USER'S MANUAL
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through
direct assistance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
Model No. PFEX35430
Serial No.
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Patent Pending

2
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
HOW TO USE THE EXERCISE CYCLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
MAINTENANCE AND TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
HOW TO ORDER REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
PROFORM is a registered trademark of ICON Health & Fitness, Inc.

3
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read the following important precau-
tions before using the exercise cycle.
1. Read all instructions in this manual before
using the exercise cycle.
2. Use the exercise cycle only as described in
this manual.
3. It is the responsibility of the owner to ensure
that all users of the exercise cycle are ade-
quately informed of all precautions.
4. The exercise cycle is intended for in-home
use only. Do not use the exercise cycle in a
commercial, rental, or institutional setting.
5. Keep the exercise cycle indoors, away from
moisture and dust. Place the exercise cycle
on a level surface and place a mat under the
exercise cycle to protect the floor or carpet.
6. Inspect and properly tighten all parts regularly.
Replace any worn parts immediately.
7. Keep children under the age of 12 and pets
away from the exercise cycle at all times.
8. The exercise cycle should not be used by
persons weighing more than 250 pounds.
9. Wear appropriate clothes when using the
exercise cycle; do not wear loose clothes
that could become caught on the exercise
cycle. Always wear athletic shoes.
10. Always keep your back straight when using
the exercise cycle; do not arch your back.
11. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
12. If you feel pain or dizziness while exercising,
stop immediately and begin cooling down.
13. The exercise cycle does not have a free-
wheel; the pedals will move until the flywheel
stops.
WARNING: Before beginning this or any exercise program, consult your physician.
This is especially important for persons over the age of 35 or persons with pre-existing health prob-
lems. Read all instructions before using. ICON assumes no responsibility for personal injury or
property damage sustained by or through the use of this product.

4
Congratulations for selecting the new PROFORM®
C55 exercise cycle. Cycling is one of the most effec-
tive exercises for increasing cardiovascular fitness,
building endurance, and toning the entire body. The
PROFORM C55 exercise cycle offers an impressive
array of features designed to let you enjoy this health-
ful exercise in the comfort and privacy of your home.
For your benefit, read this manual carefully before
you use the exercise cycle. If you have questions
after reading this manual, please call our Customer
Service Department toll-free at 1-800-999-3756,
Monday through Friday, 6 a.m. until 6 p.m. Mountain
Time (excluding holidays). To help us assist you,
please mention the product model number and serial
number when calling. The model number is
PFEX35430. The serial number can be found on a
decal attached to the exercise cycle (see the front
cover of this manual for the location of the decal).
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Console
Handlebar
BACK
Backrest
Seat Knob
Seat Handle
Wheel
Pedal with Strap
Bottle Holder*
*No bottle is included
Handgrip Pulse Sensor Bookrack
Seat
RIGHT SIDE
BEFORE YOU BEGIN

5
ASSEMBLY
Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the
packing materials until assembly is completed.
Assembly requires the included tools and your own adjustable wrench .
Refer to the drawings below to identify the small parts needed for assembly. The number in parenthesis below
each drawing is the key number of the part, from the PART LIST on page 22. The number following the key
number is the quantity needed for assembly. Note: Some small parts may have been pre-assembled. If a
part is not found in the parts bag, check to see if it has been pre-assembled.
M6 Washer
(25)–6 M8 Split
Washer (70)–4 M8 Flat
Washer (18)–4 M8 Nylon
Locknut (56)–8 M10 Nylon
Locknut (63)–4
M4 x 16mm
Screw (21)–4 M4 x 21mm
Screw (81)–2 M6 x 16mm
Screw (62)–2 M8 x 19mm Button
Bolt (43)–4 M8 x 25mm Button
Screw (27)–4
M8 x 39mm Button
Bolt (47)–4 1/4” x 16mm Hex
Screw (29)–4 1/4” x 38mm Hex
Screw (78)–4
M10 x 91mm Carriage Bolt (35)–2
M10 x 105mm Carriage Bolt (36)–2

6
63
2
75
75
1
35
1. Identify the Front Stabilizer (2). Attach the Front
Stabilizer to the front of the Frame (1) with two M10
x 91mm Carriage Bolts (35) and two M10 Nylon
Locknuts (63). Make sure that the Front Stabilizer
is oriented so the Wheels (75) are not touching
the floor.
2. Attach the Rear Stabilizer (3) to the rear of the
Frame (1) with two M10 x 105mm Carriage Bolts
(36) and two M10 Nylon Locknuts (63).
3. While a second person holds the Handlebar Post (6)
near the Frame (1), connect the Upper Wire
Harness (16) to the Lower Wire Harness (77).
Carefully slide the Handlebar Post (6) onto the
Frame (1); be careful to avoid pinching the Wire
Harnesses (16, 77). Attach the Handlebar Post with
four M8 x 25mm Button Screws (27) and four M8
Split Washers (70).
2
36
3
1
6
77
27
16
27
70
70
16
4. Hold the Left Handlebar (32) on the left side of the
Handlebar Post (6). Connect the left Pulse Sensor
Wire (71) to the Pulse Wire Harness (22). Next, slide
the Left Handlebar onto the small tube on the left
side of the Handlebar Post. Attach the Left
Handlebar with two M8 x 39mm Button Bolts (47)
and two M8 Nylon Locknuts (56); be careful not to
damage the Pulse Sensor Wire or the Pulse Wire
Harness as you insert the Button Bolts. Make
sure that the Nylon Locknuts are resting in the
hexagonal holes in the Left Handlebar.
Attach the Right Handlebar (33) in the same way.
447
47
56
56
32
33
71
71
6
22
1
3
63
1

