (9) onto the Frame (1).
Attach the Carriage Rail with six M10 x 20mm
Screws (61).
7. Identify and orient the Seat Frame (7) and the
Backrest Frame (5) as shown.
Set the Backrest Frame (5) in the Seat Carriage
(3). Then, set the Seat Frame (7) on the Seat
Carriage.
Attach the Seat Frame (7) and the Backrest
Frame (5) to the Seat Carriage (3) with two M8
x 48mm Screws (58), an M8 x 120mm Bolt (64),
and an M8 Jam Nut (62).
8. Identify and orient the Backrest (6) as shown.
Attach the Backrest (6) to the Backrest Frame
(5) with four M6 x 38mm Screws (42).
9
1
61
61
7
5
58
62
58
64
3
5
42
6
42

9
9
11
10
55
55
2
1
9. Orient the Upright (2) as shown. Have a second
person hold the Upright near the Frame (1).
Set the Upright (2) on the Frame (1). Attach the
Upright with four M8 x 20mm Screws (55).
10. Locate the wire tie inside the Upright (2). Tie the
lower end of the wire tie to the end of the Main
Wire (53).
Then, pull the other end of the wire tie upward
until the Main Wire (53) is routed completely
through the Upright (2).
2
2
53
38, 39
12
53
Wire Tie
Wire Tie
11. Orient the Shield Cover (12) as shown. Then,
insert the Main Wire (53) upward through the
Shield Cover.
Slide the Shield Cover (12) onto the Upright (2).
Then, press the Shield Cover into the Right and
Left Shields (38, 39).

10
13
14
12
12. Orient the Console Plate (11) as shown. Then,
insert the Main Wire (53) upward through the
Console Plate.
Tip: Avoid pinching the Main Wire (53). Insert
the Console Plate (11) into the Upright (2), and
align the indicated holes.
13. Orient the Handlebar (13) as shown.
While a second person holds the Handlebar (13)
near the Upright (2), insert the Pulse Wire (22)
into the Upright and pull it upward out of the top
of the Console Plate (11).
Tip: Avoid pinching the wires. Attach the
Handlebar (13) and the Console Plate (11) to the
Upright (2) with two M8 x 20mm Screws (55).
11
11
22
13
55
53
Holes
2
Avoid pinching the
Main Wire (53)
Avoid pinching
the wires
2
14. The Console (4) can use four D batteries (not
included); alkaline batteries are recommended.
Do not use old and new batteries together or
alkaline, standard, and rechargeable batter-
ies together. IMPORTANT: If the Console has
been exposed to cold temperatures, allow it
to warm to room temperature before insert-
ing batteries. Otherwise, you may damage
the console displays or other electronic
components.
Remove the battery covers from the back of the
Console (4), and insert batteries into the battery
compartments. Make sure to orient the bat-
teries as shown by the diagrams inside the
battery compartments. Then, reattach the bat-
tery covers.
To purchase an optional power adapter, call
the telephone number on the cover of this
manual. To avoid damaging the console,
use only a manufacturer-supplied power
adapter. Plug one end of the power adapter into
the receptacle inside the battery compartment
on the console; plug the other end into an outlet
installed in accordance with all local codes and
ordinances.
4
Battery
Cover
Battery
Cover
Receptacle