7
6. Attach the Seat (12) to the Seat Carriage (11) with
four 1/4” x 16mm Hex Screws (29) and four M8 Flat
Washers (18).
7. Attach the Right Seat Handle (31) to the Seat
Carriage (11) with two M8 x 19mm Button Bolts (43)
and two M8 Nylon Locknuts (56).
Attach the Left Seat Handle (14) to the Seat
Carriage (11) in the same way.
43
31
14
56
11
6
7
12
11
29
18
5. Hold the Console (9) near the Handlebar Post (6).
Connect the wire harness on the Console (9) to the
Upper Wire Harness (16). Then, insert the wire har-
nesses into the Handlebar Post.
Attach the Console (9) to the Handlebar Post (6)
with four M4 x 16mm Screws (21). Be careful to
avoid pinching the wire harnesses.
Attach the Bottle Holder (69) to the Handlebar Post
(6) with two M4 x 21mm Screws (81). Note: The
bottle holder is designed to be used with your own
bottle.
69
6
81
9
Wire
Harness
16
21
5

8
10. Firmly tighten the four M8 x 31mm Button Bolts (80)
in the Seat Carriage (11). Note: There are two
Button Bolts in each side.
Pull the seat knob and slide the Seat Carriage (11)
to the desired position. Release the seat knob, and
slide the Seat Carriage back and forth slightly
until it locks into position. Make sure to regularly
tighten the four M8 x 31mm Button Bolts (80).
11. Identify the Right Pedal (37), which is marked with
an “R.” Using an adjustable wrench, firmly tighten
the Right Pedal clockwise into the right arm of the
Crank (19). Tighten the Left Pedal (not shown)
counterclockwise into the left arm of the Crank (not
shown). After using the exercise cycle for one
week, retighten the Pedals.
Attach the Right Pedal Strap (38) to the Right Pedal
(37). Press the end of the Right Pedal Strap onto
the tab on the Right Pedal. Attach the Left Pedal
Strap (not shown) in the same way.
11
80
19 38
37
Tab
10
12. Make sure that all parts are properly tightened before you use the exercise cycle. Place a mat
beneath the exercise cycle to protect the floor.
9. Pull the seat knob and slide the Seat Carriage (11)
onto the Seat Rail (7).
See the inset drawing. Hold the Bumper Axle (73)
inside of the Seat Rail (7). Attach the two Bumpers
(65) to the ends of the Bumper Axle with two M6 x
16mm Screws (62) and two M6 Washers (25) as
shown. Press the Seat Rail Endcap (23) into the
end of the Seat Rail.
11
Knob
7
9
23
73
62
65
25 7
8. Attach the Backrest (13) to the Seat Carriage (11)
with four 1/4” x 38mm Hex Screws (78) and four M6
Washers (25). 13
25
11
25
78
8
Knob
65 62
11
25

9
HOW TO ADJUST THE POSITION OF THE SEAT
For effective exercise, the seat should be in the proper
position. As you pedal, there should be a slight bend
in your knees when the pedals are in the farthest
position. To adjust the seat, pull the seat knob and
slide the seat carriage to the desired position.
Release the seat knob and slide the seat carriage
back and forth slightly until it locks into position.
HOW TO ADJUST THE PEDAL STRAPS
To adjust the pedal straps, first pull the ends of the
straps off the tabs on the pedals. Adjust the straps to
the desired positions and press the ends of the straps
back onto the tabs.
Seat
Carriage
Seat
Knob
Strap
Tab
HOW TO USE THE EXERCISE CYCLE

10
FEATURES OF THE CONSOLE
The advanced console offers a selection of features
designed to make your workouts more enjoyable and
effective. When the manual mode of the console is
selected, the resistance of the pedals can be changed
with the touch of a button. As you exercise, the con-
sole will provide continuous exercise feedback. You
can even measure your heart rate using the handgrip
pulse sensor.
The console also offers eight workout programs. Each
program automatically changes the resistance of the
pedals and prompts you to increase or decrease your
pedaling pace as it guides you through an effective
workout.
In addition, the console features new iFIT.com interac-
tive technology. Having iFIT.com interactive technology
is like having a personal trainer in your home. Using a
stereo audio cable (available at electronics stores), you
can connect the exercise cycle to your home stereo,
portable stereo, computer, or VCR and play special
iFIT.com CD and video programs (iFIT.com CDs and
videocassettes are available separately). iFIT.com CD
and video programs automatically control the resis-
tance of the pedals and prompt you to vary your pace
as a personal trainer coaches you through every step
of your workout. High-energy music provides added
motivation. To purchase iFIT.com CDs and video-
cassettes, call toll-free 1-800-735-0768.
With the exercise cycle connected to your computer,
you can also go to our Web site at www.iFIT.com and
access programs directly from the internet. Explore
www.iFIT.com for more information.
Note: If there is a sheet of clear plastic on the face of
the console, remove it before using the console.
CONSOLE DIAGRAM
Matrix
Displays
